SPECIFICATION
| Item | Specifications | ||
|---|---|---|---|
| Vehicle model | AT | ||
| Starter | Type | Reduction type | |
| Model | 428000-5250 | ||
| Manufacturer | DENSO | ||
| Voltage and output | 12 V - 1.6 kW | ||
| Direction of rotation | Counterclockwise (when observed from pinion) | ||
| Number of pinion teeth | 9 | ||
| No-load characteristics | Voltage | 11 V | |
| Current | 90 A or less | ||
| Rotating speed | 1, 550 rpm or more | ||
| Load characteristics | Voltage | 8 V | |
| Current | 370 A | ||
| Torque | 12.8 N.m (1.3 kgf-m, 9.4 ft-lb) or more | ||
| Rotating speed | 800 rpm or more | ||
| Lock characteristics | Voltage | 3 V | |
| Current | 750 A or less | ||
| Torque | 19.0 N.m (1.9 kgf-m, 14.0 ft-lb) or more | ||
| Generator | Type | Rotating-field three-phase type, voltage regulator built-in type, with load response control system | |
| Model | A3TJ3591 | ||
| Manufacturer | Mitsubishi Electric | ||
| Voltage and output | 12 V - 130 A | ||
| Polarity on ground side | Negative | ||
| Direction of rotation | Clockwise (when observed from pulley side) | ||
| Stator connection | 3-phase delta type | ||
| Output current | 1, 500 rpm - 55 A or more 2, 500 rpm - 108 A or more 5, 000 rpm - 127 A or more | ||
| Regulated voltage | 14.1 - 14.8 V [20°C (68°F)] | ||
| Rotor slip ring outer diameter | Standard | 22.7 mm (0.894 in) | |
| Limit | 22.1 mm (0.870 in) | ||
| Brush length | Standard | 22.5 mm (0.886 in) | |
| Limit | 5.0 mm (0.197 in) | ||
| Battery | Type and capacity | 12 V - 52 AH (75D 23R) | |
Scheme 67
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.4 (0.1, 1.0)
T2: 6 (0.6, 4.4)
T3: 7.5 (0.8, 5.5)
T4: 10 (1.0, 7.4)
Scheme 68
Tightening torque: N.m (kgf-m, ft-lb)
T1: 4.4 (0.4, 3.2)
T2: 3.9 (0.4, 2.9)
T3: 117.5 (12.0, 86.7)
T4: 2 (0.2, 1.5)
T5: 8.9 (0.9, 6.6)
Scheme 69
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 16 (1.6, 11.8)
T3: 25 (2.5, 18.4)
