Engine Control Module (ECM) Diagnostic Trouble Codes - 9 of 11: Other Volvo S80 I

Fault-tracing information

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal missing. Intermittent fault

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

Verification

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 293

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Start the engine.
5. Increase engine speed (RPM) on the engine and read off the camshaft timing alterations.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S19447879342011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal missing. Permanent fault

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal too high. Intermittent fault

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

Checking cables

Check the camshaft reset valve resistance between #1 and #2, resistance should be approximately 3.7 ohms.

Check the signal cable between engine control module (ECM) #A13 and camshaft reset valve #2 for a short-circuit to supply voltage according to Short-circuit to supply voltage. Permanent faults .

Remedy as necessary

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
2. To access/replace the camshaft reset valve, see «CAMSHAFT SEAL/VARIABLE VALVE TIMING (VVT) UNIT, REPLACING»(ref-440293-S12558219492011121400000) .
3. With the ignition on and the camshaft reset valve connector disconnected the voltage on connector #1 should be approximately U batt and at connector #2 it should be a pulse modulated signal with a peak voltage of approximately Ubatt and with a frequency of approximately 250 Hz.
4. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
5. For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

1. Continue Refer to «Verification»(ref-440291-S06149291182011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Start the engine.
5. Increase engine speed (RPM) on the engine and read off the camshaft timing alterations.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S25657661512011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal too high. Permanent fault

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Signal too low. Intermittent fault

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

Check the camshaft reset valve resistance between #1 and #2, resistance should be approximately 3.7 ohms.

Check the signal cable between engine control module (ECM) #A13 and camshaft reset valve #2 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Check power supply cable #5 and camshaft reset valve #1 for a short-circuit to ground according to Short-circuit to ground, permanent faults .

Remedy as necessary

Other information

1. To connect the breakout box, see «Connecting the breakout box»(ref-440211-S03702023042011121400000) .
2. To access/replace the camshaft reset valve, see «CAMSHAFT SEAL/VARIABLE VALVE TIMING (VVT) UNIT, REPLACING»(ref-440293-S12558219492011121400000) .
3. With the ignition on and the camshaft reset valve connector disconnected the voltage on connector #1 should be approximately U batt and at connector #2 it should be a pulse modulated signal with a peak voltage of approximately U batt and with a frequency of approximately 250 Hz.
4. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000) .
5. For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

1. Continue Refer to «Verification»(ref-440291-S42183036382011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Ignition on.
4. Start the engine.
5. Increase engine speed (RPM) on the engine and read off the camshaft timing alterations.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S42623020372011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal too low. Permanent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

Checking components

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

If the adaptation value is too high (higher than +8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. the timing belt is incorrectly seated
2. the basic setting of the camshaft is incorrect
3. faulty camshaft reset valve (the slide in the valve has stuck).

HINT: First try adjusting the basic set up of the camshaft. Then read off the adaptation value for the camshaft at idle speed with the engine at operating temperature. The value must be between -8° and +8°. If the adaptation value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault can also be caused by a defective variable valve timing unit. The variable valve timing unit may be defective if the above fault tracing and corrective action does not remedy the fault.

Other information

1. To clean the camshaft reset valve, see «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To adjust the camshaft position (CMP), see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)
3. To replace the camshaft reset valve, see «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000) .

1. Continue Refer to «Verification»(ref-440291-S28903800302011121400000)

Intermittent fault

If the diagnostic trouble code (DTC) for this fault is stored but the adaptation value is correct, the fault is intermittent. The cause of the intermittent fault is probably a defective camshaft reset valve.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Other information

1. To clean the camshaft reset valve, see «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To replace the camshaft reset valve, see «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
3. To adjust the camshaft position (CMP), see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000) .

1. Continue Refer to «Verification»(ref-440291-S28903800302011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S22866585252011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the status

1. Start the engine and run it to normal operating temperature
2. Read off and note the adaptation value for the camshaft at idle speed. The value must be between -8° and +8°. If the adaptation value is correct (between -8° and +8°) the fault is intermittent. If the adaptation value is incorrect (lower than -8° or higher than +8°), the fault is permanent.

Is the adaptation value correct?

1. YES Refer to «Intermittent fault»(ref-440291-S26669177762011121400000)
2. NO Refer to «Checking components»(ref-440291-S23180917162011121400000)

For variable valve timing control to operate correctly the engine oil must be at the correct level, of the correct quality and not contaminated.

Check the engine oil level and quality. Check for contaminants in particular.

If the adaptation value is too high (higher than +8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. the timing belt is incorrectly seated
2. the basic setting of the camshaft is incorrect
3. faulty camshaft reset valve (the slide in the valve has stuck).

HINT: First try adjusting the basic set up of the camshaft. Then read off the adaptation value for the camshaft at idle speed with the engine at operating temperature. The value must be between -8° and +8°. If the adaptation value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault can also be caused by a defective variable valve timing unit. The variable valve timing unit may be defective if the above fault tracing and corrective action does not remedy the fault.

Other information

1. To clean the camshaft reset valve, see «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To adjust the camshaft position (CMP), see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)
3. To replace the camshaft reset valve, see «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000) .

1. Continue Refer to «Verification»(ref-440291-S37328001502011121400000)

If the diagnostic trouble code (DTC) for this fault is stored but the adaptation value is correct, the fault is intermittent. The cause of the intermittent fault is probably a defective camshaft reset valve.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Other information

1. To clean the camshaft reset valve, see «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To replace the camshaft reset valve, see «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
3. To adjust the camshaft position (CMP), see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000) .

1. Continue Refer to «Verification»(ref-440291-S37328001502011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S33731584512011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature
2. Read off and note the adaptation value for the camshaft at idle speed. The value must be between -8° and +8°. If the adaptation value is correct (between -8° and +8°) the fault is intermittent. If the adaptation value is incorrect (lower than -8° or higher than +8°), the fault is permanent.

Is the adaptation value correct?

1. YES Refer to «Intermittent fault»(ref-440291-S24258143682011121400000)
2. NO Refer to «Checking components»(ref-440291-S28526568962011121400000)

In order for the variable valve timing control to function correctly, the correct grade of engine oil must be used. The oil must be clean and the oil pressure must be correct.

Check the engine oil level and quality. Check for contaminants in particular.

Check the engine oil pressure.

Remedy as necessary.

If no fault is found in the above fault tracing and the adaptation value is too low (lower than -8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. the timing belt is incorrectly seated
2. incorrect base setting of the timing belt
3. faulty camshaft reset valve (the slide in the valve has stuck).

HINT: If no fault is found in the above fault tracing, first try adjusting the basic set up of the camshaft. Then read off the adaptation value for the camshaft at idle speed with the engine at operating temperature. The value must be between -8° and +8°. If the adaptation value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault may also be caused by a defective variable valve timing unit. The variable valve timing unit may be defective if the above fault tracing and corrective action does not remedy the fault.

Other information

1. To clean the camshaft reset valve, see «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To check the engine oil pressure, see «Checking oil pressure»(ref-440290-S04777117452011121400000)
3. To replace the camshaft reset valve, see «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
4. To adjust the camshaft position (CMP), see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000) .

1. Continue Refer to «Verification»(ref-440291-S35080912122011121400000)

If the diagnostic trouble code (DTC) for this fault is stored but the adaptation value is correct, the fault is intermittent. The cause of the intermittent fault is probably a defective camshaft reset valve.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Other information

1. To clean the camshaft reset valve, see «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To replace the camshaft reset valve, see «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
3. To adjust the camshaft position (CMP), see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000) .

1. Continue Refer to «Verification»(ref-440291-S35080912122011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S37116704932011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature
2. Read off and note the adaptation value for the camshaft at idle speed. The value must be between -8° and +8°. If the adaptation value is correct (between -8° and +8°) the fault is intermittent. If the adaptation value is incorrect (lower than -8° or higher than +8°), the fault is permanent.

Is the adaptation value correct?

1. YES Refer to «Intermittent fault»(ref-440291-S15724238272011121400000)
2. NO Refer to «Checking components»(ref-440291-S15068798042011121400000)

In order for the variable valve timing control to function correctly, the correct grade of engine oil must be used. The oil must be clean and the oil pressure must be correct.

Check the engine oil level and quality. Check for contaminants in particular.

Check the engine oil pressure.

Remedy as necessary.

If no fault is found in the above fault tracing and the adaptation value is too low (lower than -8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. the timing belt is incorrectly seated
2. incorrect base setting of the timing belt
3. faulty camshaft reset valve (the slide in the valve has stuck).

HINT: If no fault is found in the above fault tracing, first try adjusting the basic set up of the camshaft. Then read off the adaptation value for the camshaft at idle speed with the engine at operating temperature. The value must be between -8° and +8°. If the adaptation value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault may also be caused by a defective variable valve timing unit. The variable valve timing unit may be defective if the above fault tracing and corrective action does not remedy the fault.

Other information

1. To clean the camshaft reset valve, see «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To check the engine oil pressure, see «Checking oil pressure»(ref-440290-S04777117452011121400000)
3. To adjust the camshaft position (CMP), see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)
4. To replace the camshaft reset valve, see «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000) .

1. Continue Refer to «Verification»(ref-440291-S35299525352011121400000)

If the diagnostic trouble code (DTC) for this fault is stored but the adaptation value is correct, the fault is intermittent. The cause of the intermittent fault is probably a defective camshaft reset valve.

HINT: Faults may result from dirt in the camshaft reset valve. Try cleaning the valve.

Other information

1. To clean the camshaft reset valve, see «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To replace the camshaft reset valve, see «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
3. To adjust the camshaft position (CMP), see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000) .

1. Continue Refer to «Verification»(ref-440291-S35299525352011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S31176657242011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking component

Check camshaft position (CMP) sensor connector for contact resistance and oxidation according to Contact resistance and oxidation

Remedy as necessary

Other information

1. For the camshaft reset valve diagnostic functions, see «Camshaft diagnostics»(ref-440292-S41918985682011121400000) .
2. To access/replace the camshaft position (CMP) sensor, see «Replacing camshaft position (CMP) sensor»(ref-440291-S02296319142011121400000) .
3. For information about signals, see «Signal specification»(ref-440214-S33124753252011121400000) .

Scheme 294

1. Continue Refer to «Verification»(ref-440291-S18311738052011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the engine. Check the camshaft adaptation by reading off the adaptation values of the camshaft (flanks 1-4). All values must be between -7° and +7°. Turbocharged engines: When checking, the accelerator pedal (AP) must be depressed slightly but the engine speed must be below 1200 RPM. Naturally aspirated engines: When checking the engine must be idling. HINT: Theoretically the values for flanks 1-4 should be the same, however because of mechanical tolerances the values may vary between the different flanks by approximately 2°.

Are all the adaptation values correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S25197236252011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Replacing camshaft position (CMP) sensor

Removing camshaft position (CMP) sensor

1. Disconnect camshaft position (CMP) sensor connector.
2. Unscrew the sensor mounting screw and withdraw the sensor.

Installing camshaft position (CMP) sensor

In reverse order.

Tighten to 12 Nm.

Faulty control

See Faulty control

See Faulty control

Checking status

1. Start the engine. Check the camshaft adaptation by reading off the adaptation values of the camshaft (flanks 1-4). All values must be between -7° and +7°. Turbocharged engines: When checking, the accelerator pedal (AP) must be depressed slightly but the engine speed must be below 1200 RPM. Naturally aspirated engines: When checking the engine must be idling. HINT: Theoretically the values for flanks 1-4 should be the same, however because of mechanical tolerances the values may vary between the different flanks by approximately 2°. If all the adaptation values are correct (between -7° and +7°) the fault is intermittent. If any adaptation value is incorrect (lower than -7° or higher than +7°), the fault is permanent. Other information: For further information about variable valve timing control, see «Variable valve timing control»(ref-461760-S01132949542012040200000) To adjust the camshaft position (CMP) on 5-cylinder engines, see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S04072828902012040200000) To adjust the camshaft position (CMP) on 6-cylinder engines, see «Camshaft seal / variable valve timing (VVT) unit, replacing»(ref-440293-S26914517422011121400000) To replace the camshaft reset valve on 6-cylinder engines, see «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000) .

Are the adaptation values correct?

1. YES Refer to «Intermittent fault»(ref-440291-S28283018182011121400000)
2. NO Refer to «Checking the camshaft adjustment»(ref-440291-S32059689782011121400000)

Checking adaptation

1. Start the engine. Check the camshaft adaptation by reading off the adaptation values of the camshaft (flanks 1-4). All values must be between -7° and +7°. Turbocharged engines: When checking, the accelerator pedal (AP) must be depressed slightly but the engine speed must be below 1200 RPM. Naturally aspirated engines: When checking the engine must be idling. HINT: Theoretically the values for flanks 1-4 should be the same, however because of mechanical tolerances the values may vary between the different flanks by approximately +/-2°. If all the adaptation values are correct (between -7° and +7°) the fault is cured by adjusting the camshaft settings. If the adaptation values are -20° or +20° (maximum adaptation) and the camshaft setting has been adjusted, the camshaft reset valve is defective. If any adaptation value is between -20° and -8° or between +8° and +20° (not maximum adaptation but higher or lower than 7°) and the camshaft setting has been adjusted, the variable valve timing unit is defective. Remedy as necessary. Other information: To replace the camshaft reset valve on 6-cylinder engines, see «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000) To adjust the camshaft position (CMP) on 5 cylinder engines, see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S04072828902012040200000) To adjust the camshaft position (CMP) on 6 cylinder engines, see «Replacing the camshaft seals / variable valve timing unit»(ref-440293-S39941701822011121400000) For further information about variable valve timing control, see «Variable valve timing control»(ref-461760-S01132949542012040200000) .

1. Continue Refer to «Verification»(ref-440291-S05189077292011121400000)

If the diagnostic trouble code (DTC) for this fault is stored but the adaptation values are correct, the fault is intermittent. The cause of the intermittent fault is probably a defective camshaft reset valve.

HINT: If the diagnostic trouble code (DTC) for the fault recurs after erasing diagnostic trouble codes (DTCs) and the camshaft reset valve is not defective, the variable valve timing unit may be defective.

Other information

1. For further information about variable valve timing control, see «Variable valve timing control»(ref-461760-S01132949542012040200000)
2. To replace the camshaft reset valve on 6-cylinder engines, see «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
3. To adjust the camshaft position (CMP) on 5 cylinder engines, see «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S04072828902012040200000)
4. To adjust the camshaft position (CMP) on 6 cylinder engines, see «Replacing the camshaft seals / variable valve timing unit»(ref-440293-S39941701822011121400000) .

1. Continue Refer to «Verification»(ref-440291-S05189077292011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Ignition on
4. Start the engine. Check the camshaft adaptation by reading off the adaptation values of the camshaft (flanks 1-4). All values must be between -7° and +7°. Turbocharged engines: When checking, the accelerator pedal (AP) must be depressed slightly but the engine speed must be below 1200 RPM. Naturally aspirated engines: When checking the engine must be idling. HINT: Theoretically the values for flanks 1-4 should be the same, however because of mechanical tolerances the values may vary between the different flanks by approximately 2°.

Are all the adaptation values correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S20754345082011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Faulty position

See Faulty position

See Faulty position

1. Check the engine oil level and quality. Check for contaminants in particular.
2. Check the engine oil pressure.
3. Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination. NOTE: If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced. Try with a new camshaft reset valve if no fault is found in the above troubleshooting. HINT: If the fault persists after carrying out the above checks or corrective action, this can mean a damaged VVT unit. Remedy as necessary. Other information See «Checking oil pressure»(ref-440290-S04777117452011121400000) To access/replace the camshaft reset valve, see: «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000) See «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-440293-S12558219492011121400000) See «Variable valve timing control»(ref-461760-S01132949542012040200000)

1. Continue Refer to «Verification»(ref-440291-S02143682242011121400000)

HINT: This problem may be caused by small air bubbles in the engine oil. The bubbles are air that has penetrated since the O-ring gaskets in the oil sump are old. Investigate the gaskets in the oil sump.

Check the resistance on camshaft reset valve between terminals #1 and #2. Resistance must be approximately 3.7 ohms.

Check the signal cable between Engine control module (ECM) terminal #A13 and camshaft reset valve terminal #2. Check for an open-circuit, short-circuit to ground and short-circuit to voltage.

Check the power supply cable between system relay terminal #5 and camshaft reset valve terminal #1. Check for an open-circuit.

Check the engine oil level and quality. Check for contaminants in particular.

Check the engine oil pressure.

Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination.

Note. If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced.

HINT: The diagnostic trouble code (DTC) can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

1. See «Oil sump replacement»(ref-440293-S41478745532011121400000)
2. See «Checking wiring and terminals»(ref-440209-S33835172972011121400000)
3. See «Connecting the breakout box»(ref-440211-S03702023042011121400000)
4. For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000)
5. For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000)
6. For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000)
7. For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
8. See «Checking oil pressure»(ref-440290-S04777117452011121400000)
9. To access/replace the camshaft reset valve, see: «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
10. See «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-440293-S12558219492011121400000)
11. See «Variable valve timing control»(ref-461760-S01132949542012040200000)

Scheme 295

1. Continue Refer to «Verification»(ref-440291-S02143682242011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Read off the camshaft shift angle and the camshaft shift angle, desired value. Check at idle speed and at approximately 4000 RPM that the camshaft shift angle, desired value, corresponds to the camshaft shift angle to an accuracy of 3°. The difference between the values can be read off in the lower display. Carry out the check at stable engine speed (RPM). NOTE: Before the engine speed stabilizes, the difference between the values may be 3° over approximately 1 second. This is normal. If the values correspond with an accuracy of 3°, it indicates that the fault is intermittent. If the values deviate by more than 3° it indicates that the fault is permanent.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S14360779402011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine. Read off the camshaft shift angle and the camshaft shift angle, desired value. At idle and at 4000 RPM, check that the camshaft's shift angle (desired value) corresponds with the camshaft's shift angle by an accuracy of 3 degrees. The difference between the values can be read off in the lower display. Carry out the check at stable engine speed (RPM). NOTE: Before the engine speed (RPM) stabilizes, the difference between the values can be greater than 3 degrees for approximately 1 second, this is normal. If the values correspond by an accuracy of 3 degrees, this means that the fault is intermittent. If the values deviate more than 3 degrees, this means that the fault is permanent.

Do the values match?

1. NO Refer to «Checking the components and wiring»(ref-440291-S37046445262011121400000)
2. YES Refer to «Intermittent fault»(ref-440291-S32909221892011121400000)

1. Check the engine oil level and quality. Check for contaminants in particular.
2. Check the engine oil pressure.
3. Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination. NOTE: If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced. Try with a new camshaft reset valve if no fault is found in the above troubleshooting. HINT: If the fault persists after carrying out the above checks or corrective action, this can mean a damaged VVT unit. Remedy as necessary. Other information See «Checking oil pressure»(ref-440290-S04777117452011121400000) To access/replace the camshaft reset valve, see: «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000) See «Replacing the camshaft seals / variable valve timing unit»(ref-440293-S09774996162011121400000) See «Variable valve timing control»(ref-461760-S01132949542012040200000)

1. Continue Refer to «Verification»(ref-440291-S09537232382011121400000)

HINT: This problem may be caused by small air bubbles in the engine oil. The bubbles are air that has penetrated since the O-ring gaskets in the oil sump are old. Investigate the gaskets in the oil sump.

Check the resistance on camshaft reset valve between terminals #1 and #2. Resistance must be approximately 3.7 ohms.

Check the signal cable between Engine control module (ECM) terminal #A13 and camshaft reset valve terminal #2. Check for an open-circuit, short-circuit to ground and short-circuit to voltage.

Check the power supply cable between system relay terminal #5 and camshaft reset valve terminal #1. Check for an open-circuit.

Check the engine oil level and quality. Check for contaminants in particular.

Check the engine oil pressure.

Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination.

Note. If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced.

HINT: The diagnostic trouble code (DTC) can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

1. See «Oil sump replacement»(ref-440293-S41478745532011121400000)
2. See «Checking wiring and terminals»(ref-440209-S33835172972011121400000)
3. See «Connecting the breakout box»(ref-440211-S03702023042011121400000)
4. For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000)
5. For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000)
6. For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000)
7. For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
8. See «Checking oil pressure»(ref-440290-S04777117452011121400000)
9. To access/replace the camshaft reset valve, see: «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
10. See «Replacing the camshaft seals / variable valve timing unit»(ref-440293-S09774996162011121400000)
11. See «Variable valve timing control»(ref-461760-S01132949542012040200000)

1. Continue Refer to «Verification»(ref-440291-S09537232382011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Read off the camshaft shift angle and the camshaft shift angle, desired value. Check at idle speed and at approximately 4000 RPM that the camshaft shift angle, desired value, corresponds to the camshaft shift angle to an accuracy of 3°. The difference between the values can be read off in the lower display. Carry out the check at stable engine speed (RPM). NOTE: Before the engine speed stabilizes, the difference between the values may be 3° over approximately 1 second. This is normal. If the values correspond with an accuracy of 3°, it indicates that the fault is intermittent. If the values deviate by more than 3° it indicates that the fault is permanent.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S08319635412011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine. Read off the camshaft shift angle and the camshaft shift angle, desired value. At idle and at 4000 RPM, check that the camshaft's shift angle (desired value) corresponds with the camshaft's shift angle by an accuracy of 3 degrees. The difference between the values can be read off in the lower display. Carry out the check at stable engine speed (RPM). NOTE: Before the engine speed (RPM) stabilizes, the difference between the values can be greater than 3 degrees for approximately 1 second, this is normal. If the values correspond by an accuracy of 3 degrees, this means that the fault is intermittent. If the values deviate more than 3 degrees, this means that the fault is permanent.

Do the values match?

1. NO Refer to «Checking the components and wiring»(ref-440291-S30074576652011121400000)
2. YES Refer to «Intermittent fault»(ref-440291-S34182970972011121400000)

1. Check the engine oil level and quality. Check for contaminants in particular.
2. Check the engine oil pressure.
3. Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination. NOTE: If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced. Try with a new camshaft reset valve if no fault is found in the above troubleshooting. HINT: If the fault persists after carrying out the above checks or corrective action, this can mean a damaged VVT unit. Remedy as necessary. Other information See «Checking oil pressure»(ref-440290-S04777117452011121400000) To access/replace the camshaft reset valve, see: «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000) See «Replacing the camshaft seals / variable valve timing unit»(ref-440293-S39941701822011121400000) See «Variable valve timing control»(ref-461760-S01132949542012040200000)

1. Continue Refer to «Verification»(ref-440291-S29380761182011121400000)

HINT: This problem may be caused by small air bubbles in the engine oil. The bubbles are air that has penetrated since the O-ring gaskets in the oil sump are old. Investigate the gaskets in the oil sump.

Check the resistance on camshaft reset valve between terminals #1 and #2. Resistance must be approximately 3.7 ohms.

Check the signal cable between Engine control module (ECM) terminal #A13 and camshaft reset valve terminal #2. Check for an open-circuit, short-circuit to ground and short-circuit to voltage.

Check the power supply cable between system relay terminal #5 and camshaft reset valve terminal #1. Check for an open-circuit.

Check the engine oil level and quality. Check for contaminants in particular.

Check the engine oil pressure.

Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination.

Note. If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced.

HINT: The diagnostic trouble code (DTC) can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

1. See «Oil sump replacement»(ref-440293-S41478745532011121400000)
2. See «Checking wiring and terminals»(ref-440209-S33835172972011121400000)
3. See «Connecting the breakout box»(ref-440211-S03702023042011121400000)
4. For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000)
5. For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000)
6. For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000)
7. For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
8. See «Checking oil pressure»(ref-440290-S04777117452011121400000)
9. To access/replace the camshaft reset valve, see: «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
10. See «Replacing the camshaft seals / variable valve timing unit»(ref-440293-S39941701822011121400000)
11. See «Variable valve timing control»(ref-461760-S01132949542012040200000)

1. Continue Refer to «Verification»(ref-440291-S29380761182011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Read off the camshaft shift angle and the camshaft shift angle, desired value. Check at idle speed and at approximately 4000 RPM that the camshaft shift angle, desired value, corresponds to the camshaft shift angle to an accuracy of 3°. The difference between the values can be read off in the lower display. Carry out the check at stable engine speed (RPM). NOTE: Before the engine speed stabilizes, the difference between the values may be 3° over approximately 1 second. This is normal. If the values correspond with an accuracy of 3°, it indicates that the fault is intermittent. If the values deviate by more than 3° it indicates that the fault is permanent.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S37669150112011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine. Read off the camshaft shift angle and the camshaft shift angle, desired value. At idle and at 4000 RPM, check that the camshaft's shift angle (desired value) corresponds with the camshaft's shift angle by an accuracy of 3 degrees. The difference between the values can be read off in the lower display. Carry out the check at stable engine speed (RPM). NOTE: Before the engine speed (RPM) stabilizes, the difference between the values can be greater than 3 degrees for approximately 1 second, this is normal. If the values correspond by an accuracy of 3 degrees, this means that the fault is intermittent. If the values deviate more than 3 degrees, this means that the fault is permanent.

Do the values match?

1. NO Refer to «Checking the components and wiring»(ref-440291-S06418221412011121400000)
2. YES Refer to «Intermittent fault»(ref-440291-S15312166632011121400000)

1. Check the engine oil level and quality. Check for contaminants in particular.
2. Check the engine oil pressure.
3. Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination. NOTE: If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced. Try with a new camshaft reset valve if no fault is found in the above troubleshooting. HINT: If the fault persists after carrying out the above checks or corrective action, this can mean a damaged VVT unit. Remedy as necessary. Other information See «Checking oil pressure»(ref-440290-S04777117452011121400000) To access/replace the camshaft reset valve, see: «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000) See «Camshaft seal / variable valve timing (VVT) unit, replacing»(ref-440293-S26914517422011121400000) See «Variable valve timing control»(ref-461760-S01132949542012040200000)

1. Continue Refer to «Verification»(ref-440291-S21008083632011121400000)

HINT: This problem may be caused by small air bubbles in the engine oil. The bubbles are air that has penetrated since the O-ring gaskets in the oil sump are old. Investigate the gaskets in the oil sump.

Check the resistance on camshaft reset valve between terminals #1 and #2. Resistance must be approximately 3.7 ohms.

Check the signal cable between Engine control module (ECM) terminal #A13 and camshaft reset valve terminal #2. Check for an open-circuit, short-circuit to ground and short-circuit to voltage.

Check the power supply cable between system relay terminal #5 and camshaft reset valve terminal #1. Check for an open-circuit.

Check the engine oil level and quality. Check for contaminants in particular.

Check the engine oil pressure.

Remove the camshaft reset valve. Check the oil ducts in the cylinder head for the camshaft's reset valve. Check for blockage and contamination.

Note. If it is suspected that there are any contaminants in the camshaft reset valve it should be replaced.

HINT: The diagnostic trouble code (DTC) can also be caused by a damaged variable valve timing (VVT) unit.

Remedy as necessary.

Other information

1. See «Oil sump replacement»(ref-440293-S41478745532011121400000)
2. See «Checking wiring and terminals»(ref-440209-S33835172972011121400000)
3. See «Connecting the breakout box»(ref-440211-S03702023042011121400000)
4. For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000)
5. For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000)
6. For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000)
7. For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
8. See «Checking oil pressure»(ref-440290-S04777117452011121400000)
9. To access/replace the camshaft reset valve, see: «Variable valve timing solenoid, replacing»(ref-440293-S14706191732011121400000)
10. See «Camshaft seal / variable valve timing (VVT) unit, replacing»(ref-440293-S26914517422011121400000)
11. See «Variable valve timing control»(ref-461760-S01132949542012040200000)

1. Continue Refer to «Verification»(ref-440291-S21008083632011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine. Read off the camshaft shift angle and the camshaft shift angle, desired value. Check at idle speed and at approximately 4000 RPM that the camshaft shift angle, desired value, corresponds to the camshaft shift angle to an accuracy of 3°. The difference between the values can be read off in the lower display. Carry out the check at stable engine speed (RPM). NOTE: Before the engine speed stabilizes, the difference between the values may be 3° over approximately 1 second. This is normal. If the values correspond with an accuracy of 3°, it indicates that the fault is intermittent. If the values deviate by more than 3° it indicates that the fault is permanent.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S09229516002011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Slow regulation

See Slow regulation

See Slow regulation

See Slow regulation

See Slow regulation

Signal missing

See Signal missing

Signal too high

See Signal too high

Signal too low

See Signal too low

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and let it run at idle speed
4. Activate the malfunction indicator lamp (MIL)
5. Check that the function is OK.

Is function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S02859248042011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and let it run at idle speed
4. Activate the malfunction indicator lamp (MIL)
5. Check that the function is OK.

Is function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S09711502462011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and let it run at idle speed
4. Activate the malfunction indicator lamp (MIL)
5. Check that the function is OK.

Is function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S07975439712011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and let it run at idle speed
4. Activate the malfunction indicator lamp (MIL)
5. Check that the function is OK.

Is function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S05764732422011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature
2. Read off and note the adaptation value for the camshaft at idle speed. The value must be between -8° and +8°. The fault is intermittent if the adaptation value is between -8° and +8°. The fault is permanent if the adaptation value is lower than -8° or higher than +8°.

Is the adaptation value correct?

1. YES Refer to «Intermittent fault»(ref-440291-S09609897032011121400000)
2. NO Refer to «Checking components»(ref-440291-S36096035052011121400000)

For the variable valve timing control to work, the engine oil must be at the correct level, of the correct grade and free of contaminants.

Check the level and quality of the engine oil. Check for contaminants in particular.

If the adaptation value is too high (higher than +8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. Camshaft belt incorrectly seated
2. Incorrect basic setting of the timing belt
3. Faulty camshaft reset valve (the slide in the valve has stuck).

Try to adjust the basic setting of the camshaft. Then read off the adaptation value for the camshaft with the engine idling and at operating temperature. The value must be between -8° and +8°. If the adaptation value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To adjust camshaft settings: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)
3. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)

1. Continue Refer to «Verification»(ref-440291-S07826345482011121400000)

If the diagnostic trouble code (DTC) for this fault is stored but the adaptation value is correct, the fault is intermittent. Cause of the intermittent fault is probably a damaged camshaft reset valve.

HINT: The fault can be caused by contaminants in the camshaft reset valve. Try cleaning the valve.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
3. To adjust camshaft settings: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)

1. Continue Refer to «Verification»(ref-440291-S07826345482011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S41966285812011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature
2. Read off and note the adaptation value for the camshaft at idle speed. The value must be between -8° and +8°. The fault is intermittent if the adaptation value is between -8° and +8°. The fault is permanent if the adaptation value is lower than -8° or higher than +8°.

Is the adaptation value correct?

1. YES Refer to «Intermittent fault»(ref-440291-S12223670482011121400000)
2. NO Refer to «Checking components»(ref-440291-S06351121762011121400000)

For the variable valve timing control to work, the engine oil must be at the correct level, of the correct grade and free of contaminants.

Check the level and quality of the engine oil. Check for contaminants in particular.

If the adaptation value is too high (higher than +8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. Camshaft belt incorrectly seated
2. Incorrect basic setting of the timing belt
3. Faulty camshaft reset valve (the slide in the valve has stuck).

Try to adjust the basic setting of the camshaft. Then read off the adaptation value for the camshaft with the engine idling and at operating temperature. The value must be between -8° and +8°. If the adaptation value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To adjust the camshaft position (CMP), see: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)
3. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)

1. Continue Refer to «Verification»(ref-440291-S40925080442011121400000)

If the diagnostic trouble code (DTC) for this fault is stored but the adaptation value is correct, the fault is intermittent. Cause of the intermittent fault is probably a damaged camshaft reset valve.

HINT: The fault can be caused by contaminants in the camshaft reset valve. Try cleaning the valve.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
3. To adjust the camshaft position (CMP), see: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)

1. Continue Refer to «Verification»(ref-440291-S40925080442011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S34537960662011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature
2. Read off and note the adaptation value for the camshaft at idle speed. The value must be between -8° and +8°. The fault is intermittent if the adaptation value is between -8° and +8°. The fault is permanent if the adaptation value is lower than -8° or higher than +8°.

1. Continue Refer to «Checking components»(ref-440291-S14247166432011121400000)

For the variable valve timing control to work, the engine oil must be at the correct level, of the correct grade and free of contaminants.

Check the level and quality of the engine oil. Check for contaminants in particular.

Adjust the camshaft settings.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Other information

1. To adjust the camshaft position (CMP), see: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)

1. Continue Refer to «Verification»(ref-440291-S06350115342011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S39403146792011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature
2. Read off and note the adaptation value for the camshaft at idle speed. The value must be between -8° and +8°. The fault is intermittent if the adaptation value is between -8° and +8°. The fault is permanent if the adaptation value is lower than -8° or higher than +8°.

Is the adaptation value correct?

1. YES Refer to «Intermittent fault»(ref-440291-S29859100762011121400000)
2. NO Refer to «Checking components»(ref-440291-S03816623352011121400000)

For the variable valve timing control to work, the engine oil must be at the correct level, of the correct grade and free of contaminants.

Check the level and quality of the engine oil. Check for contaminants in particular.

If the adaptation value is too high (higher than +8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. Camshaft belt incorrectly seated
2. Incorrect basic setting of the timing belt
3. Faulty camshaft reset valve (the slide in the valve has stuck).

HINT: Try to adjust the basic setting of the camshaft. Then read off the adaptation value for the camshaft with the engine idling and at operating temperature. The value must be between -8° and +8°. If the adaptation value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To adjust the camshaft position (CMP), see: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)
3. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)

1. Continue Refer to «Verification»(ref-440291-S41456081232011121400000)

If the diagnostic trouble code (DTC) for this fault is stored but the adaptation value is correct, the fault is intermittent. Cause of the intermittent fault is probably a damaged camshaft reset valve.

HINT: The fault can be caused by contaminants in the camshaft reset valve. Try cleaning the valve.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
3. To adjust the camshaft position (CMP), see: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)

1. Continue Refer to «Verification»(ref-440291-S41456081232011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S04830828282011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature
2. Read off and note the adaptation value for the camshaft at idle speed. The value must be between -8° and +8°. The fault is intermittent if the adaptation value is between -8° and +8°. The fault is permanent if the adaptation value is lower than -8° or higher than +8°.

Is the adaptation value correct?

1. YES Refer to «Intermittent fault»(ref-440291-S33570016812011121400000)
2. NO Refer to «Checking components»(ref-440291-S04536444272011121400000)

For the variable valve timing control to work, the engine oil must be at the correct level, of the correct grade and free of contaminants.

Check the level and quality of the engine oil. Check for contaminants in particular.

If the adaptation value is too high (higher than +8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. Camshaft belt incorrectly seated
2. Incorrect basic setting of the timing belt
3. Faulty camshaft reset valve (the slide in the valve has stuck).

HINT: Try to adjust the basic setting of the camshaft. Then read off the adaptation value for the camshaft with the engine idling and at operating temperature. The value must be between -8° and +8°. If the adaptation value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault can also be caused by a damaged variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. To adjust the camshaft position (CMP), see: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)
3. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)

1. Continue Refer to «Verification»(ref-440291-S30797252242011121400000)

If the diagnostic trouble code (DTC) for this fault is stored but the adaptation value is correct, the fault is intermittent. Cause of the intermittent fault is probably a damaged camshaft reset valve.

HINT: The fault can be caused by contaminants in the camshaft reset valve. Try cleaning the valve.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
3. To adjust the camshaft position (CMP), see: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)

1. Continue Refer to «Verification»(ref-440291-S30797252242011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S33102753482011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Start the engine and run it to normal operating temperature
2. Read off and note the adaptation value for the camshaft at idle speed. The value must be between -8° and +8°. The fault is intermittent if the adaptation value is between -8° and +8°. The fault is permanent if the adaptation value is lower than -8° or higher than +8°.

Is the adaptation value correct?

1. YES Refer to «Intermittent fault»(ref-440291-S21564929982011121400000)
2. NO Refer to «Checking components»(ref-440291-S09874355482011121400000)

In order for the variable valve timing control to function correctly, the correct grade of engine oil must be used. The oil must be clean and the oil pressure must be correct.

Check the level and quality of the engine oil. Check for contaminants in particular.

Check the engine oil pressure.

Remedy as necessary.

If no fault is found in the above fault tracing and the adaptation value is too low (lower than -8°) when the engine is at operating temperature, the cause of the fault is probably one of the following

1. Camshaft belt incorrectly seated
2. Incorrect basic setting of the timing belt
3. Faulty camshaft reset valve (the slide in the valve has stuck).

HINT: Try adjusting the basic setting of the camshaft if no fault is found during the above fault-tracing. Then read off the adaptation value for the camshaft with the engine idling and at operating temperature. The value must be between -8° and +8°. If the adaptation value is incorrect when the basic setting of the camshaft is correct, try cleaning the camshaft reset valve.

Note. The camshafts must be adjusted using the adjustment tool for the camshafts and crankshaft in the prescribed manner.

Try a new camshaft reset valve if the above fault-tracing does not solve the fault.

Remedy as necessary.

HINT: The fault may also be caused by a defective variable valve timing unit. The variable valve timing unit may be damaged if the above fault-tracing and corrective action do not remedy the fault.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. See «Checking oil pressure»(ref-440290-S04777117452011121400000)
3. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
4. To adjust the camshaft position (CMP), see: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)

1. Continue Refer to «Verification»(ref-440291-S03701148832011121400000)

The fault is intermittent if the diagnostic trouble code (DTC) for this fault is stored but the adaptation value is correct. Cause of the intermittent fault is probably a damaged camshaft reset valve.

HINT: The fault can be caused by contaminants in the camshaft reset valve. Try cleaning the valve.

Other information

1. See «VVT solenoid, inspection and cleaning»(ref-461760-S18954093482012040200000)
2. See «VARIABLE VALVE TIMING SOLENOID, REPLACING»(ref-440293-S04742139552011121400000)
3. To adjust the camshaft position (CMP), see: «Camshaft seal/variable valve timing (VVT) unit, replacing»(ref-461752-S25200707242012040200000)

1. Continue Refer to «Verification»(ref-440291-S03701148832011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine and run it to normal operating temperature
2. Read off the camshaft adaptation at idle speed. The adaptation value must be between -8° and +8. The function is OK if the adaptation value is correct.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S18894523232011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

See Signal missing. Permanent fault

See Signal missing. Permanent fault

See Signal missing. Permanent fault

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

See Signal too high. Permanent fault

See Signal too high. Permanent fault

See Signal too high. Permanent fault

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

Checking the hoses and the turbocharger (TC) control valve

Check that the hoses between the pressure servo for the boost pressure control (BPC) valve and the turbocharger (TC) control valve are not trapped, blocked or damaged.

Check that the hoses between the turbocharger (TC) control valve and the charge air pipe (between the turbocharger (TC) and the charge air cooler (CAC)) are not trapped, blocked or damaged.

Check the turbocharger (TC) control valve by activating it. The turbocharger (TC) control valve must click when it is activated.

Check the setting of the waste gate valve's pressure servo as well as the waste gate valve. Check the function and check for jamming according to: Wastegate valve, adjusting

Other information

1. To access the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000) .

1. Continue Refer to «Verification»(ref-440291-S37991177812011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 296

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT 2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT 2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT 2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status display as not found?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S36237564242011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check that the hoses between the pressure servo for the boost pressure control (BPC) valve and the turbocharger (TC) control valve are not trapped, blocked or damaged.

Check that the hoses between the turbocharger (TC) control valve and the charge air pipe (between the turbocharger (TC) and the charge air cooler (CAC)) are not trapped, blocked or damaged.

Check the turbocharger (TC) control valve by activating it. The turbocharger (TC) control valve must click when it is activated.

Check the setting of the waste gate valve's pressure servo as well as the waste gate valve. Check the function and check for jamming according to: Pressure regulator, checking/adjusting

Other information

1. To access the turbocharger (TC) control valve, see «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000) .

1. Continue Refer to «Verification»(ref-440291-S22633663912011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT 2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT 2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT 2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status display as not found ?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S19907470702011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check that the hoses between the intake manifold, the pressure regulator and the turbocharger (TC) control valve are not trapped, blocked or damaged.

Check the turbocharger (TC) control valve by activating it.

Check the setting of the waste gate valve's pressure servo as well as the waste gate valve. Check the function and check for jamming according to: Pressure regulator, checking/adjusting

Other information

1. See «Replacing the turbocharger (TC) control valve»(ref-440280-S33817022192011121400000)

1. Continue Refer to «Verification»(ref-440291-S05419605572011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT 2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT 2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT 2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status display as not found ?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S11554197322011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Check intake system for leakage according to Check for air leaks in the intake system .

Remedy as necessary

1. Continue Refer to «Verification»(ref-440291-S24350630832011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT 2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT 2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT 2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status. When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status displayed as "Ready, no fault"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S00783221182011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the hoses and turbocharger (TC) control valve

Check that the hoses between the intake manifold, pressure regulator and turbocharger (TC) control valve are not trapped, blocked or damaged.

Check the turbocharger (TC) control valve by activating it.

Check the setting of the waste gate valve's pressure servo as well as the waste gate valve. Check the function and check for jamming according to: Pressure regulator, checking/adjusting

Remedy as necessary

1. Continue Refer to «Verification»(ref-440291-S03563432832011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT 2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT 2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT 2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status. When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status displayed as "Ready, no fault"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S15609040652011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking turbo system

Check the turbocharger (TC) control valve by activating it. The turbocharger (TC) control valve must click when it is activated.

Check the setting of the waste gate valve's pressure servo as well as the waste gate valve. Check the function and check for jamming according to: Wastegate valve, adjusting

Other information

1. See «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000)
2. See «Quick check, turbocharger (TC)»(ref-440268-S27606993462011121400000)
3. See «Turbocharger (TC)»(ref-440280-S01433931702011121400000)

1. Continue Refer to «Verification»(ref-440291-S25989080392011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT 2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT 2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT 2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status. When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status displayed as "Ready, no fault"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S26570923662011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking for air leakage

1. Ignition off.

Check the intake system for air leakage and loose charge-air pipe.

See Air leakage in the intake system, checking

Does the problem persist?

1. YES Refer to «Checking turbo system»(ref-440291-S01949523342011121400000)
2. NO Refer to «Verification»(ref-440291-S21650593472011121400000)

Check the turbocharger (TC) control valve by activating it. The turbocharger (TC) control valve must click when it is activated.

Check the setting of the waste gate valve's pressure servo as well as the waste gate valve. Check the function and check for jamming according to: Pressure regulator, checking/adjusting

Other information

1. See «Replacing the turbocharger (TC) control valve»(ref-440280-S37124804542011121400000)
2. See «Quick check, turbocharger (TC)»(ref-440268-S27606993462011121400000)
3. See «Turbocharger (TC), replacing»(ref-440280-S06814885032011121400000)

1. Continue Refer to «Verification»(ref-440291-S21650593472011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT 2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT 2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT 2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status. When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status displayed as "Ready, no fault"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S17914479242011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing

See Signal too high

See Signal too low

Check that the boost pressure sensor is correctly installed and has not come loose.

Check the intake system for air leakage. Check in particular the hose between the turbocharger (TC) and the throttle unit.

The boost pressure sensor is defective if no fault is found in the above fault-tracing.

Other information

1. To check the intake system for air leakage, see «Check for air leaks in the intake system»(ref-440264-S10239834622011121400000)
2. To access or replace the boost pressure sensor, see «Temperature and pressure sensor, replacing»(ref-461759-S30434624902012040200000) .

1. Continue Refer to «Verification»(ref-440291-S06339190562011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off.
2. Reinstall connectors, components etc.
3. Disconnect the VCT 2000 from the data link connector (DLC).
4. Test drive the car and check that high boost pressure is obtained.
5. Connect the VCT 2000 to the data link connector (DLC). NOTE: Do not switch off the ignition before the VCT 2000 has been connected and the boost pressure has been tested with the smart tool. Read off the boost pressure fault status. When the boost pressure has been tested the display should show that the diagnostic is complete.

Is the fault status displayed as "Ready, no fault"?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S41050109342011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and let it run at idle speed
4. Activate the malfunction indicator lamp (MIL)
5. Check that the function is OK.

Is function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S24301478152011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and let it run at idle speed
4. Activate the malfunction indicator lamp (MIL)
5. Check that the function is OK.

Is function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S21286688132011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal missing. Permanent fault

See Signal missing. Permanent fault

See Signal missing. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and let it run at idle speed
4. Activate the malfunction indicator lamp (MIL)
5. Check that the function is OK.

Is function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S29282468622011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall the connectors, components etc.
3. Start the engine and let it run at idle speed
4. Activate the malfunction indicator lamp (MIL)
5. Check that the function is OK.

Is function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S02903872302011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

Internal fault

See Internal fault

See Internal fault

Checking the component

HINT: The diagnostic trouble code (DTC) may due to a damaged cooling fan for the control module boxes. If diagnostic trouble code (DTC) ECM-680X is stored it must be remedied first.

Activate the cooling fan for the control module box. Check the function. There must be a buzzing noise from the cooling fan when the fan for the control module box is activated.

Check that the air ducts for the control module box are not blocked.

Remedy as necessary.

Other information

1. For the location of components on 5 cylinder engines, see «Location of components»(ref-461673-S37190921092012040200000)
2. For the location of components on 6 cylinder normally aspirated engines: For 6 cylinder naturally aspirated engines -2001, see «Location of components»(ref-440286-S07141424702011121400000) For 6 cylinder naturally aspirated engines 2002, see «Location of components, engine compartment»(ref-440286-S07948714472011121400000) For 6 cylinder naturally aspirated engines 2003-, see «Location of components, engine compartment»(ref-440286-S42548706262011121400000) .
3. For the location of components on 6 cylinder turbocharged engines: For 6 cylinder turbocharged engines -2001, see «Location of components»(ref-440286-S18591874812011121400000) For 6 cylinder turbocharged engines 2002, see «Location of components, engine compartment»(ref-440286-S07948714472011121400000) For 6 cylinder turbocharged engines 2003-, see «Location of components, engine compartment»(ref-440286-S42548706262011121400000) .

1. Continue Refer to «Information»(ref-440291-S20734758992011121400000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

Faulty signal

See Faulty signal

Information

This diagnostic trouble code (DTC) indicates that the immobilizer code does not match between the engine control module (ECM) and the central electronic module (CEM). This may be because

1. the immobilizer code in the engine control module (ECM) is incorrect i. e. the code does not correspond to the code stored in the central electronic module (CEM)
2. the engine control module (ECM) is not programmed and has no immobilizer code
3. the immobilizer code in the central electronic module (CEM) is incorrect
4. the central electronic module (CEM) is not programmed and has no immobilizer code
5. the engine control module (ECM) is damaged
6. the central electronic module (CEM) is damaged.

Note. A programmed engine control module (ECM) or central electronic module (CEM) cannot be moved from one vehicle to another.

HINT: Read off the diagnostic trouble codes (DTCs) for the central electronic module (CEM).

For further information about this diagnostic trouble code (DTC), select Information, then DTC information.

Other information

1. To access and replace the engine control module (ECM), see «Engine control module (ECM), replacing»(ref-440263-S40872388582011121400000)
2. To access or replace the central electronic module (CEM), see «Central electronic module (CEM), replacing»(ref-461683-S35742770022012040200000)
3. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
4. For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

1. Continue Refer to «Verification»(ref-440291-S09583323992011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall connectors, components etc.
3. Start the engine.

Did the engine start?

1. YES OKAY: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S37221412592011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

The immobilizer function is integrated in the central electronic module (CEM).

This diagnostic trouble code (DTC) can be caused by missing CAN communication. If there is a diagnostic trouble code (DTC) stored in the central electronic module (CEM) fault trace accordingly.

If no diagnostic trouble codes (DTCs) are stored in the central electronic module (CEM), try a new central electronic module (CEM).

Other information

1. To access or replace the central electronic module (CEM), see «Central electronic module (CEM), replacing»(ref-461683-S35742770022012040200000)
2. To access and replace the engine control module (ECM), see «Engine control module (ECM), replacing»(ref-440263-S40872388582011121400000)
3. For signal specifications for the central electronic module (CEM): -2004: «Signal specification»(ref-440221-S13875419782011121400000) 2005-: «Signal specification»(ref-440221-S31671939612011121400000)
4. For information about signals on 5-cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
5. For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .

1. Continue Refer to «Information»(ref-440291-S14650987942011121400000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

Signal too high/signal too low. Intermittent fault

See Signal too high/signal too low. Intermittent fault

See Signal too high/signal too low. Intermittent fault

Signal too high/signal too low. Permanent fault

See Signal too high/signal too low. Permanent fault

See Signal too high/signal too low. Permanent fault

HINT: The fault may be due to a defective cooling fan for the control modules. If diagnostic trouble code (DTC) ECM-6220 is stored it must be remedied first.

Activate the cooling fan for the control modules. Check the function. There must be a buzzing noise from the cooling fan when the fan for the control modules is activated.

Check that the air ducts for the control module box are not blocked.

Remedy as necessary.

Other information

1. For the location of components on 5 cylinder engines, see «Location of components»(ref-461673-S37190921092012040200000)
2. For the location of components on 6 cylinder normally aspirated engines: For 6 cylinder naturally aspirated engines -2001, see «Location of components»(ref-440286-S07141424702011121400000) For 6 cylinder naturally aspirated engines 2002, see «Location of components, engine compartment»(ref-440286-S07948714472011121400000) For 6 cylinder naturally aspirated engines 2003-, see «Location of components, engine compartment»(ref-440286-S42548706262011121400000) .
3. For the location of components on 6 cylinder turbocharged engines: For 6 cylinder turbocharged engines -2001, see «Location of components»(ref-440286-S18591874812011121400000) For 6 cylinder turbocharged engines 2002, see «Location of components, engine compartment»(ref-440286-S07948714472011121400000) For 6 cylinder turbocharged engines 2003-, see «Location of components, engine compartment»(ref-440286-S42548706262011121400000) .

1. Continue Refer to «Information»(ref-440291-S39832317662011121400000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

See Faulty signal

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Faulty signal

See Faulty signal

See Fault-tracing information

See Fault-tracing information

See Fault-tracing information

See Signal too high/signal too low. Intermittent fault

See Signal too high/signal too low. Intermittent fault

See Signal too high/signal too low. Intermittent fault

See Signal too high/signal too low. Intermittent fault

See Signal too high/signal too low. Intermittent fault

See Signal too high/signal too low. Permanent fault

See Signal too high/signal too low. Permanent fault

See Signal too high/signal too low. Permanent fault

See Signal too high/signal too low. Permanent fault

See Signal too high/signal too low. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

The immobilizer function is integrated in the central electronic module (CEM).

The engine control module (ECM) has previously registered a fault in communication with the central electronic module (CEM), but detects that the fault no longer exists.

1. Continue Refer to «Information»(ref-440291-S03733651282011121400000)

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

See Signal missing. Intermittent fault

See Signal missing. Permanent fault

See Signal missing. Permanent fault

See Signal missing. Permanent fault

See Signal missing. Permanent fault

See Signal missing. Permanent fault

See Internal fault

See Fault-tracing information

Checking connectors and components

Check the engine control module (ECM) and the system relay connectors. Check for contact resistance. Check for oxidation.

Check the cable between system relay terminal #5 and the engine control module (ECM). Check for an open-circuit.

Remedy as necessary.

Try a new system relay if no fault is found during the above fault-tracing.

HINT: Read off the voltage from the system relay to the engine control module (ECM) by clicking on the VCT2000 symbol.

Other information

1. For information about signals for 5 cylinder engines: «Signal specification»(ref-440279-S07999612052011121400000)
2. For information about signals for 6 cylinder engines: «Signal specification»(ref-440279-S13492600202011121400000)
3. See «Contents»(ref-440209-S18666729612011121400000)

Scheme 297

1. Continue Refer to «Verification»(ref-440291-S17537200582011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition on
2. Read off the voltage from the system relay to the engine control module (ECM). Check that the voltage is correct. The voltage must be approximately 12 V.

Is the voltage correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S28588932182011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking the connectors and components

Check the battery voltage.

Check the charging function of the generator (GEN).

Check the engine control module (ECM) and system relay connectors. Check for contact resistance and oxidation.

Check the cable between system relay terminal #5 and control module terminal #A17 (#A17). Check for an open-circuit. Check for a short-circuit to ground.

Remedy as necessary.

Try a new system relay if no fault is found during the above fault-tracing.

HINT: Read off the voltage from the system relay to the engine control module (ECM) by clicking on the VCT2000 symbol.

Other information

1. To fault-trace the charging system, see «Fault-tracing and testing the voltage supply system»(ref-440215-S26701988262011121400000)
2. To connect the breakout box and access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
3. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
4. For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
5. See «Contents»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440291-S00765837212011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition on
2. Read off the voltage from the system relay to the engine control module (ECM). Check that the voltage is correct. The voltage must be approximately 12 V.

Is the voltage correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S06963235402011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal

Check the charging function of the generator (GEN). Check for high charging voltage.

Remedy as necessary.

Other information

1. To fault-trace the charging system, see «Fault-tracing and testing the voltage supply system»(ref-440215-S26701988262011121400000) .

1. Continue Refer to «Verification»(ref-440291-S23277797742011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Start the engine
2. Read off the voltage from the system relay to the engine control module (ECM). Check that the voltage is correct. The voltage must be approximately 12 V.

Is the voltage correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S03801135082011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high

Check the battery voltage.

Check the charging function of the generator (GEN).

Check the engine control module (ECM) and system relay connectors. Check for contact resistance and oxidation.

Check the cable between system relay terminal #5 and control module terminal #A17 (#A17). Check for contact resistance and oxidation.

Remedy as necessary.

Try a new system relay if no fault is found during the above fault-tracing.

HINT: Read off the voltage from the system relay to the engine control module (ECM) by clicking on the VCT2000 symbol.

Other information

1. To fault-trace the charging system, see «Fault-tracing and testing the voltage supply system»(ref-440215-S26701988262011121400000)
2. To connect the breakout box / access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
3. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
4. For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
5. See «Contents»(ref-440209-S18666729612011121400000)

1. Continue Refer to «Verification»(ref-440291-S07684071902011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition on
2. Read off the voltage from the system relay to the engine control module (ECM). Check that the voltage is correct. The voltage must be approximately 12 V.

Is the voltage correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S20581748412011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low

See Faulty signal. Intermittent fault

See Faulty signal. Intermittent fault

Checking the cable

Check the cable between system relay terminal #3 and control module terminal #A70 (#B10). Check for an open-circuit. Check for a short-circuit to ground. See Contents .

Try a new system relay if no fault is found during the above fault-tracing.

Remedy as necessary.

1. Continue Refer to «Verification»(ref-440291-S03924378692011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reinstall connectors, components etc.
3. Start the engine.

Does the engine start?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S41564632552011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Faulty signal. Permanent fault

See Faulty signal. Permanent fault

Replacing the component

Try a new charging regulator.

Was a fault detected?

1. YES OKAY: Troubleshooting has been completed.
2. NO FAULT TRACING FAILED: The fault should have been detected and remedied. As this is not the case fault-tracing has failed. Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

Replacing component

Check boost pressure according to Fault-tracing and testing the voltage supply system .

Was a fault detected?

1. YES OKAY: Troubleshooting has been completed.
2. NO FAULT TRACING FAILED: The fault should have been detected and remedied. As this is not the case fault-tracing has failed. Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

Check the cable between system relay terminal 3 and control module terminal A70 (#B10) for contact resistance and oxidation according to Contact resistance and oxidation .

Other information

1. To fault-trace the charging system, see «Fault-tracing and testing the voltage supply system»(ref-440215-S26701988262011121400000) .

Scheme 298

Was a fault detected?

1. YES OKAY: Troubleshooting has been completed.
2. NO FAULT TRACING FAILED: The fault should have been detected and remedied. As this is not the case fault-tracing has failed. Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

Check the battery voltage

Check the generator (GEN) charging voltage

Check the cable between system relay terminal 3 and control module terminal A70 (#B10) for contact resistance and oxidation according to Contact resistance and oxidation .

Other information

1. To fault-trace the charging system see «Fault-tracing and testing the voltage supply system»(ref-440215-S26701988262011121400000) .

Was a fault detected?

1. YES OKAY: Troubleshooting has been completed.
2. NO FAULT TRACING FAILED: The fault should have been detected and remedied. As this is not the case fault-tracing has failed. Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

Check the battery voltage.

Check the charging function of the generator (GEN).

Check the fuse before the circuit. If the fuse is blown, check the circuit. Check for a short-circuit to ground.

Check the cable between system relay terminal #5 and control module terminal #A17 (#A17). Check for an open-circuit.

Check the engine control module (ECM) and system relay connectors. Check for contact resistance and oxidation.

Remedy as necessary.

Try a new system relay if no fault is found during the above fault-tracing.

HINT: Read off the voltage from the system relay to the engine control module (ECM).

Other information

1. To fault-trace the charging system, see «Fault-tracing and testing the voltage supply system»(ref-440215-S26701988262011121400000)
2. To connect the breakout box and access the control module, see «Connecting the breakout box»(ref-440211-S03702023042011121400000)
3. For information about signals on 5 cylinder engines, see «Signal specification»(ref-440214-S33124753252011121400000)
4. For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) .
5. See «Contents»(ref-440209-S18666729612011121400000)

1. Continue Refer to «Verification»(ref-440291-S17227867032011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition on
2. Read off the voltage from the system relay to the engine control module (ECM). The voltage must be approximately 12 V.

Is the voltage correct?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S21314939532011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Faulty signal or signal missing

See Faulty signal or signal missing

See Fault-tracing information

See Signal too low

See Internal fault

See Signal too high

See Signal too low

See Faulty signal or signal missing

See Faulty signal or signal missing

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

See Signal too high. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition on.
2. Read off the 5 volt supply. The value must be 5 V.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S05146323152011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too high. Permanent fault

See Signal too high. Permanent fault

See Signal too high. Permanent fault

If the fault is intermittent, do not verify fault-tracing if the fault does not recur.

It is possible to view the information again, or leave fault-tracing for this diagnostic trouble code (DTC).

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

See Signal too low. Intermittent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition on.
2. Read off the 5 volt supply. The value must be 5 V.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S10112049842011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

See Signal too low. Permanent fault

See Signal too low. Permanent fault

See Signal too low. Permanent fault

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition on.
2. Read off the 5 volt supply. The value must be 5 V.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S03747715522011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition on.
2. Read off the 5 volt supply. The value must be 5 V.

Is the value OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S41728314212011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

1. Ignition on
2. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault is intermittent at the moment.

1. Continue Refer to «Checking the power supply»(ref-440291-S39882166572011121400000)

Scheme 299

1. Ignition on. Check the power supply to the stop lamp switch. Take readings between stop lamp switch terminal #1 (cable harness side) and the ground terminal. The power supply must be approximately 12 V. If there is no power supply: Check the power supply circuit for stop lamp switch terminal #1 (cable harness side). Check for an open-circuit. Check for a short-circuit to ground. Check for a blown fuse in the circuit. Remedy as necessary. Other information: See «Connecting the breakout box»(ref-440211-S03702023042011121400000) For information about signals for 5 cylinder engines: «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Stop lamp switch, replacing»(ref-440304-S21119270472011121400000) See «Contents»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Checking components and wiring»(ref-440291-S01820328292011121400000)

Scheme 300

1. Ignition off
2. Check that the stop lamp switch is correctly installed. Check the resistance of the stop lamp switch with the switch pressed in and with the switch released. Take readings between terminals #1 and #5 (component side) on the stop lamp switch. HINT: The stop lamp switch must be closed when the brake pedal is depressed. The resistance of the stop lamp switch must be infinite when the brake pedal is unaffected. Check the stop lamp switch and engine control module (ECM) connectors. Check for contact resistance and oxidation. Check the cable between stop lamp switch terminal #5 (cable harness side) and engine control module (ECM) terminal #B26 (#B36). Check for an open-circuit. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Check central electronic module (CEM) connector B. Check for contact resistance and oxidation. Check the cable between stop lamp switch terminal #5 (cable harness side) and central electronic module (CEM) terminal #4B. Check for an open-circuit. Check for a short-circuit to ground. Check for a short-circuit to supply voltage. Remedy as necessary. Other information: See «Connecting the breakout box»(ref-440211-S03702023042011121400000) For information about signals for 5 cylinder engines: «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . For resistance values: «Component specifications»(ref-461750-S34427939622012040200000) See «Central electronic module (CEM), replacing»(ref-461683-S35742770022012040200000) See «Contents»(ref-440209-S18666729612011121400000) .

1. Continue Refer to «Verification»(ref-440291-S32621499052011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Ignition on
4. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault has been remedied.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S01721449662011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Signal missing or faulty signal

See Signal missing or faulty signal

1. Ignition on
2. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault is intermittent at the moment.

1. Continue Refer to «Checking the power supply»(ref-440291-S10074476842011121400000)

Checking the power supply

1. Ignition on. Check the power supply to the stop lamp switch. Take readings between stop lamp switch terminal #1 (cable harness side) and the ground terminal. The power supply must be approximately 12 V. If there is no power supply: Check the power supply circuit for stop lamp switch terminal #1 (cable harness side). Check for an open-circuit. Check for a short-circuit to ground. Check for a blown fuse in the circuit. Remedy as necessary. Other information: See «Connecting the breakout box»(ref-440211-S03702023042011121400000) For information about signals for 5 cylinder engines: «Signal specification»(ref-440214-S33124753252011121400000) For information about signals on 6-cylinder engines: For 6 cylinder engines -2001, see «Signal specification»(ref-440279-S16581672222011121400000) For 6 cylinder engines 2002-, see «Signal specification»(ref-440279-S30114162992011121400000) For 6 cylinder engines -2004, see «Signal specification»(ref-440279-S11542834502011121400000) For 6 cylinder engines 2005-, see «Signal specification»(ref-440279-S13492600202011121400000) . See «Stop lamp switch, replacing»(ref-440304-S21119270472011121400000) See «Contents»(ref-440209-S18666729612011121400000)

1. Continue Refer to «Checking components and wiring»(ref-440291-S25374992562011121400000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Ignition off
2. Reconnect the connectors, reinstall components etc.
3. Ignition on
4. Read off the status from the stop lamp switch. Check the function of the stop lamp switch by carefully pressing and releasing the brake pedal. Check that the status changes between "OFF" when the brake pedal is unaffected and "ON" when the brake pedal is depressed. If the status of the stop lamp switch changes as described above when the brake pedal is depressed, the fault has been remedied.

Is the function OK?

1. YES VERIFIED: Troubleshooting has been completed.
2. NO Refer to «Information»(ref-440291-S09393965092011121400000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Checking a short-circuit in CAN cables

Connect an ohmmeter between the relevant CAN cable (CAN-L and CAN-H) and the power supply, and between the CAN cable and ground. Twist the connectors and turn the cable harness to different positions at each reading to determine any intermittent short-circuits.

Take the following readings

1. The resistance between CAN-L and ground
2. The resistance between CAN-L and voltage
3. The resistance between CAN-H and ground
4. The resistance between CAN-H and voltage.

The resistance must be infinite or very high in all cases (greater than 1 Mohms).

HINT: The reading can be taken from the same connector if the CAN cables, power supply and ground are exposed. If possible, take readings on the rear of the connector to prevent damage to the terminals in the connector. If this is not possible, use the adapter wiring or loose terminal pins to obtain a good contact.

Was a fault detected?

1. YES Refer to «Identifying fault causes in the CAN network»(ref-440291-S02648331542012030700000)
2. NO Refer to «Checking the traffic load on the CAN cables»(ref-440291-S12941895372012030700000)

Checking the traffic load on the CAN cables

1. Connect the battery
2. Ignition on Also read: «Battery, disconnecting»(ref-440259-S31019869382011121400000) Faults in the CAN network may be due to a control module sending faulty messages that disrupt "normal" communication. When messages are sent incorrectly, this results in a considerable increase in the amount of traffic on the CAN network. Check the load by measuring the average voltage value on the CAN cables in relation to ground. Connect a voltmeter between CAN-L and ground. The voltage must be approximately 2.3 V. Then connect a voltmeter between CAN-H and ground. The voltage must be approximately 2.8 V. HINT: If possible measure from the rear of the affected connectors so that they are not damaged.

Is the value OK?

1. YES Refer to «Information»(ref-440291-S38398552552012030700000)
2. NO Refer to «Identifying a control module in the CAN network»(ref-440291-S08903015162012030700000)

Identifying fault causes in the CAN network

1. Disconnect a control module that disconnects the CAN network (a control module that has four terminals to the CAN network). HINT: For the low speed network, suitable places for disconnecting the network are at the steering wheel module (SWM), the driver information module (DIM) or the climate control module (CCM). In the event of a short-circuit between one of the CAN cables and voltage or ground, the fault can be located by disconnecting a control module that disconnects the CAN network. Readings can then be taken to determine on which side of the disconnected control module the fault is located. Connect an ohmmeter between the CAN cable and supply voltage or ground. Take readings at both ends of the CAN network where the network is disconnected. Twist and bend the cable harness to locate any intermittent short-circuits. The resistance must be infinite or very high (greater than 1 Mohms). If a fault can be localized in one direction, disconnect the network at a point further down on the CAN network in the direction in which the fault was discovered and repeat the reading. In this way, try to identify where in the network the fault might be located. HINT: A short-circuit between the CAN cables and supply voltage or ground may be in either the wiring or in a control module. Rectify the wiring as necessary. Replace the control module if the fault has been localized to a control module.

1. Continue Refer to «Verification»(ref-440291-S16013611492012030700000)

Identifying a control module in the CAN network

1. Connect the battery Also read: «Battery, disconnecting»(ref-440259-S31019869382011121400000)
2. Ignition on If the load on the CAN network is too high, this may be due to a control module sending faulty messages on the CAN network (known as a disruptive control module). The fault may also be due to an intermittent short-circuit to supply voltage or ground in one of the CAN cables. This results in the control modules on the CAN network starting to send faulty messages. The faults can occur without a diagnostic trouble code (DTC) being stored by the control modules. The voltage can be measured between the CAN cables in order to check the load on the CAN network. Connect a voltmeter between the CAN cables. If the communication on the network is correct, the average voltage value should be approximately 0.5 V (0.4 V to 0.6 V). If there is a fault in the communication, the voltage reading will be approximately 0.7 V or higher. In order to identify from which control module the faulty communication is being transmitted, cut the supply voltage to one control module at a time and check the voltage in the CAN cables again. The easiest way to cut the supply voltage is to remove a fuse. Repeat until the voltage between the CAN cables drops to approximately 0.5 V. HINT: When the probable faulty control module has been identified, connect and disconnect the supply voltage to the control module a number of times to verify that the fault appears and disappears. NOTE: Do not cut the power to the central electronic module (CEM) unless it is the last control module left to check. The control module that is communicating incorrectly must be replaced. Remedy as necessary. NOTE: Following a fault involving "disruptive" control modules, other modules may remain in "Limp-Home mode" even after switching the ignition off and on a number of times. To remedy this, disconnect and reconnect the battery negative terminal to restore the control modules to normal function.

1. Continue Refer to «Verification»(ref-440291-S16013611492012030700000)

1. Disconnect a control module that disconnects the CAN network (a control module that has four terminals to the CAN network). HINT: For the low speed network, suitable places for disconnecting the network are at the steering wheel module (SWM), the driver information module (DIM) or the climate control module (CCM). In the event of an open-circuit or a short-circuit between the CAN cables, the fault can be localized by disconnecting a control module that disconnects the CAN network. Readings can then be taken to determine on which side of the disconnected control module the fault is located. Connect an ohmmeter between the CAN cables. Take readings at both ends of the CAN network where the network is disconnected. Twist and bend the cable harness to locate any intermittent short-circuits. The resistance must be 120 ohm. If a fault can be localized in one direction, disconnect the network at a point further down on the CAN network in the direction in which the fault was discovered and repeat the reading. In this way, try to identify where in the network the fault might be located. Remedy the cables as necessary.

1. Continue Refer to «Verification»(ref-440291-S16013611492012030700000)

HINT: After carrying out the repair, check that the fault has been remedied.

1. Reinstall the connectors, components, etc.
2. Ignition on
3. Erase diagnostic trouble codes by clicking the VCT2000 symbol
4. Start the car. Allow the car to run for 10 minutes.
5. Read off diagnostic trouble codes (DTCs). Check if a diagnostic trouble codes (DTCs) for communication fault recurs in the central electronic module (CEM).

Does the diagnostic trouble code (DTC) recur?

1. YES Refer to «Information»(ref-440291-S05823064662012030700000)
2. NO OKAY: Troubleshooting has been completed.

Verification shows that the fault is no longer present. The diagnostic trouble code (DTC) was probably caused by an intermittent fault.

Fault-tracing for this diagnostic trouble code (DTC) is not followed by a verification.

You can view the information again or exit fault-tracing for this diagnostic trouble code (DTC).

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
