CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Use SUBARU genuine fluid, grease or equivalent. Do not mix fluid and grease of different grades or manufacturers.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Apply grease onto sliding or revolving surfaces before installation.
9. Before installing the O-ring or snap ring, apply a sufficient amount of fluid to avoid damage and deformation.
10. Before securing a part in a vise, place cushioning material such as wood blocks, aluminum plate or cloth between the part and the vise.
11. Before disconnecting electrical connectors, be sure to disconnect the negative terminal from battery.

GENERAL TOOL

Scheme 708

Scheme 709

Scheme 710

Scheme 711

Scheme 712

Scheme 713

Scheme 714

1. Output Signal for Unlock
2. Output Signal for Lock

Scheme 715

Scheme 716

BODY INTEGRATED UNIT POWER SUPPLY AND GROUND CIRCUIT

Note. For the DC power supply circuit, refer to the appropriate SYSTEM WIRING DIAGRAM article.

Scheme 717

Scheme 718

Scheme 719

1. Model without push button ignition switch
2. Model with push button ignition switch

KEY INTERLOCK DOES NOT LOCK OR RELEASE

Note. Check of this item only applies to models without a push button ignition switch.

Scheme 720

Scheme 721

Scheme 722

Scheme 723

Scheme 724

Scheme 725

Scheme 726

Scheme 727

Scheme 728

Scheme 729

Scheme 730

Scheme 731

1. Shift the select lever to "N" range.
2. Disconnect the ground cable from battery.
3. Lift up the vehicle.
4. Remove the rear exhaust pipe. 2.5 L model Refer to «REMOVAL»(ref-565184-S13103619792013071000000) . 3.6 L model Refer to «REMOVAL»(ref-565201-S14922056002013071000000) .
5. Remove the heat shield cover.
6. Remove the cable from arm assembly.
7. Raise the claw of clamp and remove the cable.
8. Lower the vehicle.
9. Lower the cover grip AT vertically toward the lever.
10. Remove the clamp grip pin.
11. Remove the grip assembly.
12. Turn over the rubber and remove the console front cover assembly.
13. Remove the console box. Refer to «REMOVAL»(ref-565181-S32794896752013071000000) .
14. Remove the harness clip from the select lever.
15. Disconnect the harness connector.
16. Remove the four bolts to remove the select lever assembly.

Scheme 732

Scheme 733

Scheme 734

1. Set the select lever assembly to the vehicle body.
2. Tighten the four mounting bolts to attach the select lever assembly to the vehicle body. Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb)
3. Connect the harness connector.
4. Install the harness clip to the select lever assembly.
5. Shift the select lever to "N" range.
6. Install the console box and the console front cover assembly. Refer to «INSTALLATION»(ref-565181-S34792434162013071000000) .
7. Accessing from the button side of the grip, attach the clamp grip pin.
8. Install the cover grip AT securely. NOTE: After installation, check that the cover grip AT cannot be detached.
9. Insert the grip assembly to the select lever and press it down until a click is heard.
10. After installation of grip, check the following points. The grip will not come off. The button on the grip operates normally.
11. Lift up the vehicle.
12. Shift the range select lever to "N" range.
13. Secure the cable to the bracket. Refer to «INSTALLATION»(ref-565197-S25996506042013071000000) .
14. Adjust the select cable position. Refer to «ADJUSTMENT»(ref-565197-S31315338362013071000000) .
15. After adjustment, confirm that the select lever operates properly at all range positions using the shift lock release button.
16. Install the heat shield cover. Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb)
17. Install the rear exhaust pipe. 2.5 L model Refer to «INSTALLATION»(ref-565184-S10239718472013071000000) . 3.6 L model Refer to «INSTALLATION»(ref-565201-S00442187542013071000000) .
18. Inspect the following items. If a malfunction is found in the inspection, adjust the select cable or inhibitor switch (CVT model). The shift lock operates normally. Refer to «SHIFT LOCK OPERATION»(ref-565197-S03523776662013071000000) . Engine starts when the select lever is in "P" or "N" range, but not in other ranges. Back-up light illuminates when the select lever is in the "R" range, but not in other ranges. Select lever and indicator positions are matched.

Scheme 735

Scheme 736

1. Remove the cover grip AT.
2. Remove the button assembly-AT.
3. Remove the rod COMPL.

Scheme 737

Scheme 738

Scheme 739

Scheme 740

Scheme 741

Scheme 742

Scheme 743

Scheme 744

Scheme 745

Scheme 746

Scheme 747

Scheme 748

Scheme 749

Scheme 750

Scheme 751

Scheme 752

1. Remove the spacer plate.
2. Remove the gasket.
3. Insert a flat tip screwdriver with a thin tip under the connector and disconnect the harness connector from the plate COMPL.
4. Remove the harness from the plate COMPL.
5. Raise the claw with a flat tip screwdriver with a thin tip and remove the solenoid unit.
6. Using a flat tip screwdriver with a thin tip, remove the solenoid unit terminals from the connector.
7. Remove the clamp push nut. NOTE: Replace the clamp push nut with a new part.
8. Pull out shaft control.
9. Remove the clamp push nut. NOTE: Replace the clamp push nut with a new part.
10. Pull out spacer pin guide.
11. Remove the clamp pin.
12. Remove the spacer pin guide.
13. Remove the select lever COMPL from the plate COMPL.
14. Remove the arm assembly.
15. Remove the plate guide from the select lever COMPL.
16. Remove the rod detent and detent spring from the select lever COMPL.

Scheme 753

Scheme 754

1. Disconnect the harness connector from the console front cover assembly.
2. Remove the four screws and remove the indicator assembly from the console front cover assembly.

Scheme 755

1. Clean all the parts before assembly.
2. Apply Multemp D or equivalent to the sliding portion of each part.
3. Assemble in the reverse order of disassembly. NOTE: Insert the solenoid unit terminals to the harness connector.
4. After installation, check the following points. The select indicator matches the select lever position when the select lever is changed from "P" range to "D" range. The select lever position and the position mark match each other. Operating force to move the select lever from "P" to "D" range.

"P" RANGE SWITCH

For the removal of "P" range switch, refer to the procedure for AT select lever. Refer to DISASSEMBLY .

Refer to AT SELECT LEVER ASSEMBLY .

NOTE

Refer to BODY INTEGRATED UNIT for removal and installation procedure.

Scheme 756

Scheme 757

Scheme 758

Scheme 759

Scheme 760

Scheme 761

1. Disconnect the ground cable from battery.
2. Lift up the vehicle.
3. Remove the center exhaust pipe. Refer to «REMOVAL»(ref-565184-S03793321452013071000000) .
4. Remove the heat shield cover.
5. Remove the plate cable assembly.
6. Remove the spring at the MT gear shift cable by expanding it and pulling down, and remove the MT gear shift cable from the gear shift lever assembly. CAUTION: Be careful not to deform the cable inner.
7. Remove the MT gear select cable from the gear shift lever assembly by pulling it in the direction of arrow in the figure. CAUTION: Be careful not to deform the cable inner.
8. Remove the cover cable assembly.
9. Lower the vehicle.
10. Remove the shift knob.
11. Remove the console front cover assembly and console box. Refer to «REMOVAL»(ref-565181-S32794896752013071000000) .
12. Remove the bolts, and then remove the gear shift lever assembly from the vehicle. NOTE: The MT gear shift lever cannot be disassembled.

Scheme 762

1. Install the gear shift lever assembly. Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb)
2. Lift up the vehicle.
3. Install the cover cable assembly. Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
4. Connect the MT gear shift cable and MT gear select cable. CAUTION: Be careful not to deform the cable inner. Do not twist the cable inner excessively.
5. Install the plate cable assembly. Tightening torque: 7.5 N.m (0.8 kgf-m, 5.5 ft-lb)
6. Install the heat shield cover. Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb)
7. Install the center exhaust pipe. Refer to «INSTALLATION»(ref-565184-S27754215802013071000000) .
8. Lower the vehicle.
9. Adjust the detent of the MT gear shift lever. Refer to «ADJUSTMENT»(ref-565197-S26798096292013071000000) .
10. Install the console front cover assembly and the console box. Refer to «INSTALLATION»(ref-565181-S34792434162013071000000) .
11. Install the shift knob.
12. Make sure the gears can be shifted accurately into each gear. Adjust the MT gear select cable, if the gears cannot be shifted correctly. Refer to «ADJUSTMENT»(ref-565197-S36200362052013071000000) .

Scheme 763

1. Check the parts for deformation, damage and wear. Repair or replace if necessary. Compare the removed parts with new parts to confirm if there are damages or not.
2. Check that selecting to the reverse direction is disable unless the slider is pulled up.
3. Check that selecting to the reverse direction is possible when the slider is pulled up to the full.
4. Check that the shift lever moves to initial position, when the slider backs to the neutral position from step 3 ).
