GENERAL DESCRIPTION

1. Follow the messages displayed on the Subaru Select Monitor when working.
2. Perform as necessary in FWD mode.
3. When switched to FWD, AWD light illuminates.

ENGINE BRAKE OPERATION

1. Drive in "6th speed of manual mode" [70 - 80 km/h (43 - 50 MPH)], and shift down from 6th to 5th. Check if the indicator of combination meter switches "6" --> "5". At the same time, check the engine brake in 5th gear.
2. Drive in "5th speed of manual mode" [60 - 70 km/h (37 - 43 MPH)], and shift down from 5th to 4th. Check if the indicator of combination meter switches "5" --> "4". At the same time, check the engine brake in 4th gear.
3. Drive in "4th speed of manual mode" [50 - 60 km/h (31 - 37 MPH)], and shift down from 4th to 3rd. Check if the indicator of combination meter switches "4" --> "3". At the same time, check the engine brake in 3rd gear.
4. Drive in "3rd speed of manual mode" [40 - 50 km/h (25 - 31 MPH)], and shift down from 3rd to 2nd. Check if the indicator of combination meter switches "3" --> "2". At the same time, check the engine brake in 2nd gear.
5. Drive in "2nd speed of manual mode" [20 - 30 km/h (12 - 19 MPH)], and shift down from 2nd to 1st. Check if the indicator of combination meter switches "2" --> "1". At the same time, check the engine brake in 1st gear.

P RANGE OPERATION

Stop the vehicle on an uphill grade of 5% or more and shift to the "P" range and apply the parking brake. Check that the vehicle does not move when the parking brake is released.

Before disassembling and assembling the transmission, follow the following procedures to prepare.

Scheme 250

Scheme 251

1. Clean the transmission exterior.
2. Attach the ST on the transmission. ST 18632AA000 STAND ASSY
3. Remove the torque converter assembly. Refer to «TORQUE CONVERTER ASSEMBLY»(ref-565171-S41142124062013071000000) .
4. Remove the transmission case cover on the transmission upper side. NOTE: Install using the following tightening torque. Tightening torque: 8 N.m (0.8 kgf-m, 5.9 ft-lb)
5. Place the transmission assembly on end.
6. When completely overhauling the transmission, refill approx. 10 L (2.6 US qt, 8.8 Imp qt) of CVTF through the transmission right side plug, and install the plug. Finally, install the transmission case cover. CAUTION: Always use specified CVTF. Using other fluid will cause malfunction. Refer to «HYDRAULIC CONTROL AND LUBRICATION»(ref-565171-S33023028772013071000000) . NOTE: Use a new gasket. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)

Scheme 252

Scheme 253

1. Remove the transmission assembly from the vehicle. Refer to «REMOVAL»(ref-565171-S25233894212013071000000) .
2. Remove the extension case and transmission hanger. NOTE: The total number of extension case mounting bolts is 13.
3. Remove the O-ring.

Scheme 254

1. Clean the mating surface of extension case and transmission case.
2. Select the transfer drive gear shim. Refer to «ADJUSTMENT»(ref-565171-S25021989002013071000000) .
3. Select the transfer driven gear shim. Refer to «ADJUSTMENT»(ref-565171-S16379846502013071000000) .
4. Attach the selected transfer drive gear shim to extension case with vaseline.
5. Attach the selected transfer driven gear shim to extension case with vaseline.
6. Install the O-ring to the transmission case. NOTE: Use new O-rings. Apply CVTF to the O-ring.
7. Apply liquid gasket to extension case seamlessly. Liquid gasket: THREE BOND 1215 (Part No. 004403007) or equivalent
8. Install the extension case to transmission hanger. Tightening torque: 25 N.m (2.5 kgf-m, 18.4 ft-lb)
9. Install the transmission assembly. Refer to «INSTALLATION»(ref-565171-S34027850992013071000000) .
