Breakout Box, Control Module - Activation & Connection: Overhaul Volvo V70 II

Body Electrical 2 illustrations ~160 words

Connector, assembling

Note. Wheel sensor cables are twisted pair (positive and negative signal) cables for each wheel. It is important that paired cables are twinned in the same way when they are reinstalled in the connector. The cables must be twisted approximately 3 times per 100 mm.

Reassemble the connector

Assemble the secondary locks and slide the connector into the central electrical unit.

Note. Wheel sensor cables are twisted pair (positive and negative signal) cables for each wheel. It is important that paired cables are twinned in the same way when they are reinstalled in the connector. The cables must be twisted approximately 3 times per 100 mm.

Scheme 2306

Scheme 2306: Primary lock

Check that the cable terminal is undamaged.

Press the cable terminal into the housing.

Check that the cable terminal is properly locked by pulling carefully on the cable.

Scheme 2307

Scheme 2307: Secondary lock

Slide the catch in the direction of the arrow, as illustrated.
