REMOVAL

1. Remove the engine unit. REMOVAL, Engine Assembly .>
2. Remove the engine mounting from engine assembly.

INSTALLATION

Install in the reverse order of removal.

Tightening torque

Engine mounting

35 N.m (3.6 kgf-m, 25.8 ft-lb)

Note. Perform the work with the engine installed to body when replacing a single part.

Scheme 86

Scheme 87

1. Remove the V-belt covers.
2. Loosen the lock bolt (A).
3. Loosen the slider bolt (B).
4. Remove the front side belt (C).

Scheme 88

Scheme 89

1. Loosen the lock nut (A).
2. Loosen the slider bolt (B).
3. Remove the rear side belt.
4. Remove the belt tensioner.

Note. Perform the work with the engine installed to body when replacing a single part.

Scheme 90

1. Remove the V-belts. REMOVAL, V-belt .>
2. Remove the crank pulley bolt. To lock the crankshaft, use ST. ST 499977100 CRANK PULLEY WRENCH
3. Remove the crank pulley.

1. Install the crank pulley.
2. Install the pulley bolt. To lock the crankshaft, use ST. ST 499977100 CRANK PULLEY WRENCH Clean the crankshaft thread using compressed air. Apply engine oil to the crank pulley bolt seat and thread. Tighten the bolts temporarily with tightening torque of 44 N.m (4.5 kgf-m, 33 ft-lb). Tighten the crank pulley bolts. Tightening torque: 180 N.m (18.4 kgf-m, 132.8 ft-lb)
3. Check that the tightening angle of the crank pulley bolt is 65° or more. Perform the following procedures when less than 65°. CAUTION: If the tightening angle of crank pulley bolt is less than 65°, the bolt is damaged. In this case, the bolt must be replaced. Replace the crank pulley bolts and clean them. Crank pulley bolt: 12369A A011 Clean the crankshaft thread using compressed air. Apply engine oil to the crank pulley bolt seat and thread. Tighten the bolts temporarily with tightening torque of 44 N.m (4.5 kgf-m, 33 ft-lb). Tighten the crank pulley bolts 65° to 75°. NOTE: Conduct the tightening procedures by confirming the turning angle of crank pulley bolt referring to the gauge indicated on timing belt cover.
4. Install the belt tensioner.
5. Install the V-belts. INSTALLATION, V-belt .>

Note. Perform the work with the engine installed to body when replacing a single part.

Scheme 91

1. Remove the V-belts. REMOVAL, V-belt .>
2. Remove the crank pulley. REMOVAL, Crank Pulley .>
3. Remove the timing belt cover (LH).
4. Remove the front timing belt cover.

Scheme 92

1. Install the front timing belt cover. Tightening torque: 5 N.m (0.5 kgf-m, 3.6 ft-lb)
2. Install the timing belt cover (LH). Tightening torque: 5 N.m (0.5 kgf-m, 3.6 ft-lb)
3. Install the crank pulley. INSTALLATION, Crank Pulley .>
4. Install the V-belts. INSTALLATION, V-belt .>

Note. Perform the work with the engine installed to body when replacing a single part. For operation procedures, TIMING BELT . >

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

1. Remove the V-belts. REMOVAL, V-belt .>
2. Remove the crank pulley. REMOVAL, Crank Pulley .>
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover .>
4. Remove the timing belt guide. (MT model)
5. If the alignment mark (a) or arrow mark (which indicates rotation direction) on the timing belt has faded away, put new marks on the belt before removing as shown in procedures below. Use the ST to turn crankshaft. Align the mark (a) of sprocket to the cylinder block notch (b), and then ensure the right side cam sprocket mark (c), cam cap and cylinder head matching surface (d) or left side cam sprocket mark (e), timing belt cover notch (f) are properly adjusted. ST 499987500 CRANKSHAFT SOCKET Using white paint, put an alignment mark or an arrow mark on timing belts in relation to the crank sprocket and cam sprockets. Specified data: Z 1 : 46.8 teeth Z 2 : 43.7 teeth
6. Remove the belt idler (No. 2).
7. Remove the belt idler No. 2.
8. Remove the timing belt.

Scheme 100

Scheme 101

1. Remove the belt idler (No. 1).
2. Remove the automatic belt tension adjuster assembly.

Scheme 102

Scheme 103

Scheme 104

Scheme 105

1. Prepare for installation of automatic belt tension adjuster assembly. CAUTION: Always use a vertical type pressing tool to move the adjuster rod down. Do not use a lateral type vise. Push the adjuster rod vertically. Press-in the push adjuster rod gradually taking three minutes or more. Do not allow press pressure to exceed 9,807 N (1,000 kgf, 2,205 lb). Push in the adjuster rod to the end face of the cylinder. Do not press the adjuster rod into cylinder. Doing so may damage the cylinder. Do not release the press pressure until stopper pin is completely inserted. Attach the automatic belt tension adjuster assembly to vertical pressing tool. Slowly move the adjuster rod down with a pressure of 294 N (30 kgf, 66 lb) or more until the adjuster rod is aligned with the stopper pin hole in the cylinder. With a 2 mm (0.08 in) dia. stopper pin or a 2 mm (0.08 in) (nominal) dia. hex wrench inserted into the stopper pin hole in cylinder, secure the adjuster rod.
2. Install the automatic belt tension adjuster assembly. Tightening torque: 39 N.m (4.0 kgf-m, 28.9 ft-lb)
3. Install the belt idler (No. 1). Tightening torque: 39 N.m (4.0 kgf-m, 28.9 ft-lb)

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

1. Prepare for installation of the automatic belt tension adjuster assembly. AUTOMATIC BELT TENSION ADJUSTER ASSEMBLY AND BELT IDLER, INSTALLATION, Timing Belt .>
2. Installation of timing belt: Turn the cam sprocket No. 1 and No. 2 using an ST, and position the alignment marks (A) on each at the highest positions. ST1 18231AA010 CAM SPROCKET WRENCH NOTE: CAM SPROCKET WRENCH (499207100) can also be used. While aligning the alignment mark (B) on timing belt with the mark (A) on sprockets, position the timing belt properly.
3. Install the belt idlers (A) and (B), with (B) first. Tightening torque: 39 N.m (4.0 kgf-m, 28.9 ft-lb)
4. After ensuring the marks on timing belt and camshaft sprockets are aligned, remove the stopper pin from belt tension adjuster.
5. Install the timing belt guide. (MT model) Temporarily tighten the bolts mounting the timing belt guide. Check and adjust the clearance between timing belt and timing belt guide by using thickness gauge. Clearance: 1.0±0.5 mm (0.039±0.020 in) Tighten the bolts mounting the timing belt guide. Tightening torque: 9.75 N.m (1.0 kgf-m, 7.2 ft-lb)
6. Install the timing belt cover. INSTALLATION, Timing Belt Cover .>
7. Install the crank pulley. INSTALLATION, Crank Pulley .>
8. Install the V-belts. INSTALLATION, V-belt .>

Scheme 113

1. Check the timing belt teeth for breaks, cracks or wear. If any fault is found, replace the belt.
2. Check the condition of the back surface of belt. If cracks are found, replace the belt. CAUTION: Be careful not to let oil, grease or coolant contact the belt. Remove quickly and thoroughly if this happens. Do not bend the timing belt sharply. In radial diameter h: 60 mm (2.36 in) or more

Scheme 114

1. Visually check the oil seals for leaks, and rod ends for abnormal wear and scratches. If necessary, replace the automatic belt tension adjuster assembly. NOTE: Slight traces of oil at rod's oil seal does not indicate a problem.
2. Check that the adjuster rod does not move when a pressure of 294 N (30 kgf, 66 lb) is applied to it. This is to check adjuster rod stiffness.
3. If the adjuster rod is not stiff and moves freely when applying 294 N (30 kgf, 66 lb), check it using the following procedures: Slowly press the adjuster rod down to the end surface of cylinder. Repeat this operation two to three times. With the adjuster rod moved all the way up, apply a pressure of 294 N (30 kgf, 66 lb) to it. Check the adjuster rod movement. If the adjuster rod is not stiff and moves down, replace the automatic belt tension adjuster assembly with a new part. CAUTION: Always use a vertical type pressing tool to move the adjuster rod down. Do not use a lateral type vise. Push the adjuster rod vertically. Press the adjuster rod gradually taking three minutes or more. Do not allow press pressure to exceed 9,807 N (1,000 kgf, 2,205 lb). Push in the adjuster rod to the end face of the cylinder. Do not press the adjuster rod into cylinder. If this instruction is not followed, this may damage the cylinder.
4. Measure the amount of rod protrusion beyond the body. If it is not within specified range, replace with new part. Amount of rod protrusion H: 5.2 - 6.2 mm (0.204 - 0.244 in)

Note. Perform the work with the engine installed to body when replacing a single part.

Scheme 115

1. Remove the V-belts. REMOVAL, V-belt .>
2. Remove the crank pulley. REMOVAL, Crank Pulley .>
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover .>
4. Remove the timing belt. REMOVAL, Timing Belt .>
5. Remove the camshaft position sensor. REMOVAL , Camshaft Position Sensor .>
6. Remove the cam sprockets No. 1 and No. 2. To lock the camshaft, use the ST. ST 18231AA010 CAM SPROCKET WRENCH NOTE: CAM SPROCKET WRENCH (499207100) can also be used.

1. Install the cam sprocket No. 1 and No. 2. To lock the camshaft, use the ST. ST 18231AA010 CAM SPROCKET WRENCH NOTE: CAM SPROCKET WRENCH (499207100) can also be used. Tightening torque: 78 N.m (8.0 kgf-m, 57.9 ft-lb) NOTE: Do not confuse left and right side cam sprockets during installation. They should be distinguished by the L or R indication.
2. Install the camshaft position sensor. INSTALLATION , Camshaft Position Sensor .>
3. Install the timing belt. INSTALLATION, Timing Belt .>
4. Install the timing belt cover. INSTALLATION, Timing Belt Cover .>
5. Install the crank pulley. INSTALLATION, Crank Pulley .>
6. Install the V-belts. INSTALLATION, V-belt .>

Note. Perform the work with the engine installed to body when replacing a single part.

Scheme 116

1. Remove the V-belts. REMOVAL, V-belt .>
2. Remove the crank pulley. REMOVAL, Crank Pulley .>
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover .>
4. Remove the timing belt. REMOVAL, Timing Belt .>
5. Remove the crank sprocket.

1. Install the crank sprocket.
2. Install the timing belt. INSTALLATION, Timing Belt .>
3. Install the timing belt cover. INSTALLATION, Timing Belt Cover .>
4. Install the crank pulley. INSTALLATION, Crank Pulley .>
5. Install the V-belts. INSTALLATION, V-belt .>

Note. Perform the work with the engine installed to body when replacing a single part. Refer to "Valve Clearance" for preparation. VALVE CLEARANCE. >

Scheme 117

Scheme 118

Scheme 119

Scheme 120

1. Remove the V-belts. REMOVAL, V-belt .>
2. Remove the crank pulley. REMOVAL, Crank Pulley .>
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover .>
4. Remove the timing belt. REMOVAL, Timing Belt .>
5. Remove the cam sprocket. REMOVAL, Cam Sprocket .>
6. Disconnect the PCV hose and remove the rocker cover.
7. Remove the valve rocker assembly. Use the ST to rotate the spring stopper in the direction of the arrow to remove it from adjuster pin. ST 18258AA000 SPRING INSTALLER Remove the bolts (a) through (j) in alphabetical sequence. NOTE: Leave two or three threads of bolts (i) and (j) engaged in order to retain the valve rocker assembly. Remove the valve rocker assembly. NOTE: Set the ST in the position shown in the drawing to remove the intake valve rocker assembly. ST 18354AA000 VALVE ROCKER HOLDER

Scheme 121

Scheme 122

Scheme 123

Scheme 124

1. Install the valve rocker assembly. Temporarily tighten the bolts equally in alphabetical order as shown in the figure. NOTE: Do not temporarily tighten the bolts (i) and (j). Set the ST in the position shown in the drawing to mount the intake valve rocker assembly. ST 18354AA000 VALVE ROCKER HOLDER Tighten the bolts (a) through (h) to specified torque. Tightening torque: 25 N.m (2.5 kgf-m, 18.1 ft-lb) Tighten the bolts (i) through (j) to specified torque. Tightening torque: 6 N.m (0.6 kgf-m, 4.3 ft-lb) Use the ST to rotate the spring stopper in the direction of the arrow to fasten the adjuster pin. ST 18258AA000 SPRING INSTALLER
2. Install the cam sprocket. INSTALLATION, Cam Sprocket .>
3. Install the timing belt. INSTALLATION, Timing Belt .>
4. Adjust the valve clearance. ADJUSTMENT, Valve Clearance .>
5. Install the rocker cover and rocker cover gasket, and then connect PCV hose. NOTE: Use a new rocker cover gasket. Tighten the bolts in two stages in alphabetical sequence as shown in figure. Tightening torque: 1st 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) 2nd (only (a) and (b) are tightened) 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) RH side LH side
6. Install the timing belt cover. INSTALLATION, Timing Belt Cover .>
7. Install the crank pulley. INSTALLATION, Crank Pulley .>
8. Install the V-belts. INSTALLATION, V-belt .>

Note. Perform the work with the engine installed to body when replacing a single part. Refer to "Valve Clearance" for preparation. VALVE CLEARANCE. >

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

1. Remove the V-belts. REMOVAL, V-belt .>
2. Remove the crank pulley. REMOVAL, Crank Pulley .>
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover .>
4. Remove the timing belt. REMOVAL, Timing Belt .>
5. Remove the cam sprocket. REMOVAL, Cam Sprocket .>
6. Remove the timing belt cover No. 2 (LH).
7. Remove the timing belt cover No. 2 (RH). NOTE: Do not damage or lose the seal rubber when removing the timing belt covers.
8. Remove the tensioner bracket.
9. Remove the camshaft position sensor support. (LH side only)
10. Remove the oil level gauge guide. (LH side only)
11. Remove the valve rocker assembly. REMOVAL, Valve Rocker Assembly .>
12. Remove the camshaft cap. Remove the bolts (a) and (b) in alphabetical sequence. Equally loosen the bolts (c) through (j) all the way in alphabetical sequence. Remove the bolts (k) through (p) in alphabetical sequence using ST. ST 499497000 TORX® PLUS Remove the camshaft cap.
13. Remove the camshaft.
14. Remove the oil seal.
15. Remove the plug from rear side of camshaft. CAUTION: Do not remove the oil seal unless necessary. Do not scratch the journal surface when removing the oil seal.

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

1. Apply a thin coat of engine oil to camshaft journals, and install the camshaft.
2. Install the camshaft cap. Apply liquid gasket to the mating surfaces of camshaft cap. Liquid gasket: THREE BOND 1280B (Part No. K0877YA018) NOTE: Apply a coat of liquid gasket of 3 mm (0.12 in) in diameter (A) along the edge (B) of camshaft cap (C) mating surface. Install within 5 min. after applying liquid gasket. Temporarily tighten the bolts (a) through (d) in alphabetical sequence. Install the valve rocker assembly. INSTALLATION, Valve Rocker Assembly .> Tighten the TORX® bolts (e) through (j) in alphabetical sequence using the ST. ST 499497000 TORX® PLUS Tightening torque: 18 N.m (1.8 kgf-m, 13.0 ft-lb) Tighten the bolts (k) through (r) in alphabetical sequence. Tightening torque: 9.75 N.m (1.0 kgf-m, 7.2 ft-lb) Tighten the bolts (s) and (t) in alphabetical sequence. NOTE: Use a new seal washer. Install and tighten the seal washer. Tightening torque: 9.75 N.m (1.0 kgf-m, 7.2 ft-lb)
3. Apply a coat of engine oil to oil seal periphery and oil seal lips and install the oil seal (A) on camshaft using ST1 and ST2. NOTE: Use a new oil seal. ST1 499597000 OIL SEAL GUIDE ST2 499587500 OIL SEAL INSTALLER
4. Install the plug (A) using ST. ST 499587700 CAMSHAFT OIL SEAL INSTALLER
5. Adjust the valve clearance. ADJUSTMENT, Valve Clearance .>
6. Install the rocker cover and rocker cover gasket, and then connect PCV hose. NOTE: Use a new rocker cover gasket. Tighten the bolts in two stages in alphabetical sequence as shown in figure. Tightening torque: 1st 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) 2nd (only (a) and (b) are tightened) 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) RH side LH side
7. Install the oil level gauge guide. (LH side only)
8. Install the camshaft position sensor support. (LH side only)
9. Install the tensioner bracket. Tightening torque: 24.5 N.m (2.5 kgf-m, 18.1 ft-lb)
10. Install the timing belt cover No. 2 (RH). Tightening torque: 5 N.m (0.5 kgf-m, 3.6 ft-lb)
11. Install the timing belt cover No. 2 (LH). Tightening torque: 5 N.m (0.5 kgf-m, 3.6 ft-lb)
12. Install the cam sprocket. INSTALLATION, Cam Sprocket .>
13. Install the timing belt. INSTALLATION, Timing Belt .>
14. Install the timing belt cover. INSTALLATION, Timing Belt Cover .>
15. Install the crank pulley. INSTALLATION, Crank Pulley .>
16. Install the V-belts. INSTALLATION, V-belt .>

Scheme 140

Scheme 141

1. Measure the bend, and repair or replace if necessary. Service limit: 0.025 mm (0.00098 in)
2. Check the journal for damage and wear. Replace if faulty.
3. Measure the outer diameter of camshaft journal and inner diameter of cylinder head journal, and confirm the difference (oil clearance) between the two values. If the oil clearance exceeds the standard, replace the camshaft or cylinder head as necessary. OIL CLEARANCE SPECIFICATION Unit: mm (in) Oil clearance Standard 0.055 - 0.090 (0.0022 - 0.0035) Camshaft journal O.D. 31.928 - 31.945 (1.2570 - 1.2577) Journal hole I.D. 32.000 - 32.018 (1.2598 - 1.2605)
4. Check the cam face condition, and remove the minor faults by grinding with oil stone. Measure the cam height H. If it exceeds the standard, replace it. Cam height H: CAM HEIGHT SPECIFICATION Part Unit: mm (in) Intake Constant Standard 40.075 - 40.175 (1.5778 - 1.5817) Low speed Standard 35.182 - 35.282 (1.3851 - 1.3891) High speed Standard 40.315 - 40.415 (1.5872 - 1.5911) Exhaust Standard 40.088 - 40.188 (1.5783 - 1.5822) Cam base circle diameter A: Intake 34.00 mm (1.3386 in) Exhaust 34.00 mm (1.3386 in) Base circle step of adjacent intake cams (low speed and high speed): 0.03 mm (0.001 in) or less
5. Measure the thrust clearance of camshaft with setting the dial gauge at end of camshaft. If the thrust clearance exceeds the limit, replace the camshaft caps and cylinder head as a set. If necessary, replace the camshaft. Standard: 0.030 - 0.090 mm (0.0012 - 0.0035 in)

Note. Perform the work with the engine installed to body when replacing a single part. Refer to "Valve Clearance" for preparation. VALVE CLEARANCE. >

Scheme 142

1. Remove the V-belts. REMOVAL, V-belt .>
2. Remove the crank pulley. REMOVAL, Crank Pulley .>
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover .>
4. Remove the timing belt. REMOVAL, Timing Belt .>
5. Remove the cam sprocket. REMOVAL, Cam Sprocket .>
6. Remove the intake manifold. REMOVAL , Intake Manifold .>
7. Remove the bolt which installs the A/C compressor bracket on cylinder head.
8. Remove the valve rocker assembly. REMOVAL, Valve Rocker Assembly .>
9. Remove the camshaft. REMOVAL, Camshaft .>
10. Remove the cylinder head bolts in alphabetical sequence as shown in the figure. NOTE: Leave bolts (a) and (c) engaged by three or four threads to prevent the cylinder head from falling.
11. While tapping the cylinder head with a plastic hammer, separate it from cylinder block.
12. Remove the bolts (a) and (c) to remove cylinder head.
13. Remove the cylinder head gasket. CAUTION: Be careful not to scratch the mating surface of cylinder head and cylinder block.
14. Similarly, remove the right side cylinder head.

Scheme 143

1. Install the cylinder head and gaskets on cylinder block. CAUTION: Be careful not to scratch the mating surface of cylinder block and cylinder head. NOTE: Use a new gasket.
2. Tighten the cylinder head bolts. Apply a thin coat of engine oil to washer and bolt thread. Tighten all bolts to 29 N.m (3.0 kgf-m, 22 ft-lb) in alphabetical order. Then tighten all bolts to 69 N.m (7.0 kgf-m, 51 ft-lb) in alphabetical sequence. Loosen all the bolts by 180° in reverse order of installation, and loosen again by 180° in the same order. Tighten all bolts to 42 N.m (3.9 kgf-m, 31 ft-lb) in alphabetical order. Tighten all bolts by 80 to 90° in alphabetical sequence. Tighten all bolts by 40 to 45° in alphabetical sequence. CAUTION: The tightening angle of the bolt should not exceed 45°. Further tighten the bolts (a) and (b) by 40 - 45°. CAUTION: Make sure the total "re-tightening angle" of the step (6) and (7) does not exceed 90°.
3. Install the camshaft. INSTALLATION, Camshaft .>
4. Install the valve rocker assembly. INSTALLATION .>
5. Install the A/C compressor bracket on cylinder head.
6. Install the intake manifold. INSTALLATION , Intake Manifold .>
7. Install the cam sprocket. INSTALLATION, Cam Sprocket .>
8. Install the timing belt. INSTALLATION, Timing Belt .>
9. Adjust the valve clearance. ADJUSTMENT, Valve Clearance .>
10. Install the rocker cover and rocker cover gasket, and then connect PCV hose. NOTE: Use a new gasket.
11. Install the timing belt cover. INSTALLATION, Timing Belt Cover .>
12. Install the crank pulley. INSTALLATION, Crank Pulley .>
13. Install the V-belts. INSTALLATION, V-belt .>

Scheme 144

1. Place the cylinder head on the ST. ST 498267800 CYLINDER HEAD TABLE
2. Set the ST on valve spring. Compress the valve spring and remove the valve spring retainer key. Remove each valve and valve spring. ST 499718000 VALVE SPRING REMOVER NOTE: Keep all the removed parts in order for re-installing in their original positions. Mark each valve to prevent confusion. Pay careful attention not to damage the lips of intake valve oil seals and exhaust valve oil seals.

Scheme 145

Scheme 146

1. Installation of valve spring and valve: Place the cylinder head on the ST. ST 498267800 CYLINDER HEAD TABLE Coat the stem of each valve with engine oil and insert the valve into the valve guide. NOTE: When inserting the valve into valve guide, use special care not to damage the oil seal lip. Install the valve spring and retainer. NOTE: Be sure to install the valve spring with its close-coiled end facing the seat on cylinder head. Set the ST on valve spring. ST 499718000 VALVE SPRING REMOVER Compress the valve spring and fit the valve spring retainer key. After installing, tap the valve spring retainers lightly with a plastic hammer for better seating.

Scheme 147

1. Check for cracks or damage. Use liquid penetrant tester on the important sections to check for fissures. Check that there are no marks of gas leaking or water leaking on gasket installing surface.
2. Place the cylinder head on the ST. ST 498267800 CYLINDER HEAD TABLE
3. Measure the warping of the cylinder head surface that mates with the cylinder block using a straight edge and thickness gauge. If the warping exceeds the limit, correct the surface by grinding it with a surface grinder. Warping limit: 0.035 mm (0.0014 in) Grinding limit: 0.1 mm (0.004 in) Standard height of cylinder head: 97.5 mm (3.839 in) NOTE: Uneven torque for the cylinder head bolts can cause warping. When reassembling, pay special attention to the torque so as to tighten evenly.

Note. Before conducting this procedure, drain the engine oil completely.

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

1. Remove the intake manifold. REMOVAL , Intake Manifold .>
2. Remove the V-belts. REMOVAL, V-belt .>
3. Remove the crank pulley. REMOVAL, Crank Pulley .>
4. Remove the timing belt cover. REMOVAL, Timing Belt Cover .>
5. Remove the timing belt. REMOVAL, Timing Belt .>
6. Remove the cam sprocket. REMOVAL, Cam Sprocket .>
7. Remove the crank sprocket. REMOVAL, Crank Sprocket .>
8. Remove the generator and A/C compressor with their brackets.
9. Remove the rocker cover.
10. Remove the cylinder head bolts in alphabetical order shown in the figure. NOTE: Leave bolts (a) and (d) engaged by three or four threads to prevent the cylinder head from falling.
11. While tapping the cylinder head with a plastic hammer, separate it from cylinder block.
12. Remove the bolts (a) and (d) to remove cylinder head.
13. Remove the cylinder head gasket. NOTE: Do not scratch the mating surface of cylinder head and cylinder block.
14. Similarly, remove the right side cylinder head.
15. Remove the clutch cover. (MT model)
16. Remove the flywheel (MT model) or drive plate (AT model). Using the ST, lock the crankshaft. ST 498497100 CRANKSHAFT STOPPER MT model AT model
17. Remove the oil separator cover.
18. Remove the water by-pass pipe for heater.
19. Remove the water pump after loosening the bolts in alphabetical sequence as shown in the figure.
20. Remove the bolts which install oil pump onto cylinder block. NOTE: When disassembling and checking the oil pump, loosen the relief valve plug before removing the oil pump.
21. Remove the oil pump from cylinder block using a flat tip screwdriver. CAUTION: Be careful not to scratch the mating surface of cylinder block and oil pump.
22. Remove the oil pan. Set the part so that the cylinder block (LH) is on the upper side. Remove the bolts which secure oil pan to cylinder block. Insert an oil pan cutter blade between cylinder block-to-oil pan clearance and remove the oil pan. CAUTION: Do not use a screwdriver or similar tools in place of oil pan cutter.
23. Remove the oil strainer stay.
24. Remove the oil strainer.
25. Remove the baffle plate.
26. Remove the oil filter. REMOVAL , Engine Oil Filter .>
27. Remove the water pipe.
28. Remove the service hole plug using a hexagon wrench (14 mm).
29. Remove the service hole cover.
30. Rotate the crankshaft to bring #1 and #2 pistons to bottom dead center position, then remove the piston snap ring through service hole of #1 and #2 cylinders.
31. Draw out the piston pin from #1 and #2 pistons using ST. ST 499097700 PISTON PIN REMOVER NOTE: Be careful not to confuse the original combination of piston, piston pin and cylinder.
32. Similarly remove the piston pins from #3 and #4 pistons.
33. Remove the cylinder block connecting bolt on the RH side.
34. Loosen the cylinder block connecting bolt on the LH side by 2-3 turns.
35. Set the part so that the cylinder block (LH) is on the upper side, and remove the cylinder block connecting bolt.
36. Separate the cylinder block (RH) and (LH). NOTE: When separating the cylinder block, do not allow the connecting rod to fall or damage the cylinder block.
37. Remove the rear oil seal.
38. Remove the crankshaft along with the connecting rods.
39. Remove the crankshaft bearings from cylinder block using a hammer handle. NOTE: Do not confuse the combination of crankshaft bearings. Press the bearing at the end opposite to locking lip.
40. Draw out each piston from cylinder block using wooden bar or hammer handle. NOTE: Do not confuse the combination of piston and cylinder.

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

1. Remove oil on the mating surface of cylinder block before installation. Apply a coat of engine oil to the bearing and crankshaft journal.
2. Position the crankshaft and O-ring on the cylinder block (RH).
3. Apply liquid gasket to the mating surfaces of cylinder block (RH), and position the cylinder block (LH). Liquid gasket: THREE BOND 1215 (Part No. 004403007) or equivalent NOTE: Do not allow liquid gasket to jut into O-ring grooves, oil passages, bearing grooves, etc.
4. Apply a coat of engine oil to the washer and bolt thread. NOTE: Use a new seal washer.
5. Tighten the 10 mm cylinder block connecting bolts on the LH side (A - D) in alphabetical order. Tightening torque: 10 N.m (1.0 kgf-m, 7.2 ft-lb)
6. Tighten the 10 mm cylinder block connecting bolts on the RH side (E - J) in alphabetical order. Tightening torque: 10 N.m (1.0 kgf-m, 7.2 ft-lb)
7. Tighten the LH side cylinder block connecting bolts (A - D) further in alphabetical order. Tightening torque: 18 N.m (1.8 kgf-m, 13 ft-lb)
8. Tighten the RH side cylinder block connecting bolts (E - J) further in alphabetical order. Tightening torque: 18 N.m (1.8 kgf-m, 13 ft-lb)
9. Tighten the LH side cylinder block connecting bolts (A - D) further in alphabetical order. (A), (C): Angle tightening Tightening angle: 90° (B), (D): Torque tightening Tightening torque: 40 N.m (4.1 kgf-m, 29.6 ft-lb)
10. Tighten the RH side cylinder block connecting bolts (E - J) in alphabetical order. Tightening angle: 90°
11. Tighten the 8 mm and 6 mm cylinder block connecting bolts on LH side (A - H) in alphabetical sequence. Tightening torque: (A) - (G): 25 N.m (2.5 kgf-m, 18.1 ft-lb) (H): 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
12. Apply a coat of engine oil to the oil seal periphery, then install the rear oil seal using ST1 and ST2. NOTE: Use new rear oil seal. ST1 499597100 OIL SEAL GUIDE ST2 499587200 OIL SEAL INSTALLER
13. Position the top ring gap at (A) or (B) in the figure. NOTE: Assemble so that the piston ring mark "R" faces the top side of the piston.
14. Position the second ring gap at 180° on the reverse side the top ring gap. NOTE: Assemble so that the piston ring mark "R" faces the top side of the piston.
15. Position the upper rail gap at (C) in the figure.
16. Align the upper rail spin stopper (E) to the side hole (D) on the piston.
17. Position the expander gap at (F) in the figure.
18. Position the lower rail gap at (G) in the figure. NOTE: Make sure ring gaps do not face the same direction. Make sure ring gaps are not within the piston skirt area.
19. Install the snap ring. Before installing the piston to the cylinder block, install the snap rings to the piston holes on the opposite side of the service holes on the cylinder block. NOTE: Use new snap rings.
20. Install the piston. Set the parts so that the #1 and #2 cylinders are on the upper side. Using the ST1, turn the crankshaft so that #1 and #2 connecting rods are set at bottom dead center. ST1 499987500 CRANKSHAFT SOCKET Tightening torque: N.m (kgf-m, ft-lb) T: 70 (7.1, 50.6) Apply a coat of engine oil to the pistons and cylinders and insert pistons in their cylinders using ST2. ST2 498747300 PISTON GUIDE CAUTION: Piston front mark faces towards the front of engine.
21. Install the piston pin. Apply a coat of engine oil to ST3. Insert ST3 into the service hole to align piston pin hole with connecting rod small end. ST3 499017100 PISTON PIN GUIDE Apply a coat of engine oil to piston pin, and insert the piston pin into piston and connecting rod through service hole. Install the snap ring. NOTE: Use new snap rings. Apply liquid gasket to the threaded portion of the service hole plug. Liquid gasket: THREE BOND 1105 (Part No. 004403010) or equivalent Install the service hole plug and gasket. NOTE: Use a new gasket. Set the parts so that the #3 and #4 cylinders are on the upper side. Following the same procedures as used for #1 and #2 cylinders, install the pistons and piston pins.
22. Install the water pipe. Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
23. Install the baffle plate. Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
24. Install the O-ring to the oil strainer, then install it to the cylinder block. Tightening torque: 10 N.m (1.0 kgf-m, 7.4 ft-lb)
25. Install the oil strainer stay. Tighten the oil strainer together with the baffle plate. Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
26. Apply liquid gasket to the mating surfaces, and install the oil pan. NOTE: Install within 5 min. after applying liquid gasket. Liquid gasket: THREE BOND 1207C (Part No. 004403012) or equivalent Tightening torque: 5 N.m (0.5 kgf-m, 3.6 ft-lb)
27. Apply liquid gasket to the mating surfaces and the threaded portion of bolt (A) shown in the figure (when reusing the bolt), and then install the oil separator cover. NOTE: Install within 5 min. after applying liquid gasket. Liquid gasket: Mating surface THREE BOND 1217G or equivalent (A) bolt threads (when reusing bolts) THREE BOND 1324 (Part No. 004403042) or equivalent Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
28. Install the flywheel. (MT model) B: INSTALLATION , Flywheel .> To lock the crankshaft, use the ST. ST 498497100 CRANKSHAFT STOPPER Tightening torque: 72 N.m (7.3 kgf-m, 52.8 ft-lb)
29. Install the drive plate. (AT model) To lock the crankshaft, use the ST. ST 498497100 CRANKSHAFT STOPPER Tightening torque: 72 N.m (7.3 kgf-m, 52.8 ft-lb)
30. Install the clutch cover. (MT model)
31. Installation of oil pump: Replace the front oil seal with a new part using ST. ST 499587100 OIL SEAL INSTALLER Apply liquid gasket to the matching surface of oil pump. Liquid gasket: THREE BOND 1215 (Part No. 004403007) or equivalent Apply a coat of engine oil to the inside of oil seal. Install the oil pump to cylinder block. Be careful not to damage the oil seal during installation. NOTE: Make sure the oil seal lip is not folded. Align the flat surface of oil pump's inner rotor with crankshaft before installation. Use new O-rings and oil seals. Apply liquid gasket to the three bolts thread shown in figure, (when reusing bolts) Liquid gasket: THREE BOND 1324 (Part No. 004403042) or equivalent Tightening torque: T: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
32. Install the water pump and gasket. Tightening torque: First: 12 N.m (1.2 kgf-m, 8.7 ft-lb) Second: 12 N.m (1.2 kgf-m, 8.7 ft-lb) NOTE: When installing the water pump, tighten bolts in two stages in alphabetical order as shown in the figure. Use a new gasket.
33. Install the water by-pass pipe for heater.
34. Install the oil filter. INSTALLATION , Engine Oil Filter .>
35. Tighten the cylinder head bolts. INSTALLATION, Cylinder Head .>
36. Install the oil level gauge guide and tighten the bolts. (LH side only)
37. Install the crank sprocket. INSTALLATION, Crank Sprocket .>
38. Install the cam sprocket. INSTALLATION, Cam Sprocket .>
39. Install the timing belt. INSTALLATION, Timing Belt .>
40. Adjust the valve clearance. ADJUSTMENT, Valve Clearance .>
41. Install the rocker cover gasket to the rocker cover, install it to the cylinder head, and then connect the PCV hose. NOTE: Use a new gasket.
42. Install the timing belt cover. INSTALLATION, Timing Belt Cover .>
43. Install the crank pulley. INSTALLATION, Crank Pulley .>
44. Install the generator and A/C compressor brackets on cylinder head.
45. Install the V-belts. INSTALLATION, V-belt .>
46. Install the intake manifold. INSTALLATION , Intake Manifold .>

Scheme 186

1. Remove the connecting rod cap.
2. Remove the connecting rod bearing. NOTE: Arrange the removed connecting rod, connecting rod cap and bearing in order, to prevent confusion.
3. Remove the piston rings using piston ring expander.
4. Remove the oil ring by hand. NOTE: Arrange the removed piston rings in proper order, to prevent confusion.
5. Remove the snap ring.

Scheme 187

1. Apply oil to the surfaces of the connecting rod bearings.
2. Install the connecting rod bearings on connecting rods and connecting rod caps.
3. Position each connecting rod with the marking side facing forward, and install it.
4. Install the connecting rod cap with connecting rod nut. Make sure the arrow on connecting rod cap faces toward front during installation. NOTE: Each connecting rod has its own mating cap. Make sure that they are assembled correctly by checking their matching number. When tightening the connecting rod nuts, apply oil on the threads.
5. Install the expander, lower rail and upper rail by hand. Install the second ring and top ring using piston ring expander. Tightening torque: N.m (kgf-m, ft-lb) T: 45 (4.6, 33.3)
