Electrical - Connector Identification: Overhaul Volvo V70 II

Body Electrical 5 illustrations ~539 words

Assembly

Note. Wheel sensor cables are twisted pair (positive and negative signal) cables for each wheel. It is important that paired cables are twinned in the same way when they are reinstalled in the connector. The cables must be twisted approximately 3 times per 100mm.

Assembling primary lock

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the cable terminal is properly locked by pulling carefully on the cable.

Assembling secondary lock

Press the secondary lock into place.

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the seal is correctly positioned and the cable terminal has locked by carefully pulling the cable.

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the seal is correctly positioned and the cable terminal has locked by carefully pulling the cable.

Press the secondary lock into place.

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the seal is correctly positioned and the cable terminal has locked by carefully pulling the cable.

Press the secondary lock into place.

Check that the cable terminal's catches are undamaged.

Press the cable terminal into the housing.

Check that the cable terminal is properly locked by pulling carefully on the cable.

Press the secondary lock into place.

Disassembling secondary lock

Pin housing

Scheme 2342

Scheme 2342: Disassembling secondary lock

Release the front housing section on the pin housing by pulling out the rear catches while at the same time pressing the housing section forwards.

Socket housing

Scheme 2343

Scheme 2343

Release the catches and pull out the secondary lock. Use tool: 9512853 or an electrician's screwdriver, see the graphic.

Scheme 2344

Scheme 2344: Disassembling primary lock

Use tool: 9512632 , 9512633 and 9512639 to remove the primary lock, as graphics.

Scheme 2345

Scheme 2345

Scheme 2346

Scheme 2346

Alternatively use tool: 9512852 , see graphic.

Note. Tool 9512852 can only be used for socket housings.

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the cable terminal is properly locked by pulling carefully on the cable.

Press the secondary lock into place.

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the cable terminal is properly locked by pulling carefully on the cable.

Press the secondary lock into place.

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the cable terminal is properly locked by pulling carefully on the cable.

Press the secondary lock into place.

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the cable terminal is properly locked by pulling carefully on the cable.

Press the secondary lock into place.

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the cable terminal is properly locked by pulling carefully on the cable.

Press the secondary lock into place.

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the cable terminal is properly locked by pulling carefully on the cable.

Slide the housings into the connector.

Press the secondary lock into place.
