Engine Intake System - Intake (Induction) (H4DOTC): Other Subaru Outback BP рестайлинг

CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from the battery.

Scheme 475

Scheme 476

1. Remove the collector cover.
2. Disconnect the ground cable from the battery.
3. Disconnect the connector (A) from the mass air flow sensor.
4. Loosen the clamp (B) which connects the air intake boot and intake duct.
5. Remove the clip (C) from the air cleaner case.
6. Remove the air cleaner case (rear) and air intake boot.
7. Remove the air cleaner element.
