ADJUSTMENT
Note. Adjustment of valve clearance should be performed while engine is cold.
Scheme 53
- Set #1 cylinder piston to top dead center of compression stroke by rotating the crank pulley clockwise using the socket wrench. NOTE: When the arrow mark (A) on cam sprocket (LH) comes exactly to the top, #1 cylinder piston is brought to the top dead center of compression stroke.
- Adjust the #1 cylinder valve clearance. Loosen the valve rocker nut and screw. Set a suitable thickness gauge. While noting the valve clearance, tighten the valve rocker adjusting screw. When the specified valve clearance is obtained, tighten the valve rocker nut. Tightening torque: 9.75 N.m (1.0 kgf-m, 7.2 ft-lb) NOTE: Insert a thickness gauge in a direction as horizontal as possible with respect to the valve stem end face. Lift up the vehicle and adjust the exhaust valve clearances. Valve clearance: Intake 0.20±0.04 mm (0.0079±0.0016 in) Exhaust 0.25±0.04 mm (0.0098±0.0016 in)
- Adjust the valve clearance in #3, #2 and #4 cylinder in the same adjustment procedure as #1 cylinder in this order. NOTE: Be sure to set the cylinder pistons to their respective top dead centers on compression stroke before adjusting valve clearances. By rotating the crank pulley clockwise every 180° from the state that #1 cylinder piston is on the top dead center of compression stroke, #3, #2 and #4 cylinder pistons come to the top dead center of compression stroke in this order.
- Ensure the valve clearances of each cylinder are within specifications. If necessary, readjust the valve clearances.
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
- Set the vehicle on a lift.
- Open the front hood fully and support with the front food stay.
- Collect the refrigerant from the A/C system. PROCEDURE , Refrigerant Recovery Procedure .>
- Release the fuel pressure. RELEASING OF FUEL PRESSURE , PROCEDURE, Fuel .>
- Disconnect the ground cable from the battery.
- Open the fuel filler flap lid, and remove the fuel filler cap.
- Remove the air intake duct, air cleaner case and air intake chamber. REMOVAL , Air Intake Duct .> REMOVAL , Air Cleaner Case .> REMOVAL , Air Intake Chamber .>
- Remove the under cover.
- Remove the radiator from the vehicle. REMOVAL , Radiator .>
- Disconnect the A/C pressure hoses from A/C compressor.
- Remove the air intake chamber stay.
- Disconnect the following connectors and cables. Front oxygen (A/F) sensor connector Rear oxygen sensor connector Engine ground cable Engine harness connectors Generator connector and terminal A/C compressor connector Power steering switch connector
- Disconnect the following hoses. Brake booster vacuum hose Heater inlet and outlet hoses
- Remove the power steering pump. Remove the front side V-belts. FRONT SIDE BELT, REMOVAL, V-belt .> Remove the bolts which secure the power steering pump to the bracket. Place the power steering pump on the right side wheel apron.
- Remove the front and center exhaust pipes. REMOVAL , Front Exhaust Pipe .>
- Remove the bolts and nuts which hold lower side of transmission to engine.
- Remove the nuts which install front cushion rubber onto front crossmember.
- Separate the torque converter clutch from drive plate. (AT model) Lower the vehicle. Remove the service hole plug. Remove the bolts which hold torque converter clutch to drive plate. Remove all bolts while turning the crankshaft with a socket wrench.
- Remove the pitching stopper.
- Disconnect the fuel hoses from fuel pipe. Disconnect the quick connector on the fuel delivery line by pushing the ST in the direction of the arrow. ST 42099AE000 CONNECTOR REMOVER Remove the clip and disconnect the evaporation hose from the pipe. CAUTION: Be careful not to spill fuel. Catch the fuel from hoses using a container or cloth.
- Support the engine with a lifting device and wire ropes.
- Support the transmission with a garage jack. CAUTION: Be sure to perform this work to prevent the transmission from lowering due to its own weight. CAUTION: Before removing the engine away from transmission, check to be sure no work has been overlooked.
- Separation of engine and transmission. Remove the starter. REMOVAL , Starter .> Remove the bolts which hold upper side of transmission to engine.
- Attach the ST to the converter case. (AT model) ST 498277200 STOPPER SET
- Remove the engine from vehicle. Slightly raise the engine. Raise the transmission with garage jack. Move the engine horizontally until main shaft is withdrawn from clutch cover. Slowly move the engine away from engine compartment. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc.
- Remove the front cushion rubbers.
Scheme 72
Scheme 73
Scheme 74
- Install the front cushion rubbers to engine. Tightening torque: 35 N.m (3.6 kgf-m, 25.8 ft-lb)
- Position the engine in engine compartment and align it with transmission. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc.
- Apply a small amount of grease to splines of main shaft. (MT model)
- Tighten the bolts which hold upper side of transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
- Remove the lifting device and wire ropes.
- Remove the garage jack.
- Install the pitching stopper. Tightening torque: T1: 50 N.m (5.1 kgf-m, 36.9 ft-lb) T2: 58 N.m (5.9 kgf-m, 42.8 ft-lb)
- Remove the ST from converter case. (AT model) NOTE: Be careful not to drop the ST into the converter case when removing the ST. ST 498277200 STOPPER SET
- Install the starter. INSTALLATION , Starter .>
- Install the torque converter clutch to drive plate. (AT model) Tighten the bolts which hold torque converter clutch to drive plate. Tighten other bolts while rotating the crankshaft using socket wrench. NOTE: Be careful not to drop bolts into the torque converter clutch housing. Tightening torque: 25 N.m (2.5 kgf-m, 18.1 ft-lb) Attach the service hole plug to prevent entry of foreign objects.
- Install the power steering pump. Install the power steering pump to the bracket, and tighten the bolts. Tightening torque: 22 N.m (2.2 kgf-m, 16 ft-lb) Connect the power steering switch connector. Install and adjust the front side belt. FRONT SIDE BELT, INSTALLATION, V-belt .>
- Lift up the vehicle.
- Tighten the bolts and nuts which hold lower side of the transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
- Tighten the nuts which install the front cushion rubber onto crossmember. Tightening torque: 75 N.m (7.6 kgf-m, 55.3 ft-lb) NOTE: Make sure the front cushion rubber mounting bolts (A) and locator (B) are securely installed.
- Install the front and center exhaust pipe. INSTALLATION , Front Exhaust Pipe .>
- Lower the vehicle.
- Connect the following hoses. Fuel delivery hose and evaporation hose Heater inlet and outlet hoses Brake booster vacuum hose
- Connect the following connectors. Front oxygen (A/F) sensor connector Rear oxygen sensor connector Engine harness connectors Generator connector and terminal A/C compressor connector
- Install the air intake chamber stay. Tightening torque: 16 N.m (1.6 kgf-m, 11.6 ft-lb)
- Tighten the engine ground cable. Tightening torque: 14 N.m (1.4 kgf-m, 10.1 ft-lb)
- Install the A/C pressure hoses. INSTALLATION , Hose and Tube.>
- Install the radiator to vehicle. INSTALLATION , Radiator.>
- Install the air intake duct, air cleaner case and air intake chamber. INSTALLATION , Air Intake Duct .> INSTALLATION , Air Cleaner Case .> INSTALLATION , Air Intake Chamber .>
- Install the under cover.
- Install the battery in the vehicle, and connect cables.
- Fill engine coolant. FILLING OF ENGINE COOLANT , REPLACEMENT, Engine Coolant.>
- Check the ATF level and replenish it if necessary. A: INSPECTION , Automatic Transmission Fluid .>
- Charge the A/C system with refrigerant. PROCEDURE , Refrigerant Charging Procedure .>
- Remove the front hood stay, and close the front hood.
- Lower the vehicle from the lift.
