Climate Units - Component Location: Other Volvo V40 I рестайлинг

Data Link Connector (DLC)

On left of center console (Right-hand drive cars on right of center console)

Engine Compartment

1. Integrated relay/fusebox 11/A
2. Pressure switch
3. Receiver/Drier
4. Condenser
5. Condenser fan
6. Compressor

Climate Control Unit

1. Air distribution damper motor
2. Temperature damper motor
3. Recirculation damper motor
4. Blower fan power unit
5. Blower fan relay
6. Blower fan

Scheme 474

1. Evaporator temperature sensor
2. Engine coolant temperature sensor
3. Outside temperature sensor
4. Evaporator

Pollen Filter

1. Pollen filter

Scheme 475

Location in the car

The heater is located inside the front fender, in front of the front left wheel arch.

The timer is located in the center console inside the passenger compartment or in the glove compartment (only for parking heater function).

Scheme 476

Components

1. Control module
2. Fan shroud
3. Heat exchanger
4. Fuel pump (FP)
5. Water pump
6. Outer temperature sensor

Scheme 477

1. Coolant temperature sensor
2. Flame sensor
3. Overheat protection thermostat
4. Outer temperature sensor
5. Glow plug

Scheme 478

The timer only when the car is equipped with parking heater function.
