Electronic Climate Control (Ecc) Diagnostic Trouble Codes: Other Volvo V40 I рестайлинг

Connecting the breakout box

Special tools

See 9813190

See 9813194

Breakout box and checking ground terminals

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking the voltage for the outside temperature sensor»(ref-441376-S32776268122011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S20679460852011121500000)

Areas of use for the breakout box

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

Scheme 273

1. Continue Refer to «Connecting the breakout box»(ref-441376-S21775614622011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S32832562152011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S07113432722011121500000)

Scheme 274

Scheme 275

Scheme 276

1. Ignition off
2. ECC control module connected. Check the control module and the control module connector visually according to «Check terminals visually»(ref-441291-S04910850932011121500000) Connect adapter «9813194»(ref-403953-S13746433212011061000000) (only the 30-pin connector) between the ECC control module and the climate control connector. Then connect breakout box «9813190»(ref-403953-S32930552542011061000000) to the adapter. This is connection is carried out when taking readings with the control module connected. The control module terminals 1- 30 correspond to terminals 1-30 on the breakout box.

1. Continue Refer to «Checking ground terminals»(ref-441376-S19025025302011121500000)

Scheme 277

Scheme 278

1. Ignition off
2. Disconnect the ECC control module. Check the control module and the control module connector visually according to «Check terminals visually»(ref-441291-S04910850932011121500000) Connect adapter «9813194»(ref-403953-S13746433212011061000000) (only the 30-pin connector) to the climate control system connector. Then connect breakout box «9813190»(ref-403953-S32930552542011061000000) to the adapter. The breakout box is now only connected to the climate control connector. This connection is used to measure resistance in the ECC system cables and components with the ECC control module disconnected. The control module terminals 1- 30 correspond to terminals 1-30 on the breakout box.

1. Continue Refer to «Checking ground terminals»(ref-441376-S19025025302011121500000)

Scheme 279

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S23988984522011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S21039845162011121500000)

Checking ground terminals

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking the voltage for the outside temperature sensor»(ref-441376-S32776268122011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S29190103252011121500000)

Scheme 280

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S13653089042011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S37990449302011121500000)

Replacing the component

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S19668271702011121500000)

Checking for an open-circuit

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Scheme 281

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S19868415602011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S19913405692011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S19668271702011121500000)

Remedy open-circuit

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S19668271702011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S19025025302011121500000)

Scheme 282

Scheme 283

1. Turn on the ignition. Connect a voltmeter between terminals 17 and 14 on the breakout box.

The voltmeter should read approximately 2.4 V at 20°C. To read off at other temperatures, see Sensor characteristics .

1. OK Refer to «Verification»(ref-441376-S35564922432011121500000)
2. NOT OK Refer to «Checking the resistance in the outside temperature sensor»(ref-441376-S17911959792011121500000)

Scheme 284

1. Ignition off
2. Disconnect the connector from the outside temperature sensor according to «Outside pressure sensor»(ref-441328-S16274460552011121500000) . Connect an ohmmeter between terminal pins 1 and 2 on the outside temperature sensor connector.

The ohmmeter should read approximately 4.8 kohms at 20°C. To read off at other temperatures, see Sensor characteristics .

1. OK Refer to «Checking the resistance in the cable»(ref-441376-S16259313502011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S26782899792011121500000)

Scheme 285

Scheme 286

1. Ignition off
2. Disconnect the ECC control module.
3. Outside temperature sensor connector disconnected. Bridge across terminal pins 1 and 2 on the connector Connect an ohmmeter between terminals 17 and 14 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking for a short-circuit»(ref-441376-S12119042912011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S12993767632011121500000)

If the ohmmeter reads infinity, there is an open-circuit in the outside temperature sensor.

1. Replace the outside temperature sensor according to «Outside pressure sensor»(ref-441328-S16274460552011121500000) .

1. Continue Refer to «Verification»(ref-441376-S35564922432011121500000)

Scheme 287

1. Disconnect the breakout box. Check the cable between ECC control module connector terminal 17 and outside temperature sensor connector terminal 1 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

1. Continue Refer to «Verification»(ref-441376-S35564922432011121500000)

1. Disconnect the breakout box. Check the following cables for an open-circuit according to according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) : the cable between outside temperature sensor connector terminal 1 and ECC control module connector terminal 17 the cable between outside temperature sensor connector terminal 2 and ECC control module connector terminal 14.

1. Continue Refer to «Verification»(ref-441376-S35564922432011121500000)

Verification

HINT: Check after repair that the fault has been rectified.

Scheme 288

Scheme 289

Scheme 290

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC-system.

1. Continue Refer to «Verification, continued»(ref-441376-S10617949282011121500000)

Verification, continued

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S22217128962011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S40962926832011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S41924027552011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S19960571782011121500000)
2. NO Refer to «Checking the voltage for the outside temperature sensor»(ref-441376-S32776268122011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S29498924402011121500000)

Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S20389369372011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S26537696332011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S19960571782011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

Fault-tracing information

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the resistance in the outside temperature sensor

1. Ignition off
2. Disconnect the connector from the outside temperature sensor according to «Outside pressure sensor»(ref-441328-S16274460552011121500000)
3. ECC control module connected. Connect an ohmmeter between terminals 1 and 2 on the outside temperature sensor connector.

The ohmmeter should read approximately 4.8 kohms at 20°C. To read off at other temperatures, see Sensor characteristics .

1. OK Refer to «Checking for a short-circuit»(ref-441376-S41108856782011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S36356527822011121500000)

Checking for a short-circuit

Check the signal cable between the outside temperature connector terminal 1 and ECC control module connector terminal 17 for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

1. Continue Refer to «Verification»(ref-441376-S06173080792011121500000)

If the ohmmeter reads 0 ohms there is a short-circuit in the outside temperature sensor.

1. Replace the outside temperature sensor according to «Outside pressure sensor»(ref-441328-S16274460552011121500000) .

1. Continue Refer to «Verification»(ref-441376-S06173080792011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S20843070902011121500000)

Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S10197665132011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S29609502802011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S08955839592011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Internal fault in control module.

1. Replace the ECC control module according to «Replace the entire control panel»(ref-461600-S33199768622012040200000) .

1. Continue Refer to «Self-adjustment of the shutter motor end position»(ref-441376-S24620360442011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S04667873692011121500000)

Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S15276732402011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S08191558952011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S23813090632011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Internal fault in control module.

1. Replace the ECC control module according to «Replace the entire control panel»(ref-461600-S33199768622012040200000) .

1. Continue Refer to «Self-adjustment of the shutter motor end position»(ref-441376-S15211546132011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S06026145142011121500000)

Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S07066361042011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S39049063722011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S05606574842011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking the power supply to the coolant temperature sensor»(ref-441376-S25688292702011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S11733682822011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S00366250422011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S05085030932011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S30251117992011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S39837043172011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S05108861862011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking the power supply to the coolant temperature sensor»(ref-441376-S25688292702011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S17205755282011121500000)

Checking breakout box

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S23019760652011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S07768886472011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S18040825902011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S02128163362011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S42947451772011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S18040825902011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S18040825902011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S22066657802011121500000)

Checking the power supply to the coolant temperature sensor

1. Ignition on. Connect a voltmeter between terminals 18 and 16 on the breakout box.

The voltmeter should read approximately 2.4 V at 20°C. To read off at other temperatures, see Sensor characteristics .

1. OK Refer to «Verification»(ref-441376-S01694441672011121500000)
2. NOT OK Refer to «Checking the resistance in the coolant temperature sensor»(ref-441376-S10448031282011121500000)

Scheme 291

1. Ignition off
2. Disconnect the water temperature sensor connector according to «Engine coolant temperature sensor»(ref-441328-S31740867822011121500000) . Connect an ohmmeter between terminals 1 and 2 on the outside temperature sensor connector.

The ohmmeter should read approximately 4.8 kohms at 20°C. To read off at other temperatures, see Sensor characteristics .

1. OK Refer to «Checking the resistance in the cable»(ref-441376-S05069043922011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S40903861772011121500000)

Scheme 292

1. Ignition off
2. Disconnect the ECC control module
3. Coolant temperature sensor connector disconnected. Bridge across terminals 1 and 2 on the connectors Connect an ohmmeter between terminals 18 and 16 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking for a short-circuit»(ref-441376-S36568914442011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S38551308962011121500000)

If the ohmmeter reads infinity there is an open-circuit in the coolant temperature sensor.

1. Replace the coolant temperature sensor according to «Engine coolant temperature sensor»(ref-441328-S31740867822011121500000) .

1. Continue Refer to «Verification»(ref-441376-S01694441672011121500000)

Scheme 293

1. Disconnect the breakout box. Check the cable between ECC control module connector terminal 18 and coolant temperature sensor terminal 1 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

1. Continue Refer to «Verification»(ref-441376-S01694441672011121500000)

1. Disconnect the breakout box. Check the following cables for an open-circuit according to according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) : the cable between the coolant temperature sensor terminal 1 and ECC control module connector terminal 18 the cable between the coolant temperature sensor terminal 2 and ECC control module connector terminal 16.

1. Continue Refer to «Verification»(ref-441376-S01694441672011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC-system.

1. Continue Refer to «Verification, continued»(ref-441376-S05473887102011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S30111380252011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S04368377972011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S11674070922011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S40463533762011121500000)
2. NO Refer to «Checking the power supply to the coolant temperature sensor»(ref-441376-S25688292702011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S28911510712011121500000)

Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S00184909272011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S12249161762011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S40463533762011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking components

1. Ignition off
2. Disconnect the connector from the coolant temperature sensor according to «Engine coolant temperature sensor»(ref-441328-S31740867822011121500000)
3. ECC control module connected. Connect an ohmmeter between terminals 1 and 2 on the coolant temperature sensor connector.

The ohmmeter should read approximately 4.8 kohms at 20°C. To read off at other temperatures, see Sensor characteristics .

1. OK Refer to «Checking for a short-circuit»(ref-441376-S19186048502011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S10540529872011121500000)

Check the signal cable between the coolant temperature sensor connector terminal 1 and ECC control module connector terminal 18 for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

1. Continue Refer to «Verification»(ref-441376-S08977107432011121500000)

If the ohmmeter reads 0 ohms there is a short-circuit in the coolant temperature sensor.

1. Replace the coolant temperature sensor according to «Engine coolant temperature sensor»(ref-441328-S31740867822011121500000) .

1. Continue Refer to «Verification»(ref-441376-S08977107432011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S40518589712011121500000)

Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S12039932462011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S28986018252011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S17035297022011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking the supply voltage to the evaporator sensor»(ref-441376-S04421361032011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S27702010622011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S22363470162011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S39017928352011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S20132454162011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S27603410722011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S36887317462011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking the supply voltage to the evaporator sensor»(ref-441376-S04421361032011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S05267110492011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S36818078392011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S00318102502011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S35588347002011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S14488161352011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S23763828302011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S35588347002011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S35588347002011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S14651114352011121500000)

Checking the supply voltage to the evaporator sensor

1. Ignition on. Connect a voltmeter between terminals 15 and 22 on the breakout box.

The voltmeter should read approximately 2.4 V at 20°C. To read off at other temperatures, see Sensor characteristics .

1. OK Refer to «Verification»(ref-441376-S00855068862011121500000)
2. NOT OK Refer to «Checking the resistance in the evaporator sensor»(ref-441376-S11562725712011121500000)

Scheme 294

1. Ignition off
2. Disconnect the connector from the evaporator sensor according to «Evaporator temperature sensor»(ref-441328-S20938199492011121500000) . Connect an ohmmeter between terminals 1 and 2 on the evaporator sensor.

The ohmmeter should read approximately 4.8 kohms at 20°C. To read off at other temperatures, see Sensor characteristics .

1. OK Refer to «Checking the resistance in the cable»(ref-441376-S30196034512011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S31897728632011121500000)

Scheme 295

1. Ignition off
2. ECC control module disconnected
3. Disconnect the evaporator sensor connector according to. Bridge across terminals 1 and 2 on the evaporator sensor connector. Connect an ohmmeter between breakout box connectors terminals 15 and 22.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking for a short-circuit»(ref-441376-S12761360262011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S29473599622011121500000)

If the ohmmeter reads infinity there is an open-circuit in the evaporator sensor.

1. Replace the evaporator sensor according to «Evaporator temperature sensor»(ref-441328-S20938199492011121500000) .

1. Continue Refer to «Verification»(ref-441376-S00855068862011121500000)

Scheme 296

1. Disconnect the breakout box. Check the signal cable between ECC control module connector terminal 15 and evaporator sensor terminal 1 for a short-circuit to ground according to «Short-circuit to ground, permanent faults»(ref-441291-S27984344722011121500000) .

1. Continue Refer to «Verification»(ref-441376-S00855068862011121500000)

1. Disconnect the breakout box. Check the following cables for an open-circuit according to according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) : the cable between connector terminal 1 and connector terminal 15 on the ECC control module the cable between connector terminal 2 and connector terminal 22 on the ECC control module.

1. Continue Refer to «Verification»(ref-441376-S00855068862011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S37223695452011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S28191175292011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S06533071912011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S11061995192011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S18988478322011121500000)
2. NO Refer to «Checking the supply voltage to the evaporator sensor»(ref-441376-S04421361032011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S35493002192011121500000)

Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S03757726052011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S21925431502011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S18988478322011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition off
2. Disconnect the connector from the evaporator sensor according to «Evaporator temperature sensor»(ref-441328-S20938199492011121500000)
3. ECC control module connected. Connect an ohmmeter between terminals 1 and 2 on the evaporator sensor connector.

The ohmmeter should read approximately 4.8 kohms at 20°C. To read off at other temperatures, see Sensor characteristics .

1. OK Refer to «Checking for a short-circuit»(ref-441376-S28812866092011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S18053141952011121500000)

Check the signal cable between the evaporator sensor connector terminal 1 and ECC control module connector terminal 15 for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

1. Continue Refer to «Verification»(ref-441376-S24939450482011121500000)

If the ohmmeter reads 0 ohms there is a short-circuit in the evaporator sensor.

1. Replace the evaporator sensor according to «Evaporator temperature sensor»(ref-441328-S20938199492011121500000) .

1. Continue Refer to «Verification»(ref-441376-S24939450482011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S17977896252011121500000)

Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S07614157842011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S37270295612011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S08431904622011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the voltage, continued

1. Start the engine. Connect a voltmeter between ground and generator (GEN) D+ terminal pin (behind the connector).

The voltmeter should show about 14.5 V.

1. OK Refer to «Checking the (D+) voltage to the ECC control module»(ref-441376-S24135277732011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S42890285982011121500000)

Checking the (D+) voltage to the ECC control module

1. Ignition off
2. Connect the generator (GEN) D+ connector (the 1-pin blade receptacle terminal).

1. Continue Refer to «Connecting the breakout box»(ref-441376-S03181680792011121500000)

Checking the (D+) voltage to the ECC control module, continued

1. Ignition on Connect a voltmeter between terminal 3 (0 V) and terminal 30 on the breakout box.

The voltmeter should show between 0.7 V and about 2 V.

1. OK Refer to «Checking the voltage, continued»(ref-441376-S36912907082011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S15872178432011121500000)

1. Start the engine
2. Generator (GEN) D+ connector connected. Connect a voltmeter between terminal 3 (0 V) and terminal 30 on the breakout box.

The voltmeter should show about 14.5 V.

1. OK Refer to «Replacing the component»(ref-441376-S13971577002011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S15872178432011121500000)

There is no open-circuit in the cable between generator (GEN) D+ and ECC control module connector terminal 30.

1. Replace the ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Self-adjustment of the shutter motor end position»(ref-441376-S37727046362011121500000)

The fault is in generator (GEN) D+.

1. See «Spring strut and spring front, replacing»(ref-441377-S20045262232011121500000)

1. Continue Refer to «Verification»(ref-441376-S07461456642011121500000)

Check the cable between ECC control module connector terminal 30 and generator (GEN) D+ connector for an open-circuit according to Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S07461456642011121500000)

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking the (D+) voltage to the ECC control module, continued»(ref-441376-S10712106082011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S04949724132011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S13183227182011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S23764271082011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S18020510062011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0 ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S17958335682011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S37692687082011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking the (D+) voltage to the ECC control module, continued»(ref-441376-S10712106082011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S19336678932011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S21204853012011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S03099460162011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S35278164412011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S40416379472011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S13407906032011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S35278164412011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S35278164412011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S13422045082011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC-system.

1. Continue Refer to «Verification, continued»(ref-441376-S34336010932011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S08376201522011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S15190962502011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S08467927612011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S32648853862011121500000)
2. NO Refer to «Checking the (D+) voltage to the ECC control module, continued»(ref-441376-S10712106082011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to the data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S16328747582011121500000)

1. Engine running Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S17594248132011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S05391916222011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S32648853862011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the signal

1. Ignition off
2. Connect VCT 2000 to the data link connector (DLC). The front wheels must be able to rotate freely. A speed corresponding to 10 km/h is required before the ECC control module detects the signal. Raise the car. Support it so that it is secure Remove the front wheels Start the car Increase speed Read off the signal from the speedometer in the scrolling values Check that the speed signal is within reasonable when compared with the speedometer reading.

Is the speed signal OK?

1. YES Refer to «Checking components»(ref-441376-S19767240822011121500000)
2. NO Refer to «Connecting the breakout box»(ref-441376-S11846727792011121500000)

1. Ignition off
2. Disconnect the ECC control module. Check the cable terminals in the female half of the ECC control module ECC control module. Check the male half of the ECC control module connector according to «Check terminals visually»(ref-441291-S04910850932011121500000) .

Are both the female and male pin connectors OK?

1. YES Refer to «Verification»(ref-441376-S14393814192011121500000)
2. NO Refer to «Checking components»(ref-441376-S06539509272011121500000)

Scheme 297

1. Ignition off
2. The car has been raised and is secure. The front wheels have been removed. Connect a multimeter (frequency meter) between terminals 3 and 4 on the breakout box. Start the car Increase speed.

The frequency meter should display a constant voltage with a frequency which varies with speed. At 10 km/h the frequency should be approximately 10 Hz. At 30 km/h the frequency should be approximately 20 Hz.

1. OK Refer to «Replacing the component»(ref-441376-S03096802262011121500000)
2. NOT OK Refer to «Checking the resistance in the cable»(ref-441376-S35449117572011121500000)

1. The ECC control module connector (female section) is defective. Refer to «Replacing the component»(ref-441376-S12912773942011121500000) .
2. The ECC control module connector (male section) is defective. Refer to «Replacing the component»(ref-441376-S03096802262011121500000) .

1. Replace the female section of the connector.

1. Continue Refer to «Verification»(ref-441376-S14393814192011121500000)

1. Replace the ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Self-adjustment of the shutter motor end position»(ref-441376-S36156940392011121500000)

Checking the resistance in the cable

1. Ignition off
2. Disconnect the breakout box from the ECC control module connector. Connect an ohmmeter between ECC control module connector terminal 4 and combined instrument panel connector B terminal 16.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S30602387422011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S11477263942011121500000)

1. Replace the combined instrument panel according to «Driver information module (DIM), installation/removal, component replacement»(ref-441303-S00728029162011121500000) .

1. Continue Refer to «Verification»(ref-441376-S14393814192011121500000)

Check the cable between combined instrument panel connector B terminal 16 and ECC control module terminal 4 for an open-circuit according to Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S14393814192011121500000)

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking voltage»(ref-441376-S36923083622011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S09619297072011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S00994895122011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S32340012532011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S03382091292011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S01174405932011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S29339737882011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking voltage»(ref-441376-S36923083622011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S29809337052011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S03646677212011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S41509417522011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S26419246302011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S03815491962011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S41356215882011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S26419246302011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S26419246302011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S32944588052011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S34238102262011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S33838478112011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S16586577562011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S20068010512011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S30148665922011121500000)
2. NO Refer to «Checking voltage»(ref-441376-S36923083622011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off.
2. Connect the connectors, reinstall components etc.
3. ECC control module connected.
4. Ignition on.
5. VCT 2000 connected to the data link connector (DLC). Establish communication with the ECC system.

1. Continue Refer to «Verification, continued»(ref-441376-S31946927942011121500000)

1. Engine running Read off diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S32282013852011121500000)

Erase the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S04053852942011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S30148665922011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking for a short-circuit in the cable»(ref-441376-S17127022462011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S24884020452011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S30076035932011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S13835915222011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S03339992112011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S01700532692011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S35007356132011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking for a short-circuit in the cable»(ref-441376-S17127022462011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S30303683742011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S21410645992011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S34312031162011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S00043369462011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S07112856332011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S32343945002011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S00043369462011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S00043369462011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S38277479452011121500000)

Checking for a short-circuit in the cable

1. Ignition off
2. Disconnect the ECC control module. Connect an ohmmeter between terminals 20 and 23 on the breakout box.

The ohmmeter should display approximately 100 ohms or 5 kohms depending on the position of the damper motor.

1. OK Refer to «Verification»(ref-441376-S27120407542011121500000)
2. NOT OK Refer to «Checking the resistance in the damper motor potentiometer»(ref-441376-S20782506692011121500000)

Scheme 298

1. Ignition off
2. ECC control module disconnected. Connect an ohmmeter between terminals 20 and 23 on the breakout box. Check the damper motor by: connecting terminals 7 and 8 on the breakout box to battery voltage (the control arms should now move in one direction) interrupting the voltage when an end position is reached changing the polarity of the battery voltage between terminals 7 and 8 on the breakout box (the control arms should now move in the opposite direction) reading off the resistance of the ohmmeter while the control arms are moving.

The ohmmeter reading (between terminals 20 and 23) must change from approximately 100 ohms to 5 kohms or vice versa, depending on the direction that the control arms are moving. The value for the reading between terminals 22 and 23 must be approximately 5 kohms.

1. OK Refer to «Checking components»(ref-441376-S35896612222011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S26731790652011121500000)

Check the wiring according to Short-circuit to ground, intermittent faults .

Is the wiring OK?

1. YES Refer to «Replacing the component»(ref-441376-S01317701282011121500000)
2. NO Refer to «Self-adjustment of the damper motor end positions»(ref-441376-S28306581392011121500000)

Short-circuit in the ECC control module.

1. Replace the ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Self-adjustment of the damper motor end positions»(ref-441376-S28306581392011121500000)

Short-circuit in the position sensor for the damper motor.

1. Replace the damper motor according to «Air distribution»(ref-441328-S07525919422011121500000) .

1. Continue Refer to «Self-adjustment of the damper motor end positions»(ref-441376-S28306581392011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S36280521952011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S06065080212011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S05732480662011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S21601347582011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S15454222272011121500000)
2. NO Refer to «Checking for a short-circuit in the cable»(ref-441376-S17127022462011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S08552548552011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S34825121742011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S34766379632011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S18680701622011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S15454222272011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should be diagnosed and remedied. Since this is not the case the fault-tracing process has failed.

Complete the fault-tracing for those fault or try again.

1. Ignition off
2. Disconnect the connector for the temperature damper motor according to «Temperature»(ref-441328-S33133212622011121500000) . Check the cable terminals in both the female and male halves of the connector according to «Check terminals visually»(ref-441291-S04910850932011121500000) .

1. Continue Refer to «Connecting the breakout box»(ref-441376-S35981718572011121500000)

Checking the voltage

1. Ignition off. Connect a voltmeter between terminals 3 and 22 on the breakout box. Ignition on.

The voltmeter should read reference voltage (5 V).

1. OK Refer to «Checking the voltage»(ref-441376-S31465747592011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S34161308202011121500000)

1. Ignition off
2. Connect the connector for the temperature damper motor. Connect a stand-alone multimeter, set to volts, between terminals 23 and 20 on the breakout box. Begin to check the damper motor: For information about self-adjustment, according to «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Activate the self-adjustment function by clicking on the VCT 2000 symbol The voltmeter reading should change from 0.25 V to 4.5 V or vice versa, depending on the direction that the control arms are moving.

1. U = 0.25-4.5 V or 4.5-0.25 V Refer to «Verification»(ref-441376-S28796386792011121500000)
2. U = battery voltage Refer to «Checking for a short-circuit»(ref-441376-S12015527792011121500000)
3. U = 0 V Refer to «Checking the resistance in the cable»(ref-441376-S21312184372011121500000)

1. Ignition off
2. Disconnect the ECC control module.
3. Disconnect the breakout box. Connect an ohmmeter between ECC control module connector terminal 20 on the female half and damper motor connector terminal 4 on the female half.

The ohmmeter should read 0 ohms.

1. OK Refer to «Checking the resistance in the cable»(ref-441376-S05610947252011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S28108479692011121500000)

Connect an ohmmeter between ECC control module connector terminal 23 on the female half and damper motor connector terminal 3 on the female half.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S09812238532011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S02829028702011121500000)

Check the cable between ECC control module connector terminal 20 and terminal 4 on the connector for the damper motor position sensor for an open-circuit according to Open-circuit, permanent faults .

Scheme 299

1. Continue Refer to «Verification»(ref-441376-S28796386792011121500000)

1. Replace the temperature damper motor according to «Temperature»(ref-441328-S33133212622011121500000) .

1. Continue Refer to «Self-adjustment of the shutter motor end position»(ref-441376-S01525175862011121500000)

Check the cable between ECC control module connector terminal 23 and terminal 3 on the connector for the damper motor position sensor for an open-circuit according to Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S28796386792011121500000)

Check the cable between ECC control module connector terminal 22 and terminal 1 on the connector for the damper motor position sensor for an open-circuit according to Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S28796386792011121500000)

Check the cable between ECC control module connector terminal 20 on the female half and terminal 4 on the female section of the connector for the damper motor position sensor for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

1. Continue Refer to «Verification»(ref-441376-S28796386792011121500000)

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking the voltage»(ref-441376-S11437336482011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S28503749462011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S06474213022011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S39481107132011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S36436974962011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S42906477412011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S26576219162011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking the voltage»(ref-441376-S11437336482011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S13158690062011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S27265796112011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S15477177812011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S37077548872011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S33573184642011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S30254120522011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S37077548872011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S37077548872011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S20396641602011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC-system.

1. Continue Refer to «Verification, continued»(ref-441376-S19811843222011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S13167991272011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S23045098692011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S26789698442011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S01568393222011121500000)
2. NO Refer to «Checking the voltage»(ref-441376-S11437336482011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S23710257702011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S10838943042011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S16941300162011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S08285498842011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S01568393222011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should be diagnosed and remedied. Since this is not the case the fault-tracing process has failed.

Complete the fault-tracing for those fault or try again.

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking for a short-circuit in the cable»(ref-441376-S34463163842011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S10349797502011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components when the control module is disconnected

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Switch off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S01648830112011121500000)

1. Refer to «Connecting the breakout box between the control module and the wiring»(ref-441376-S29325961822011121500000)
2. Refer to «Connecting the breakout box to the wiring only»(ref-441376-S21184736942011121500000)

1. Ignition off. Connect an ohmmeter between the chassis and terminal #3 to check the power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S03063998072011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S22021669302011121500000)

Connect an ohmmeter between terminals #3 and #23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking for a short-circuit in the cable»(ref-441376-S34463163842011121500000)
2. NOT OK Refer to «Checking the breakout box»(ref-441376-S28832185382011121500000)

Checking the breakout box

1. Ignition off.
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal #3 and adapter connector terminal #3 breakout box terminal #23 and adapter connector terminal 23

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S03727198812011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S35012130242011121500000)

1. Try a new ECC control module according to «Replace the entire control panel»(ref-461600-S33199768622012040200000) .

1. Continue Refer to «Verification»(ref-441376-S30765575802011121500000)

Check the ground lead between the 30 pin connector terminal #3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedying an open-circuit»(ref-441376-S33145886932011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S08897947252011121500000)

Check for an open-circuit between ground rail D10 and the chassis according to Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S30765575802011121500000)

Remedying an open-circuit

1. Remedy the open-circuit.

1. Continue Refer to «Verification»(ref-441376-S30765575802011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace the breakout box or the adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S38138576992011121500000)

1. Ignition off
2. Disconnect the ECC control module. Connect an ohmmeter between terminals 21 and 23 on the breakout box.

The ohmmeter should display approximately 100 ohms or 5 kohms depending on the position of the damper motor.

1. OK Refer to «Verification»(ref-441376-S28849484232011121500000)
2. NOT OK Refer to «Checking the resistance in the damper motor position sensor»(ref-441376-S07371208612011121500000)

Checking the resistance in the damper motor position sensor

1. Ignition off
2. ECC control module disconnected. Connect an ohmmeter between terminals 21 and 23 on the breakout box. Check the damper motor by: connecting terminals 9 and 10 on the breakout box to battery voltage (the control arms should now move in one direction) interrupt the voltage when one of the end positions is reached reversing the polarity of the battery voltage between terminals 9 and 10 on the breakout box (the control arms should now move in the opposite direction) reading off the resistance at the ohmmeter while the control arms are moving.

The ohmmeter reading (between terminals 21 and 23) must change from approximately 100 ohms to 5 kohms or vice versa, depending on the direction that the control arms are moving. The value for the reading between terminals 6 and 23 must be approximately 5 kohms.

1. OK Refer to «Checking components»(ref-441376-S32078352412011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S35615950842011121500000)

Check the wiring according to Short-circuit to ground, intermittent faults .

Is the wiring OK?

1. YES Refer to «Replacing the component»(ref-441376-S34939704452011121500000)
2. NO Refer to «Self-adjustment of the damper motor end positions»(ref-441376-S02875794692011121500000)

Short-circuit in the ECC control module.

1. Replace the ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Self-adjustment of the damper motor end positions»(ref-441376-S02875794692011121500000)

Short-circuit in the damper motor position sensor.

1. Replace the damper motor according to «Temperature»(ref-441328-S33133212622011121500000) .

1. Continue Refer to «Self-adjustment of the damper motor end positions»(ref-441376-S02875794692011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S26161003472011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S36114638902011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S33686510802011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S03114643442011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S07048821772011121500000)
2. NO Refer to «Checking for a short-circuit in the cable»(ref-441376-S34463163842011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC-control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S28759164862011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S28372088882011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S11631407562011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S42792677522011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S07048821772011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should be diagnosed and remedied. Since this is not the case the fault-tracing process has failed.

Complete the fault-tracing for those fault or try again.

1. Ignition off
2. Disconnect the connector for the air distribution damper motor according to «Air distribution»(ref-441328-S07525919422011121500000)
3. ECC control module connected. Check the cable terminals in the female half of the connector and the male half according to «Check terminals visually»(ref-441291-S04910850932011121500000) .

1. Continue Refer to «Connecting the breakout box»(ref-441376-S32920929082011121500000)

Checking voltage

1. Ignition off. Connect a voltmeter between terminals 3 and 6 on the breakout box. Ignition on.

The voltmeter should read reference voltage (5 V).

1. OK Refer to «Checking voltage»(ref-441376-S13024856502011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S23617991372011121500000)

1. Ignition off
2. Connector for the damper motor air distribution disconnected. Connect a stand-alone multimeter, set to volts, between terminals 23 and 21 on the breakout box. Begin to check the damper motor: For information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Activate the self-adjustment function by clicking on the VCT 2000 symbol The voltmeter reading should change from 0.25 V to 4.5 V or vice versa, depending on the direction that the control arms are moving.

1. U = 0.25-4.5 V or 4.5-0.25 V Refer to «Verification»(ref-441376-S35438966192011121500000)
2. U = battery voltage Refer to «Checking for a short-circuit»(ref-441376-S17724259972011121500000)
3. U = 0 V Refer to «Checking the resistance in the cable»(ref-441376-S30525632842011121500000)

1. Ignition off
2. Disconnect the ECC control module.
3. Disconnect the breakout box. Connect an ohmmeter between ECC control module connector terminal 21 on the female half and damper motor connector terminal 4 on the female half.

The ohmmeter should read 0 ohms.

1. OK Refer to «Checking the resistance in the cable»(ref-441376-S23044647932011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S13126549192011121500000)

Connect an ohmmeter between ECC control module connector terminal 23 on the female half and damper motor connector terminal 3 on the female half.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S09605970912011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S05038940952011121500000)

Check the cable between ECC control module connector terminal 21 on the female half and position sensor connector terminal 4 on the female section for an open-circuit according to Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S35438966192011121500000)

Replace the air distributor damper motor according to Air distribution .

1. Continue Refer to «Self-adjustment of the shutter motor end position»(ref-441376-S13608551422011121500000)

Check the cable between ECC control module connector terminal 23 on the female half and position sensor connector terminal 3 on the female section for an open-circuit according to Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S35438966192011121500000)

Check the cable between ECC control module connector terminal 6 on the female half and position sensor connector terminal 1 on the female section for an open-circuit according to Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S35438966192011121500000)

Check the cable between ECC control module connector terminal 21 on the female half and terminal 4 on the female section of the connector for the damper motor position sensor for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

1. Continue Refer to «Verification»(ref-441376-S35438966192011121500000)

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking voltage»(ref-441376-S06091985312011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S07430154252011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S35519575832011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S11893999412011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S31369990322011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S20157773492011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S09818088502011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking voltage»(ref-441376-S06091985312011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S42567203252011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S02856379562011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S00883871692011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S34772544062011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S37685643092011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S04487308372011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S34772544062011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S34772544062011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S16138202552011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S09508426422011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S39866183512011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S12222943052011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S02608596592011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S34924560972011121500000)
2. NO Refer to «Checking voltage»(ref-441376-S06091985312011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC-control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S02150111752011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S25339444842011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S38429229912011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S30142834822011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S34924560972011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should be diagnosed and remedied. Since this is not the case the fault-tracing process has failed.

Complete the fault-tracing for those fault or try again.

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking the control voltage to the damper motor»(ref-441376-S32117196532011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S42616026292011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S18469759332011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S26107186952011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S24906759382011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0 ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S02627722422011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S15247710532011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking the control voltage to the damper motor»(ref-441376-S32117196532011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S07629315592011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S41800819012011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S24602387252011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S39779301712011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S34238758302011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S08159768592011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S39779301712011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S39779301712011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S29367373242011121500000)

Checking the control voltage to the damper motor

1. Ignition on
2. ECC control module connected.
3. Connect a stand-alone multimeter, set to volts, between terminals 7 and 8 on the breakout box
4. For information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Activate the self-adjustment function by clicking on the VCT 2000 symbol. Read off the multimeter. The voltmeter value should vary from 0 V to 10 V (depending on whether the shutter is opening or closing) and back to 0 V in approximately 12 seconds.

Are these conditions fulfilled?

1. YES Refer to «Checking components»(ref-441376-S36506266012011121500000)
2. NO Refer to «Checking for a short-circuit»(ref-441376-S33722622852011121500000)

Scheme 300

1. Ignition off
2. Disconnect the damper motor connector according to «Temperature»(ref-441328-S33133212622011121500000) . Connect an ohmmeter between terminals 2 and 6 on the damper motor connector. The ohmmeter should display approximately 120 ohms.

Is the value OK?

1. YES Refer to «Checking components»(ref-441376-S29558300042011121500000)
2. NO Refer to «Replacing the component»(ref-441376-S06010340042011121500000)

1. Rotate the output shaft on the damper motor: Connect battery voltage between terminals 2 and 6 on the damper motor connector
2. Interrupt the voltage when the output shaft for the damper motor is at one of its end positions
3. Reverse the polarity (across damper motor connector terminals 2 and 6) so that the output shaft for the damper motor returns to its original position.

Scheme 301

Does the damper motor react according to the above description?

1. YES Refer to «Verification»(ref-441376-S23649347972011121500000)
2. NO Refer to «Replacing the component»(ref-441376-S06010340042011121500000)

1. Replace the temperature damper motor according to «Temperature»(ref-441328-S33133212622011121500000) .

1. Continue Refer to «Self adjustment of the shutter motor end position»(ref-441376-S29631540552011121500000)

1. If the voltmeter reads 0 V continuously, check for a short-circuit to ground. Refer to «Checking for a short-circuit»(ref-441376-S20397494042011121500000) .
2. If the voltmeter reads 12 V continuously, check for a short-circuit to supply voltage. Refer to «Checking for a short-circuit»(ref-441376-S20780002372011121500000) .

1. Ignition off
2. Disconnect the connector for the temperature damper motor according to «Temperature»(ref-441328-S33133212622011121500000)
3. Disconnect the ECC control module. Connect an ohmmeter between ground and the temperature damper motor connector as follows. Take care not to damage the connecting sockets on the connector. Connect one of the ohmmeter test probes to ground Connect the other ohmmeter test probe to the connector terminal 2. Read of the value Then connect the other ohmmeter test probe to the female half of the connector terminal 6. Read of the value. If the value from one cable is approximately 0 ohms, there is a short-circuit to ground in the cable.

1. Continue Refer to «Checking for a short-circuit, continued»(ref-441376-S29121810412011121500000)

Checking for a short-circuit, continued

Check one of the following cables for a short-circuit to ground according to Short-circuit to supply voltage. Permanent faults

1. the cable from the damper motor connector terminal 2 on the female half, to the ECC control module connector terminal 7 on the female half
2. the cable from the damper motor connector terminal 6 on the female half, to the ECC control module connector terminal 8 on the female half.

1. Continue Refer to «Verification»(ref-441376-S23649347972011121500000)

1. Ignition off
2. Disconnect the connector for the temperature damper motor according to «Temperature»(ref-441328-S33133212622011121500000)
3. Disconnect the ECC control module.
4. Disconnect the battery positive lead. Connect an ohmmeter between the disconnected battery positive lead and the female half of the connector for the temperature damper motor as follows. Take care not to damage the connecting sockets on the connector. Connect one of the ohmmeter test probes to ground Connect the other ohmmeter test probe to the connector terminal 2. Read of the value Then connect the other ohmmeter test probe to the female half of the connector terminal 6. Read of the value. If the value from one cable is approximately 0 ohms, there is a short-circuit to supply voltage in the cable.

1. Continue Refer to «Checking for a short-circuit, continued»(ref-441376-S17139888492011121500000)

Check one of the following cables for a short-circuit to supply voltage according to Short-circuit to ground, permanent faults

1. the cable from the damper motor connector terminal 2 on the female half, to the ECC control module connector terminal 7 on the female half
2. the cable from the damper motor connector terminal 6 on the female half, to the ECC control module connector terminal 8 on the female half.

1. Continue Refer to «Verification»(ref-441376-S23649347972011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S03293996252011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S00254278062011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S07418003942011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S02478297112011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S18620992572011121500000)
2. NO Refer to «Checking the control voltage to the damper motor»(ref-441376-S32117196532011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S02868523372011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S12944757212011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S24735577632011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S06130408452011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S18620992572011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should be diagnosed and remedied. Since this is not the case the fault-tracing process has failed.

Complete the fault-tracing for those fault or try again.

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking the control voltage to the damper motor»(ref-441376-S21553910842011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S07590198862011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S29421015232011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S23515601992011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S25946709652011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S26042951062011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S25118245782011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking the control voltage to the damper motor»(ref-441376-S21553910842011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S15027694172011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S12480588712011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S41010524522011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S22277666802011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S01308656362011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S33080179312011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S22277666802011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S22277666802011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S19671819902011121500000)

1. Ignition on
2. ECC control module connected. Connect a stand-alone multimeter, set to volts, between terminals 7 and 8 on the breakout box. For information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Activate the self-adjustment function by clicking on the VCT 2000 symbol. Read off the multimeter. The voltmeter value should vary from 0 V to 10 V (depending on whether the shutter is opening or closing) and back to 0 V in approximately 12 seconds.

Are these conditions fulfilled?

1. YES Refer to «Verification»(ref-441376-S30531547822011121500000)
2. NO Refer to «Checking the resistance in the cable»(ref-441376-S14211063852011121500000)

Scheme 302

1. Ignition off
2. Disconnect the ECC control module.
3. Disconnect the connector for the temperature damper motor according to «Temperature»(ref-441328-S33133212622011121500000) . Bridge across terminals 2 and 6 on the female half of the damper motor connector. Connect an ohmmeter between terminals 7 and 8 on the breakout box.

The ohmmeter should read 0 ohms.

1. OK Refer to «Checking components»(ref-441376-S10860620872011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S37076061602011121500000)

1. Ignition off
2. The connector for the temperature damper motor is disconnected. Connect an ohmmeter between terminals 2 and 6 on the damper motor connector.

The ohmmeter should read approximately 120 ohms.

1. OK Refer to «Checking for blockage»(ref-441376-S21801807602011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S10861266692011121500000)

Checking for blockage

Check that the shutter is not blocked. Check that the shutter can move unimpeded: Activate the self-adjustment function. For further information about self-adjustment, see Self adjustment of damper motor limit positions . Activate self-adjustment: Click the VCT 2000 symbol. Also check that the toothed segment that runs against the shutter shaft is unimpeded.

Is the shutter blocked?

1. YES Refer to «Remedy the blockage»(ref-441376-S14646063762011121500000)
2. NO Refer to «Replacing the component»(ref-441376-S10861266692011121500000)

Remedy the blockage

1. Remedy the blockage.

1. Continue Refer to «Verification»(ref-441376-S30531547822011121500000)

1. Replace the temperature damper motor according to «Temperature»(ref-441328-S33133212622011121500000) .

1. Continue Refer to «Self-adjustment of the shutter motor end position»(ref-441376-S14383170212011121500000)

Check the following signal cables for an open-circuit according to according to Open-circuit, permanent faults

1. the cable between ECC control module connector terminal 7 on the female half and damper motor connector terminal 2 on the female half
2. the cable between ECC control module connector terminal 8 on the female half and damper motor connector terminal 6 on the female half.

1. Continue Refer to «Verification»(ref-441376-S30531547822011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC-control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC-system.

1. Continue Refer to «Verification, continued»(ref-441376-S29559255162011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S13048950522011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S03126000852011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S21053140482011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S41218025702011121500000)
2. NO Refer to «Checking the control voltage to the damper motor»(ref-441376-S21553910842011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S42217226782011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S14948855972011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S10236483652011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S14138180652011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S41218025702011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should be diagnosed and remedied. Since this is not the case the fault-tracing process has failed.

Complete the fault-tracing for those fault or try again.

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking the control voltage to the damper motor»(ref-441376-S00173912582011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S24112355942011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S16722638472011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S36508233132011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S05889477412011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S22960373152011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S26889321682011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking the control voltage to the damper motor»(ref-441376-S00173912582011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S08033921802011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S27236540032011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S35979972172011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S06424204852011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S35703463492011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S01732309722011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S06424204852011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S06424204852011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S17813883472011121500000)

1. Ignition on
2. ECC control module connected.
3. Connect a stand-alone multimeter, set to volts, between terminals 9 and 10 on the breakout box. For information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Activate the self-adjustment function by clicking on the VCT 2000 symbol. Read off the multimeter. The voltmeter value should vary from 0 V to 10 V (depending on whether the shutter is opening or closing) and back to 0 V in approximately 12 seconds.

Are these conditions fulfilled?

1. YES Refer to «Checking components»(ref-441376-S30765977962011121500000)
2. NO Refer to «Checking for a short-circuit»(ref-441376-S22618380382011121500000)

1. Ignition off
2. Disconnect the connector for the damper motor according to «Air distribution»(ref-441328-S07525919422011121500000) . Connect an ohmmeter between terminals 2 and 6 on the damper motor connector. The ohmmeter should display approximately 120 ohms.

Is the value OK?

1. YES Refer to «Checking components»(ref-441376-S25567763772011121500000)
2. NO Refer to «Replacing the component»(ref-441376-S14056567302011121500000)

1. Rotate the output shaft on the damper motor: Connect battery voltage between terminals 2 and 6 on the damper motor connector
2. Interrupt the voltage when the output shaft for the damper motor is at one of its end positions
3. Reverse the polarity (across damper motor connector terminals 2 and 6) so that the output shaft for the damper motor returns to its original position.

Does the damper motor react according to the above description?

1. YES Refer to «Verification»(ref-441376-S00314657372011121500000)
2. NO Refer to «Replacing the component»(ref-441376-S14056567302011121500000)

1. Replace the air distribution damper motor according to «Air distribution»(ref-441328-S07525919422011121500000) .

1. Continue Refer to «Self-adjustment of the shutter motor end position»(ref-441376-S10142603602011121500000)

1. If the voltmeter reads 0 V continuously, check for a short-circuit to ground. Refer to «Checking for a short-circuit»(ref-441376-S22268938502011121500000)
2. If the voltmeter reads 12 V continuously, check for a short-circuit to supply voltage. Refer to «Checking for a short-circuit»(ref-441376-S31766195972011121500000)

1. Ignition off
2. Disconnect the connector for the air distribution damper motor according to «Air distribution»(ref-441328-S07525919422011121500000)
3. Disconnect the ECC control module. Connect an ohmmeter between ground and the air distribution damper motor connector as follows. Take care not to damage the connecting sockets on the connector. Connect one of the ohmmeter test probes to ground Connect the other ohmmeter test probe to the connector terminal 2. Read of the value Then connect the other ohmmeter test probe to the female half of the connector terminal 6. Read of the value. If the value from one cable is approximately 0 ohms, there is a short-circuit to ground in the cable.

1. Continue Refer to «Checking for a short-circuit, continued»(ref-441376-S00757710032011121500000)

Check one of the following cables for a short-circuit to ground according to Short-circuit to supply voltage. Permanent faults

1. the cable from the damper motor connector terminal 2 on the female half, to the ECC control module connector terminal 7 on the female half
2. the cable from the damper motor connector terminal 6 on the female half, to the ECC control module connector terminal 8 on the female half.

1. Continue Refer to «Verification»(ref-441376-S00314657372011121500000)

1. Ignition off
2. Disconnect the connector from the air distribution damper motor
3. Disconnect the ECC control module.
4. Disconnect the battery positive lead. Connect an ohmmeter between the disconnected battery positive lead and the female half of the connector for the temperature damper motor as follows. Take care not to damage the connecting sockets on the connector. Connect one of the ohmmeter test probes to ground Connect the other ohmmeter test probe to the connector terminal 2. Read of the value Then connect the other ohmmeter test probe to the female half of the connector terminal 6. Read of the value. If the value from one cable is approximately 0 ohms, there is a short-circuit to supply voltage in the cable.

1. Continue Refer to «Checking for a short-circuit, continued»(ref-441376-S01834733912011121500000)

Check one of the following cables for a short-circuit to supply voltage according to Short-circuit to ground, permanent faults

1. the cable from the damper motor connector terminal 2 on the female half, to the ECC control module connector terminal 7 on the female half
2. the cable from the damper motor connector terminal 6 on the female half, to the ECC control module connector terminal 8 on the female half.

1. Continue Refer to «Verification»(ref-441376-S00314657372011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC-system.

1. Continue Refer to «Verification, continued»(ref-441376-S27347669622011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S37655515682011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S00181923542011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S31135683072011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S32934193982011121500000)
2. NO Refer to «Checking the control voltage to the damper motor»(ref-441376-S00173912582011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC -system.

1. Continue Refer to «Verification, continued»(ref-441376-S13555401042011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S16620955502011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S12554371012011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S28162418952011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S32934193982011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should be diagnosed and remedied. Since this is not the case the fault-tracing process has failed.

Complete the fault-tracing for those fault or try again.

Special tools

See 9813190

See 9813194

Is the breakout box connected? Have the ground terminals been checked?

1. YES Refer to «Checking the control voltage to the damper motor»(ref-441376-S19996697142011121500000)
2. NO Refer to «Areas of use for the breakout box»(ref-441376-S08507576002011121500000)

Breakout box 9813190 is designed to facilitate reading off

1. the control module input and output signals when the control module is connected
2. the resistance of cables and components with the control module disconnected.

The breakout box makes it safer to take readings because it is easier to see and access measurement points. The risk of accidental short-circuits and damaged connector pins is also reduced.

Turn off the power to the ECC control module when connecting the breakout box otherwise the control module may be damaged and incorrect diagnostic trouble codes (DTCs) stored.

1. Continue Refer to «Connecting the breakout box»(ref-441376-S36683671872011121500000)

1. Refer to «Connecting breakout box between control module and wiring»(ref-441376-S41161137072011121500000)
2. Refer to «Connecting breakout box to wiring only»(ref-441376-S03207062232011121500000)

1. Ignition off. Connect an ohmmeter the chassis and terminal 3 to check power ground.

The ohmmeter should read 0ohms.

1. OK Refer to «Checking ground terminals»(ref-441376-S39468756312011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S33839532002011121500000)

Connect an ohmmeter between terminals 3 and 23 on the breakout box.

The ohmmeter should read approximately 0 ohms.

1. OK Refer to «Checking the control voltage to the damper motor»(ref-441376-S19996697142011121500000)
2. NOT OK Refer to «Checking breakout box»(ref-441376-S14900870342011121500000)

1. Ignition off
2. Disconnect the adapter from the ECC control module and from the ECC control module connector. Check the internal cables in the breakout box for the ground terminal which deviated from 0 ohms. Connect an ohmmeter between: breakout box terminal 3 and adapter connector terminal 3 breakout box terminal 23 and adapter connector terminal 23.

The ohmmeter should read 0 ohms.

1. OK Refer to «Replacing the component»(ref-441376-S28350058832011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S15351098762011121500000)

1. Try a new ECC control module according to «Control module, climate»(ref-441328-S07954369152011121500000) .

1. Continue Refer to «Verification»(ref-441376-S09551299742011121500000)

Check the ground lead between the 30 pin connector terminal 3 (ECC control module side) and ground terminal relay box 15/14, ground rail D8, for an open-circuit according to Open-circuit, permanent faults

Is there an open-circuit in the cable?

1. YES Refer to «Remedy open-circuit»(ref-441376-S20090094572011121500000)
2. NO Refer to «Checking for an open-circuit»(ref-441376-S30681881662011121500000)

Check for an open-circuit between ground rail D10 and chassis Open-circuit, permanent faults .

1. Continue Refer to «Verification»(ref-441376-S09551299742011121500000)

1. Remedy open-circuit.

1. Continue Refer to «Verification»(ref-441376-S09551299742011121500000)

1. Disconnect adapter «9813194»(ref-403953-S13746433212011061000000) from the breakout box «9813190»(ref-403953-S32930552542011061000000) . Check the relevant leads in the breakout box and adapter to establish where the fault is. Replace breakout box or adapter.

1. Continue Refer to «Checking ground terminals»(ref-441376-S08476923632011121500000)

1. Ignition on
2. ECC control module connected. Connect a stand-alone multimeter, set to volts, between terminals 9 and 10 on the breakout box. For information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Activate the self-adjustment function by clicking on the VCT 2000 symbol. Read off the multimeter. The voltmeter value should vary from 0 V to 10 V (depending on whether the shutter is opening or closing) and back to 0 V in approximately 12 seconds.

Are these conditions fulfilled?

1. YES Refer to «Verification»(ref-441376-S22016871122011121500000)
2. NO Refer to «Checking the resistance in the cable»(ref-441376-S16173778002011121500000)

1. Ignition off
2. Disconnect the connector from the control module.
3. Disconnect the connector for the air distribution damper motor according to «Air distribution»(ref-441328-S07525919422011121500000) . Bridge across terminals 2 and 6 on the female half of the damper motor connector. Connect an ohmmeter between terminals 9 and 10 on the breakout box.

The ohmmeter should read 0 ohms.

1. OK Refer to «Checking components»(ref-441376-S12238466782011121500000)
2. NOT OK Refer to «Checking for an open-circuit»(ref-441376-S28177994112011121500000)

1. Ignition off
2. Connector for the damper motor air distribution disconnected. Connect an ohmmeter between terminal 2 and 6 on the connector.

The ohmmeter should read approximately 120 ohms.

1. OK Refer to «Checking for blockage»(ref-441376-S08192240922011121500000)
2. NOT OK Refer to «Replacing the component»(ref-441376-S01605825112011121500000)

Check that the shutter is not blocked. Check that the shutter can move unimpeded: Activate the self-adjustment function. For further information about self-adjustment, see Self adjustment of damper motor limit positions . Activate self-adjustment: Click the VCT 2000 symbol. Also check that the toothed segment that runs against the shutter shaft is unimpeded.

Is the shutter blocked?

1. YES Refer to «Remedy the blockage»(ref-441376-S40280171302011121500000)
2. NO Refer to «Replacing the component»(ref-441376-S01605825112011121500000)

1. Remedy the blockage.

1. Continue Refer to «Verification»(ref-441376-S22016871122011121500000)

1. Replace the air distribution damper motor according to «Air distribution»(ref-441328-S07525919422011121500000) .

1. Continue Refer to «Self-adjustment of the shutter motor end position»(ref-441376-S04465687552011121500000)

1. Air distribution damper motor OK. Check the following signal cables for an open-circuit according to according to «Open-circuit, permanent faults»(ref-441291-S38831997352011121500000) : the cable between ECC control module connector terminal 10 on the female half and damper motor connector terminal 2 on the female half the cable between ECC control module connector terminal 9 on the female half and damper motor connector terminal 6 on the female half.

1. Continue Refer to «Verification»(ref-441376-S22016871122011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC-system.

1. Continue Refer to «Verification, continued»(ref-441376-S02281276352011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S14384716482011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S28292716282011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S40231293002011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S18687781692011121500000)
2. NO Refer to «Checking the control voltage to the damper motor»(ref-441376-S19996697142011121500000)

HINT: Check after repair that the fault has been rectified.

1. Ignition off
2. Reconnect connectors, reinstall components etc.
3. ECC- control module connected.
4. Engine running
5. VCT2000 connected to the data link connector (DLC). Establish communication with the ECC-system.

1. Continue Refer to «Verification, continued»(ref-441376-S14859448172011121500000)

1. For further information about self-adjustment, see «Self adjustment of damper motor limit positions»(ref-441329-S22377793302011121500000) . Click the VCT2000 symbol to activate the self adjustment function.

1. Continue Refer to «Verification, continued»(ref-441376-S26505976222011121500000)

Click on the VCT2000 symbol to read off the diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S35184635742011121500000)

Erase diagnostic trouble codes (DTCs).

1. Continue Refer to «Verification, continued»(ref-441376-S26696211342011121500000)

Check that diagnostic trouble codes (DTCs) do not recur.

Do the diagnostic trouble codes (DTCs) recur?

1. YES Refer to «Information»(ref-441376-S18687781692011121500000)
2. NO VERIFIED: Troubleshooting has been completed.

The fault should be diagnosed and remedied. Since this is not the case the fault-tracing process has failed.

Complete the fault-tracing for those fault or try again.
