SPECIAL TOOL
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 41099AJ130 (Newly adopted tool) SPECIAL TOOL FB Used for holding and balancing the engine unit. 99099AJ000 ENGINE HANGER Used for removing and installing the automatic transmission assembly. Used together with CHAIN BALANCER (99099AJ010). 99099AJ010 CHAIN BALANCER Used for removing and installing the automatic transmission assembly. Used together with ENGINE HANGER (99099AJ000). 18769AA010 EXPANDER PULLEY Used for removing and installing the secondary pulley assembly. 18767AA010 BEARING REMOVER Used for removing the ball bearing of transfer clutch assembly. 18762AA010 COMPRESSOR SPECIAL TOOL Used for removing and installing snap ring of forward clutch assembly. 18761AA010 SHEET SPECIAL TOOL Used for removing and installing control valve body. Used for removing and installing valve cover. Used for removing and installing transmission harness. 18681AA010 PRESSURE GAUGE ADAPTER Used for measuring the secondary pressure (line pressure). NOTE: Used together with the genuine O-ring (part No. 806916050). 18801AA000 OIL PRESSURE GAUGE ASSY Used for measuring the secondary pressure (line pressure). 18658AA020 WRENCH COMPL RETAINER Used for removing and installing the differential side retainer. 34099AC020 ADAPTER HOSE B Used for measuring the transfer clutch hydraulic pressure. NOTE: Used with genuine union screw (Part No. 801914010) and gasket (Part No. 803914060). 34099AC010 ADAPTER HOSE A Used for measuring the transfer clutch hydraulic pressure. 18681AA000 PRESSURE GAUGE ADAPTER Used for measuring the transfer clutch hydraulic pressure. NOTE: Used together with the genuine O-ring (part No. 806911080). 498575400 OIL PRESSURE GAUGE ASSY Used for measuring the transfer clutch hydraulic pressure. 498277200 STOPPER SET Used for removing and installing transmission assembly to engine. Used for preventing the torque converter from dropping off. 398527700 PULLER ASSY Used for removing the extension case oil seal. Used for removing the bearing of reduction driven gear. Used for removing the bearing outer race of the drive pinion shaft. 398673600 COMPRESSOR Used for removing and installing snap ring of forward clutch assembly. 18355AA000 PULLEY WRENCH Used for removing and installing the lock nut of reduction driven gear. Used together with PIN SET (18334AA000). 18334AA000 PIN SET Used for removing and installing the lock nut of reduction driven gear. Used together with PULLEY WRENCH (18355AA000). 499987003 SOCKET WRENCH (35) Used for removing and installing the lock nut of reduction driven gear. 498057300 OIL SEAL INSTALLER Used for installing the extension case oil seal. 18632AA000 STAND ASSY Used for disassembling and assembling the transmission. 498515500 REMOVER Used for removing the bearing inner race of the drive pinion shaft. 498255400 PLATE Used for measuring the backlash of hypoid gear. 498247001 MAGNET BASE Used for measuring the backlash of differential bevel pinion gear. Used for measuring the backlash of hypoid gear. Used together with DIAL GAUGE (498247100). 498247100 DIAL GAUGE Used for measuring the backlash of differential bevel pinion gear. Used for measuring the backlash of hypoid gear. Used together with DIAL GAUGE (498247101). 18675AA000 DIFFERENTIAL SIDE OIL SEAL INSTALLER Used for installing the differential side retainer oil seal. 18762AA000 COMPRESSOR SPECIAL TOOL Used for disassembling and installing the multi-plate clutch piston. 927720000 HOUSING BUSHING INSTALLER AND REMOVER Used for installing the oil seal. Use BUSHING SHAFT (927880000). 18763AA000 COMPRESSOR SHAFT Used for measuring the backlash of hypoid gear. 28399SA010 OIL SEAL PROTECTOR Used for protecting oil seal when installing front drive shaft. 498937110 HOLDER Used for removing and installing the drive pinion lock nut. Used as a holder to rotate gear when checking tooth contact. 18270KA020 SOCKET (E20) Used for removing and installing the hypoid driven gear. Used for removing and installing the drive pinion shaft retainer. 398497701 SEAT Used for removing and installing the bearing. 398177700 INSTALLER Used for installing the ball bearing. Used for installing the parking gear. Used for installing the bearing outer race. Used for installing the plug. 28499TC010 PRESS SNAP RING Used for installing the ball bearing of the transmission case. Used for installing the bearing outer race of drive pinion shaft. 899864100 REMOVER Used for removing and installing the ball bearing. Used for removing the parking gear and transfer drive gear. Used for removing the bearing inner race of the front differential. 498077000 REMOVER Used for removing the bearing inner race of the front differential. 18657AA010 INSTALLER Used for installing the oil seal at shifter arm shaft portion. 498077600 REMOVER Used for removing the ball bearing of drive sprocket. 18723AA000 REMOVER Used for removing the ball bearing of transfer clutch assembly. 18854AA000 ANGLE GAUGE Used for installing the hypoid driven gear. Used for installing the drive plate. 498497300 CRANKSHAFT STOPPER Used for stopping the drive plate rotation when removing and installing the drive plate. 399513600 INSTALLER Used for removing the ball bearing of drive sprocket. 499267300 STOPPER PIN Used for adjusting the inhibitor switch. 499277100 BUSHING 1-2 INSTALLER Used for installing the bearing of the transmission case. Used for installing the ball bearing. Used for installing the bearing inner race. 499277200 INSTALLER Used for installing the ball bearing of the transfer clutch assembly. 499575400 GAUGE Used for measuring height of end play. 499575500 GAUGE Used for measuring height of end play. 499787500 ADAPTER Used for removing and installing the drive pinion shaft lock nut. Used for measuring the preload of the drive pinion shaft. Used for measuring the backlash of hypoid gear. 499575600 GAUGE Used for measuring height of end play. 499787700 WRENCH Used for removing and installing the drive pinion shaft lock nut. Used for measuring the preload of the drive pinion shaft. Used for measuring the backlash of hypoid gear. 499757002 INSTALLER Used for removing the bearing of reduction driven gear. Used for installing the parking gear. Used for installing the transfer drive gear. 899580100 INSTALLER Used for installing the collar of reduction driven gear. Used for installing the ball bearing of the transfer drive gear. Used for installing the bearing inner race of drive pinion shaft. 498077300 REMOVER Used for installing the ball bearing of reduction driven gear. 499755602 PRESS SNAP RING Used for installing the oil seal. Used for installing the ball bearing and roller bearing. Used for installing the plug. 498077400 REMOVER Used for removing the ball bearing of transfer driven gear. 20099AE020 INSTALLER Used for installing the bearing outer race of drive pinion shaft. 927130000 EXTENSION DRIVE SHAFT Used for installing the bearing inner race of drive pinion shaft. 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system
