Checking components and connectors
Check the engine control module (ECM) connector. Check for contact resistance and oxidation.
Check for air leakage in the intake system.
HINT: The fault may be due to a defective engine control module (ECM). The engine control module (ECM) may be defective if the above fault tracing and corrective action does not remedy the fault.
Remedy as necessary.
Other information
- To access or replace the engine control module (ECM), see «Engine control module (ECM), replacing»(ref-440263-S40872388582011121400000)
- To check for air leakage, see «Check for air leaks in the intake system»(ref-440264-S10239834622011121400000)
- See «Contents»(ref-440209-S18666729612011121400000)
Scheme 44
Scheme 45
- Continue Refer to «Information»(ref-440262-S10047401422011121400000)
Fault-tracing information
In case of this defect, troubleshooting is not followed by verification.
The information can be displayed again or the fault-tracing for this fault can be interrupted.
Control module previously registered a fault. The fault is now no longer present.
Scheme 46
- Continue Refer to «Information»(ref-440262-S24038711742011121400000)
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
In case of this defect, troubleshooting is not followed by verification.
The information can be displayed again or the fault-tracing for this fault can be interrupted.
Signal too high/signal too low. Intermittent fault
See Signal too high/signal too low. Intermittent fault
See Signal too high/signal too low. Intermittent fault
See Signal too high/signal too low. Intermittent fault
See Signal too high/signal too low. Intermittent fault
See Signal too high/signal too low. Intermittent fault
Signal too high/signal too low. Permanent fault
See Signal too high/signal too low. Permanent fault
See Signal too high/signal too low. Permanent fault
See Signal too high/signal too low. Permanent fault
See Signal too high/signal too low. Permanent fault
See Signal too high/signal too low. Permanent fault
Check the connector for the outside temperature sensor. Check for contact resistance and oxidation.
The sensor may be defective if the above fault tracing and corrective action does not remedy the fault.
Remedy as necessary.
Other information
- To access and replace the outside temperature sensor for other models, see «Outside temperature sensor door mirror, replacing»(ref-461638-S05762406572012040200000)
- See «Contents»(ref-440209-S18666729612011121400000) .
Scheme 47
- Continue Refer to «Verification»(ref-440262-S14720636572011121400000)
Verification
HINT: After carrying out the repair, check that the fault has been remedied.
Scheme 48
Scheme 49
Scheme 50
- Ignition off.
- Reconnect connectors, reinstall components.
- Ignition on.
- Read off outside temperature.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S39061016272011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Faulty signal
See Faulty signal
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect connectors, reinstall components.
- Ignition on.
- Read off outside temperature.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S41916073942011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Signal too high
See Signal too high
Checking cables and connectors
Check signal cable between control module #B29 (#B39) and outside temperature sensor #1 for an intermittent short-circuit to ground according to Short-circuit to ground, intermittent faults
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
- To access/replace the outside temperature sensor, see «Outside temperature sensor door mirror, replacing»(ref-461638-S05762406572012040200000) .
- For information about signals on 5-cyl engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
- For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
- Continue Refer to «Information»(ref-440262-S29297142252011121400000)
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
Signal too high. Intermittent fault
See Signal too high. Intermittent fault
See Signal too high. Intermittent fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect connectors, reinstall components.
- Ignition on.
- Read off outside temperature.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S11057903892011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Signal too high. Permanent fault
See Signal too high. Permanent fault
See Signal too high. Permanent fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect connectors, reinstall components.
- Ignition on.
- Read off outside temperature.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S06592812412011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Signal too low
See Signal too low
Checking connector
- Ignition off
- Check wiring and connectors for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-461653-S26956869552012040200000) .
- Reinstall components, reconnect connectors etc.
- Ignition on.
- Read off outside temperature. If the temperature is now within its permitted range, the fault was caused by loose connections in the connector. Other information To access/replace the outside temperature sensor see «Outside temperature sensor door mirror, replacing»(ref-461638-S05762406572012040200000) .
Is the temperature within its permitted range?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Checking wiring and components»(ref-440262-S23546766572011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect connectors, reinstall components.
- Ignition on.
- Read off outside temperature.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S03027030842011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Signal too low. Permanent fault
See Signal too low. Permanent fault
See Signal too low. Permanent fault
Check outside temperature sensor connector for contact resistance and oxidation according to Contact resistance and oxidation and loose connections according to Loose connections (terminals)
Check signal cable between control module #B29 (#B39) and outside temperature #1 for an intermittent open-circuit according to Open-circuit, intermittent faults and an intermittent short-circuit to supply voltage according to Short-circuit to supply voltage, intermittent faults
Check ground lead between control module #B2 (#B12) and outside temperature sensor #2 for an intermittent open-circuit according to Open-circuit, intermittent faults
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
- To access/replace the outside temperature sensor, see «Outside temperature sensor door mirror, replacing»(ref-461638-S05762406572012040200000) .
- For information about signals on 5-cyl engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
- For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
- Continue Refer to «Information»(ref-440262-S06083100802011121400000)
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
Signal too low. Intermittent fault
See Signal too low. Intermittent fault
See Signal too low. Intermittent fault
Replacing the component
The engine control module (ECM) has registered an internal fault.
If the fault is intermittent, it has been registered previously but is no longer present. Intermittent faults can be caused by interference at start up of the engine control module (ECM) or may be a different type of fault which occurs on different occasions. The fault is evaluated depending on how it occurs. Replace the engine control module (ECM) if the fault recurs.
Replace the engine control module (ECM) in the event of a permanent fault.
See Engine control module (ECM), replacing
Remedy as necessary.
- Continue Refer to «Information»(ref-440262-S29729158922011121400000)
In case of this defect, troubleshooting is not followed by verification.
The information can be displayed again or the fault-tracing for this fault can be interrupted.
Internal fault
See Internal fault
See Internal fault
See Internal fault
See Internal fault
See Internal fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Ignition on
- Read off the intake air temperature (IAT).
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S07686182432011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too high
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
Check signal cable between control module #A5 (#A5) and mass air flow (MAF) sensor connector terminal 1 for an intermittent short-circuit to ground according to Short-circuit to ground, intermittent faults . The Intake Air Temperature (IAT) sensor is integrated into the Mass Air Flow (MAF) sensor
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
- To access/replace the Mass Air Flow (MAF) sensor, see «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
- For information about signals on 5-cyl engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
- For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
Scheme 51
- Continue Refer to «Information»(ref-440262-S09907545362011121400000)
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
See Signal too high. Intermittent fault
See Signal too high. Intermittent fault
See Signal too high. Intermittent fault
See Signal too high. Intermittent fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect connectors, reinstall components
- Ignition on.
- Read off the intake air temperature (IAT). The Intake Air Temperature (IAT) sensor is integrated into the Mass Air Flow (MAF) sensor.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S14965687392011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect the connectors, reinstall components etc.
- Ignition on.
- Read off Intake Air Temperature (IAT) sensor signal. The Intake Air Temperature (IAT) sensor is integrated into the Mass Air Flow (MAF) sensor. Check that the signal is OK according to the table value: see «Intake Air Temperature (IAT) sensor inlet»(ref-440262-S37230115192012032800000)
Is the signal OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S39131247042011121400000) Refer to «Information»(ref-440262-S39131247042011121400000)
Intake Air Temperature (IAT) sensor inlet
| Temperature, °C | Resistance ohms | Voltage, V |
|---|---|---|
| 0 | 6000 | 1.55 |
| 10 | 4000 | 2.01 |
| 20 | 2450 | 2.62 |
| 25 | 2000 | 2.13 |
| 30 | 1800 | 2.00 |
Intake air temperature (IAT) sensor inlet
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too high. Permanent fault
See Signal too high. Permanent fault
See Signal too high. Permanent fault
See Signal too high. Permanent fault
Checking the connector
- Ignition off
- Check the boost pressure sensor connector. Check for contact resistance and oxidation. NOTE: The intake air temperature (IAT) sensor is integrated in the boost pressure sensor
- Reinstall the components, reconnect the connectors etc.
- Ignition on
- Read off the intake air temperature (IAT). Check that the intake air temperature (IAT) is within its permitted range. If the intake air temperature (IAT) is now within its permitted range, the fault was caused by loose connections in the connector. Other information: To access or replace the intake air temperature (IAT) sensor, see «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000) .
Is the temperature within its permitted range?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Checking the wiring and component»(ref-440262-S17610780622011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Ignition on
- Read off the intake air temperature (IAT).
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S35504911472011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too low
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
Check Mass Air Flow (MAF) sensor connector for contact resistance and oxidation according to Contact resistance and oxidation and loose connections according to Loose connections (terminals) . The Intake Air Temperature (IAT) sensor is integrated into the Mass Air Flow (MAF) sensor.
Check signal cable between control module #A5 (#A5) and mass air flow (MAF) sensor connector #1 for an intermittent open-circuit according to Open-circuit, intermittent faults and an intermittent short-circuit to supply voltage according to Short-circuit to supply voltage, intermittent faults
Check ground lead between control module #A58 (#A58) and Mass Air Flow (MAF) sensor connector #3 for an intermittent open-circuit according to Open-circuit, intermittent faults
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
- To access/replace the Mass Air Flow (MAF) sensor, see «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
- For information about signals on 5-cyl engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
- For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
- Continue Refer to «Information»(ref-440262-S29502144242011121400000)
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
See Signal too low. Intermittent fault
See Signal too low. Intermittent fault
See Signal too low. Intermittent fault
See Signal too low. Intermittent fault
- Ignition off
- Check the intake air temperature (IAT) sensor connector. Check for contact resistance and oxidation
- Reinstall the components, reconnect the connectors etc.
- Ignition on
- Read off the signal from the intake air temperature (IAT) sensor. Check that the signal is within its permitted range. The voltage may vary between 0.17 V and 4.9 V depending on the air temperature. At 20 °C voltage should be approximately 3.5 V. If the signal is now OK, the fault was caused by poor contact in the connector. Other information To access or replace the intake air temperature (IAT) sensor, see «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000) See «Contents»(ref-440209-S18666729612011121400000) .
Is the signal OK?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Checking the wiring and component»(ref-440262-S16912567252011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect connectors, reinstall components
- Ignition on.
- Read off the intake air temperature (IAT). The Intake Air Temperature (IAT) sensor is integrated into the Mass Air Flow (MAF) sensor.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S22653676222011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
- Ignition off.
- Check Mass Air Flow (MAF) sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-461653-S26956869552012040200000) . The Intake Air Temperature (IAT) sensor is integrated into the Mass Air Flow (MAF) sensor.
- Reinstall components, reconnect connectors etc.
- Ignition on.
- Read off the intake air temperature (IAT). If the temperature is now within its permitted range, the fault was caused by loose connections in the connector. Other information To access/replace the Mass Air Flow (MAF) sensor, see «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
Is the signal OK?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Checking wiring and components»(ref-440262-S31060750642011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect the connectors, reinstall components etc.
- Ignition on.
- Read off Intake Air Temperature (IAT) sensor signal. The Intake Air Temperature (IAT) sensor is integrated into the Mass Air Flow (MAF) sensor. Check that the signal is OK according to the table value: see «Intake Air Temperature (IAT) sensor inlet»(ref-440262-S03398544792012032800000) .
Is the signal OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S41151537412011121400000)
| Temperature, °C | Resistance ohms | Voltage, V |
|---|---|---|
| 0 | 6000 | 1.55 |
| 10 | 4000 | 2.01 |
| 20 | 2450 | 2.62 |
| 25 | 2000 | 2.13 |
| 30 | 1800 | 2.00 |
Intake air temperature (IAT) sensor inlet
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too low. Permanent fault
See Signal too low. Permanent fault
See Signal too low. Permanent fault
See Signal too low. Permanent fault
- Ignition off
- Check the boost pressure sensor connector and terminal. Check for contact resistance and oxidation. NOTE: The intake air temperature (IAT) sensor is integrated in the boost pressure sensor. If no errors are found and the fault is permanent, replace the intake air temperature (IAT) sensor. Remedy as necessary. Other information: See «Contents»(ref-440209-S18666729612011121400000) For resistance values, see «Component specifications»(ref-461750-S34427939622012040200000) To access or replace the intake air temperature (IAT) sensor, see «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000) .
- Continue Refer to «Verification»(ref-440262-S21086138452011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
Scheme 52
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Start the engine. Allow the engine to idle for 5 minutes
- Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.
Is the status of the diagnostic trouble code (DTC) intermittent?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S42346774482011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
- Ignition off
- Check the mass air flow (MAF) sensor connector and terminal. Check for contact resistance and oxidation. NOTE: The intake air temperature (IAT) sensor is integrated in the mass air flow (MAF) sensor. Remedy as necessary. If no faults are found and the fault returns as a permanent fault, replace the intake air temperature (IAT) sensor. Other information See «Contents»(ref-440209-S18666729612011121400000) For resistance values, see «Component specifications»(ref-461750-S34427939622012040200000) To access or replace the mass air flow (MAF) sensor. See «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
- Continue Refer to «Verification»(ref-440262-S27115894542011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Start the engine. Allow the engine to idle for 5 minutes
- Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.
Is the status of the diagnostic trouble code (DTC) intermittent?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S03016443882011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Faulty signal
Checking the intake system
Check the mass air flow (MAF) sensor connector. Check for contact resistance and oxidation.
Check the intake system for leakage. In particular, check the hoses and hose connectors between the mass air flow (MAF) sensor and the throttle unit. Check for leakage and damage.
Check the inside of the throttle body (TB). Check for contamination. When the throttle body (TB) is contaminated, the air flow to the engine is impaired and diagnostic trouble code (DTCs) or fault symptoms can occur.
Clean the throttle body (TB) if needed.
If no fault is found, try a new mass air flow (MAF) sensor.
Remedy as necessary.
Other information
- See «Air leakage in the intake system, checking»(ref-440268-S25463484082011121400000)
- See «Throttle body (TB), cleaning»(ref-440268-S03142937152011121400000)
- See «Mass air flow (MAF) sensor, replacing»(ref-440269-S11593902572011121400000)
- See «Contents»(ref-440209-S18666729612011121400000)
- Continue Refer to «Verification»(ref-440262-S09785483302011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reinstall the connectors, components etc.
- Ignition on.
- Read off and make a note of the adaptation value.
- Start the engine. Increase the engine speed (RPM) a couple of times.
- Read off the adaptation value and check that the adaptation value approaches 1.
Does the adaptation value approach 1?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S28307643462011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Check the mass air flow (MAF) sensor connector. Check for contact resistance and oxidation.
Check the intake system for leakage. In particular, check the hoses and hose connectors between the mass air flow (MAF) sensor and the throttle unit. Check for leakage and damage.
Check the inside of the throttle body (TB). Check for contamination. When the throttle body (TB) is contaminated, the air flow to the engine is impaired and diagnostic trouble code (DTCs) or fault symptoms can occur.
Clean the throttle body (TB) if needed.
If no fault is found, try a new mass air flow (MAF) sensor.
Remedy as necessary.
Other information
- See «Air leakage in the intake system, checking»(ref-440268-S25463484082011121400000)
- See «Throttle body, cleaning»(ref-440268-S26570711832011121400000)
- See «Mass air flow (MAF) sensor, replacing»(ref-440269-S11593902572011121400000)
- See «Contents»(ref-440209-S18666729612011121400000)
- Continue Refer to «Verification»(ref-440262-S15601732742011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reinstall the connectors, components etc.
- Ignition on.
- Read off and make a note of the adaptation value.
- Start the engine. Increase the engine speed (RPM) a couple of times.
- Read off the adaptation value and check that the adaptation value approaches 1.
Does the adaptation value approach 1?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S38939394822011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Check the mass air flow (MAF) sensor connector. Check for contact resistance and oxidation.
Check the induction system for air leaks. In particular, check the hoses and hose connectors between the mass air flow (MAF) sensor and the throttle unit. Check for leakage and damage.
Check the inside of the throttle body (TB). Check for contamination. When the throttle body (TB) is contaminated, the air flow to the engine is impaired and diagnostic trouble code (DTCs) or fault symptoms can occur. Clean the throttle body (TB) if needed.
Remedy as necessary.
Other information
- See «Air leakage in the intake system, checking»(ref-440268-S25463484082011121400000)
- See «Throttle body (TB), cleaning»(ref-440268-S03142937152011121400000)
- See «Mass air flow (MAF) sensor, replacing»(ref-440269-S11593902572011121400000)
- See «Contents»(ref-440209-S18666729612011121400000)
- Continue Refer to «Verification»(ref-440262-S30585449852011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reinstall the connectors, components etc.
- Ignition on.
- Read off and make a note of the adaptation value.
- Start the engine. Increase the engine speed (RPM) a couple of times.
- Read off the adaptation value and check that the adaptation value approaches 1.
Does the adaptation value approach 1?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S39264539172011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Check the mass air flow (MAF) sensor connector. Check for contact resistance and oxidation.
Check the induction system for air leaks. In particular, check the hoses and hose connectors between the mass air flow (MAF) sensor and the throttle unit. Check for leakage and damage.
Check the inside of the throttle body (TB). Check for contamination. When the throttle body (TB) is contaminated, the air flow to the engine is impaired and diagnostic trouble code (DTCs) or fault symptoms can occur. Clean the throttle body (TB) if needed.
Remedy as necessary.
Other information
- See «Air leakage in the intake system, checking»(ref-440268-S25463484082011121400000)
- See «Throttle body, cleaning»(ref-440268-S26570711832011121400000)
- See «Mass air flow (MAF) sensor, replacing»(ref-440269-S11593902572011121400000)
- See «Contents»(ref-440209-S18666729612011121400000)
- Continue Refer to «Verification»(ref-440262-S02353359582011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reinstall the connectors, components etc.
- Ignition on.
- Read off and make a note of the adaptation value.
- Start the engine. Increase the engine speed (RPM) a couple of times.
- Read off the adaptation value and check that the adaptation value approaches 1.
Does the adaptation value approach 1?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S38375995032011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Flow too low or too high
See Flow too low or too high
See Flow too low or too high
See Flow too low or too high
See Flow too low or too high
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Check that the air flow is correct. The value must be approximately 0 kg/h with the engine switched off
- Start the engine. Read off the air flow. The value may vary by between 12-20 kg/h at idle speed, depending on the engine load and temperature. The value may be in excess of 20 kg/h if the engine is cold
- Increase the engine speed (RPM) and check that the air flow increases with increased engine speed.
Are the values correct?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S37171920722011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Check that the air flow is correct. The value must be approximately 0 kg/h with the engine switched off
- Start the engine. Read off the air flow. The value may vary by between 12-20 kg/h at idle speed, depending on the engine load and temperature. The value may be in excess of 20 kg/h if the engine is cold
- Increase the engine speed (RPM) and check that the air flow increases with increased engine speed.
Are the values correct?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S00983895942011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Read off the boost pressure sensor pressure and atmospheric pressure sensor pressure
- The difference between the pressure sensors should not be greater than 140 hPa.
Is the difference between the pressure sensors less than 140 hPa?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S18767000082011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Read off the boost pressure sensor pressure and atmospheric pressure sensor pressure
- The difference between the pressure sensors should not be greater than 140 hPa.
Is the difference between the pressure sensors less than 140 hPa?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S06535999532011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Read off the boost pressure sensor pressure and atmospheric pressure sensor pressure
- The difference between the pressure sensors should not be greater than 140 hPa.
Is the difference between the pressure sensors less than 140 hPa?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S09603543872011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Read off the boost pressure sensor pressure and atmospheric pressure sensor pressure
- The difference between the pressure sensors should not be greater than 140 hPa.
Is the difference between the pressure sensors less than 140 hPa?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S20293303182011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too high
Signal too low / signal too high
See Signal too low / signal too high
Check signal cable between engine control module (ECM) #A22 (#A22) and mass air flow (MAF) sensor #5 for an intermittent short-circuit to supply voltage according to Short-circuit to supply voltage, intermittent faults .
Check power supply cable between engine control module (ECM) #A58 (#A58) and mass air flow (MAF) sensor #3 for an intermittent open-circuit according to Open-circuit, intermittent faults
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
- To access/replace the Mass Air Flow (MAF) sensor, see «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
- With the ignition on and mass air flow (MAF) sensor connector connected the voltage at mass air flow (MAF) sensor #2 should be approximately U bat , mass air flow (MAF) sensor #3 should be ground and mass air flow (MAF) sensor #5 should be approximately 1 volt.
- For information about signals on 5-cyl engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
- For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
- Continue Refer to «Information»(ref-440262-S18009503762011121400000)
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
Flow too high. Intermittent fault
See Flow too high. Intermittent fault
See Flow too high. Intermittent fault
See Flow too high. Intermittent fault
See Flow too high. Intermittent fault
Checking cables
Check the cable between engine control module (ECM) #A22 (#A22) and mass air flow (MAF) sensor #5 for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .
Check the ground lead between #A58 (#A58) and mass air flow (MAF) sensor #3 for an open-circuit according to Open-circuit, permanent faults
Remedy as necessary
Other information
- Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
- To access/replace the Mass Air Flow (MAF) sensor, see «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
- With the ignition on and the mass air flow (MAF) sensor connector connected the voltage at mass air flow (MAF) sensor #2 should be approximately U batt , mass air flow (MAF) sensor #3 should be ground and mass air flow (MAF) sensor #5 should be approximately 1 V.
- For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
- For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
- Continue Refer to «Verification»(ref-440262-S15462533492011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Check that the air flow is correct. The value must be approximately 0 kg/h with the engine switched off
- Start the engine. Read off the air flow. The value may vary by between 12-20 kg/h at idle speed, depending on the engine load and temperature. The value may be in excess of 20 kg/h if the engine is cold
- Increase the engine speed (RPM) and check that the air flow increases with increased engine speed.
Are the values correct?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S22707414532011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Flow too high. Permanent fault
See Flow too high. Permanent fault
See Flow too high. Permanent fault
See Flow too high. Permanent fault
See Flow too high. Permanent fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Check that the air flow is correct. The value must be approximately 0 kg/h with the engine switched off
- Start the engine. Read off the air flow. The value may vary by between 12-20 kg/h at idle speed, depending on the engine load and temperature. The value may be in excess of 20 kg/h if the engine is cold
- Increase the engine speed (RPM) and check that the air flow increases with increased engine speed.
Are the values correct?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S12563147842011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
Flow too low. Intermittent fault
See Flow too low. Intermittent fault
Flow too low
See Flow too low
See Flow too low. Intermittent fault
See Flow too low
- Ignition off
- Check mass air flow (MAF) sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-461653-S26956869552012040200000) .
- Reinstall components, reconnect connectors etc.
- Ignition on.
- Check that the air flow corresponds, the value should be approximately 0 kg/h with engine switched off.
- Start the engine and read off the air flow which should be approximately 14 kg/h (30.9 lb) when idling.
- Increase the engine speed (RPM) and check that the air flow increases with increased engine speed. If the values correspond it means that the cause of the fault has been loose connections in the connector. Other information To access/replace the mass air flow (MAF) sensor, see «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
Is the function OK?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Checking component and wiring»(ref-440262-S15940958382011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Check that the air flow is correct. The value must be approximately 0 kg/h with the engine switched off
- Start the engine. Read off the air flow. The value may vary by between 12-20 kg/h at idle speed, depending on the engine load and temperature. The value may be in excess of 20 kg/h if the engine is cold
- Increase the engine speed (RPM) and check that the air flow increases with increased engine speed.
Are the values correct?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S23021893282011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Flow too low. Permanent fault
See Flow too low. Permanent fault
See Flow too low
See Flow too low. Permanent fault
Checking components, intake system
Check using information about combined diagnostic trouble codes if this trouble code is a root problem or not. If the diagnostic trouble code is stored as lone diagnostic trouble code or if it is indicated as a root problem, continue with the troubleshooting below, otherwise follow troubleshooting for the diagnostic trouble code pointed out as root problem.
ECM-130A can be generated due to a damaged mass air flow sensor. An indication of this is that the engine control system has increased the fuel amount at partial load and then primarily the value for "Lambda adaption, upper partial load". If any of the diagnostic trouble codes ECM-260A, ECM-261A, ECM-270A and/or ECM-271A with trouble type Upper limit is stored together with ECM-130A, troubleshoot according to any of these diagnostic trouble codes, otherwise continue according to the following.
Read off "Air mass, correction value" and check in which way the air adaption has gone. A low value, less than approx. 0.85 indicates a clogged crankcase ventilation and/or dirty throttle module. A higher value, greater than approximately 1.15, indicates a (smaller) air leak somewhere in the intake system.
High value
Check the induction system for air leaks.
Check that the intake air temperature (IAT) sensor and boost pressure sensor are correctly installed. Check for air leakage around the components.
Note. Even extremely small air leaks can cause this diagnostic trouble code (DTC) to be stored.
Low value
For markets where upgraded software, released during year 2006 or later, is available, then if ECM-91A7 and/or ECM-91B7 is stored together with ECM-130A, then the throttle module shall be cleaned.
Otherwise, the solution to the diagnostic trouble code/symptom is to load the upgraded software in the vehicle.
For markets where upgraded software, released during year 2006 or later, is not available, the solution is to clean the throttle module and the crankcase ventilation.
See Identifying upgraded software ECM/ETM
Remedy as necessary.
Other information
- See «Information about combined diagnostic trouble codes (DTCs)»(ref-461763-S38970835512012040200000)
- See «Air leakage in the intake system, checking»(ref-440268-S25463484082011121400000)
- See «Throttle body (TB), cleaning»(ref-461751-S10631308792012040200000)
- See «Mass air flow (MAF) sensor, replacing»(ref-440269-S11593902572011121400000)
| CAUTION | In order for Electronic throttle module (ETM) to reset any reconfigurations as well as delete internally stored problems, the following must be performed: Turn off the ignition and then wait three minutes for the main relay or system relay to release the voltage feed to, among others, Electronic throttle module (ETM). Wait another three minutes, but if the electric cooling fan is running you have to wait another two minutes after the cooling fan has stopped, to ensure that Electronic throttle module (ETM) is shut off correctly. If this is not done correctly, diagnostic trouble codes may remain even after deleting diagnostic trouble codes and any reconfiguration may remain, despite the problem being fixed. |
- Continue Refer to «Information»(ref-440262-S42239872862011121400000)
In case of this defect, troubleshooting is not followed by verification.
The information can be displayed again or the fault-tracing for this fault can be interrupted.
Check using information about combined diagnostic trouble codes if this trouble code is a root problem or not. If the diagnostic trouble code is stored as lone diagnostic trouble code or if it is indicated as a root problem, continue with the troubleshooting below, otherwise follow troubleshooting for the diagnostic trouble code pointed out as root problem.
ECM-130A can be generated due to a damaged mass air flow sensor. An indication of this is that the engine control system has increased the fuel amount at partial load and then primarily the value for "Lambda adaption, upper partial load". If any of the diagnostic trouble codes ECM-260A, ECM-261A, ECM-270A and/or ECM-271A with trouble type Upper limit is stored together with ECM-130A, troubleshoot according to any of these diagnostic trouble codes, otherwise continue according to the following.
Read off "Air mass, correction value" and check in which way the air adaption has gone. A low value, less than approx. 0.85 indicates a clogged crankcase ventilation and/or dirty throttle module. A higher value, greater than approximately 1.15, indicates a (smaller) air leak somewhere in the intake system.
High value
Check the induction system for air leaks.
Check that the intake air temperature (IAT) sensor and boost pressure sensor are correctly installed. Check for air leakage around the components.
Note. Even extremely small air leaks can cause this diagnostic trouble code (DTC) to be stored.
Low value
For markets where upgraded software, released during year 2006 or later, is available, then if ECM-91A7 and/or ECM-91B7 is stored together with ECM-130A, then the throttle module shall be cleaned.
Otherwise, the solution to the diagnostic trouble code/symptom is to load the upgraded software in the vehicle.
For markets where upgraded software, released during year 2006 or later, is not available, the solution is to clean the throttle module and the crankcase ventilation.
See Identifying upgraded software ECM/ETM
Remedy as necessary.
Other information
- See «Information about combined diagnostic trouble codes (DTCs)»(ref-461763-S38970835512012040200000)
- See «Air leakage in the intake system, checking»(ref-440268-S00922598552011121400000)
- See «Throttle body (TB), cleaning»(ref-461751-S10631308792012040200000)
- See «Mass air flow (MAF) sensor, replacing»(ref-440269-S11593902572011121400000)
| CAUTION | In order for Electronic throttle module (ETM) to reset any reconfigurations as well as delete internally stored problems, the following must be performed: Turn off the ignition and then wait three minutes for the main relay or system relay to release the voltage feed to, among others, Electronic throttle module (ETM). Wait another three minutes, but if the electric cooling fan is running you have to wait another two minutes after the cooling fan has stopped, to ensure that Electronic throttle module (ETM) is shut off correctly. If this is not done correctly, diagnostic trouble codes may remain even after deleting diagnostic trouble codes and any reconfiguration may remain, despite the problem being fixed. |
- Continue Refer to «Information»(ref-440262-S16200217132011121400000)
In case of this defect, troubleshooting is not followed by verification.
The information can be displayed again or the fault-tracing for this fault can be interrupted.
HINT: This diagnostic trouble code can be caused by a damaged mass air flow sensor.
Check that lambda adaptations are within the specified normal values.
Incorrect lambda adaptations can indicate a faulty mass air flow (MAF) sensor.
HINT: Use the adaptations for the mass air flow (MAF) sensor and leak flow (parameter read out) to determine how much the system has adapted.
An adaptation on one or both parameters that is less than approximately 0.85 indicates blocked crankcase ventilation and/or a dirty electronic throttle module (ETM).
Adaptations greater than approximately 1.15 indicate a (smaller) air leak somewhere in the intake system.
Note. Even extremely small air leaks can cause this diagnostic trouble code (DTC) to be stored.
Check that the intake air temperature (IAT) sensor and boost pressure sensor are correctly installed. Check for air leakage around the components.
Check the crankcase ventilation for blockage. In particular check the positive crankcase ventilation (PCV) valve on turbocharged engines.
HINT: Indications of a blocked positive crankcase ventilation (PCV) valve include contamination or oil on components in the intake system.
Remedy as necessary.
Other information
- See «Information about combined diagnostic trouble codes (DTCs)»(ref-461763-S38970835512012040200000)
- See «Air leakage in the intake system, checking»(ref-440268-S00922598552011121400000)
- See «Throttle body (TB), cleaning»(ref-461751-S10631308792012040200000)
- See «Mass air flow (MAF) sensor, replacing»(ref-440269-S11593902572011121400000)
- Continue Refer to «Verification»(ref-440262-S07738385422011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reinstall the connectors, components etc.
- Ignition on.
- Read off and make a note of the adaptation value.
- Start the engine. Increase the engine speed (RPM) a couple of times.
- Read off the adaptation value and check that the adaptation value approaches 1.
Does the adaptation value approach 1?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S19803718252011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: This diagnostic trouble code can be caused by a damaged mass air flow sensor.
Check that lambda adaptations are within the specified normal values.
Incorrect lambda adaptations can indicate a faulty mass air flow (MAF) sensor.
HINT: Use the adaptations for the mass air flow (MAF) sensor and leak flow (parameter read out) to determine how much the system has adapted.
An adaptation on one or both parameters that is less than approximately 0.85 indicates blocked crankcase ventilation and/or a dirty electronic throttle module (ETM).
Adaptations greater than approximately 1.15 indicate a (smaller) air leak somewhere in the intake system.
Note. Even extremely small air leaks can cause this diagnostic trouble code (DTC) to be stored.
Check that the intake air temperature (IAT) sensor and boost pressure sensor are correctly installed. Check for air leakage around the components.
Check the crankcase ventilation for blockage. In particular check the positive crankcase ventilation (PCV) valve on turbocharged engines.
HINT: Indications of a blocked positive crankcase ventilation (PCV) valve include contamination or oil on components in the intake system.
Remedy as necessary.
Other information
- See «Information about combined diagnostic trouble codes (DTCs)»(ref-461763-S38970835512012040200000)
- See «Air leakage in the intake system, checking»(ref-440268-S25463484082011121400000)
- See «Throttle body (TB), cleaning»(ref-461751-S10631308792012040200000)
- See «Mass air flow (MAF) sensor, replacing»(ref-440269-S11593902572011121400000)
- Continue Refer to «Verification»(ref-440262-S13652702142011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reinstall the connectors, components etc.
- Ignition on.
- Read off and make a note of the adaptation value.
- Start the engine. Increase the engine speed (RPM) a couple of times.
- Read off the adaptation value and check that the adaptation value approaches 1.
Does the adaptation value approach 1?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S00048740462011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Check that the hoses and hose connectors between the mass air flow (MAF) sensor and the throttle unit are not leaking or defective.
Check that the boost pressure sensor is correctly mounted. Check for air leakage around the component.
HINT: This diagnostic trouble code can be caused by a damaged mass air flow sensor.
Remedy as necessary.
Other information
- See «Check for air leaks in the intake system»(ref-440264-S10239834622011121400000)
- See «Throttle body (TB), cleaning»(ref-461751-S10631308792012040200000)
- See «Mass air flow (MAF) sensor, replacing»(ref-440269-S11593902572011121400000)
- Continue Refer to «Verification»(ref-440262-S40844416392011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reinstall the connectors, components etc.
- Ignition on.
- Read off and make a note of the adaptation value.
- Start the engine. Increase the engine speed (RPM) a couple of times.
- Read off the adaptation value and check that the adaptation value approaches 1.
Does the adaptation value approach 1?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S39365924912011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Faulty signal
See Signal too high
See Signal too low
See Faulty signal
- Ignition off
- Check the boost pressure sensor connector and terminal. Check for contact resistance and oxidation. NOTE: The intake air temperature (IAT) sensor is integrated in the boost pressure sensor. If no errors are found and the fault is permanent, replace the intake air temperature (IAT) sensor. Remedy as necessary. Other information: See «Contents»(ref-440209-S18666729612011121400000) For resistance values: «Component specifications»(ref-461750-S34427939622012040200000) See «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000)
- Continue Refer to «Verification»(ref-440262-S12195372882011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Start the engine. Allow the engine to idle for 5 minutes
- Read off diagnostic trouble codes (DTCs). The fault has been remedied if status of the diagnostic trouble code (DTC) is intermittent.
Is the status of the diagnostic trouble code (DTC) intermittent?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S03402992012011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Signal too high / Signal too low
See Signal too high / Signal too low
Checking the status
Check whether the fault is permanent or intermittent by reading the signals from the fuel, outside and engine temperature sensors.
Note. In order for the correct values to be shown, reading of the temperatures must take place at the moment of start.
- Start the engine.
Check that the intake temperature is reasonable. The temperature must correspond to the ambient temperature.
The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.
HINT: Remove the air temperature sensor, but let the connector remain connected. Let the hood remain open, the sensor should then indicate the same temperature as the outdoor temperature.
- Continue Refer to «Checking the component and wiring»(ref-440262-S01277580652011121400000)
Scheme 53
Scheme 54
- Ignition off.
- Unplug the air temperature sensor connectors.
- Check the connectors. Check for loose connections. Check for contact resistance. Check for oxidation. Check the resistance of the sensor between #1 and #2 (to the sensor). Remedy as necessary. Other information See «Connecting the breakout box»(ref-440211-S03702023042011121400000) See «Signal specification»(ref-440214-S33124753252011121400000) See «Component specifications»(ref-461750-S34427939622012040200000) See «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000) See «Checking wiring and terminals»(ref-440209-S33835172972011121400000)
- Continue Refer to «Verification»(ref-440262-S27595127012011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Ignition on. Read off the air temperature sensor signal. Check that the signal is plausible, compare with the external temperature.
Is the value OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S02715549342011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Fault-tracing
See Fault-tracing
See Signal too high
See Signal too low
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect connectors, reinstall components.
- Ignition on.
- Read off outside temperature.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S26741868912011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Faulty signal or signal missing
See Faulty signal or signal missing
Information
No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is first stored in the Central electronic module (CEM), then in the Engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble codes (DTC) in the central electronic module (CEM) has been remedied and erased.
Therefore, first read off diagnostic trouble codes in Central electronic module (CEM), perform troubleshooting and perform actions as needed. This diagnostic trouble code (DTC) can then be erased.
For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.
See Fault-tracing information
There is no fault-tracing for this diagnostic fault code (DTC).
For further information on this diagnostic trouble code, see Diagnostic trouble code (DTC) information.
See Fault-tracing information
- Ignition off. Check the boost pressure sensor connector. Check for contact resistance and oxidation. Check that the boost pressure sensor is correctly installed and has not come loose. HINT: The fault may be due to a defective boost pressure sensor. The boost pressure sensor may be defective if the above fault tracing and corrective action does not remedy the fault. Remedy as necessary. Other information: To access or replace the boost pressure sensor, see «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000) See «Contents»(ref-440209-S18666729612011121400000) .
- Continue Refer to «Verification»(ref-440262-S15778712282011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
Scheme 55
- Reinstall the connectors, components etc.
- Test drive the car to reach different boost pressures
- Read off the diagnostic status and the fault status for diagnostic trouble code (DTC) ECM-1600. NOTE: Do not switch off the engine before VCT2000 has been connected and the status of the fault has been read off. Check that the fault status is "NO FAULT FOUND" when the diagnostic status is COMPLETED. If the fault status is "FAULT FOUND" when the diagnostic status is COMPLETED there is a fault.
Is the fault status "NO FAULT FOUND"?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S00961092382011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Check the boost pressure sensor connector. Check for contact resistance and oxidation.
Check that the boost pressure sensor is correctly installed and has not come loose.
HINT: The fault may also be caused by a defective boost pressure sensor. The boost pressure sensor may be defective if the above fault tracing and corrective action does not remedy the fault.
Remedy as necessary.
Other information
- To access or replace the boost pressure sensor, see «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000)
- See «Contents»(ref-440209-S18666729612011121400000) .
- Continue Refer to «Verification»(ref-440262-S14099515562011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Reinstall the connectors, components etc.
- Test drive the car to reach different boost pressures
- Read off the diagnostic status and the fault status for diagnostic trouble code (DTC) ECM-1600. NOTE: Do not switch off the engine before VCT2000 has been connected and the status of the fault has been read off. Check that the fault status is "NO FAULT FOUND" when the diagnostic status is COMPLETED. If the fault status is "FAULT FOUND" when the diagnostic status is COMPLETED there is a fault.
Is the fault status "NO FAULT FOUND"?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S12810582722011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Faulty signal
- Ignition off
- Check the boost pressure sensor connector. Check for contact resistance and oxidation
- Reinstall the components, reconnect the connectors etc.
- Ignition on
- Read off the boost pressure sensor signal. Check that the signal is within its permitted range. With the engine switched off, the voltage should be approximately 1.9 V. If the signal is now OK, the fault was caused by poor contact in the connector. Other information: To access or replace the boost pressure sensor, see «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000) See «Contents»(ref-440209-S18666729612011121400000) .
Is the signal OK?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Checking components and wiring»(ref-440262-S24537987042011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Read off the boost pressure sensor signal. With the ignition on the voltage should be approximately 1.9 V.
Is the signal OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S21138768582011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too high
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
See Signal too high. Intermittent fault
- Ignition off
- Check the boost pressure sensor connector. Check for contact resistance and oxidation
- Reinstall the components, reconnect the connectors etc.
- Ignition on
- Read off the boost pressure sensor signal. Check that the signal is within its permitted range. With the engine switched off, the voltage should be approximately 1.9 V. If the signal is now OK, the fault was caused by poor contact in the connector. Other information To access or replace the boost pressure sensor, see «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000) See «Contents»(ref-440209-S18666729612011121400000) .
Is the signal OK?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Checking components and wiring»(ref-440262-S20862280162011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect connectors, reinstall components
- Ignition on.
- Read off boost pressure sensor signal. With the ignition on voltage should be approximately 1.9 V.
Is the signal OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S10066736582011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too high. Permanent fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Read off the boost pressure sensor signal. With the ignition on the voltage should be approximately 1.9 V.
Is the signal OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S03974864072011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too low
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
See Signal too low. Intermittent fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off.
- Reconnect connectors, reinstall components
- Ignition on.
- Read off boost pressure sensor signal. With the ignition on voltage should be approximately 1.9 V.
Is the signal OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S22768342912011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too low. Permanent fault
- Ignition off
- Check the boost pressure sensor connector. Check for contact resistance and oxidation
- Reinstall the components, reconnect the connectors etc.
- Ignition on. Read off the boost pressure and the atmospheric pressure. The difference in pressure must not be greater than 140 hPa. If the difference is less than 140 hPa, the cause of the fault was loose connections in the connector. Other information: To access or replace the boost pressure sensor. See «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000) .
Is the difference between the pressures less than 140 hPa?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Replacing the component»(ref-440262-S33507139142011121400000)
If the difference between the pressures is greater than 140 hPa, try replacing the boost pressure sensor.
HINT: Normal atmospheric pressure is 1013 hPa. Check which of the sensors appears to display the incorrect reading.
If the fault is not in the boost pressure sensor, replace the engine control module (ECM).
Note. The atmospheric pressure sensor is built into the engine control module (ECM) and therefore cannot be replaced as a separate item.
| CAUTION | New engine control module (ECM)s (ECM) are supplied without software. The engine control module (ECM) must be programmed before it will function after replacement. |
Remedy as necessary.
Other information
- Normal atmospheric pressure is 1013 hPa
- To access or replace the boost pressure sensor, see «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000)
- To access or replace the engine control module (ECM), see «Engine control module (ECM), replacing»(ref-440263-S40872388582011121400000)
- For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
- For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
- Continue Refer to «Verification»(ref-440262-S10893006362011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Read off the boost pressure sensor pressure and atmospheric pressure sensor pressure
- The difference between the pressure sensors should not be greater than 140 hPa.
Is the difference between the pressure sensors less than 140 hPa?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S16206072712011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Faulty signal
Checking connectors
Check boost pressure sensor connector for intermittent contact resistance, oxidation according to Contact resistance and oxidation .
Other information
- To access/replace the boost pressure sensor, see «Manifold absolute pressure (MAP) sensor, replacing»(ref-461749-S06916815572012040200000) .
- To access/replace the engine control module (ECM), see «Engine control module (ECM), replacing»(ref-440263-S40872388582011121400000) .
- For information about signals on 5-cyl engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
- For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
- Continue Refer to «Information»(ref-440262-S38122051332011121400000)
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
Faulty signal. Intermittent fault
See Faulty signal. Intermittent fault
See Faulty signal. Intermittent fault
See Faulty signal. Intermittent fault
- Ignition off.
- Check boost pressure sensor connector for contact resistance and oxidation according to «Contact resistance and oxidation»(ref-461653-S26956869552012040200000) .
- Reinstall components, reconnect connectors etc.
- Ignition on.
- Read boost pressure and atmospheric pressure.
- The difference in pressure should not be greater than 140 hPa. If the difference is less than 140 hPa it means that the cause of the fault has been loose connections in the connector. Other information To access/replace the boost pressure sensor, see «Manifold absolute pressure (MAP) sensor, replacing»(ref-461749-S06916815572012040200000) .
Is the difference between the pressures less than 140 hPa?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Replacing component»(ref-440262-S34866869452011121400000)
Replacing component
If the difference between the pressures is greater than 140 hPa, try replacing the boost pressure sensor according to Manifold absolute pressure (MAP) sensor, replacing .
HINT: Normal atmospheric pressure is 1013 hPa. Check which of the sensors appears to display the incorrect reading.
If the fault is not in the boost pressure sensor, replace the engine control module (ECM) according to Engine control module (ECM), replacing .
Note. The atmospheric pressure sensor is built into the engine control module (ECM) and therefore cannot be replaced as a separate item.
| CAUTION | A new engine control module (ECM) is delivered without software. For the engine control module (ECM) to function after replacement the engine control module (ECM) must be programmed. |
Remedy as necessary.
Other information
- Normal atmospheric pressure is 1013 hPa.
- For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
- For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
- Continue Refer to «Verification»(ref-440262-S03818890972011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reinstall the connectors, components etc.
- Ignition on
- Read off the boost pressure sensor pressure and atmospheric pressure sensor pressure
- The difference between the pressure sensors should not be greater than 140 hPa.
Is the difference between the pressure sensors less than 140 hPa?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S14679536522011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Faulty signal. Permanent fault
See Faulty signal. Permanent fault
See Faulty signal. Permanent fault
See Faulty signal. Permanent fault
Checking the engine coolant temperature (ECT)
- Fault-tracing must begin with the engine cold (+20 °C) so that the engine coolant temperature (ECT) sensor can be tested over as wide a temperature range as possible
- Switch off the climate control system
- Start the engine. Read off the engine coolant temperature (ECT). Check that the engine coolant temperature (ECT) is within its permitted range and corresponds with the engine warming up.
Is the temperature reasonable?
- YES Refer to «Checking the thermostat»(ref-440262-S25173626422011121400000)
- NO Refer to «Replacing the component»(ref-440262-S00602267472011121400000)
Checking the thermostat
- Start the engine. Run the engine until the engine coolant temperature (ECT) reaches approximately 100 °C
- Activate the engine cooling fan (FC) with the engine running
- Wait approximately 90 seconds and then shut-off the engine cooling fan (FC). Read off the engine coolant temperature (ECT). If the temperature is 85 °C or lower when the fan stops, the thermostat is defective.
Is the temperature lower than 86 °C?
- YES Refer to «Replacing the component»(ref-440262-S14644011022011121400000)
- NO FAULT TRACING FAILED: The fault should have been detected and remedied. As this is not the case fault-tracing has failed. Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Try a new thermostat. See Thermostat, replacing .
Scheme 56
Try a new engine coolant temperature (ECT) sensor. See Temperature sensor engine coolant, replacing .
- Continue Refer to «Verification»(ref-440262-S37697009842011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Fault-tracing must begin with the engine cold (+20 °C) so that the engine coolant temperature (ECT) sensor can be tested over as wide a temperature range as possible
- Ignition off
- Reconnect connectors, reinstall components etc.
- Start the engine
- Read off the engine coolant temperature. Check that the engine coolant temperature (ECT) is within its permitted range and corresponds with the engine warming up.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S33939667752011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
See Faulty signal. Intermittent fault
See Faulty signal. Intermittent fault
See Faulty signal. Intermittent fault
- Start the engine. Run the engine until the engine coolant temperature (ECT) reaches approximately 100 °C
- Activate the engine cooling fan (FC) with the engine running
- Wait approximately 90 seconds and then shut-off the engine cooling fan (FC). Read off the engine coolant temperature (ECT). If it is 85 °C or lower when the fan stops, the thermostat is defective.
Is the temperature lower than 86 °C?
- YES Refer to «Replacing the component»(ref-440262-S27071070852011121400000)
- NO FAULT TRACING FAILED: The fault should have been detected and remedied. As this is not the case fault-tracing has failed. Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Try a new thermostat. See Thermostat, replacing .
Try a new engine coolant temperature (ECT) sensor. See Temperature sensor engine coolant, replacing .
- Continue Refer to «Verification»(ref-440262-S30973006812011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Fault-tracing must begin with the engine cold (+20 °C) so that the engine coolant temperature (ECT) sensor can be tested over as wide a temperature range as possible
- Ignition off
- Reconnect connectors, reinstall components etc.
- Start the engine
- Read off the engine coolant temperature. Check that the engine coolant temperature (ECT) is within its permitted range and corresponds with the engine warming up.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S30673168892011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Faulty signal. Permanent fault
See Faulty signal. Permanent fault
See Faulty signal. Permanent fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect connectors, reinstall components etc.
- Ignition on
- Read off the engine coolant temperature (ECT) sensor.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S37228285172011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
See Signal too high. Intermittent fault
See Signal too high. Intermittent fault
See Signal too high. Intermittent fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Ignition on
- Read off the engine coolant temperature (ECT) sensor.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S00844337412011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too high. Permanent fault
See Signal too high. Permanent fault
See Signal too high. Permanent fault
| WARNING | Before fault-tracing can begin, the engine cooling fan (FC) connector must be disconnected to prevent the engine cooling fan (FC) engaging. Diagnostic trouble code (DTC) ECM-6110 Engine cooling fan (FC) low-speed signal may be stored. After fault-tracing the connector must be reconnected. |
- Ignition off
- Check the connector on the engine coolant temperature (ECT) sensor. Check for contact resistance and oxidation
- Reinstall the components, reconnect the connectors etc.
- Ignition on
- Read off the engine coolant temperature (ECT) sensor. If the temperature is now within its permitted range, the fault was caused by loose connections in the connector. Other information See «Contents»(ref-440209-S18666729612011121400000) To access the engine coolant temperature (ECT) sensor, see «Temperature sensor engine coolant, replacing»(ref-461758-S26261417092012040200000) .
Is the temperature within its permitted range?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Checking the wiring and component»(ref-440262-S38099929742011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect connectors, reinstall components etc.
- Ignition on
- Read off the engine coolant temperature (ECT) sensor.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S16702143912011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
If the fault is intermittent, do not verify fault-tracing if the fault does not recur.
It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).
See Signal too low. Intermittent fault
See Signal too low. Intermittent fault
See Signal too low. Intermittent fault
| WARNING | Before fault-tracing can begin, the engine cooling fan (FC) connector must be disconnected to prevent the engine cooling fan (FC) engaging. Diagnostic trouble code (DTC) ECM-6110 Engine cooling fan (FC) control module may be stored. After fault-tracing the connector must be reconnected. |
- Ignition off
- Check the engine coolant temperature (ECT) sensor connector. Check for contact resistance and oxidation
- Reinstall the components, reconnect the connectors etc.
- Ignition on
- Read off the engine coolant temperature (ECT) sensor. If the temperature is now within its permitted range, the fault was caused by loose connections in the connector. Other information To access the engine coolant temperature (ECT) sensor, see «Temperature sensor engine coolant, replacing»(ref-461758-S26261417092012040200000) See «Contents»(ref-440209-S18666729612011121400000) .
Is the temperature within its permitted range?
- YES OKAY: Troubleshooting has been completed.
- NO Refer to «Checking the wiring and component»(ref-440262-S06101860452011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Ignition on
- Read off the engine coolant temperature (ECT) sensor.
Is the temperature within its permitted range?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S40473221782011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
See Signal too low. Permanent fault
See Signal too low. Permanent fault
See Signal too low. Permanent fault
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect connectors, reinstall components etc.
- Ignition on
- Activate the relevant injector. A "click" should be heard when the injector is activated.
Is the injector working?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S01709462882011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect connectors, reinstall components etc.
- Ignition on
- Activate the relevant injector. A "click" should be heard when the injector is activated.
Is the injector working?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S00346630462011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect connectors, reinstall components etc.
- Ignition on
- Activate the relevant injector. A "click" should be heard when the injector is activated.
Is the injector working?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S25221963162011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Replacing the thermostat
Note. This diagnostic trouble code (DTC) is stored if the engine coolant temperature (ECT) sensor freezes. This may happen if the coolant level is low or there is too little glycol in the coolant. Check the engine coolant level and its freezing point. Remedy as necessary.
The engine control module (ECM) has registered that the actual temperature increase has deviated from the calculated temperature increase. This deviation is due to a defective thermostat.
Try replacing the thermostat. See Temperature sensor engine coolant, replacing .
- Continue Refer to «Information»(ref-440262-S11976090592011121400000)
In case of this defect, troubleshooting is not followed by verification.
The information can be displayed again or the fault-tracing for this fault can be interrupted.
See Faulty signal
See Faulty signal
Signal missing
See Signal missing
See Signal too high
See Signal too low
See Signal missing
See Signal too high
See Signal too low
See Signal missing
See Signal too high
See Signal too low
See Signal missing
See Signal too high
See Signal too low
Checking the fuel injection system
Check the intake system for air leakage.
HINT: Air leakage in the intake system can occur through the evaporative emission system (EVAP) valve, the secondary air solenoid valve or the power brake booster.
Check the fuel pressure.
Test drive the car for approximately 10 minutes.
Check the mass air flow (MAF) sensor. Read off its correction factor. The value must be between 0.8 and 1.2.
Note. There must not be any air leakage when this test is carried out.
Remedy as necessary.
Other information
- See «Check for air leaks in the intake system»(ref-440264-S10239834622011121400000)
- See «Checking fuel and residual pressures»(ref-461755-S21263159602012040200000)
- See «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000)
- Continue Refer to «Verification»(ref-440262-S17864733622011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Test drive the vehicle on the road. Run a TRIP schedule so that the engine control module (ECM) compares the diagnostics. To run a TRIP schedule, see: «Verifying repairs»(ref-440264-S06906222842011121400000)
- Connect VCT2000 to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.
Is the function OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S41985106062011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Check the intake system for air leakage.
HINT: Air leakage in the intake system can occur through the evaporative emission system (EVAP) valve, the secondary air solenoid valve or the power brake booster.
Check the exhaust system for leakage.
Check the fuel pressure and residual pressure.
Check that the oil level is within the minimum and maximum markings.
Check the viscosity of the engine oil by reading off the short-term fuel trim with the engine running. Plug the crankcase ventilation and read off the short-term fuel trim again. The value must be more or less unchanged.
Remedy as necessary.
Other information
- See «Check for air leaks in the intake system»(ref-440264-S10239834622011121400000)
- See «Checking for air leakage in the exhaust system»(ref-461753-S22407718952012040200000)
- See «Checking fuel and residual pressures»(ref-461755-S21263159602012040200000)
Was a fault detected?
- YES Refer to «Verification»(ref-440262-S37905818102011121400000)
- NO Refer to «Checking the mass air flow (MAF) sensor»(ref-440262-S05101463102011121400000)
Checking the mass air flow (MAF) sensor
Test drive the car for approximately 10 minutes.
Read off the correction factor of the mass air flow (MAF) sensor. The value must be between 0.8 and 1.2.
Note. There must not be any air leakage when this test is carried out.
Remedy as necessary.
Other information
- See «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
- Continue Refer to «Verification»(ref-440262-S37905818102011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Test drive the vehicle on the road. Run a TRIP schedule so that the engine control module (ECM) compares the diagnostics. To run a TRIP schedule, see: «Verifying repairs»(ref-440264-S06906222842011121400000)
- Connect VCT2000 to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.
Is the function OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S17994843862011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Check the intake system for air leakage.
HINT: Air leakage in the intake system can occur through the evaporative emission system (EVAP) valve, the secondary air solenoid valve or the power brake booster.
Check the fuel pressure.
Test drive the car for approximately 10 minutes.
Check the mass air flow (MAF) sensor. Read off its correction factor. The value must be between 0.8 and 1.2.
Note. There must not be any air leakage when this test is carried out.
Remedy as necessary.
Other information
- See «Check for air leaks in the intake system»(ref-440264-S10239834622011121400000)
- See «Checking fuel and residual pressures»(ref-461755-S21263159602012040200000)
- See «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
- Continue Refer to «Verification»(ref-440262-S22497160802011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Test drive the vehicle on the road. Run a TRIP schedule so that the engine control module (ECM) compares the diagnostics. To run a TRIP schedule, see: «Verifying repairs»(ref-440264-S06906222842011121400000)
- Connect VCT2000 to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.
Is the function OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S36455161402011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
Check the intake system for air leakage.
HINT: Air leakage in the intake system can occur through the evaporative emission system (EVAP) valve, the secondary air solenoid valve or the power brake booster.
Check the exhaust system for leakage.
Check the fuel pressure and residual pressure.
Check that the oil level is within the minimum and maximum markings.
Check the viscosity of the engine oil by reading off the short-term fuel trim with the engine running. Plug the crankcase ventilation and read off the short-term fuel trim again. The value must be more or less unchanged.
Remedy as necessary.
Other information
- See «Check for air leaks in the intake system»(ref-440264-S10239834622011121400000)
- See «Checking for air leakage in the exhaust system»(ref-461753-S22407718952012040200000)
- See «Checking fuel and residual pressures»(ref-461755-S21263159602012040200000)
Was a fault detected?
- YES Refer to «Verification»(ref-440262-S07944009982011121400000)
- NO Refer to «Checking the mass air flow (MAF) sensor»(ref-440262-S36989826572011121400000)
Test drive the car for approximately 10 minutes.
Read off the correction factor of the mass air flow (MAF) sensor. The value must be between 0.8 and 1.2.
Note. There must not be any air leakage when this test is carried out.
Remedy as necessary.
Other information
- See «Mass air flow sensor (MAF), replacing»(ref-461749-S37193842222012040200000) .
- Continue Refer to «Verification»(ref-440262-S07944009982011121400000)
HINT: After carrying out the repair, check that the fault has been remedied.
- Ignition off
- Reconnect the connectors, reinstall components etc.
- Test drive the vehicle on the road. Run a TRIP schedule so that the engine control module (ECM) compares the diagnostics. To run a TRIP schedule, see: «Verifying repairs»(ref-440264-S06906222842011121400000)
- Connect VCT2000 to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.
Is the function OK?
- YES VERIFIED: Troubleshooting has been completed.
- NO Refer to «Information»(ref-440262-S33577559432011121400000)
The fault should have been detected and remedied. As this is not the case fault-tracing has failed.
Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
