Diagnostic trouble code (DTC) information UEM-003A
Condition
The upper electronic module (UEM) supplies power to a number of functions in the car via Extended X-supply (EXT_X). These functions include the sun roof logic, mirror lamps in the sun visor, rain sensor, buttons for the headlining lighting and certain button lighting.
Diagnostic trouble code (DTC) UEM-003A is stored if the upper electronic module (UEM) registers too low a level for power supply Extended X-supply (EXT_X).
Diagnostic trouble code (DTC) UEM-003A can be diagnosed in ignition positions I or II.
Substitute Value
- Sun roof, mirror lamps in the sun visor, buttons for the headlining lighting and certain button lighting are switched off.
Possible Source
- The power supply to the sun roof, mirror lamps in the sun visor, rain sensor, buttons for the headlining lighting and certain button lighting functions is short-circuited to ground.
Fault symptom[s]
- The power sun roof does not operate
- The interior lighting does not operate
- No rain sensor function.
Scheme 1889
Scheme 1890
- Ignition off. If all the functions that are supplied with power from the upper electronic module (UEM) via Extended X-supply (EXT_X) are not working (i. e. sun roof logic, mirror lamps in the sun visor, rain sensor or interior lighting), it can be assumed that either the cable between the upper electronic module (UEM) and the junction point 53/505 is short-circuited to ground or the wiring from the junction point to each component is short-circuited to ground. First check the power supply cable between the upper electronic module (UEM) and each component. If the cable is short-circuited to ground, 0 ohms will be measured. For mirror lamps in the sun visor, check the cable between the mirror lamp connector terminal #1 and the connector for the upper electronic module (UEM) terminal #A8. Check for a short-circuit to ground. For sun roof and interior lighting, take readings on the cable between the connector for roof lamps terminal #A2 (and the sun roof module) and the connector for the upper electronic module (UEM) #A8. Check for a short-circuit to ground. For rain sensor, take readings on the cable between the rain sensor connector terminal #A3 and the connector for the upper electronic module (UEM) terminal #A8. Check for a short-circuit to ground. If all the readings result in a short-circuit to ground, it can be assumed that the fault is between the upper electronic module (UEM) #A8 and junction point 53/505. Remedy as necessary. Other information: To connect the breakout box, see «Connecting the breakout box»(ref-430921-S34302379142011101900000) For information about signals, see «Signal specification»(/volvo/v70/ii-2000-2004/remont/body-electrical/#cables-and-fuses-specifications-electricalelectronic-xc) To access or replace the interior lighting, For -2002, see «Interior lighting and upper electronic module (UEM), replacing»(ref-430927-S13783131922011101900000) For 2003-, see «Interior lighting, replacing»(ref-430927-S21103868592011101900000). To fault-trace wiring and terminals, see «Contents»(/volvo/v70/ii-2000-2004/remont/body-electrical/#wiring-terminals-general-diagnostics-and-tests-xc__contents).
Was a fault detected?
- YES Refer to «Verification»(ref-431021-S40251184372011101900000)
- NO FAULT NOT FOUND: Troubleshooting has been completed.
Diagnostic trouble code (DTC) information UEM-003C
Condition
The upper electronic module (UEM) uses the same power stages and outputs for interior lighting in several different models. Diagnostic trouble code (DTC) UEM-003C indicates faults in various units, depending on whether the car is a V70, XC70 or an XC90. In the V70 and XC70, faults are indicated by the control signal from the cargo compartment lighting. In the XC90, faults are indicated by the control signal from the 3rd row reading lamps.
Diagnostic trouble code (DTC) UEM-003C is stored if the control module registers that the control signal from the cargo compartment lighting/third row reading lamps is too low.
Diagnostic trouble code (DTC) UEM-003C can be diagnosed when the general roof lighting is lit and the cargo compartment lighting/third row reading lighting is not lit.
Substitute Value
- Cargo compartment lighting/3rd row reading lamps switched off.
Possible Source
- The cable for power supply to the cargo compartment lighting/third row reading lamps is short-circuited to ground
- Loose connections in the cable for power supply to cargo compartment lighting/third row reading lamps.
Fault symptom[s]
- The cargo compartment lighting is not working
- The interior lighting does not work.
Diagnostic trouble code (DTC) information UEM-003D
Condition
The upper electronic module (UEM) uses the same power stages and outputs for interior lighting in several different models. Diagnostic trouble code (DTC) UEM-003D indicates faults in various units, depending on whether the car is a V70, XC70 or an XC90. In the V70 and XC70, faults are indicated by the control signal from the cargo compartment lighting. In the XC90, faults are indicated by the control signal from the 3rd row reading lamps.
Diagnostic trouble code (DTC) UEM-003D is stored if the control module registers that the control signal to the cargo compartment lighting/third row reading lamps is too high.
Diagnostic trouble code (DTC) UEM-003D can be diagnosed in ignition position II and when the general roof lighting is lit and the cargo compartment lighting/third row reading lighting is not lit.
Substitute Value
- Cargo compartment lighting/third row reading lamps switched off.
Possible Source
- The cable for power supply to the cargo compartment lighting/third row reading lamps is short-circuited to supply voltage
- Open-circuit in the cable for power supply to cargo compartment lighting/third row reading lamps.
Fault symptom[s]
- The cargo compartment lighting is not working
- The interior lighting does not work.
Diagnostic trouble code information
Condition
If the control unit tries to store data in its memory and the data becomes corrupted, the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- Fault in EEPROM.
Fault symptom[s]
- Courtesy lighting does not work
- Alarm does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- Unknown position of sunroof.
Fault symptom[s]
- Automatic sunroof closing does not work.
Condition
If the control unit detects that SRM-0002 is given when contact is made with the sunroof control unit (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- Even though the relay is switched off, the sunroof motor is fed by a current
- Faulty relay.
Fault symptom[s]
- Automatic sunroof closing does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- Short circuit to voltage supply on control unit ground wire.
- Open circuit/short circuit to ground on wire from the control unit to the motor.
- Contact resistance or oxidation on the connectors.
- Fuse blown (11C/34).
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof control unit (SRM), diagnostic trouble code is set.
Substitute Value
- Nothing.
Possible Source
- Despite the relay being activated and the sunroof changing position, you cannot measure any current in the motor.
Fault symptom[s]
- Automatic sunroof closing does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- No control signal from optical sensor 1 when the relay is activated and the motor is supplied with power.
Fault symptom[s]
- Automatic sunroof closing does not work.
Scheme 1891
- Ignition off. Check that the position pulley on the sun roof control module is correctly aligned with the drive wire. A diagnostic trouble code (DTC) is stored if they are not correctly aligned. Remedy as necessary if a fault is found. Other information: To access the position pulley, see «Control module, sun roof, replacing»(ref-430952-S23697945242011101900000).
Were any faults detected?
- YES Refer to «Verification»(ref-431021-S29806470922011101900000)
- NO Refer to «Replacing the sun roof control module»(ref-431021-S26181235392011101900000)
Condition
If the control unit registers an internal fault in the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- No control signal from optical sensor 2 when the relay is activated and the motor is supplied with power.
Fault symptom[s]
- Automatic sunroof closing does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- Sunroof blocked after starting
- Incorrectly installed sunroof.
Fault symptom[s]
- Nothing.
Erasing diagnostic trouble code (DTC)
Erase diagnostic trouble codes (DTCs).
- Continue Refer to «Reading off diagnostic trouble codes (DTC)»(ref-431021-S35753616412011101900000)
Reading off diagnostic trouble codes (DTC)
Read off diagnostic trouble codes (DTCs). If the diagnostic trouble code (DTC) recurs, replace the sun roof.
Other information
- See «Sun roof, replacing»(ref-430952-S25522546012011101900000).
Condition
If the control unit registers an internal fault in the sunroof module (SRM), diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- Sunroof motor works and sunroof moves even when the relay is not activated.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- Sunroof motor works and sunroof moves even when the relay is not activated.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof control unit (SRM), diagnostic trouble code is set.
Substitute Value
- Nothing.
Possible Source
- The voltage supply wire for forward movement of the sunroof is short circuited to voltage supply.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof control unit (SRM), diagnostic trouble code is set.
Substitute Value
- Nothing.
Possible Source
- The voltage supply wire for rearward movement of the sunroof is short circuited to voltage supply.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof control unit (SRM), diagnostic trouble code is set.
Substitute Value
- Nothing.
Possible Source
- The voltage supply wire for automatic movement of the sunroof is short circuited to voltage supply.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof control unit (SRM), diagnostic trouble code is set.
Substitute Value
- Nothing.
Possible Source
- The voltage supply wire for tilt movement of the sunroof is short circuited to voltage supply.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- The signal for forwards movement of the sunroof is activated too long.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- The signal for backwards movement of the sunroof is activated too long.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- The sunroof AUTO signal is activated too long.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- The sunroof TILT signal is activated too long.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit registers an internal fault in the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- The signals for AUTO and TILT occur at the same time.
Fault symptom[s]
- Electric sunroof does not work.
Condition
If the control unit detects that SRM-0021 is given when contact is made with the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- Fault with voltage drop in sunroof module (SRM)
- Internal fault in sunroof module.
Fault symptom[s]
- Electric sunroof does not work
- Automatic sunroof closing does not work.
Condition
If the control unit detects that SRM-0022 is given when contact is made with the sunroof module (SRM), the diagnostic trouble code is displayed.
Substitute Value
- Nothing.
Possible Source
- Fault in programming of or reading from EEPROM.
Fault symptom[s]
- Automatic sunroof closing does not work.
- Ignition on. Read off diagnostic trouble codes (DTCs).
Has diagnostic trouble code (DTC) UEM-0078 been stored again?
- YES Refer to «Replacing the siren»(ref-431021-S41500239182011101900000)
- NO OKAY: Troubleshooting has been completed.
Diagnostic trouble code (DTC) information
Condition
Diagnostic trouble code (DTC) UEM-0078 is stored if the control module registers that the configuration of the siren does not correspond to the car.
Substitute Value
- None.
Possible Source
- The siren has not been configured after replacement
- Failed configuration after replacing the siren.
Fault symptom[s]
- None.
Condition
The upper electronic module communicates with the rain sensor. If diagnostic trouble code (DTC) UEM-0081 or UEM-0082 is stored diagnostic trouble code (DTC) UEM-0080 is not stored. Diagnostic trouble code (DTC) UEM-0080 is stored if the rain sensor does not respond to the upper electrical module. Diagnostic Trouble Code (DTC) UEM-0080 can be diagnosed 2 seconds after ignition on.
Substitute Value
- Intermittent windshield wipers
- High speed windshield wipers.
Possible Source
- Open-circuit in the power supply cable for the rain sensor
- Short-circuit to ground in the power supply cable for the rain sensor
- Open-circuit in the data cable for the rain sensor
- Short-circuit to supply voltage in the data cable for the rain sensor
- Short-circuit to ground in the data cable for the rain sensor
- Open-circuit in the ground lead for the rain sensor
- Short-circuit to supply voltage in the ground lead for the rain sensor
- Contact fault on the sensor side and/or control module side
- Defective rain sensor
- Defective control module.
Fault symptom[s]
- No rain sensor function.
Diagnostic trouble code (DTC) information UEM-0080
Condition
Scheme 1892
The upper electronic module (UEM) regularly checks the communication with the rain sensor module (RSM).
A diagnostic trouble code (DTC) is stored If the rain sensor module (RSM) does not respond to a request from the upper electronic module (UEM).
The diagnostic trouble code (DTC) can be diagnosed 20 seconds after the ignition is switched on. Diagnostic trouble code (DTC) UEM-0080 is not stored if UEM-0081 or UEM-0082 is stored.
Substitute Value
- Intermittent windshield wipers
- The windshield wipers operate at high speed.
Possible Source
- Open-circuit in the power supply cable for the rain sensor
- Short-circuit to ground in the power supply cable for the rain sensor
- Open-circuit, short-circuit to ground or supply voltage in the data cable for the rain sensor
- Open-circuit or short-circuit to supply in the ground lead for the rain sensor
- Contact fault on the sensor side and/or control module side
- Defective rain sensor
- Defective control module.
Fault symptom[s]
- No rain sensor function.
Diagnostic trouble code information UEM-0081
Condition
The upper electronic module (UEM) regularly compares a communication test with the rain sensor.
The diagnostic trouble code (DTC) is generated if the upper electronic module (UEM) registers that the signal cable of the rain sensor is short-circuited to ground.
The diagnostic trouble code can be diagnosed when the ignition is on.
Substitute Value
- Intermittent windshield wiping.
- High speed windshield wiping.
Possible Source
- The rain sensor's signal cable is short-circuited to ground.
- Faulty rain sensor.
Fault symptom[s]
- No rain sensor function.
Diagnostic trouble code information UEM-0082
Condition
The upper electronic module (UEM) regularly compares a communication test with the rain sensor.
The diagnostic trouble code (DTC) is generated if the upper electronic module (UEM) registers that the signal cable of the rain sensor is short-circuited to supply voltage. The diagnostic trouble code (DTC) is not generated if UEM-0081 is stored.
The diagnostic trouble code can be diagnosed when the ignition is on.
Substitute Value
- Intermittent windshield wiping.
- High speed windshield wiping.
Possible Source
- Short-circuit to supply voltage in the signal cable for the rain sensor
- Faulty rain sensor.
Fault symptom[s]
- No rain sensor function.
Diagnostic trouble code (DTC) information UEM-0083
Condition
The rain sensor checks itself at start.
The rain sensor checks factors such as reflections on the windshield.
The diagnostic trouble code (DTC) is stored if the rain sensor registers incorrect function.
The diagnostic trouble code (DTC) can be diagnosed with the ignition on and with an outside temperature above + 5°C (41°F).
Note. On early model years, this diagnostic trouble code (DTC) may be stored if for example there was frost on the window when the check was run. In this case, it does not help to replace any components. Fault-trace the function of the rain sensor before replacing any components.
Substitute Value
- Intermittent windshield wipers
- The windshield wipers operate at high speed.
Possible Source
- Frost on the windshield during the check
- Crack in the windshield by the rain sensor
- Stone chip on the windshield close to the rain sensor
- The rain sensor is not properly secured to the windshield
- Defective rain sensor.
Fault symptom[s]
- No rain sensor function.
Condition
Diagnostic trouble code (DTC) UEM-0083 is stored if the rain sensor registers an internal error when carrying out self diagnostics.
Substitute Value
- Intermittent windshield wipers
- High speed windshield wipers.
Possible Source
- Defective rain sensor
- The rain sensor is not properly secured to the windshield
- Crack in the windshield by the rain sensor
- Stone chip on the windshield by the rain sensor.
Fault symptom[s]
- No rain sensor function.
Diagnostic trouble code information UEM-0084
Condition
The upper electronic module (UEM) regularly checks communication with the rain sensor.
The diagnostic trouble code (DTC) is generated if the upper electronic module or the rain sensor registers a fault in communication.
The diagnostic trouble code can be diagnosed when the ignition is on.
Substitute Value
- Intermittent windshield wiping.
- High speed windshield wiping.
Possible Source
- Contact resistance or oxidation on the signal cable.
- Communication disrupted.
- Faulty rain sensor.
Fault symptom[s]
- No rain sensor function.
Diagnostic trouble code (DTC) information UEM-0090
Condition
Scheme 1893
The upper electronic module (UEM) checks the power supply to the LED for the PAD lamp (Passenger Airbag Deactivated). The LED is integrated in the rear view mirror.
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) registers that the power supply signal to the PAD lamp is too low.
The diagnostic trouble code (DTC) can be diagnosed when the LEDs in the rear view mirror are supplied with power, i. e. when the LEDs in the display satisfy conditions for lighting.
Substitute Value
- None.
Possible Source
- Defective upper electronic module (UEM) (internal fault).
Fault symptom[s]
- The SRS indicator lamp is lit.
- Message in the display.
Scheme 1894
Scheme 1895
Scheme 1896
- Ignition off. Read off by clicking the VCT2000 symbol. Turn the ignition key to position I. Check that the requested status from the Supplemental restraint system module (SRS) is ON and that the status of the PAD lamp in the Upper electronic module (UEM) is ON when the lamp is lit. Also check if the Passenger airbag warning lamp (PAD) comes on after the ignition is switched on. If the requested status from the Supplemental restraint system module (SRS) is ON, the Upper electronic module (UEM) has activated the lamp (status is ON) but the lamp does not come on, the lamp is probably broken. Replace the upper electronic module (UEM). Check that new hardware has the correct P/N. If the requested status from the Supplemental restraint system module (SRS) is ON, but the Upper electronic module (UEM) has not activated the lamp (status is OFF), check DTCs for errors in CAN communication in the Central electronic module (CEM). Also check the CAN cables between the Upper electronic module (UEM) and the Supplemental restraint system module (SRS). Remedy as necessary. Other information See «Checking wiring and terminals»(/volvo/v70/ii-2000-2004/remont/body-electrical/#wiring-terminals-general-diagnostics-and-tests-xc)
Is the function OK?
- YES FAULT NOT FOUND: Troubleshooting has been completed.
- NO Refer to «Replacing control module and programming»(ref-431021-S14817123432011101900000)
Condition
The upper electronic module (UEM) checks the power supply to the LEDs in the display in the rear view mirror. The five LEDs are supplied with power via the same cable and are internally mounted in the rear view mirror.
Diagnostic trouble code (DTC) UEM-0090 is stored in the control module if the upper electronic module (UEM) registers too low a signal for the power supply to the LEDs in the display in the rear view mirror.
Diagnostic trouble code (DTC) UEM-0090 can be diagnosed when the LEDs in the rear view mirror are supplied with power, i. e. when the LEDs in the display satisfy conditions for lighting.
Substitute Value
- None.
Possible Source
- The power supply cable to LEDs in the display in the rear view mirror is short-circuited to ground.
Fault symptom[s]
- The SRS indicator lamp is lit.
Diagnostic trouble code (DTC) information UEM-0091
Condition
The upper electronic module (UEM) checks the power supply to the LED for the PAD lamp (Passenger Airbag Deactivated) in the rear view mirror. The LED is integrated in the rear view mirror.
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) registers that the power supply signal to the PAD lamp is too high.
The diagnostic trouble code (DTC) can be diagnosed when the LEDs in the rear view mirror are not supplied with power, i. e. when the LEDs in the display do not satisfy conditions for lighting.
Substitute Value
- None.
Possible Source
- Defective upper electronic module (UEM) (internal fault).
Fault symptom[s]
- The SRS indicator lamp is lit.
- Message in the display.
Condition
The upper electronic module (UEM) checks the power supply to the LEDs in the display in the rear view mirror. The five LEDs are supplied with power via the same cable and are internally mounted in the rear view mirror.
Diagnostic trouble code (DTC) UEM-0091 is stored in the control module if the upper electronic module (UEM) registers too high a signal for the power supply to the LEDs in the display in the rear view mirror.
Diagnostic trouble code (DTC) UEM-0091 can be diagnosed when the LEDs in the rear view mirror are not supplied with power, i. e. when the LEDs in the display do not satisfy conditions for lighting.
Substitute Value
- None.
Possible Source
- The power supply cable to LEDs in the display in the rear view mirror is short-circuited to supply voltage.
Fault symptom[s]
- The SRS indicator lamp is lit.
Diagnostic trouble code (DTC) information UEM-0092
Condition
The display in the rear view mirror can indicate signals for two different functions, seat belt reminder or AOS. The different functions require different hardware. The upper electronic module (UEM) checks the hardware identity number on the installed rear view mirror and compares this with the software installed in the control module.
Diagnostic trouble code (DTC) UEM-0092 is stored in the control module if the upper electronic module (UEM) registers an identity number which is not compatible with the installed function.
Diagnostic trouble code (DTC) UEM-0092 can be diagnosed in ignition position II.
Substitute Value
- None.
Possible Source
- Read off identity number not compatible with installed function.
Fault symptom[s]
- The SRS indicator lamp is lit.
Diagnostic trouble code (DTC) information UEM-0093
Condition
The upper electronic module (UEM) receives information via the controller area network (CAN) indicating whether the seat belt reminder lamp should be on or off. The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) is notified that there is a short-circuit to ground or open-circuit in the power supply for the seat belt reminder lamp when it should be lit.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Defective upper electronic module (UEM) (internal fault).
Fault symptom[s]
- The seat belt lamp does not light.
Diagnostic trouble code (DTC) information UEM-0094
Condition
The upper electronic module (UEM) receives information via the controller area network (CAN) indicating whether the seat belt reminder lamp should be on or off. The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) receives an indication that the seat belt reminder lamp should not be lit but the lamp is lit anyway.
The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.
Substitute Value
- None.
Possible Source
- Defective upper electronic module (UEM) (internal fault).
Fault symptom[s]
- The seat belt reminder lamp is constantly on.
- The seat belt reminder lamp shines weakly
Diagnostic trouble code (DTC) information UEM-00A0
Condition
Scheme 1897
The upper electronic module (UEM) receives information transmitted by the tire pressure sensors in the wheels, irrespective of the car. The sensors which are registered in the vehicle can be checked by running a statistical selection. A list can then be stored internally in the upper electronic module (UEM).
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) registers that the signal from the first of the four accepted sensors disappears while the vehicle is being driven.
The diagnostic trouble code (DTC) can be diagnosed after 10 minutes when the tire pressure warning system is active (vehicle speed is above 40 km/h (25 mph)).
Substitute Value
- None.
Possible Source
- Defective tire pressure sensor
- The receiver is not functioning.
Fault symptom[s]
- Message in the display.
- Warning lights and chimes/Tire pressure monitoring indication/no indication
Diagnostic trouble code (DTC) information UEM-00A1
Condition
The upper electronic module (UEM) receives information transmitted by the tire pressure sensors in the wheels, irrespective of the car. The sensors which are registered in the vehicle can be checked by running a statistical selection. A list can then be stored internally in the upper electronic module (UEM).
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) registers that the signal from the second of the four accepted sensors disappears while the vehicle is being driven.
The diagnostic trouble code (DTC) can be diagnosed after 10 minutes when the tire pressure warning system is active (vehicle speed is above 40 km/h (25 mph)).
Substitute Value
- None.
Possible Source
- Defective tire pressure sensor
- The receiver is not functioning.
Fault symptom[s]
- Message in the display.
- Warning lights and chimes/Tire pressure monitoring indication/no indication
Diagnostic trouble code (DTC) information UEM-00A2
Condition
The upper electronic module (UEM) receives information transmitted by the tire pressure sensors in the wheels, irrespective of the car. The sensors which are registered in the vehicle can be checked by running a statistical selection. A list can then be stored internally in the upper electronic module (UEM).
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) registers that the signal from the third of the four accepted sensors disappears while the vehicle is being driven.
The diagnostic trouble code (DTC) can be diagnosed after 10 minutes when the tire pressure warning system is active (vehicle speed is above 40 km/h (25 mph)).
Substitute Value
- None.
Possible Source
- Defective tire pressure sensor
- The receiver is not functioning.
Fault symptom[s]
- Message in the display.
- Warning lights and chimes/Tire pressure monitoring indication/no indication
Diagnostic trouble code (DTC) information UEM-00A3
Condition
The upper electronic module (UEM) receives information transmitted by the tire pressure sensors in the wheels, irrespective of the car. The sensors which are registered in the vehicle can be checked by running a statistical selection. A list can then be stored internally in the upper electronic module (UEM).
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) registers that the signal from the fourth of the four accepted sensors disappears while the vehicle is being driven.
The diagnostic trouble code (DTC) can be diagnosed after 10 minutes when the tire pressure warning system is active (vehicle speed is above 40 km/h (25 mph)).
Substitute Value
- None.
Possible Source
- Defective tire pressure sensor
- The receiver is not functioning.
Fault symptom[s]
- Message in the display.
- Warning lights and chimes/Tire pressure monitoring indication/no indication
Diagnostic trouble code (DTC) information UEM-00A4
Condition
The upper electronic module (UEM) receives information transmitted by the tire pressure sensors in the wheels, irrespective of the car. The sensors which are registered in the vehicle can be checked by running a statistical selection. A list can then be stored internally in the upper electronic module (UEM). The messages transmitted by the sensors contain information such as the voltage of the internal battery in the sensor.
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) receives a message from the first of the four accepted sensors indicating low battery voltage.
The diagnostic trouble code (DTC) can be diagnosed after 10 minutes when the tire pressure warning system is active (vehicle speed is above 40 km/h (25 mph)).
Substitute Value
- None.
Possible Source
- Low battery voltage in the tire pressure sensor.
Fault symptom[s]
- Message in the display.
- Warning lights and chimes/Tire pressure monitoring indication/no indication
Diagnostic trouble code (DTC) information UEM-00A5
Condition
The upper electronic module (UEM) receives information transmitted by the tire pressure sensors in the wheels, irrespective of the car. The sensors which are registered in the vehicle can be checked by running a statistical selection. A list can then be stored internally in the upper electronic module (UEM). The messages transmitted by the sensors contain information such as the voltage of the internal battery in the sensor.
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) receives a message from the second of the four accepted sensors indicating low battery voltage.
The diagnostic trouble code (DTC) can be diagnosed after 10 minutes when the tire pressure warning system is active (vehicle speed is above 40 km/h (25 mph)).
Substitute Value
- None.
Possible Source
- Low battery voltage in the tire pressure sensor.
Fault symptom[s]
- Message in the display.
- Warning lights and chimes/Tire pressure monitoring indication/no indication
Diagnostic trouble code (DTC) information UEM-00A6
Condition
The upper electronic module (UEM) receives information transmitted by the tire pressure sensors in the wheels, irrespective of the car. The sensors which are registered in the vehicle can be checked by running a statistical selection. A list can then be stored internally in the upper electronic module (UEM). The messages transmitted by the sensors contain information such as the voltage of the internal battery in the sensor.
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) receives a message from the third of the four accepted sensors indicating low battery voltage.
The diagnostic trouble code (DTC) can be diagnosed after 10 minutes when the tire pressure warning system is active (vehicle speed is above 40 km/h (25 mph)).
Substitute Value
- None.
Possible Source
- Low battery voltage in the tire pressure sensor.
Fault symptom[s]
- Message in the display.
- Warning lights and chimes/Tire pressure monitoring indication/no indication
Diagnostic trouble code (DTC) information UEM-00A7
Condition
The upper electronic module (UEM) receives information transmitted by the tire pressure sensors in the wheels, irrespective of the car. The sensors which are registered in the vehicle can be checked by running a statistical selection. A list can then be stored internally in the upper electronic module (UEM). The messages transmitted by the sensors contain information such as the voltage of the internal battery in the sensor.
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) receives a message from the fourth of the four accepted sensors indicating low battery voltage.
The diagnostic trouble code (DTC) can be diagnosed after 10 minutes when the tire pressure warning system is active (vehicle speed is above 40 km/h (25 mph)).
Substitute Value
- None.
Possible Source
- Low battery voltage in the tire pressure sensor.
Fault symptom[s]
- Message in the display.
- Warning lights and chimes/Tire pressure monitoring indication/no indication
Diagnostic trouble code (DTC) information UEM-00A8
Condition
The upper electronic module (UEM) receives information transmitted by the tire pressure sensors in the wheels, irrespective of the car. The sensors which are registered in the vehicle can be checked by running a statistical selection. A list can then be stored internally in the upper electronic module (UEM).
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) registers that the signal from fewer than four of the accepted sensors has been received during an operating cycle.
The diagnostic trouble code (DTC) can be diagnosed after 10 minutes when the tire pressure warning system is active (vehicle speed is above 40 km/h (25 mph)).
Substitute Value
- None.
Possible Source
- A rim without a tire pressure sensor has been installed
- A rim with a tire pressure sensor not intended for this model has been installed (the sensor is unable to communicate with the receiver)
- Defective tire pressure sensor
- The receiver is not functioning.
Fault symptom[s]
- Message in the display.
- Warning lights and chimes/Tire pressure monitoring indication/no indication
Diagnostic trouble code (DTC) information UEM-00A9
Condition
The upper electronic module (UEM) has a configuration file which controls certain internal settings. The upper electronic module (UEM) checks that the configuration file is correct.
The diagnostic trouble code (DTC) is stored if the upper electronic module (UEM) registers that the configuration file is incorrect or missing.
The diagnostic trouble code (DTC) can be detected when the control module is initialized after being reset or when diagnostic trouble codes (DTCs) are erased.
Substitute Value
- Factory settings are used.
Possible Source
- Incorrect or missing configuration file.
Fault symptom[s]
- None.
Diagnostic trouble code (DTC) information UEM-E001
Condition
The control modules transmit and receive information via a standardized serial communication method - CAN (Controller Area Network). The diagnostic trouble code (DTC) is stored if the control module registers serious interference (CAN communication blocked).
Note. In the event of system communication problems, it is not possible to communicate with the control module. Therefore it will only be possible to read off the fault if it is intermittent.
Substitute Value
- The control module shuts itself off ("bus-off"). HINT: The control module will remain shut off until the power supply is broken (15, 30, X). When the power supply is connected the control module will make a new attempt to communicate.
Possible Source
- Short-circuit between the control area network (CAN) wiring
- Open-circuit in the control area network (CAN) wiring
- Internal fault in the control module
- Internal fault in another control module in the same part of the control area network (CAN).
Fault symptom[s]
- Cannot be controlled with the remote control
- The interior lighting does not operate
- The power sun roof does not operate
- The alarm does not function at all
- No rain sensor function.
See Diagnostic trouble code (DTC) information UEM-E001
Diagnostic trouble code (DTC) information UEM-E003
Condition
The control module compares its configuration ID with the signal configuration transmitted on the control area network (CAN) by the central electronic module (CEM). If the configuration IDs do not correspond the fault code is stored. The diagnostic trouble code (DTC) is also stored if the communication between the control module and the central electronic module (CEM) is interrupted.
Note. In the event of open-circuit in both the control area network (CAN) cables, it is not possible to communicate with the control module. Therefore it will only be possible to read off the diagnostic trouble code (DTC) if this type of fault is intermittent. When the diagnostic trouble code (DTC) is stored, the control module responds to the diagnostic command, however normal control area network (CAN) communication does not work. ("Expulsion mode")
Substitute Value
- None.
Possible Source
- Faulty control area network (CAN) configuration ID. (The node is not intended for this car, for example a used control module with different software/hardware.)
- Open-circuit in the control area network (CAN) wiring between the control module and the central electrical module (CEM).
Fault symptom[s]
- Cannot be controlled with the remote control
- The interior lighting does not operate
- The power sun roof does not operate
- The alarm does not function at all
- No rain sensor function.
See Diagnostic trouble code (DTC) information UEM-E003
Reading off diagnostic trouble codes (DTCs)
- Ignition on. Read off the diagnostic trouble code (DTC) that is stored in the car. Make a note of the code. Report the code to VIDA customer support.
See also:
• Signal specification
• Contents
• Checking wiring and terminals
• 9512987
