SPECIFICATION
| Item | Specifications | |||
|---|---|---|---|---|
| Vehicle model | CVT | MT | ||
| Starter | Type | Reduction type | ||
| Model | 428000-4790 | 428000-4780 | ||
| Manufacturer | DENSO | |||
| Voltage and output | 12 V - 1.6 kW | |||
| Direction of rotation | Counterclockwise (when observed from pinion) | |||
| Number of pinion teeth | 9 | |||
| No-load characteristics | Voltage | 11 V | ||
| Current | 90 A or less | |||
| Rotating speed | 1, 900 rpm or more | |||
| Load characteristics | Voltage | 8 V | ||
| Current | 370 A | |||
| Torque | 11.1 N.m (1.1 kgf-m, 8.2 ft-lb) or more | |||
| Rotating speed | 910 rpm or more | |||
| Lock characteristics | Voltage | 3 V | ||
| Current | 750 A or less | |||
| Torque | 15.5 N.m (1.6 kgf-m, 11.4 ft-lb) or more | |||
| Generator | Type | Rotating-field three-phase type, voltage regulator built-in type, with load response control system | ||
| Model | A3TG6781 | |||
| Manufacturer | Mitsubishi Electric | |||
| Voltage and output | 12 V - 110 A | |||
| Polarity on ground side | Negative | |||
| Direction of rotation | Clockwise (when observed from pulley side) | |||
| Stator connection | 3-phase Y-type | |||
| Output current | 1, 500 rpm - 49 A or more 2, 500 rpm - 89 A or more 5, 000 rpm - 102 A or more | |||
| Regulated voltage | 14.1 - 14.8 V [20°C (68°F)] | |||
| Rotor slip ring outer diameter | Standard | 22.7 mm (0.894 in) | ||
| Limit | 22.1 mm (0.870 in) | |||
| Brush length | Standard | 18.5 mm (0.728 in) | ||
| Limit | 5.0 mm (0.197 in) | |||
| Battery | Type and capacity | 12 V - 52 AH (75D 23R) | ||
Scheme 3
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.4 (0.1, 1.0)
T2: 6 (0.6, 4.4)
T3: 7.5 (0.8, 5.5)
T4: 10 (1.0, 7.4)
Scheme 4
Tightening torque: N.m (kgf-m, ft-lb)
T1: 4.4 (0.4, 3.2)
T2: 3.9 (0.4, 2.9)
T3: 80 (8.2, 59.0)
T4: 2 (0.2, 1.5)
T5: 8.9 (0.9, 6.6)
Scheme 5
Tightening torque: N.m (kgf-m, ft-lb)
T1: 8.5 (0.9, 6.3)
T2: 16 (1.6, 11.8)
T3: 25 (2.5, 18.4)
T4: 36 (3.7, 26.6)
