OPERATION OF SHIFT SELECT LEVER
Make sure there is no noise, dragging or contact pattern in each select lever range.
| WARNING | Stop the engine while checking operation of the select lever. |
OPERATION
For detailed operation procedures, refer to "PC application help for Subaru Select Monitor".
For detailed operation procedures, refer to "PC application help for Subaru Select Monitor".
- The support data list is as follows.
| Item | Display | Unit of measure |
|---|---|---|
| Engine speed signal | Engine Speed | RPM |
| Battery voltage | Battery Voltage | V |
| Accelerator position sensor | Accel. Opening Angle | % |
| Front vehicle speed sensor signal | Front Wheel Speed | Km/h |
| Gear position | Gear Position | |
| Turbine speed sensor signal | Turbine Revolution Speed | RPM |
| Rear vehicle speed sensor signal | Rear Wheel Speed | Km/h |
| ATF temperature sensor signal | ATF Temp. | °C |
| Turbine speed sensor 1 signal | AT Turbine Speed 1 | RPM |
| Turbine speed sensor 2 signal | AT Turbine Speed 2 | RPM |
| High & low reverse clutch solenoid set current | H&LR/C Solenoid Current | A |
| Direct clutch solenoid set current | D/C Solenoid Current | A |
| Front brake solenoid set current | F/B Solenoid Current | A |
| Input clutch solenoid set current | I/C Solenoid Current | A |
| Line pressure solenoid set current | P/L Solenoid Current | A |
| Lock-up solenoid set current | L/U Solenoid Current | A |
| Transfer solenoid set current | AWD Sol. Current | A |
| High & low reverse clutch solenoid pressure | H&LR/C Solenoid Pressure | KPa |
| Direct clutch solenoid pressure | D/C Solenoid Pressure | KPa |
| Front brake solenoid pressure | F/B Solenoid Pressure | KPa |
| Input clutch solenoid pressure | I/C Solenoid Pressure | KPa |
| Line pressure solenoid pressure | P/L Solenoid Pressure | KPa |
| Lock-up solenoid pressure | L/U Solenoid Pressure | KPa |
| Transfer solenoid pressure | AWD Solenoid Pressure | KPa |
| Forward brake set current | Fwd/B solenoid current | A |
| Forward brake solenoid target hydraulic pressure | Fwd/B solenoid target pressure | KPa |
| Ignition switch | Ignition Switch | ON input or OFF input |
| Manual mode signal | Tiptronic Mode Switch | ON or OFF |
| Cruise control set signal | Cruise Control Signal | ON or OFF |
| Down shift signal | Down Switch | ON or OFF |
| Stop light switch signal | Stop Light Switch | ON or OFF |
| Up shift signal | Up Switch | ON or OFF |
| Drive range signal | D Range Signal | ON or OFF |
| Reverse range signal | R Range Signal | ON or OFF |
| Diagnosis light output signal | Diagnosis Lamp | ON or OFF |
| ATF temperature light signal | ATF Temperature Lamp | ON or OFF |
| Parking range signal | P Range | ON or OFF |
| P/N range output signal | P/N Signal | ON or OFF |
| Neutral range signal | N Range | ON or OFF |
| Inhibitor switch 1 input signal | Inhibitor SW 1 | High or Low |
| Inhibitor switch 2 input signal | Inhibitor SW 2 | High or Low |
| Inhibitor switch 3 input signal | Inhibitor SW 3 | High or Low |
| Inhibitor switch 4 input signal | Inhibitor SW 4 | High or Low |
| Back-up light relay output signal | Back Lamp Relay | ON or OFF |
| High & low reverse clutch fluid pressure switch input signal | H&LR/C Fluid Pressure | ON or OFF |
| Direct clutch fluid pressure switch input signal | D/C Fluid Pressure | ON or OFF |
| Front brake fluid pressure switch input signal | F/B Fluid Pressure | ON or OFF |
| Input clutch fluid pressure switch input signal | I/C Fluid Pressure | ON or OFF |
| Forward brake fluid pressure switch input signal | Fwd/B hydraulic pressure SW | ON or OFF |
| AT learning mode | AT learning | Completed or not completed |
For detailed operation procedures, refer to "PC application help for Subaru Select Monitor".
Note. For details concerning DTC, refer to List of Diagnostic Trouble Code (DTC). Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .
For detailed operation procedures, refer to "PC application help for Subaru Select Monitor".
Note. If {Clear Memories 2} is executed, DTCs and learned control memory are cleared. If {Clear Memories 2} is executed, perform learning. Refer to LEARNING CONTROL .
GENERAL DESCRIPTION
- Follow the messages displayed on the Subaru Select Monitor when working.
- When the following work is performed, perform learning for the transmission.
Replacement of TCM/Replacement or disassembly of transmission assembly/Replacement of control valve body/Performing "Clear Memories 2".
When any on-board diagnostics item is malfunctioning, or the learning has not yet completed, AT OIL TEMP light blinks. Blinking continues from the engine start to the ignition switch OFF. The faulty parts or unit can be identified by reading DTCs. Problems which occurred previously can also be identified through the memory function. If the AT OIL TEMP light does not blink although a problem is occurring, the problem can be determined by checking the performance characteristics of each sensor using the Subaru Select Monitor. If the learning has not yet completed, «Learning not completed» is displayed when the Subaru Select Monitor is connected while AT OIL TEMP light is blinking. The AT OIL TEMP light blinking will go off, when the learning is performed. Indicator light signal patterns are as shown in the figure.
Scheme 764
When the AT OIL TEMP light does not operate normally, check the AT OIL TEMP light circuit. Refer to INSPECTION .
AWD warning light illuminates or blinks at start, or when AWD is faulty.
Scheme 765
- Normal AWD light always illuminates when the ignition switch is ON (engine OFF). Light goes off after two seconds from engine ON.
- Faulty AWD warning light blinks at 2 Hz, when tires with different diameters are installed, or when the vehicle is driven with air pressure of any of the four tires significantly low. If the AWD light does not illuminate, or illumination patterns are not as above, check the AWD light circuit. Refer to «INSPECTION»(ref-565205-S06491079022013071000000) .
