Continuously Variable Transaxle (Cvt): Wiring Subaru Outback BR рестайлинг

Automatic Trans 2 illustrations ~306 words

COOLING AND HARNESS

Cooling systemLiquid-cooler incorporated in radiator
Inhibitor switch harness16 poles
Transmission harness12 poles

INHIBITOR HARNESS

Install in the reverse order of removal.

Note. Install the transmission ground terminal in the direction within the range of approx. 30° (A).

Tightening torque

T1: 7 N.m (0.7 kgf-m, 3.7 ft-lb)

T2: 14 N.m (1.4 kgf-m, 10.3 ft-lb)

Scheme 568

Scheme 568: INHIBITOR HARNESS
Scheme 568: INHIBITOR HARNESS

Scheme 569

Scheme 569
Scheme 569
  1. Clean the mating surface of valve cover and transmission side.
  2. Check the control valve body for dust and other foreign matter.
  3. Install the O-ring to the transmission harness. NOTE: Use new O-rings. Apply CVTF to the O-ring.
  4. Install the transmission harness to the valve cover. Tightening torque: 7 N.m (0.7 kgf-m, 5.2 ft-lb)
  5. Install the gasket to the transmission. NOTE: Use a new gasket.
  6. Apply liquid gasket to the oval hole of gasket. Liquid gasket: THREE BOND 1215 (Part No. 004403007) or equivalent
  7. Connect the transmission harness connector to the control valve body, and install the valve cover. CAUTION: Be careful not to catch the sheet of the ST. Tightening torque: 8 N.m (0.8 kgf-m, 5.9 ft-lb)
  8. Remove the ST (SHEET SPECIAL TOOL).
  9. Install the transmission harness connector to the harness stay.
  10. Install the transmission harness stay and transmission ground terminal. NOTE: Install the transmission ground terminal in the direction within the range of approx. 30° (A). Tightening torque: T1: 7 N.m (0.7 kgf-m, 5.2 ft-lb) T2: 14 N.m (1.4 kgf-m, 10.3 ft-lb)
  11. Install the transmission case cover. Tightening torque: 8 N.m (0.8 kgf-m, 5.9 ft-lb)
  12. Install the transmission hanger and transmission radio ground cord. Tightening torque: 41 N.m (4.2 kgf-m, 30.2 ft-lb)
  13. Attach the air breather hose to the transmission hanger.
  14. Connect the following harness connectors. Transmission harness connectors Inhibitor harness connector Transmission radio ground terminal Tightening torque: 13 N.m (1.3 kgf-m, 9.6 ft-lb)
  15. Install the air intake boot assembly. Refer to «INSTALLATION»(ref-565164-S07668311112013071000000) .
  16. Adjust the CVTF level. Refer to «ADJUSTMENT»(ref-565171-S15048869762013071000000) .
