Starting System & Charging System (H4DO): Overview Subaru Outback BR рестайлинг

SWITCH ASSEMBLY OPERATION

Note. Perform each test in a short period of time (3 - 5 sec).

Scheme 6

Scheme 7

Scheme 8

1. Suction test Check that the pinion gear comes flying out when the harness is disconnected from terminal M and connected as shown in the figure.
2. Holding test Check that the pinion gear remains flying out after the cable is disconnected from terminal M.
3. Returning test With terminal S connected to the positive terminal, and terminal M and starter body connected to the battery ground terminal to suction the main contact point, check that the pinion gear returns to its original position when terminal S is disconnected.
