Engine Control Module (ECM) Diagnostic Trouble Codes - 8 of 11: Wiring Volvo S80 I

Checking connectors and wiring

Check the oil level sensor connector. Check for loose connections, contact resistance and oxidation.

Check the signal cable between engine control module (ECM) terminal #A40 and oil level sensor terminal #1. Check for an open-circuit.

Check the cable between engine control module (ECM) terminal #A39 and oil level sensor terminal #3. Check for an open-circuit.

Check the cable between engine control module (ECM) terminal #A60 and oil level sensor terminal #2. Check for an open-circuit.

HINT: With the ignition on, the voltage between terminals #2 and #3 must be 5 V, with the reading taken at the oil level sensor connector.

Try a new oil level sensor if no fault is found and the fault is permanent.

Remedy as necessary.

Other information

1. See «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals for 5 cylinder engines: «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals for 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Oil level sensor, replacing»(ref-461672-S34069479642012040200000)
5. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000)

1. Continue Refer to «Verification»(ref-440289-S17822581102011121400000)

Checking the wiring

Check the signal cable between engine control module (ECM) terminal #A40 and oil level sensor terminal #1. Check for a short-circuit to supply voltage.

HINT: With the ignition on, the voltage between terminals #2 and #3 must be 5 V, with the reading taken at the oil level sensor connector.

Try a new oil level sensor if no fault is found and the fault is permanent.

Remedy as necessary.

Other information

1. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000)
2. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
3. For information about signals, see «Signal specification»(ref-440214-S33124753252011121400000)
4. To access or replace the oil level sensor see «Oil level sensor, replacing»(ref-461672-S34069479642012040200000) .

Scheme 253

1. Continue Refer to «Verification»(ref-440289-S18373923152011121400000)

Check the signal cable between engine control module (ECM) terminal #A40 and oil level sensor terminal #1. Check for a short-circuit to ground.

HINT: With the ignition on, the voltage between terminals #2 and #3 must be 5 V, with the reading taken at the oil level sensor connector.

Try a new oil level sensor if no fault is found and the fault is permanent.

Remedy as necessary.

Other information

1. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000)
2. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
3. For information about signals, see «Signal specification»(ref-440214-S33124753252011121400000)
4. To access or replace the oil level sensor see «Oil level sensor, replacing»(ref-461672-S34069479642012040200000) .

1. Continue Refer to «Verification»(ref-440289-S02646922142011121400000)

Checking wiring and connectors

Check the connector for the air conditioning (A/C) relay. Check for contact resistance and oxidation. Check for loose connections.

Check the signal cable between control module terminal #B44 and air conditioning (A/C) relay terminal #4. Check the power supply between system relay terminal #3 and A/C relay terminal #2. Check for an intermittent open-circuit.

Other information

1. To connect the breakout box / access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

Scheme 254

1. Continue Refer to «Information»(ref-440289-S11659197372011121400000)

Checking components and wiring

Check the resistance of the air conditioning (A/C) relay. At +20°C the resistance must be approximately 96 ohms between terminals #2 and #4. For the resistance values

1. For 5-cylinder turbocharged engines and 6-cylinder engines 2001, see «Component specifications»(ref-440279-S36691068112011121400000) .
2. For 5-cylinder turbocharged engines and 6-cylinder engines 2002, see «Component specifications»(ref-440279-S32869788892011121400000) .
3. For 5 cylinder turbocharged engines and 6 cylinder engines 2003-, see «Component specifications»(ref-440279-S29470938672011121400000) .
4. For B5254T4 2004-, see «Component specifications»(ref-440279-S23854582792011121400000) .
5. For 5-cylinder normally aspirated engines 1999-, see «Component specifications»(ref-461750-S15174393772012040200000)

Check the signal cable between control module terminal #B44 and air conditioning (A/C) relay terminal #4. Check the power supply between system relay terminal #3 and A/C relay terminal #2. Check for an open-circuit. Check for a short-circuit to ground.

Remedy as necessary.

Other information

1. To connect the breakout box / access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440289-S41007642742011121400000)

Check the signal cable between control module terminal #B44 and air conditioning (A/C) relay terminal #4. Check for an intermittent short-circuit to supply voltage.

Other information

1. To connect the breakout box / access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Information»(ref-440289-S10613863012011121400000)

Check the signal cable between control module terminal #B44 and air conditioning (A/C) relay terminal #4. Check for a short-circuit to supply voltage.

HINT: Use a test lamp with at least a 3 W bulb to determine whether the cable is short-circuited to supply voltage.

Remedy as necessary.

Other information

1. To connect the breakout box / access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440289-S02576860032011121400000)

Check the signal cable between control module terminal #B44 and air conditioning (A/C) relay terminal #4. Check for an intermittent short-circuit to ground.

Other information

1. To connect the breakout box / access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Information»(ref-440289-S21979408762011121400000)

Check the signal cable between control module terminal #B44 and air conditioning (A/C) relay terminal #4. Check for a short-circuit to ground.

Remedy as necessary.

Other information

1. To connect the breakout box / access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440289-S16870205432011121400000)

Checking the component, wiring and connector

Check turbocharger (TC) control valve connector for intermittent contact resistance or oxidation according to Contact resistance and oxidation and intermittent loose connections according to Contact resistance and oxidation .

Check signal cable between engine control module (ECM) #A38 (#A38) and turbocharger (TC) control valve #2 for an intermittent open-circuit according to Open-circuit, intermittent faults .

Check power supply turbocharger (TC) control valve between turbocharger (TC) control valve #1 and system relay for an intermittent open-circuit according to Open-circuit, intermittent faults .

Remedy as necessary

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
2. To access/replace the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000) .
3. Turbocharger (TC) control valve #1 has power supply via the system relay.
4. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
5. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

Scheme 255

1. Continue Refer to «Information»(ref-440289-S21599078082011121400000)

Checking component and wiring

Check signal cable between engine control module (ECM) #A38 (#A38) and turbocharger (TC) control valve #2 for an open-circuit according to Open-circuit, permanent faults .

Check power supply cable between turbo charger valve #1 and system relay for an open-circuit according to Open-circuit, permanent faults .

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
2. To access/replace the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000) .
3. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
4. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
5. Turbocharger (TC) control valve #1 has power supply via the system relay.

1. Continue Refer to «Verification»(ref-440289-S21393631302011121400000)

Check cables between engine control module (ECM) #A38 (#A38) and turbocharger (TC) control valve #2 for an intermittent short-circuit to supply voltage according to Short-circuit to supply voltage, intermittent faults .

Remedy as necessary

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
2. To access/replace the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000) .
3. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
4. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
5. Turbocharger (TC) control valve terminal 1 has Ubat power supply from the system relay.

1. Continue Refer to «Information»(ref-440289-S22859487312011121400000)

Check the cable between #A38 (#A38) and turbocharger (TC) control valve #2 for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

Remedy as necessary

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
2. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. To access/replace the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000)
5. Turbocharger (TC) control valve #1 has Ubat power supply from the system relay.

1. Continue Refer to «Verification»(ref-440289-S10605756362011121400000)

Check cables between engine control module (ECM) #A38 (#A38) and turbocharger (TC) control valve #2 for an intermittent short-circuit to ground according to Short-circuit to ground, intermittent faults .

Remedy as necessary

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. To access/replace the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000) .
3. Turbocharger (TC) control valve #1 has Ubat power supply from the system relay.
4. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
5. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

1. Continue Refer to «Information»(ref-440289-S19972681372011121400000)

Check cable between engine control module (ECM) #A38 (#A38) and turbocharger (TC) control valve #2 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
2. To access/replace the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000) .
3. Turbocharger (TC) control valve #1 has Ubat power supply from the system relay.
4. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
5. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

1. Continue Refer to «Verification»(ref-440289-S09068765422011121400000)

Checking the component and wiring

1. Ignition off. CAUTION: Avoid touching the pins in the control module and the corresponding connector on the cable harness. There is a risk of static discharge which could damage the control module. Discharge yourself and tools to be used by holding the tool's metal part and touching a body part on the car just before starting to work. If the engine cooling fan (FC) cannot be activated at any speed: Check the fuse, power supply cable and ground lead for the engine cooling fan (FC). Check the connector and wiring between the engine control module (ECM) and engine cooling fan (FC) module. Check for damage. Check for an open circuit. Check for a short circuit. If the engine cooling fan (FC) can be activated at one or more speeds: Check the connectors to the engine cooling fan (FC) control module and Engine Control Module (ECM). Check for damage to pins and connections. Also check other connectors and connections that connect cables between Engine Control Module (ECM) and the control module for electric cooling fan. Check the wiring between the engine control module (ECM) and the engine cooling fan (FC) module. Check for damage. Remedy as necessary. Other information: See «Connecting the breakout box»(ref-440211-S03702023042011121400000) 5 cylinder: «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Engine cooling fan (FC), replacing»(ref-440274-S42804862972011121400000) See «Checking wiring and terminals»(ref-440209-S18666729612011121400000)

Was a fault detected?

1. YES Refer to «Verification»(ref-440289-S13427341162011121400000)
2. NO Refer to «Replacing a component»(ref-440289-S33037753832011121400000)

1. Ignition off. CAUTION: Avoid touching the pins in the control module and the corresponding connector on the cable harness. There is a risk of static discharge which could damage the control module. Discharge yourself and tools to be used by holding the tool's metal part and touching a body part on the car just before starting to work. If the engine cooling fan (FC) cannot be activated at any speed: Check the fuse, power supply cable and ground lead for the engine cooling fan (FC). Check the connector and wiring between the engine control module (ECM) and engine cooling fan (FC) module. Check for damage. Check for an open circuit. Check for a short circuit. If the engine cooling fan (FC) can be activated at one or more speeds: Check the connectors to the engine cooling fan (FC) control module and Engine Control Module (ECM). Check for damage to pins and connections. Also check other connectors and connections that connect cables between Engine Control Module (ECM) and the control module for electric cooling fan. Check the wiring between the engine control module (ECM) and the engine cooling fan (FC) module. Check for damage. Remedy as necessary. Other information: See «Connecting the breakout box»(ref-440211-S03702023042011121400000) 5 cylinder: «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Engine cooling fan (FC), replacing»(ref-440274-S42804862972011121400000) See «Checking wiring and terminals»(ref-440209-S18666729612011121400000)

Was a fault detected?

1. YES Refer to «Verification»(ref-440289-S16355011412011121400000)
2. NO Refer to «Replacing a component»(ref-440289-S26039630492011121400000)

1. Ignition off CAUTION: Avoid touching the pins in the control module and the corresponding connector on the cable harness. There is a risk of static discharge which could damage the control module. Discharge yourself and tools to be used by holding the tool's metal part and touching a body part on the car just before starting to work. If the engine cooling fan (FC) cannot be activated at any speed: Check the fuse, power supply cable and ground lead for the engine cooling fan (FC). Check the connector and wiring between the engine control module (ECM) and engine cooling fan (FC) module. Check for damage. Check for an open circuit. Check for a short circuit. If the engine cooling fan (FC) can be activated at one or more speeds: Check the connectors to the engine cooling fan (FC) control module and Engine Control Module (ECM). Check for damage to pins and connections. Also check other connectors and connections that connect cables between Engine Control Module (ECM) and the control module for electric cooling fan. Check the wiring between the engine control module (ECM) and the engine cooling fan (FC) module. Check for damage. Remedy as necessary. Other information: See «Connecting the breakout box»(ref-440211-S03702023042011121400000) 5 cylinder: «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Engine cooling fan (FC), replacing»(ref-440274-S42804862972011121400000) See «Checking wiring and terminals»(ref-440209-S18666729612011121400000)

Was a fault detected?

1. YES Refer to «Verification»(ref-440289-S00824673012011121400000)
2. NO Refer to «Replacing a component»(ref-440289-S31645057012011121400000)

The engine fan control module has previously registered that the fan blade was blocked or that the temperature in the engine fan control module was too high, but the fault is no longer present.

Check that nothing is loose in the vicinity of the engine cooling fan (FC) which can temporarily stop the fan blade.

1. Continue Refer to «Information»(ref-440289-S28340705872011121400000)

Check the connector for contact resistance, oxidation and loose connections.

Check the cable between engine control module (ECM) terminal #A7 (#A7) and engine cooling fan (FC) control module terminal #1B for an intermittent open-circuit according to Open-circuit, intermittent faults .

Remedy as necessary

Other information

1. To connect the breakout box and access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

Scheme 256

1. Continue Refer to «Information»(ref-440289-S37038431112011121400000)

1. Ignition off. CAUTION: Avoid touching the pins in the control module and the corresponding connector on the cable harness. There is a risk of static discharge which could damage the control module. Discharge yourself and tools to be used by holding the tool's metal part and touching a body part on the car just before starting to work. If the engine cooling fan (FC) cannot be activated at any speed: Check the fuse, power supply cable and ground lead for the engine cooling fan (FC). Check the connector and wiring between the engine control module (ECM) and engine cooling fan (FC) module. Check for damage. Check for an open circuit. Check for a short circuit. If the engine cooling fan (FC) can be activated at one or more speeds: Check the connectors to the engine cooling fan (FC) control module and Engine Control Module (ECM). Check for damage to pins and connections. Also check other connectors and connections that connect cables between Engine Control Module (ECM) and the control module for electric cooling fan. Check the wiring between the engine control module (ECM) and the engine cooling fan (FC) module. Check for damage. Remedy as necessary Other information: See «Connecting the breakout box»(ref-440211-S03702023042011121400000) For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Engine cooling fan (FC), replacing»(ref-440274-S42804862972011121400000) See «Checking wiring and terminals»(ref-440209-S33835172972011121400000)

Was a fault detected?

1. YES Refer to «Verification»(ref-440289-S06904723102011121400000)
2. NO Refer to «Replacing a component»(ref-440289-S04513476832011121400000)

Check cable between engine control module (ECM) #A7 (#A7) and engine cooling fan (FC) relay #1B for an intermittent short-circuit to supply voltage according to Short-circuit to supply voltage, intermittent faults .

Remedy as necessary

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
2. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

1. Continue Refer to «Information»(ref-440289-S07157748582011121400000)

1. Ignition off. CAUTION: Avoid touching the pins in the control module and the corresponding connector on the cable harness. There is a risk of static discharge which could damage the control module. Discharge yourself and tools to be used by holding the tool's metal part and touching a body part on the car just before starting to work. If the engine cooling fan (FC) cannot be activated at any speed: Check the fuse, power supply cable and ground lead for the engine cooling fan (FC). Check the connector and wiring between the engine control module (ECM) and engine cooling fan (FC) module. Check for damage. Check for an open circuit. Check for a short circuit. If the engine cooling fan (FC) can be activated at one or more speeds: Check the connectors to the engine cooling fan (FC) control module and Engine Control Module (ECM). Check for damage to pins and connections. Also check other connectors and connections that connect cables between Engine Control Module (ECM) and the control module for electric cooling fan. Check the wiring between the engine control module (ECM) and the engine cooling fan (FC) module. Check for damage. Remedy as necessary. Other information See «Connecting the breakout box»(ref-440211-S03702023042011121400000) For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Engine cooling fan (FC), replacing»(ref-440274-S42804862972011121400000) See «Checking wiring and terminals»(ref-440209-S33835172972011121400000)

Was a fault detected?

1. YES Refer to «Verification»(ref-440289-S29525113192011121400000)
2. NO Refer to «Replacing a component»(ref-440289-S18725089482011121400000)

Check cable between engine control module (ECM) #A7 (#A7) and engine cooling fan (FC) relay #1B for an intermittent short-circuit to ground according to Short-circuit to ground, intermittent faults .

Remedy as necessary

Other information

1. Connecting the breakout box/accessing the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
2. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

1. Continue Refer to «Information»(ref-440289-S17428210502011121400000)

1. Ignition off. CAUTION: Avoid touching the pins in the control module and the corresponding connector on the cable harness. There is a risk of static discharge which could damage the control module. Discharge yourself and tools to be used by holding the tool's metal part and touching a body part on the car just before starting to work. If the engine cooling fan (FC) cannot be activated at any speed: Check the fuse, power supply cable and ground lead for the engine cooling fan (FC). Check the connector and wiring between the engine control module (ECM) and engine cooling fan (FC) module. Check for damage. Check for an open circuit. Check for a short circuit. If the engine cooling fan (FC) can be activated at one or more speeds: Check the connectors to the engine cooling fan (FC) control module and Engine Control Module (ECM). Check for damage to pins and connections. Also check other connectors and connections that connect cables between Engine Control Module (ECM) and the control module for electric cooling fan. Check the wiring between the engine control module (ECM) and the engine cooling fan (FC) module. Check for damage. Remedy as necessary Other information: See «Connecting the breakout box»(ref-440211-S03702023042011121400000) For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Engine cooling fan (FC), replacing»(ref-440274-S42804862972011121400000) See «Checking wiring and terminals»(ref-440209-S33835172972011121400000)

Was a fault detected?

1. YES Refer to «Verification»(ref-440289-S42701061232011121400000)
2. NO Refer to «Replacing a component»(ref-440289-S32880208302011121400000)

1. Ignition off. CAUTION: Avoid touching the pins in the control module and the corresponding connector on the cable harness. There is a risk of static discharge which could damage the control module. Discharge yourself and tools to be used by holding the tool's metal part and touching a body part on the car just before starting to work. If the engine cooling fan (FC) cannot be activated at any speed: Check the fuse, power supply cable and ground lead for the engine cooling fan (FC). Check the connector and wiring between the engine control module (ECM) and engine cooling fan (FC) module. Check for damage. Check for an open circuit. Check for a short circuit. If the engine cooling fan (FC) can be activated at one or more speeds: Check the connectors to the engine cooling fan (FC) control module and Engine Control Module (ECM). Check for damage to pins and connections. Also check other connectors and connections that connect cables between Engine Control Module (ECM) and the control module for electric cooling fan. Check the wiring between the engine control module (ECM) and the engine cooling fan (FC) module. Check for damage. Remedy as necessary. Other information See «Connecting the breakout box»(ref-440211-S03702023042011121400000) 5 cylinder: «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Engine cooling fan (FC), replacing»(ref-440274-S42804862972011121400000) See «Checking wiring and terminals»(ref-440209-S18666729612011121400000)

Was a fault detected?

1. YES Refer to «Verification»(ref-440289-S10903847972011121400000)
2. NO Refer to «Replacing a component»(ref-440289-S09985207992011121400000)

1. Ignition off. CAUTION: Avoid touching the pins in the control module and the corresponding connector on the cable harness. There is a risk of static discharge which could damage the control module. Discharge yourself and tools to be used by holding the tool's metal part and touching a body part on the car just before starting to work. If the engine cooling fan (FC) cannot be activated at any speed: Check the fuse, power supply cable and ground lead for the engine cooling fan (FC). Check the connector and wiring between the engine control module (ECM) and engine cooling fan (FC) module. Check for damage. Check for an open circuit. Check for a short circuit. If the engine cooling fan (FC) can be activated at one or more speeds: Check the connectors to the engine cooling fan (FC) control module and Engine Control Module (ECM). Check for damage to pins and connections. Also check other connectors and connections that connect cables between Engine Control Module (ECM) and the control module for electric cooling fan. Check the wiring between the engine control module (ECM) and the engine cooling fan (FC) module. Check for damage. Remedy as necessary. Other information See «Connecting the breakout box»(ref-440211-S03702023042011121400000) 5 cylinder: «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Engine cooling fan (FC), replacing»(ref-440274-S42804862972011121400000) See «Checking wiring and terminals»(ref-440209-S18666729612011121400000)

Was a fault detected?

1. YES Refer to «Verification»(ref-440289-S22497779752011121400000)
2. NO Refer to «Replacing a component»(ref-440289-S03823803852011121400000)

1. Ignition off. CAUTION: Avoid touching the pins in the control module and the corresponding connector on the cable harness. There is a risk of static discharge which could damage the control module. Discharge yourself and tools to be used by holding the tool's metal part and touching a body part on the car just before starting to work. If the engine cooling fan (FC) cannot be activated at any speed: Check the fuse, power supply cable and ground lead for the engine cooling fan (FC). Check the connector and wiring between the engine control module (ECM) and engine cooling fan (FC) module. Check for damage. Check for an open circuit. Check for a short circuit. If the engine cooling fan (FC) can be activated at one or more speeds: Check the connectors to the engine cooling fan (FC) control module and Engine Control Module (ECM). Check for damage to pins and connections. Also check other connectors and connections that connect cables between Engine Control Module (ECM) and the control module for electric cooling fan. Check the wiring between the engine control module (ECM) and the engine cooling fan (FC) module. Check for damage. Remedy as necessary. Other information See «Connecting the breakout box»(ref-440211-S03702023042011121400000) 5 cylinder: «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Engine cooling fan (FC), replacing»(ref-440274-S42804862972011121400000) See «Checking wiring and terminals»(ref-440209-S18666729612011121400000)

Was a fault detected?

1. YES Refer to «Verification»(ref-440289-S33810609642011121400000)
2. NO Refer to «Replacing a component»(ref-440289-S38312102982011121400000)

Check the fuse before the circuit. If the fuse is blown, check the circuit for a short-circuit to ground.

Check the resistance of the camshaft reset valve between terminals #1 and #2.

The resistance must be approximately 3.7 ohms.

Check the signal cable between engine control module (ECM) terminal #A13 (#A13) and camshaft reset valve terminal #2. Check for an open-circuit. Check for a short-circuit to ground.

Check the power supply cable between system relay terminal #5 and camshaft reset valve terminal #1. Check for an open-circuit.

HINT: With the ignition on and the reset valve and camshaft connector disconnected, the voltage at connector terminal #1 must be approximately U bat.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For B6xx4x -2001, see «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
3. For B6xx4x 2002-, see «Replacing the variable valve timing solenoid»(ref-440293-S12724902612011121400000) .
4. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
5. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
6. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

Scheme 257

1. Continue Refer to «Verification»(ref-440289-S37263073042011121400000)

Check the resistance of the camshaft reset valve between terminals #1 and #2.

The resistance must be approximately 3.7 ohms.

Check the signal cable between engine control module (ECM) terminal #A13 (#A13) and camshaft reset valve terminal #2. Check for a short-circuit to supply voltage.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For B6xx4x -2001, see «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
3. For B6xx4x 2002-, see «Replacing the variable valve timing solenoid»(ref-440293-S12724902612011121400000) .
4. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
5. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
6. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440289-S41692281892011121400000)

Check the fuse before the circuit. If the fuse is blown, check the circuit for a short-circuit to ground.

Check the resistance of the camshaft reset valve between terminals #1 and #2.

The resistance must be approximately 3.7 ohms.

Check the signal cable between engine control module (ECM) terminal #A21 (#A21) and camshaft reset valve terminal #2. Check for an open-circuit. Check for a short-circuit to ground.

Check the power supply cable between system relay terminal #5 and camshaft reset valve terminal #1. Check for an open-circuit.

HINT: With the ignition on and the reset valve and camshaft connector disconnected, the voltage at connector terminal #1 must be approximately U bat.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For B6xx4x -2001, see «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
3. For B6xx4x 2002-, see «Replacing the variable valve timing solenoid»(ref-440293-S12724902612011121400000) .
4. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
5. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
6. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440289-S05260134202011121400000)

Check the resistance of the camshaft reset valve between terminals #1 and #2.

The resistance must be approximately 3.7 ohms.

Check the signal cable between engine control module (ECM) terminal #A21 (#A21) and camshaft reset valve terminal #2. Check for a short-circuit to supply voltage.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For B6xx4x -2001, see «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
3. For B6xx4x 2002-, see «Replacing the variable valve timing solenoid»(ref-440293-S12724902612011121400000) .
4. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
5. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
6. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440289-S29959149062011121400000)

Check the fuse before the circuit. If the fuse is blown, check the circuit for a short-circuit to ground.

Check the power cable between the fuse of the circuit and terminal #1 of the control module cooling fan for open circuit.

Check the signal cable with regard to open circuit.

Take readings between

1. Engine Control Module (ECM) terminal #B48 (#B58) and terminal #2 of control module cooling fan.

If no faults are found via the aforementioned fault tracing, replace the control module cooling fan.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Information»(ref-440289-S07070464822011121400000)

Check signal cable for an open-circuit and short-circuit to supply voltage.

Take readings between

1. Engine Control Module (ECM) terminal #B48 (#B58) and terminal #2 of control module cooling fan.

If no faults are found via the aforementioned fault tracing, replace the control module cooling fan.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Information»(ref-440289-S26824978032011121400000)

Check the signal cable. Check for a short-circuit to ground.

Take readings between

1. Engine Control Module (ECM) terminal #B48 (#B58) and terminal #2 of control module cooling fan.

If no faults are found via the aforementioned fault tracing, replace the control module cooling fan.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
3. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
4. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Information»(ref-440289-S39361248762011121400000)

Check the fuse before the circuit. If the fuse is blown, check the circuit. Check for a short-circuit to ground.

Check the resistance of the camshaft reset valve between terminals #1 and #2.

The resistance must be approximately 3.7 ohms.

Check the signal cable between engine control module (ECM) terminal #A13 (#A13) and camshaft reset valve terminal #2. Check for an open-circuit. Check for a short-circuit to ground.

Check the power supply cable between system relay terminal #5 and camshaft reset valve terminal #1. Check for an open-circuit.

HINT: With the ignition on and the reset valve and camshaft connector disconnected, the voltage at connector terminal #1 must be approximately U bat.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For B6xx4x -2001, see «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
3. For B6xx4x 2002-, see «Replacing the variable valve timing solenoid»(ref-440293-S12724902612011121400000) .
4. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
5. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
6. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440289-S11792530132011121400000)

Check the fuse before the circuit. If the fuse is blown, check the circuit. Check for a short-circuit to ground.

Check the resistance of the camshaft reset valve between terminals #1 and #2.

The resistance must be approximately 3.7 ohms.

Check the signal cable between engine control module (ECM) terminal #A21 (#A21) and camshaft reset valve terminal #2. Check for an open-circuit. Check for a short-circuit to ground.

Check the power supply cable between system relay terminal #5 and camshaft reset valve terminal #1. Check for an open-circuit.

HINT: With the ignition on and the reset valve and camshaft connector disconnected, the voltage at connector terminal #1 must be approximately U bat.

Remedy as necessary.

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
2. For B6xx4x -2001, see «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
3. For B6xx4x 2002-, see «Replacing the variable valve timing solenoid»(ref-440293-S12724902612011121400000) .
4. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
5. For information about signals on 6 cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
6. See «Checking wiring and terminals»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440289-S40917710022011121400000)
