Climate Control Module (Ccm) Diagnostic Trouble Codes: Other Volvo V40 I рестайлинг

Intermittent fault

Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation.

Check the signal cable between climate control module terminal #A19 and damper motor terminal #4. Check for an intermittent open-circuit. Check for an intermittent short-circuit to ground.

Check the power supply cable between climate control module terminal #A18 and damper motor terminal #1. Check for an open-circuit. Check for a short-circuit to ground.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

Scheme 236

Scheme 237

Scheme 238

1. Continue Refer to «Information»(ref-441373-S20550298702011121500000)

Fault-tracing information

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Checking components

Check the signal cable between climate control module terminal #A19 and damper motor terminal #4. Check for an open-circuit. Check for a short-circuit to ground.

Check the power supply cable between climate control module terminal #A18 and damper motor terminal #1. Check for an open-circuit. Check for a short-circuit to ground.

If the cables are OK, try a new damper motor.

Remedy as necessary.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S23600691322011121500000)

Electronic climate control (ECC), Manual climate control (MCC), Standard (STD)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

Scheme 239

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S07846765252011121500000)

Verification

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S16219210892011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation.

Check the ground lead between climate control module terminal #A20 and damper motor terminal #3. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Check the signal cable between climate control module terminal #A19 and damper motor terminal #4. Check for an intermittent short-circuit to supply voltage.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S24591634192011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Checking connectors

1. Ignition off
2. Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Wait at least 20 seconds for the control module to carry out its diagnostics
6. Read off diagnostic trouble codes (DTCs). The fault is no longer present if the status of the diagnostic trouble code (DTC) has changed to intermittent. Other information: To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000) For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking components»(ref-441373-S12941897942011121500000)

Check the ground lead between climate control module terminal #A20 and damper motor terminal #3. Check for an open-circuit. Check for a short-circuit to supply voltage.

Check the signal cable between climate control module terminal #A19 and damper motor terminal #4. Check for a short-circuit to supply voltage.

Try a new damper motor if the wiring is OK.

Remedy as necessary.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S19791614922011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S11038524312011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S40628583952011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation.

Check the signal cable between climate control module terminal #A22 and damper motor terminal #4. Check for an intermittent open-circuit. Check for an intermittent short-circuit to ground.

Applies to left-hand drive cars only

Check the power supply cable between climate control module terminal #A21 and damper motor terminal #1. Check for an intermittent open-circuit. Check for an intermittent short-circuit to ground.

Applies to right-hand drive cars only

Check the power supply cable between climate control module terminal #A21 and damper motor terminal #3. Check for an intermittent open-circuit. Check for an intermittent short-circuit to ground.

Other information

1. To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S10950041622011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition off
2. Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Wait at least 20 seconds for the control module to carry out its diagnostics
6. Read off diagnostic trouble codes (DTCs). The fault is no longer present if the status of the diagnostic trouble code (DTC) has changed to intermittent. Other information: To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking components»(ref-441373-S17609979362011121500000)

Check the signal cable between climate control module terminal #A22 and damper motor terminal #4. Check for an open-circuit. Check for a short-circuit to ground.

Applies to left-hand drive cars only

Check the power supply cable between climate control module terminal #A21 and damper motor terminal #1. Check for an open-circuit. Check for a short-circuit to ground.

Applies to right-hand drive cars only

Check the power supply cable between climate control module terminal #A21 and damper motor terminal #3. Check for an open-circuit. Check for a short-circuit to ground.

If the cables are OK, try a new damper motor.

Remedy as necessary.

Other information

1. To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S10915368902011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S16522913132011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S24906580852011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation.

Check the signal cable between climate control module terminal #A22 and damper motor terminal #4. Check for an intermittent short-circuit to supply voltage.

Applies to left-hand drive cars only

Check the ground lead between climate control module terminal #A23 and damper motor terminal #3. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Applies to right-hand drive cars only

Check the ground lead between climate control module terminal #A23 and damper motor terminal #1. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Other information

1. To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S26758235282011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition off
2. Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Wait at least 20 seconds for the control module to carry out its diagnostics
6. Read off diagnostic trouble codes (DTCs). The fault is no longer present if the status of the diagnostic trouble code (DTC) has changed to intermittent. Other information: To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking components»(ref-441373-S27433629492011121500000)

Check the signal cable between climate control module terminal #A22 and damper motor terminal #4. Check for a short-circuit to supply voltage.

Applies to left-hand drive cars only

Check the ground lead between climate control module terminal #A23 and damper motor terminal #3. Check for an open-circuit. Check for a short-circuit to supply voltage.

Applies to right-hand drive cars only

Check the ground lead between climate control module terminal #A23 and damper motor terminal #1. Check for an open-circuit. Check for a short-circuit to supply voltage.

Try a new damper motor if the wiring is OK.

Remedy as necessary.

Other information

1. To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S42217628062011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S25325371032011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S08325517992011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Scheme 240

1. Ignition on
2. Start the blower fan
3. Read off the position sensors
4. Activate the damper motor by slowly turning the temperature selector between the minimum and maximum heat settings. Check that position sensor values change when the temperature control is turned. If the value changes this indicates that damper motor is OK.

Does the position sensor value change?

1. YES Refer to «Intermittent fault»(ref-441373-S21790265042011121500000)
2. NO Refer to «Checking components»(ref-441373-S18479704502011121500000)

Check that the temperature damper can move freely and smoothly to the limit positions. If damper is OK, try a new damper motor.

Remedy as necessary.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000) .

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S19114960622011121500000)

Fault-tracing indicates that the climate control module registered a fault previously in the damper motor but the fault is now no longer present. The earlier may have been caused by the sticking, dirt in the mechanism or in the linkage.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000) .

1. Continue Refer to «Information»(ref-441373-S07194192712011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S32291058932011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the blower fan
5. Read off the position sensor
6. Activate the damper motor by slowly turning the temperature selector between the minimum and maximum heat settings. Check that position sensor values change when the temperature control is turned. If the value changes this indicates that damper motor is OK.

Does the position sensor value change?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S07194192712011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking function air distribution damper motor

1. Ignition on
2. Start the blower fan
3. Read off the position sensor
4. Activate the damper motor by slowly turning the selector for air distribution between its different positions. Check that the value of the position sensor changes as the air distribution selector is turned. If the value changes this indicates that damper motor is OK.

Does the position sensor value change?

1. YES Refer to «Intermittent fault»(ref-441373-S03273486082011121500000)
2. NO Refer to «Checking components»(ref-441373-S23385224182011121500000)

Check that the damper, linkage and gear segment can move freely and smoothly to the end positions. If damper is OK, try a new damper motor.

Remedy as necessary.

Other information

1. To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000)
2. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000) .

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S16071726582011121500000)

Fault-tracing indicates that the climate control module registered a fault previously in the damper motor but the fault is now no longer present. The earlier may have been caused by the sticking, dirt in the mechanism or in the linkage.

Other information

1. To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000)
2. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000) .

1. Continue Refer to «Information»(ref-441373-S06625690542011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S37268349752011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the blower fan
5. Read off the position sensor
6. Activate the damper motor by slowly turning the selector for air distribution between its different positions. Check that position sensor values change when the control is turned. If the value changes this indicates that damper motor is OK.

Does the position sensor value change?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S06625690542011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking cables

Check the cable between climate control unit terminal #A27 and power unit terminal #4. Check blower fan motor terminal #2 and the maximum relay for blower fan terminal #4. Check for a short-circuit to ground.

Note. When the ignition is on and the blower fan is not activated, the voltage on the diagnostic cable is approximately the same as battery voltage (U bat ). The signal voltage falls with increased fan speed when the blower fan is activated.

Try a new power unit or a new blower fan relay if the cables are ok.

Remedy as necessary.

Other information

1. To access and replace the power unit, see «Power unit blower fan»(ref-441328-S22489487822011121500000)
2. To access and replace the blower fan relay, see «Replacing the blower fan relay»(ref-441328-S12623806572011121500000)
3. To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
6. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Scheme 241

Was a fault detected?

1. YES Refer to «Verification»(ref-441373-S33823119692011121500000)
2. NO Refer to «Intermittent fault»(ref-441373-S01924200992011121500000)

Check the cable between climate control unit terminal #A27 and power unit terminal #4. Check blower fan motor terminal #2 and the blower fan relay for blower fan terminal #4. Check for a short-circuit to ground.

Note. When the ignition is on and the blower fan is not activated, the voltage on the diagnostic cable is approximately the same as battery voltage (U bat ). The signal voltage falls with increased fan speed when the blower fan is activated.

Remedy as necessary.

Other information

1. To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To access and replace the power unit, see «Power unit blower fan»(ref-441328-S22489487822011121500000)
3. To access and replace the blower fan relay, see «Replacing the blower fan relay»(ref-441328-S12623806572011121500000)
4. To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
5. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
6. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
7. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S39955784422011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the blower fan
5. Slowly turn the blower fan selector to each position. Check that the function is OK. The fault has been remedied if the function is OK.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S39955784422011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the blower fan
5. Slowly turn the blower fan selector to each position. Check that the function is OK. The fault has been remedied if the function is OK.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S01141641992011121500000)

Check the power unit connector and climate control module connector A (30-pin). Check for contact resistance and oxidation.

Check the cable between climate control module #A27 and power unit terminal #4. Check for an open-circuit and an intermittent short-circuit to supply voltage.

Check the ground lead between power unit terminal #2 and its ground terminal. Check for an open-circuit.

Remedy as necessary.

Other information

1. To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To access or replace the power unit, see «Power unit blower fan»(ref-441328-S22489487822011121500000)
3. To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
6. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S01141641992011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking function of power unit

1. Ignition on
2. Slowly turn the blower fan selector between minimum and maximum. Check that the function is OK
3. The fault is intermittent if the function is OK.

Is the function OK?

1. YES Refer to «Intermittent fault»(ref-441373-S00069732082011121500000)
2. NO Refer to «Checking connectors»(ref-441373-S42819433512011121500000)

1. Ignition off
2. Check the climate control module connector and power unit connector A (30-pin). Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Slowly turn the blower fan selector between minimum and maximum. Check that the function is OK. Other information To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access and replace the power unit, see «Power unit blower fan»(ref-441328-S22489487822011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000) If the function is now OK this indicates that the fault was caused by poor contact in the connectors.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking cables»(ref-441373-S04219665692011121500000)

Check the cable between climate control module #A26 and power unit terminal #3. Check for an open-circuit and a short-circuit to supply voltage.

Try a new power unit if the wiring is OK.

Remedy as necessary.

Other information

1. To access and replace the power unit, see «Power unit blower fan»(ref-441328-S22489487822011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Scheme 242

1. Continue Refer to «Verification»(ref-441373-S28562880692011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least 10 seconds for the control module to carry out its diagnostics
5. Slowly turn the blower fan selector between minimum and maximum. Check that the function is OK. The fault has been remedied if the function is OK.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S26838110362011121500000)

Check the power unit connector and climate control module connector A (30-pin). Check for contact resistance and oxidation. Remedy if necessary.

Check the cable between climate control module #A26 and power unit terminal #3. Check for an intermittent open-circuit and a short-circuit to supply voltage.

Remedy as necessary.

Other information

1. To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To access and replace the power unit, see «Power unit blower fan»(ref-441328-S22489487822011121500000)
3. To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
6. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S26838110362011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on
2. Slowly turn the blower fan selector between minimum and maximum. Check that the function is OK
3. The fault is intermittent if the function is OK.

Is the function OK?

1. YES Refer to «Intermittent fault»(ref-441373-S22802456582011121500000)
2. NO Refer to «Checking cables»(ref-441373-S27544168712011121500000)

Check the cable between climate control module #A26 and power unit terminal #3. Check for a short-circuit to ground.

Try a new power unit if the wiring is OK.

Remedy as necessary.

Other information

1. To access and replace the power unit, see «Power unit blower fan»(ref-441328-S22489487822011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S20462531372011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least 10 seconds for the control module to carry out its diagnostics
5. Slowly turn the blower fan selector between minimum and maximum. Check that the function is OK. The fault has been remedied if the function is OK.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S13694412032011121500000)

Check the cable between climate control module #A26 and power unit terminal #3. Check for an intermittent short-circuit to ground.

Remedy as necessary.

Other information

1. To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To access and replace the power unit, see «Power unit blower fan»(ref-441328-S22489487822011121500000)
3. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. For other information, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
6. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S13694412032011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the function of the blower fan

1. Ignition on
2. Turn the blow fan selector to zero
3. Activate the blower fan relay
4. Check the blower fan operates at maximum speed when activated. The fault is intermittent if the blower fan operates at maximum speed when activated.

Is the function OK?

1. YES Refer to «Intermittent fault»(ref-441373-S36077043942011121500000)
2. NO Refer to «Checking the cable and component»(ref-441373-S09208752602011121500000)

Checking the cable and component

Check the signal cable between climate control module terminal #A24 and blower fan relay terminal #3. Check for a short-circuit to supply voltage.

Try a new blower fan relay if the cable is OK.

Remedy as necessary.

Other information

1. To access and replace the blower fan relay, see «Replacing the blower fan relay»(ref-441328-S12623806572011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Scheme 243

1. Continue Refer to «Verification»(ref-441373-S27940538702011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Turn the blow fan selector to zero
5. Activate the blower fan relay. The fault is remedied if the blower fan operates at maximum speed when activated.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S21723875612011121500000)

Check the signal cable between climate control module terminal #A24 and blower fan relay terminal #3. Check for an intermittent short-circuit to supply voltage.

Other information

1. To access and replace the blower fan relay, see «Replacing the blower fan relay»(ref-441328-S12623806572011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S21723875612011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on
2. Check that the blower fan speed can be controlled using the blower fan selector on the climate control module panel. NOTE: Do not select position AUT (ECC); the climate control module controls its own speed at this setting.
3. Also check the maximum speed by setting the blower fan selector to the maximum position. The fault is intermittent if the function is OK.

Is the function OK?

1. YES Refer to «Intermittent fault»(ref-441373-S30097832232011121500000)
2. NO Refer to «Checking the power supply to the blower fan relay»(ref-441373-S26517861042011121500000)

Checking the power supply to the blower fan relay

Check the power supply to the blower fan relay. Check for the following

1. Defective fuse number 1 (25 A) and fuse number 12 (15 A) in the integrated relay/fusebox in the passenger compartment
2. Contact resistance or oxidation in the terminals
3. The function of the system relay for the air conditioning (A/C) system, terminal 2
4. Open-circuit or short-circuit to ground in the cable between the air conditioning (A/C) system relay and the blower fan relay. HINT: When the ignition is on, the system relay for the air conditioning (A/C) system must activate. The voltage at blower fan relay terminal #1 should then be approximately battery voltage measured at the ground terminal (0 V).

Remedy as necessary.

Other information

1. To access and replace the system relay for the air conditioning (A/C) system, see «Replacing relay in central electrical unit in passenger compartment»(ref-461600-S01744819162012040200000)
2. To access and replace the blower fan relay, see «Replacing the blower fan relay»(ref-441328-S12623806572011121500000)
3. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
4. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Scheme 244

Was a fault detected?

1. YES Refer to «Verification»(ref-441373-S26992475892011121500000)
2. NO Refer to «Checking the connectors, components and wiring»(ref-441373-S02049985182011121500000)

Check the air conditioning (A/C) system relay (terminal 2). Check the blower fan relay connector. Check for contact resistance and oxidation.

Check the cable between the air conditioning (A/C) system relay (position 2) terminal #3 and the blower fan relay terminal #1. Check for an intermittent open-circuit.

Check the signal cable between climate control module terminal #A24 and blower fan relay terminal #3. Check for an intermittent open-circuit. Check for an intermittent short-circuit to ground.

Remedy as necessary.

Other information

1. To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

Scheme 245

1. Continue Refer to «Information»(ref-441373-S11715416382011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on. Check that the blower fan speed can be controlled using the blower fan selector on the climate control module panel. NOTE: Do not select position AUT (ECC); the climate control module controls its own blower fan speed at this setting. Also check the maximum speed by setting the blower fan selector to the maximum position. The fault has been remedied if the function is OK.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S11715416382011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Check the seat heater module connectors B and C for contact resistance and oxidation. Remedy if necessary.

Check the seat heater pads and wiring between connector B terminals #1 and #4 and connector C terminals #1 and #2. Check for an intermittent open-circuit. Check for an intermittent short-circuit to ground.

Check the thermistor wiring between connector B terminals #2 and #3. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Other information

1. To access and replace the seat heater pad, see «Heater pad backrest, replacing»(ref-441374-S19991983852011121500000) and «Heater pad seat cushion»(ref-441374-S15995027492011121500000) . To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000)
2. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
3. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

Scheme 246

Scheme 247

1. Continue Refer to «Information»(ref-441373-S25887423202011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Check the seat heater pads and wiring between connector B terminal #1 and #4 and connector C terminal #1 and #2. Check for an open-circuit. Check for a short-circuit to ground.

Check the thermistor in the seat cushion and the wiring between connector B terminals #2 and #3. Check for an open-circuit. Check for short-circuit to supply voltage.

Check that the power supply to the seat heater module is OK between connector A terminals #1 (ground) and #4 (battery voltage).

The ignition must be on during this check.

Try a new seat heater module if the components, wiring and power supply is OK.

Remedy as necessary.

Other information

1. To access and replace the seat heater pad, see «Heater pad backrest, replacing»(ref-441374-S19991983852011121500000) and «Heater pad seat cushion»(ref-441374-S15995027492011121500000)
2. To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000)
3. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
4. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S05499866882011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S10734313722011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Faulty signal. Permanent fault

See Faulty signal. Permanent fault

Check the climate control module connector A (30-pin) and the left seat heater module connector A. Check for contact resistance and oxidation.

Check the signal cable between climate control module terminal #A9 and connector terminal A#2 on the left seat heater module. Check for an intermittent open-circuit. Check for an intermittent short-circuit to ground.

Note. If the seat heater is activated at high or low level, the signal in the cable is pulsed in pulse trains between approximately 0 V and battery voltage.

Other information

1. To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

Scheme 248

1. Continue Refer to «Information»(ref-441373-S24926214762011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition off
2. Check the connector for seat heater module connector A and the (30-pin) control module connector. Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Wait at least three minutes so that the control module has time to carry out its diagnostic
6. Read off diagnostic trouble codes (DTCs). The fault is no longer present if the status of the diagnostic trouble code (DTC) has changed to intermittent. Other information: To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking the cable»(ref-441373-S29967513812011121500000)

Checking the cable

Check the signal cable between climate control module terminal #A9 and connector terminal A#2 on the left seat heater module. Check for an open-circuit. Check for a short-circuit to ground.

Note. If the seat heater is activated at high or low level, the signal in the cable is pulsed in pulse trains between approximately 0 V and battery voltage.

Check that the power supply to the seat heater module is OK between connector terminals A#1 (ground) and A#4 (battery voltage). The ignition must be on during this check.

Remedy as necessary.

Other information

1. To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S40730375872011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S36088843282011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the climate control module connector and the right seat heater control module connector A (30-pin). Check for contact resistance and oxidation.

Check the signal cable between climate control module terminal #A10 and connector terminal A#2 on the right seat heater module. Check for an intermittent open-circuit. Check for an intermittent short-circuit to ground.

Note. If the seat heater is activated at high or low level, the signal in the cable is pulsed in pulse trains between approximately 0 V and battery voltage.

Other information

1. To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S33014046612011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition off
2. Check the right seat heater module connector A and the climate control module connector A (30-pin). Check for contact resistance and oxidation. Remedy if necessary Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Wait at least three minutes so that the control module has time to carry out its diagnostic
6. Read off diagnostic trouble codes (DTCs). The fault is no longer present if the status of the diagnostic trouble code (DTC) has changed to intermittent. Other information: To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking the cable»(ref-441373-S35540631442011121500000)

Check the signal cable between climate control module terminal #A10 and connector terminal A#2 on the right seat heater module. Check for an open-circuit. Check for a short-circuit to ground.

Note. If the seat heater is activated at high or low level, the signal in the cable is pulsed between approximately 0 V and battery voltage.

Check that the power supply to the seat heater module is OK between connectors A#1 (ground) and A#4 (battery voltage).

The ignition must be on during this check.

Remedy as necessary.

Other information

1. To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S02919703182011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S10069746582011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the signal cable between climate control module (CCM) terminal #A9 and left seat heater module terminal A#2. Check for an intermittent short-circuit to supply voltage.

Note. If the seat heater is activated at high or low level, the signal in the cable is pulsed between approximately 0 V and battery voltage.

Remedy as necessary.

Other information

1. To access and replace the seat heater pad, see «Heater pad backrest, replacing»(ref-441374-S19991983852011121500000) and «Heater pad seat cushion»(ref-441374-S15995027492011121500000)
2. To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000)
3. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S03112207962011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Check the signal cable between climate control module (CCM) terminal #A9 and left seat heater module terminal A#2. Check for a short-circuit to supply voltage.

Note. If the seat heater is activated at high or low level, the signal in the cable is pulsed between approximately 0 V and battery voltage.

Check that the power supply to the seat heater module is OK between connectors A#1 (ground) and A#4 (battery voltage).

The ignition must be on during this check.

Remedy as necessary.

Other information

1. To access and replace the seat heater pad, see «Heater pad backrest, replacing»(ref-441374-S19991983852011121500000) and «Heater pad seat cushion»(ref-441374-S15995027492011121500000) . To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000)
2. To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000)
3. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S36340944732011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S10115447702011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the signal cable between climate control module (CCM) terminal #A10 and right seat heater module terminal A#2. Check for an intermittent short-circuit to supply voltage.

Note. If the seat heater is activated at high or low level, the signal in the cable is pulsed between approximately 0 V and battery voltage.

Remedy as necessary.

Other information

1. To access and replace the seat heater pad, see «Heater pad backrest, replacing»(ref-441374-S19991983852011121500000) and «Heater pad seat cushion»(ref-441374-S15995027492011121500000)
2. To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000)
3. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S10015145512011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Check the signal cable between climate control module (CCM) terminal #A10 and right seat heater module terminal A#2. Check for a short-circuit to supply voltage.

Note. If the seat heater is activated at high or low level, the signal in the cable is pulsed between approximately 0 V and battery voltage.

Check that the power supply to the seat heater module is OK between connectors A#1 (ground) and A#4 (battery voltage).

The ignition must be on during this check.

Remedy as necessary.

Other information

1. To access and replace the seat heater pad, see «Heater pad backrest, replacing»(ref-441374-S19991983852011121500000) and «Heater pad seat cushion»(ref-441374-S15995027492011121500000) . To access and replace the seat heater module, see «Seat heater module, replacing»(ref-441374-S12982118622011121500000)
2. To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000)
3. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. The voltage in the signal cable is a pulsed signal. See «Climate control signal specifications»(ref-441327-S29322084422011121500000) for the values
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S41307707892011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S19283780332011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the function of the rear defroster

1. Ignition on
2. Read off the status of the defroster relay
3. Activate the rear defroster switch on the climate control module panel. Check that the status changes when the switch is activated. The fault is intermittent if the status changes when the switch is activated.

Has the status changed?

1. YES Refer to «Intermittent fault»(ref-441373-S31034397582011121500000)
2. NO Refer to «Checking the cable and component»(ref-441373-S23959189502011121500000)

Check the signal cable between climate control module terminal #A25 and defroster relay position 1 terminal #2. Check for a short-circuit to supply voltage.

Try a new defroster relay if the cable is OK.

Remedy as necessary.

Other information

1. To access and replace the defroster relay, see «Replacing relay in central electrical unit in passenger compartment»(ref-461600-S01744819162012040200000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Scheme 249

1. Continue Refer to «Verification»(ref-441373-S15346027982011121500000)

Check the signal cable between climate control module terminal #A25 and defroster relay position 1 terminal #2. Check for an intermittent short-circuit to supply voltage.

Other information

1. To access and replace the defroster relay, see «Replacing relay in central electrical unit in passenger compartment»(ref-461600-S01744819162012040200000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S31858353552011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Read off the status of the defroster relay
5. Activate the rear defroster switch
6. Check that the status changes when the switch is activated. The fault has been remedied if the status changes.

Has the status changed?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S31858353552011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on
2. Read off the status of the defroster relay
3. Activate the rear defroster switch on the climate control module panel. Check that the status changes when the switch is activated. The fault is intermittent if the status changes when the switch is activated.

Has the status changed?

1. YES Refer to «Intermittent fault»(ref-441373-S32040855002011121500000)
2. NO Refer to «Checking connectors»(ref-441373-S12839136892011121500000)

1. Ignition off
2. Check the defroster relay base for position 1 and climate control module connector A (30-pin). Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Read off the status of the defroster relay. Activate the rear defroster switch on the climate control module panel. Check that the status changes when the switch is activated. The fault was caused by loose connections in the connectors if the status changes. Other information To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access and replace the defroster relay, see «Replacing relay in central electrical unit in passenger compartment»(ref-461600-S01744819162012040200000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Has the status changed?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking the cable and component»(ref-441373-S29442842892011121500000)

Check the cable between climate control module terminal #A25 and defroster relay position 1 terminal #2. Check for an open-circuit and a short-circuit to ground.

Check fuse number 12 (15A) in the integrated relay/fusebox in the passenger compartment.

Check that there is power to and from each fuse when the ignition is on.

Try a new defroster relay if the wiring is OK.

Remedy as necessary.

Other information

1. To access and replace the defroster relay, see «Replacing relay in central electrical unit in passenger compartment»(ref-461600-S01744819162012040200000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S28371240602011121500000)

Check the climate control module connector A (30-pin) and the defroster relay base for position 1. Check for contact resistance and oxidation.

Check the cable between climate control module terminal #A25 and defroster relay position 1 terminal #2. Check for an intermittent open-circuit and an intermittent short-circuit to ground.

Other information

1. To access and replace the defroster relay, see «Replacing relay in central electrical unit in passenger compartment»(ref-461600-S01744819162012040200000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S37574089842011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Read off the status of the defroster relay
5. Activate the rear defroster switch on the climate control module panel
6. Check that the status changes when the switch is activated. The fault has been remedied if the status changes.

Has the status changed?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S37574089842011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the function of the air conditioning (A/C) request

1. Start the engine and let it run at idle speed
2. Start the blower fan. NOTE: Check that the air distribution selector is not in the defrost position (the marking pointing straight up).
3. Read off the status for the air conditioning (A/C) request
4. Remedy as necessary. Activate the air conditioning (A/C) switch on the climate control module panel. Check that the status changes between activated and not activated when the air conditioning switch is pressed in and released. The fault is intermittent if the status changes.

Does the status change with the position of the switch?

1. YES Refer to «Intermittent fault»(ref-441373-S42348708232011121500000)
2. NO Refer to «Checking cables»(ref-441373-S07788283972011121500000)

Scheme 250

Scheme 251

1. Ignition off
2. Check the signal cable between climate control module terminal #B13 and the engine control module (ECM) for a short-circuit to ground.
3. Remedy as necessary. Other information: To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000) To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000) For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S33358579422011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and allow it to run at idle speed
4. Start the blower fan. NOTE: Check that the air distribution selector is not in the defrost position (the marking pointing straight up).
5. Read off the status for the air conditioning (A/C) request
6. Remedy as necessary. Activate the air conditioning (A/C) switch on the climate control module panel. Check that the status changes between activated and not activated when the air conditioning switch is pressed in and released. The fault has been remedied if the status changes.

Does the status change with the position of the switch?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S17375622552011121500000)

1. Ignition off. Check the signal cable between climate control module terminal #B13 and the engine control module (ECM). Check for an intermittent short-circuit to ground. Remedy as necessary. Other information: To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000) To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000) For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000) See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S17375622552011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and let it run at idle speed
2. Start the blower fan. NOTE: Check that the air distribution selector is not in the defrost position (the marking pointing straight up).
3. Read off the status for the air conditioning (A/C) request
4. Activate the air conditioning (A/C) switch on the climate control module panel. Check that the status changes between activated and not activated when the air conditioning switch is pressed in and released. The fault is intermittent if the status changes.

Does the status change with the position of the switch?

1. YES Refer to «Intermittent fault»(ref-441373-S03168056302011121500000)
2. NO Refer to «Checking cables»(ref-441373-S07162399102011121500000)

1. Check the signal cable between climate control module terminal #B13 and the engine control module (ECM). Check for a short-circuit to supply voltage.
2. Remedy as necessary. Other information: To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000) To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000) For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S38042844802011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and allow it to run at idle speed
4. Start the blower fan. NOTE: Check that the air distribution selector is not in the defrost position (the marking pointing straight up).
5. Read off the status for the air conditioning (A/C) request
6. Remedy as necessary. Activate the air conditioning (A/C) switch on the climate control module panel. Check that the status changes between activated and not activated when the air conditioning switch is pressed in and released. The fault has been remedied if the status changes.

Does the status change with the position of the switch?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S13261583522011121500000)

Check the signal cable between climate control module terminal #B13 and the engine control module (ECM). Check for an intermittent short-circuit to supply voltage.

Remedy as necessary.

Other information

1. To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S13261583522011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the cable between climate control module terminal #A15 and temperature damper motor terminal #6. Check for a short-circuit to ground.

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A16 and recirculation damper motor terminal #2. Check for a short-circuit to ground.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A16 and recirculation damper motor terminal #6. Check for a short-circuit to ground.

If the cables are OK, try a new damper motor.

Remedy as necessary.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. To access or replace the recirculation damper motor, see «Recirculation»(ref-441328-S22789708522011121500000)
3. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. For the resistance values, see «Electrical / electronic system specifications»(ref-441327-S22800567222011121500000)
6. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Was a fault detected?

1. YES Refer to «Self-adjustment of damper motor end positions»(ref-441373-S16567511802011121500000)
2. NO Refer to «Intermittent fault»(ref-441373-S15132816932011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Run it to normal operating temperature
4. Start the blower fan
5. Slowly turn the temperature selector between minimum and maximum positions. Check that the air is hot and cold. Activate the recirculation switch on the climate control module panel. Check that the recirculation motor moves to both limit positions when recirculation is engaged and disengaged. HINT: Remove the loudspeaker grille and any loudspeakers on the passenger side. Shine a flashlight on the linkage. Check that the motor moves towards the limit positions. The fault has been remedied if the functions are OK.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S04270548992011121500000)

Check the cable between climate control module terminal #A15 and temperature damper motor terminal #6. Check for an intermittent short-circuit to ground.

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A16 and recirculation damper motor terminal #2. Check for an intermittent short-circuit to ground.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A16 and recirculation damper motor terminal #6. Check for a short-circuit to ground.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. To access or replace the recirculation damper motor, see «Recirculation»(ref-441328-S22789708522011121500000)
3. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S16567511802011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S03554507002011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation.

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A17 and damper motor terminal #6. Check the cable between climate control module terminal #A16 and damper motor terminal #2. Check for an open-circuit.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A17 and damper motor terminal #2. Check the cable between climate control module terminal #A16 and damper motor terminal #6. Check for an open-circuit.

If the cables are OK, try a new damper motor.

Remedy as necessary.

Other information

1. To access or replace the recirculation damper motor, see «Recirculation»(ref-441328-S22789708522011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Was a fault detected?

1. YES Refer to «Self-adjustment of damper motor end positions»(ref-441373-S14367411962011121500000)
2. NO Refer to «Intermittent fault»(ref-441373-S21566897862011121500000)

Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation.

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A17 and damper motor terminal #6. Check the cable between climate control module terminal #A16 and damper motor terminal #2. Check for an intermittent open-circuit.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A17 and damper motor terminal #2. Check the cable between climate control module terminal #A16 and damper motor terminal #6. Check for an intermittent open-circuit.

Other information

1. To access or replace the recirculation damper motor, see «Recirculation»(ref-441328-S22789708522011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S14367411962011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S33013786722011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Activate the damper motor by pressing the recirculation switch on the climate control module panel. Check that the recirculation motor moves to both limit positions when recirculation is engaged and disengaged. HINT: Remove the loudspeaker grille and any loudspeakers on the passenger side. Shine a flashlight on the linkage. Check that the motor moves towards the limit positions. The fault has been remedied if the function is OK.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S32143825222011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A17 and damper motor terminal #6. Check for a short-circuit to ground.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A17 and damper motor terminal #2. Check for a short-circuit to ground.

If the cables are OK, try a new damper motor.

Remedy as necessary.

Other information

1. To access or replace the recirculation damper motor, see «Recirculation»(ref-441328-S22789708522011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Was a fault detected?

1. YES Refer to «Self-adjustment of damper motor end positions»(ref-441373-S36812880162011121500000)
2. NO Refer to «Intermittent fault»(ref-441373-S36328631452011121500000)

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A17 and damper motor terminal #6. Check for an intermittent short-circuit to ground.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A17 and damper motor terminal #2. Check for a short-circuit to ground.

Other information

1. To access or replace the recirculation damper motor, see «Recirculation»(ref-441328-S22789708522011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000) .

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S36812880162011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S11346353242011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Activate the damper motor by pressing the recirculation switch on the climate control module panel. Check that the recirculation motor moves to both limit positions when recirculation is engaged and disengaged. HINT: Remove the loudspeaker grille and any loudspeakers on the passenger side. Shine a flashlight on the linkage. Check that the motor moves towards the limit positions. The fault has been remedied if the function is OK.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S26444149602011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the cable between climate control module terminal #A14 and temperature damper motor terminal #2. Check for a short-circuit to ground.

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A12 and air distribution damper motor terminal #6. Check for a short-circuit to ground.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A12 and air distribution damper motor terminal #2. Check for a short-circuit to ground.

If the cables are OK, try a new damper motor.

Remedy as necessary.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000)
3. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
6. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Was a fault detected?

1. YES Refer to «Self-adjustment of damper motor end positions»(ref-441373-S32792201902011121500000)
2. NO Refer to «Intermittent fault»(ref-441373-S35528360002011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Run it to normal operating temperature
4. Start the blower fan
5. Slowly turn the temperature selector between the minimum and maximum positions. Check that the air is hot and cold. Turn the air distribution selector between its positions. Check that the air distribution changes for each air damper. The fault has been remedied if the functions are OK.

Is the function OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S39422550822011121500000)

Check the cable between climate control module terminal #A14 and temperature damper motor terminal #2. Check for an intermittent short-circuit to ground.

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A12 and air distribution damper motor terminal #6. Check for an intermittent short-circuit to ground.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A12 and air distribution damper motor terminal #2. Check for an intermittent short-circuit to ground.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000)
2. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
3. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S32792201902011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S16364055442011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on
2. Start the blower fan
3. Read off the position sensor
4. Activate the damper motor by slowly turning the selector for air distribution between its different positions. Check that the value of the position sensor changes as the air distribution selector is turned clockwise and counter-clockwise. The fault is intermittent if the status changes when the selector is turned.

Does the value of the position sensor change when turning clockwise and counter-clockwise?

1. YES Refer to «Intermittent fault»(ref-441373-S24957234852011121500000)
2. NO Refer to «Checking components»(ref-441373-S00495899292011121500000)

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A13 and damper motor terminal #2. Check for a short-circuit to ground.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A13 and damper motor terminal #6. Check for a short-circuit to ground.

Try a new damper motor if the wiring is OK.

Remedy as necessary.

Other information

1. To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S37741700272011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the blower fan
5. Wait at least 10 seconds for the control module to carry out its diagnostics
6. Read off the position sensor
7. Activate the damper motor by slowly turning the selector for air distribution between its different positions. Check that the value of the position sensor changes as the air distribution selector is turned clockwise and counter-clockwise. The fault is remedied if the status changes when the selector is turned clockwise and counter-clockwise.

Does the value of the position sensor change when turning clockwise and counter-clockwise?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S06019686192011121500000)

Applies to left-hand drive cars only

Check the cable between climate control module terminal #A13 and damper motor terminal #2. Check for an intermittent short-circuit to ground.

Applies to right-hand drive cars only

Check the cable between climate control module terminal #A13 and damper motor terminal #6. Check for an intermittent short-circuit to ground.

Other information

1. To access or replace the air distribution damper motor, see «Damper motor for air distribution»(ref-441328-S34255871022011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. For the resistance values, see «Electrical/electronic system specifications»(ref-441327-S22800567222011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Self-adjustment of damper motor end positions»(ref-441373-S37741700272011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S23902917372011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the signal cable between climate control module terminal #B5 and engine coolant temperature (ECT) sensor #2. Check for an intermittent short-circuit to ground.

Remedy as necessary.

Other information

1. To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

Scheme 252

1. Continue Refer to «Information»(ref-441373-S11136571872011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Engine running
4. Read off the engine coolant temperature (ECT). The fault has been remedied if the engine coolant temperature (ECT) is OK.

Is the temperature reading OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S22465415772011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the climate control module connector B (16-pin) for contact resistance and oxidation.

Check the signal cable between climate control module terminal #B5 and engine coolant temperature (ECT) sensor terminal #2. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Check the ground lead between climate control module terminal #B6 and engine coolant temperature (ECT) sensor terminal #1. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Remedy as necessary.

Other information

1. To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S16798115202011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition off
2. Check climate control module connector B (16-pin) for contact resistance and oxidation. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Read off the engine coolant temperature (ECT). Check that the engine coolant temperature (ECT) reading is correct. Compare with the engine coolant temperature. If the engine coolant temperature (ECT) is now OK, the fault was caused by poor contact in the connectors. Other information: To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Is the temperature reading OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking components and wiring»(ref-441373-S03769367612011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine
4. Read off the engine coolant temperature (ECT). The fault has been remedied if the temperature is OK.

Is the temperature reading OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S18325123572011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the cable between climate control module terminal #B3 and evaporator temperature sensor terminal #4. Check for an intermittent short-circuit to ground.

Remedy as necessary.

Other information

1. To replace the evaporator temperature sensor, see «Temperature sensor evaporator»(ref-441328-S03072863592011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

Scheme 253

1. Continue Refer to «Information»(ref-441373-S36859296352011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Read off the evaporator temperature. Check that the evaporator temperature is correct. The fault has been remedied if the evaporator temperature is correct.

Is the temperature reading OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S28555544982011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the evaporator temperature sensor and climate control module connector B (16-pin). Check for contact resistance and oxidation.

Check the signal cable between climate control module terminal #B3 and evaporator temperature sensor terminal #4. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Check the ground lead between climate control module terminal #B4 and evaporator temperature sensor terminal #3. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Remedy as necessary.

Other information

1. To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To connect the breakout box to the climate control module, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the temperature signal, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S16826312602011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition off
2. Check the evaporator temperature sensor and the climate control module connector B (16-pin) Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Read off the evaporator temperature. Check that the evaporator temperature is correct. Compare with the actual air temperature. The fault was loose connections in the connectors if the evaporator temperature sensor is OK. Other information To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To replace the evaporator temperature sensor, see «Temperature sensor evaporator»(ref-441328-S03072863592011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Is the temperature reading OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking components and wiring»(ref-441373-S03351820432011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Read off the evaporator temperature. Check that the evaporator temperature is correct. The fault has been remedied if the evaporator temperature is correct.

Is the temperature reading OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S23036145732011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Read off the outside temperature. Check that the outside temperature reading is correct. Compare with the actual air temperature. The fault has been remedied if the outside temperature is correct.

Is the temperature reading OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S26432514092011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check the cable between climate control module terminal #B1 and outside temperature sensor terminal #2. Check for an intermittent short-circuit to ground.

Remedy as necessary.

Other information

1. To replace the outside temperature sensor, see «Outside temperature sensor»(ref-441328-S11943014702011121500000)
2. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
3. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
4. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S34401244622011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Check the outside temperature sensor and climate control module connector B (16-pin). Check for contact resistance and oxidation.

Check the cable between climate control module terminal #B1 and outside temperature sensor terminal #2. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Check the cable between control module terminal #B2 and outside temperature sensor terminal #1. Check for an intermittent open-circuit. Check for an intermittent short-circuit to supply voltage.

Remedy as necessary.

Other information

1. To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000)
2. To access the outside temperature sensor, see «Outside temperature sensor»(ref-441328-S11943014702011121500000)
3. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
4. For the voltage of the signal cable, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
5. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

1. Continue Refer to «Information»(ref-441373-S14791200812011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition off
2. Check the outside temperature sensor connector and the climate control module connector B (16-pin) Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Read off the outside temperature. Check that the outside temperature reading is correct. Compare with the actual air temperature. The fault was caused by poor contact in the connectors if the temperature is now OK. Other information To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access or replace the outside temperature sensor, see «Outside temperature sensor»(ref-441328-S11943014702011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Is the temperature reading OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking components and wiring»(ref-441373-S10267352702011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Read off the outside temperature. Check that the outside temperature reading is correct. Compare with the actual air temperature. The fault has been remedied if the outside temperature is correct.

Is the temperature reading OK?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S12243748252011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on
2. Start the blower fan
3. Read off the damper motor position sensor
4. Activate the damper motor by turning the control for air distribution to its different positions. Check that position sensor values change when the control is turned. If the value changes this indicates that damper motor is OK.

Does the position sensor value change?

1. YES Refer to «Intermittent fault»(ref-441373-S02803666012011121500000)
2. NO Refer to «Checking connectors»(ref-441373-S05413916902011121500000)

1. Ignition off
2. Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Start the blower fan
6. Read off the damper motor position sensor
7. Activate the damper motor by turning the control for air distribution to its different positions. Check that position sensor values change when the control is turned. The cause of the fault was loose connections in the connector if the value changes. Other information: To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Does the position sensor value change?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking components and wiring»(ref-441373-S06204188902011121500000)

Fault-tracing indicates that the climate control module registered a fault previously in the damper motor, but the fault is now no longer present. The fault may have been caused by contact resistance or oxidation in the terminals.

The fault may also have been caused by an intermittent open-circuit in the signal cable to the + or - air distribution damper motor.

Other information

1. To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000) .

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the blower fan
5. Read off the damper motor position sensor
6. Activate the damper motor by turning the control for air distribution to its different positions. Check that position sensor values change when the control is turned. If the value changes this indicates that damper motor is OK.

Does the position sensor value change?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S07649555182011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S08500595572011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the function of the temperature damper motor

1. Ignition on
2. Start the blower fan
3. Read off the damper motor position sensor
4. Activate the damper motor by slowly turning the temperature selector between the minimum and maximum heat settings. Check that position sensor values change when the control is turned. If the value changes this indicates that damper motor is OK.

Does the position sensor value change?

1. YES Refer to «Intermittent fault»(ref-441373-S27515298922011121500000)
2. NO Refer to «Checking connectors»(ref-441373-S15216716152011121500000)

1. Ignition off
2. Check the connector for the damper motor and control module connector A (30-pin). Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Start the blower fan
6. Read off the damper motor position sensor
7. Activate the damper motor by turning the temperature selector between the different positions. Check that position sensor values change when the control is turned. The cause of the fault was loose connections in the connector if the value changes. Other information: To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Does the position sensor value change?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking components and wiring»(ref-441373-S28594326612011121500000)

Fault-tracing indicates that the climate control module registered a fault previously in the damper motor but the fault is now no longer present. The fault may have been caused by contact resistance or oxidation in the terminals.

The fault may also have been caused by an intermittent open-circuit in the signal cable to the + or - temperature damper motor.

Other information

1. To access or replace the temperature damper motor, see «Temperature»(ref-441328-S33133212622011121500000) .

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the blower fan
5. Read off the damper motor position sensor
6. Activate the damper motor by slowly turning the temperature selector between the minimum and maximum heat settings. Check that position sensor values change when the temperature control is turned. If the value changes this indicates that damper motor is OK.

Does the position sensor value change?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S20926661632011121500000)

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

1. Continue Refer to «Verification»(ref-441373-S28114644792011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. This diagnostic trouble code (DTC) may have been stored during transportation between the factory and dealership. Check that the transit safety catch in the integrated relay/fusebox in the engine compartment is correctly connected.

Check that battery voltage is normal and that the charging system functions. When the generator (GEN) is charging the voltage should be 12-15 V.

Check the climate control module connector A (30-pin) and the integrated relay/fusebox in the engine compartment. Check for contact resistance and oxidation.

Check fuse 8 (10 A) in the engine compartment integrated relay/fusebox.

Check the cable between climate control module terminal #A1 and fuse 8 (10 A) in the integrated relay/fusebox in the engine compartment. Check for a short-circuit to ground. Check for an open-circuit.

Remedy as necessary

Other information

1. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
2. The cable should have battery voltage regardless of the position of the ignition switch. For other values, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
3. See «Checking wiring and terminals. Intermittent faults»(ref-441291-S36551477422011121500000)

Scheme 254

1. Continue Refer to «Information»(ref-441373-S05667805782011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

1. Ignition off. NOTE: This diagnostic trouble code (DTC) may have been stored during transportation between the factory and dealership. Check that the transit safety catch in the integrated relay/fusebox in the engine compartment is correctly connected.
2. Check the climate control module connector A (30-pin) and the integrated relay/fusebox in the engine compartment. Check for contact resistance and oxidation. Remedy if necessary. Check for damage carefully
3. Reinstall the components, reconnect the connectors etc.
4. Ignition on
5. Wait at least 20 seconds for the control module to carry out its diagnostics
6. Read off diagnostic trouble codes (DTCs). The fault was caused by loose connections in the connector if the status of the diagnostic trouble code (DTC) has changed to intermittent. Other information: To remove the control module, see «Comfort module»(ref-441328-S27180039832011121500000) To access the temperature damper motor, see «Temperature damper motor»(ref-441328-S24521969372011121500000) See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Checking cables»(ref-441373-S23841632852011121500000)

Check that battery voltage is normal and that the charging system functions. When the generator (GEN) is charging the voltage should be 12-15 V.

Check fuse number 8 (10 A) in the engine compartment integrated relay/fusebox.

Check the cable between climate control module terminal #A1 and fuse number 8 (10 A) in the integrated relay/fusebox in the engine compartment. Check for an open-circuit. Check for a short-circuit to ground.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box, climate control module»(ref-441326-S35353694222011121500000)
2. The cable should have battery voltage regardless of the position of the ignition switch. For other values, see «Climate control signal specifications»(ref-441327-S29322084422011121500000)
3. See «Checking wiring and terminals. Permanent fault»(ref-441291-S06723382482011121500000)

1. Continue Refer to «Verification»(ref-441373-S40840768182011121500000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S02432398382011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the relevant switch

1. Ignition on
2. Wait at least 10 seconds for the control module to carry out its diagnostics
3. Read off the button. Check that the status changes when the switch is activated. The fault is no longer present if the status changes.

Does the status change with the position of the switch?

1. YES Refer to «Intermittent fault»(ref-441373-S34727797602011121500000)
2. NO Refer to «Checking the relevant switch»(ref-441373-S22545289232011121500000)

1. Check that the switch has not jammed in the pressed in position and that it does not stick
2. Remedy as necessary
3. If there is no fault in the switch, the climate control module is defective
4. Read off and note the programmed values before replacing the climate control module.

Other information

1. To access or remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000) .

Does the climate control module need to be replaced?

1. YES Refer to «Reading off the programmed values»(ref-441373-S01412054562011121500000)
2. NO Refer to «Verification»(ref-441373-S05077093722011121500000)

The fault-tracing indicates that the climate control module has previously registered a fault in the switch. This may be the result of a stuck switch or because the switch has been pressed in for more than three minutes.

Remedy as necessary.

Other information

1. To access or remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000) .

1. Continue Refer to «Information»(ref-441373-S21940439642011121500000)

1. Ignition on. Activate reading off the programmed values. For information about the programmed values, see «Diagnostic functions, climate control module»(ref-441375-S30508182212011121500000) .

1. Continue Refer to «Information about programming the climate control module»(ref-441373-S26407960602011121500000)

Information about programming the climate control module

The Climate control module (CCM) can be programmed with specific parameters.

Information

See Diagnostic functions, climate control module

Select one of the following options

1. Start the programming. Refer to «Programming driver position (LHD or RHD)»(ref-441373-S09196514472011121500000) .
2. Read off all programmed alternatives. Refer to «Reading off the programmed values»(ref-441373-S04851558262011121500000) .
3. Exit without programming. Refer to «Information»(ref-441373-S16521734042011121500000) .

Scheme 255

Scheme 256

1. Ignition on
2. Read off and program the climate control module. Programmable data is: left-hand drive or right-hand drive . Read off the driver position. Make a note of the value. If the programming is not correct, program in the correct version.

Do you wish to continue to program the next setting?

1. YES Refer to «Programming the seat heater in the left seat»(ref-441373-S13289451892011121500000)
2. NO Refer to «Information»(ref-441373-S16521734042011121500000)

Programming the seat heater in the left seat

Note. This function is used to program the heater for the left seat. In addition to activating the seat heater, the heat level must adapted for the type of upholstery. The maximum temperature for seat heaters with standard upholstery is 40°C (104°F). The maximum temperature for seat heaters with leather upholstery is 43°C (109°F).

1. Ignition on
2. Read off and program the climate control module. Select the temperature level. CAUTION: Programming must be carried out so that the high temperature setting is higher than the low temperature setting. The recommended difference between high and low levels is at least two degrees. Do not exceed the maximum level for the type of upholstery. Read off the seat heater. Make a note of the value. If the programming is not correct, program in the correct version.

Do you wish to continue to program the next setting?

1. YES Refer to «Programming the seat heater in the right seat»(ref-441373-S10195388612011121500000)
2. NO Refer to «Information»(ref-441373-S16521734042011121500000)

Programming the seat heater in the right seat

Note. This function is used to program the heater for the right seat. In addition to activating the seat heater, the heat level must adapted for the type of upholstery. The maximum temperature for seat heaters with standard upholstery is 40°C (104°F). The maximum temperature for seat heaters with leather upholstery is 43°C (109°F).

1. Ignition on
2. Read off and program the climate control module. Select the temperature level. CAUTION: Programming must be carried out so that the high temperature setting is higher than the low temperature setting. The recommended difference between high and low levels is at least two degrees. Do not exceed the maximum level for the type of upholstery. Read off the seat heater. Make a note of the value. If the programming is not correct, program in the correct version.

Do you wish to continue to program the next setting?

1. YES Refer to «Programming the disengagement time for rear windshield and door mirror heating»(ref-441373-S39326258982011121500000)
2. NO Refer to «Information»(ref-441373-S16521734042011121500000)

Programming the disengagement time for rear windshield and door mirror heating

Note. The heating for the rear windshield and door mirrors is engaged using the button on the climate control module. This function is used to program the disengagement time for rear windshield and door mirror heating. The heating is either engaged as long as the function is activated using the button or disengages automatically after 12 minutes.

Scheme 257

1. Ignition on
2. Read off and program the climate control module. Programmable data is: Disengagement after 12 minutes or No disengagement . Read off the disengagement time. Make a note of the value. If the programming is not correct, program in the correct version. Select "Continue" to exit programming.

1. Continue Refer to «Information»(ref-441373-S16521734042011121500000)

Information

Select one of the following options

1. Return to the start of programming or read off the programmed values. Refer to «Information about programming the climate control module»(ref-441373-S26407960602011121500000) .
2. Exit programming and carry out damper motor self-adjustment (new climate control module). Refer to «Self-adjustment of damper motor end positions»(ref-441373-S02991978432011121500000) .
3. Exit the programming. Troubleshooting has been completed.

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least ten seconds for the climate control module to carry out its diagnostic
5. Read off the relevant switch. Check that the status changes when the relevant switch is affected. The fault has been remedied if the status changes.

Has the status changed?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S21940439642011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on. Activate reading off the programmed values. For information about the programmed values, see «Diagnostic functions, climate control module»(ref-441375-S30508182212011121500000) .

1. Continue Refer to «Programming the climate control module»(ref-441373-S10623576612011121500000)

Active too long

See Active too long

See Active too long

See Active too long

See Active too long

The fault-tracing indicates that the climate control module has previously registered a fault in the internal passenger compartment temperature sensor in the climate control module. Check that the ventilation hole for the passenger compartment temperature sensor in the climate control module panel is not blocked.

Remedy as necessary.

Other information

1. To remove the climate control module, see «Comfort module»(ref-441328-S27180039832011121500000) .

1. Continue Refer to «Information»(ref-441373-S14868073022011121500000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Checking the passenger compartment temperature sensor

1. Check that the ventilation holes for the passenger compartment temperature sensor in the climate control module panel are not blocked
2. Remedy as necessary
3. The climate control module is defective if the ventilation holes are blocked. NOTE: The programmed values must be read off and noted before the climate control module is replaced.

Does the climate control module need to be replaced?

1. YES Refer to «Reading off the programmed values»(ref-441373-S20906911012011121500000)
2. NO Refer to «Verification»(ref-441373-S16755483202011121500000)

1. Ignition on. Activate reading off the programmed values. For information about the programmed values, see «Diagnostic functions, climate control module»(ref-441375-S30508182212011121500000) .

1. Continue Refer to «Information about programming the climate control module»(ref-441373-S37102607052011121500000)

The Climate control module (CCM) can be programmed with specific parameters.

Information

See Diagnostic functions, climate control module

Select one of the following options

1. Start the programming. Refer to «Programming driver position (LHD or RHD)»(ref-441373-S21921275352011121500000) .
2. Read off all programmed alternatives. Refer to «Reading off the programmed values»(ref-441373-S27047497852011121500000) .
3. Exit without programming. Refer to «Information»(ref-441373-S37450037442011121500000) .

Programming driver position (LHD or RHD)

1. Ignition on
2. Read off and program the climate control module. Programmable data is: left-hand drive or right-hand drive . Read off the driver position. Make a note of the value. If the programming is not correct, program in the correct version.

Do you wish to continue to program the next setting?

1. YES Refer to «Programming the seat heater in the left seat»(ref-441373-S18998077842011121500000)
2. NO Refer to «Information»(ref-441373-S37450037442011121500000)

Note. This function is used to program the heater for the left seat. In addition to activating the seat heater, the heat level must adapted for the type of upholstery. The maximum temperature for seat heaters with standard upholstery is 40°C (104°F). The maximum temperature for seat heaters with leather upholstery is 43°C (109°F).

1. Ignition on
2. Read off and program the climate control module. Select the temperature level. CAUTION: Programming must be carried out so that the high temperature setting is higher than the low temperature setting. The recommended difference between high and low levels is at least two degrees. Do not exceed the maximum level for the type of upholstery. Read off the seat heater. Make a note of the value. If the programming is not correct, program in the correct version.

Do you wish to continue to program the next setting?

1. YES Refer to «Programming the seat heater in the right seat»(ref-441373-S25484018952011121500000)
2. NO Refer to «Information»(ref-441373-S37450037442011121500000)

Note. This function is used to program the heater for the right seat. In addition to activating the seat heater, the heat level must adapted for the type of upholstery. The maximum temperature for seat heaters with standard upholstery is 40°C (104°F). The maximum temperature for seat heaters with leather upholstery is 43°C (109°F).

1. Ignition on
2. Read off and program the climate control module. Select the temperature level. CAUTION: Programming must be carried out so that the high temperature setting is higher than the low temperature setting. The recommended difference between high and low levels is at least two degrees. Do not exceed the maximum level for the type of upholstery. Read off the seat heater. Make a note of the value. If the programming is not correct, program in the correct version.

Do you wish to continue to program the next setting?

1. YES Refer to «Programming the disengagement time for rear windshield and door mirror heating»(ref-441373-S32022035582011121500000)
2. NO Refer to «Information»(ref-441373-S37450037442011121500000)

Note. The heating for the rear windshield and door mirrors is engaged using the button on the climate control module. This function is used to program the disengagement time for rear windshield and door mirror heating. The heating is either engaged as long as the function is activated using the button or disengages automatically after 12 minutes.

1. Ignition on
2. Read off and program the climate control module. Programmable data is: Disengagement after 12 minutes or No disengagement . Read off the disengagement time. Make a note of the value. If the programming is not correct, program in the correct version. Select "Continue" to exit programming.

1. Continue Refer to «Information»(ref-441373-S37450037442011121500000)

Select one of the following options

1. Return to the start of programming or read off the programmed values. Refer to «Information about programming the climate control module»(ref-441373-S37102607052011121500000) .
2. Exit programming and carry out damper motor self-adjustment (new climate control module). Refer to «Self-adjustment of damper motor end positions»(ref-441373-S32722550412011121500000) .
3. Exit the programming. Troubleshooting has been completed.

Note. Self-adjustment must be carried out if the control module or damper motor is replaced or the damper motor or its linkage has been removed. The indication LED on the climate control module panel will flash during adjustment.

HINT: During self-adjustment the control module runs the damper motors to their limit positions. The control module then stores the value returned from the position sensor for the damper motor. The control module is then able to operate the motor between the limit positions during normal operation.

1. Start the engine (the generator charges)
2. Activate self-adjustment. The self-adjustment takes thirty seconds. NOTE: Self-adjustment can only be carried out once in the same ignition cycle. To run the self-adjustment again, switch off the ignition, wait 10 seconds and start the engine again. The indication LED stops flashing when the self-adjustment is complete.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Wait at least three minutes so that the control module has time to carry out its diagnostic
5. Read off diagnostic trouble codes (DTCs). The fault has been remedied if the status of the diagnostic trouble code (DTC) has changed to intermittent.

Has the status of the diagnostic trouble code (DTC) changed to intermittent?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-441373-S41403320532011121500000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on. Activate reading off the programmed values. For information about the programmed values, see «Diagnostic functions, climate control module»(ref-441375-S30508182212011121500000) .

1. Continue Refer to «Programming the climate control module»(ref-441373-S41883889852011121500000)
