SPECIFICATION
| Model | 2.5 L | |||
|---|---|---|---|---|
| Engine | Cylinder arrangement | Horizontally opposed, liquid cooled, 4-cylinder, 4-stroke gasoline engine | ||
| Valve system mechanism | Belt driven Single overhead camshaft 4 valve/4 cylinder | |||
| Bore x Stroke | Mm (in) | 99.5 x 79.0 (3.917 x 3.110) | ||
| Piston displacement | Cm 3 (cu in) | 2,457 (150) | ||
| Compression ratio | 10.0 | |||
| Compression pressure (at 350 rpm) | KPa (kg/cm 2 , psi) | 1,020 - 1,275 (10.4 - 13.0, 148 - 185) | ||
| Number of piston rings | Pressure ring: 2, Oil ring: 1 | |||
| Intake valve timing | Constant | Open | BTDC 0° | |
| Close | ABDC 58° | |||
| Low speed | Open | BTDC 0° | ||
| Close | ABDC -50° | |||
| High speed | Open | BTDC 14° | ||
| Close | ABDC 62° | |||
| Exhaust valve timing | Open | BBDC46° | ||
| Close | ATDC 14° | |||
| Valve clearance | Mm (in) | Intake | 0.20±0.04 (0.0079±0.0016) | |
| Exhaust | 0.25±0.04 (0.0098±0.0016) | |||
| Idling speed [at neutral position on MT, or "P" or "N" position on AT] | Rpm | MT | 650±100 (Noload) 850±100 (A/CON) | |
| AT | 700±100 (No load) 850±100 (A/CON) | |||
| Ignition order | 1 --> 3 --> 2 --> 4 | |||
| Ignition timing | BTDC/rpm | MT | 10°±8°/650 | |
| AT | 15°±8°/700 | |||
GENERAL SPECIFICATION
Note. US: Undersize OS: Oversize
| Belt tension adjuster | Protrusion of adjuster rod | Mm (in) | 5.2 - 6.2 (0.205 - 0.244) | |||
|---|---|---|---|---|---|---|
| Belt tensioner | Spacer O.D. | Mm (in) | 17.955 - 17.975 (0.7069 - 0.7077) | |||
| Tensioner bushing I.D. | Mm (in) | 18.00 - 18.08 (0.7087 - 0.7118) | ||||
| Clearance between spacer and bushing | Mm (in) | Standard | 0.025 - 0.125 (0.0010 - 0.0049) | |||
| Side clearance of spacer | Mm (in) | Standard | 0.20 - 0.55 (0.0079 - 0.0217) | |||
| Valve rocker arm | Clearance between shaft and arm | Mm (in) | Standard | 0.020 - 0.054 (0.0008 - 0.0021) | ||
| Camshaft | Bending limit | Mm (in) | 0.025 (0.0010) | |||
| Thrust clearance | Mm (in) | Standard | 0.030 - 0.090 (0.0012 - 0.0035) | |||
| Cam lobe height | Mm (in) | Intake | Constant | Standard | 40.075 - 40.175 (1.5778 - 1.5817) | |
| Low speed | Standard | 35.182 - 35.282 (1.3851 - 1.3891) | ||||
| High speed | Standard | 40.315 - 40.415 (1.5872 - 1.5911) | ||||
| Exhaust | Standard | 40.088 - 40.188 (1.5783 - 1.5822) | ||||
| Camshaft journal O.D. | Mm (in) | 31.928 - 31.945 (1.2570 - 1.2577) | ||||
| Camshaft journal hole I.D. | Mm (in) | 32.000 - 32.018 (1.2598 - 1.2605) | ||||
| Oil clearance | Mm (in) | Standard | 0.055 - 0.090 (0.0022 - 0.0035) | |||
| Cylinder head | Surface warpage limit (Mating surface with cylinder block) | Mm (in) | 0.035 (0.0014) | |||
| Grinding limit | Mm (in) | 0.1 (0.004) | ||||
| Standard height | Mm (in) | 97.5 (3.84) | ||||
| Valve seat | Seating angle | 90° | ||||
| Contacting width | Mm (in) | Intake | Standard | 0.8 - 1.4 (0.03 - 0.055) | ||
| Exhaust | Standard | 1.2 - 1.8 (0.047 - 0.071) | ||||
| Valve guide | Inside diameter | Mm (in) | 6.000 - 6.012 (0.2362 - 0.2367) | |||
| Protrusion above head | Mm (in) | Intake | 20.0 - 21.0 (0.787 - 0.827) | |||
| Exhaust | 16.5 - 17.5 (0.650 - 0.689) | |||||
| Valve | Head edge thickness | Mm (in) | Intake | Standard | 0.8 - 1.2 (0.03 - 0.047) | |
| Exhaust | Standard | 1.0 - 1.4 (0.039 - 0.055) | ||||
| Stem outer diameter | Mm (in) | Intake | 5.950 - 5.965 (0.2343 - 0.2348) | |||
| Exhaust | 5.945 - 5.960 (0.2341 - 0.2346) | |||||
| Valve stem gap | Mm (in) | Standard | Intake | 0.035 - 0.062 (0.0014 - 0.0024) | ||
| Exhaust | 0.040 - 0.067 (0.0016 - 0.0026) | |||||
| Overall length | Mm (in) | Intake | 120.6 (4.75) | |||
| Exhaust | 121.7 (4.79) | |||||
| Valve spring | Free length | Mm (in) | 55.2 (2.173) | |||
| Squareness | 2.5°, 2.4 (0.094) or less | |||||
| Tension/spring height | N (kgf, lb)/mm (in) | Set | 235.3 - 270.7 (24 - 27.6, 52.9 - 60.8)/45.0 (1.772) | |||
| Lift | 578.9 - 639.9 (59.1 - 65.3, 130.3 - 143.9)/34.7 (1.366) | |||||
| Cylinder block | Surface warpage limit (mating with cylinder head) | Mm (in) | 0.025 (0.00098) | |||
| Grinding limit | Mm (in) | 0.1 (0.004) | ||||
| Standard height | Mm (in) | 201.0 (7.91) | ||||
| Cylinder inner diameter | Mm (in) | Standard | A | 99.505 - 99.515 (3.9175 - 3.9179) | ||
| B | 99.495 - 99.505 (3.9171 - 3.9175) | |||||
| Taper | Mm (in) | Standard | 0.015 (0.0006) | |||
| Out-of-roundness | Mm (in) | Standard | 0.010 (0.0004) | |||
| Piston clearance | Mm (in) | Standard | 0.010 - 0.010 (-0.00039 - 0.00039) | |||
| Cylinder inner diameter boring limit (diameter) | Mm (in) | To 100.005 (3.9372) | ||||
| Piston | Outer diameter | Mm (in) | Standard | A | 99.505 - 99.515 (3.9175 - 3.9179) | |
| B | 99.495 - 99.505 (3.9171 - 3.9175) | |||||
| 0.25 (0.0098) OS | 99.745 - 99.765 (3.9270 - 3.9278) | |||||
| 0.50 (0.0197) OS | 99.995 - 100.015 (3.9368 - 3.9376) | |||||
| Piston pin specified diameter | Mm (in) | 23.000 - 23.006 (0.9055 - 0.9057) | ||||
| Piston pin | Outer diameter | Mm (in) | 22.994 - 23.000 (0.9053 - 0.9055) | |||
| Clearance between piston and piston pin | Mm (in) | Standard | 0.004 - 0.008 (0.0002 - 0.0003) | |||
| Degree of fit | Piston pin must be fitted into position with thumb at 20°C (68°F). | |||||
| Piston ring | Ring closed gap | Mm (in) | Top ring | Standard | 0.20 - 0.35 (0.0079 - 0.0138) | |
| Second ring | Standard | 0.37 - 0.52 (0.0144 - 0.0203) | ||||
| Oil ring | Standard | 0.20 - 0.50 (0.0079 - 0.0197) | ||||
| Ring groove gap | Mm (in) | Top ring | Standard | 0.040 - 0.080 (0.0016 - 0.0031) | ||
| Second ring | Standard | 0.030 - 0.070 (0.0012 - 0.0028) | ||||
| Connecting rod | Bend or twist per 100 mm (3.94 in) in length | Mm (in) | Limit | 0.10 (0.0039) | ||
| Thrust clearance | Mm (in) | Standard | 0.070 - 0.330 (0.0028 - 0.0130) | |||
| Bearing of large end | Oil clearance | Mm (in) | Standard | 0.016 - 0.044 (0.00063 - 0.0017) | ||
| Bearing size (Thickness at center) | Mm (in) | Standard | 1.492 - 1.501 (0.0587 - 0.0591) | |||
| 0.03 (0.0012) US | 1.510 - 1.513 (0.0594 - 0.0596) | |||||
| 0.05 (0.0020) US | 1.520 - 1.523 (0.0598 - 0.0600) | |||||
| 0.25 (0.0098) US | 1.620 - 1.623 (0.0638 - 0.0639) | |||||
| Bushing of small end | Clearance between piston pin and bushing mm (in) | Standard | 0 - 0.022 (0 - 0.0009) | |||
| Crankshaft | Bend limit | Mm (in) | 0.035 (0.0014) | |||
| Crank pin | Out-of-roundness | Mm (in) | 0.003 (0.0001) | |||
| Cylindricality | Mm (in) | 0.004 (0.0002) | ||||
| Grinding limit (dia.) | Mm (in) | To 51.750 (2.0374) | ||||
| Crank journal | Out-of-roundness | Mm (in) | 0.005 (0.0002) | |||
| Cylindricality | Mm (in) | 0.006 (0.0002) | ||||
| Grinding limit (dia.) | Mm (in) | To 59.758 (2.3527) | ||||
| Crank pin outer diameter | Mm (in) | Standard | 51.984 - 52.000 (2.0466 - 2.0472) | |||
| 0.03 (0.0012) US | 51.954 - 51.970 (2.0454 - 2.0461) | |||||
| 0.05 (0.0020) US | 51.934 - 51.950 (2.0446 - 2.0453) | |||||
| 0.25 (0.0098) US | 51.734 - 51.750 (2.0368 - 2.0374) | |||||
| Crank journal outer diameter | Mm (in) | Standard | 59.992 - 60.008 (2.3619 - 2.3625) | |||
| 0.03 (0.0012) US | 59.962 - 59.978 (2.3607 - 2.3613) | |||||
| 0.05 (0.0020) US | 59.942 - 59.958 (2.3599 - 2.3605) | |||||
| 0.25 (0.0098) US | 59.742 - 59.758 (2.3520 - 2.3527) | |||||
| Thrust clearance | Mm (in) | Standard | 0.030 - 0.115 (0.0012 - 0.0045) | |||
| Oil clearance | Mm (in) | Standard | 0.010 - 0.030 (0.0001 - 0.0012) | |||
| Main bearing | Main bearing | Mm (in) | #1, #3 | Standard | 1.998 - 2.011 (0.0787 - 0.0792) | |
| 0.03 (0.0012) US | 2.017 - 2.020 (0.0794 - 0.0795) | |||||
| 0.05 (0.0020) US | 2.027 - 2.030 (0.0798 - 0.0799) | |||||
| 0.25 (0.0098) US | 2.127 - 2.130 (0.0837 - 0.0839) | |||||
| #2, #4, #5 | Standard | 2.000 - 2.013 (0.0787 - 0.0793) | ||||
| 0.03 (0.0012) US | 2.019 - 2.022 (0.0795 - 0.0796) | |||||
| 0.05 (0.0020) US | 2.029 - 2.032 (0.0799 - 0.0800) | |||||
| 0.25 (0.0098) US | 2.129 - 2.132 (0.0838 - 0.0839) | |||||
GENERAL SPECIFICATION
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Refer to "Cylinder Head" for removal and installation procedures of intake and exhaust valves. REMOVAL, Cylinder Head .> INSTALLATION, Cylinder Head .>
Refer to "Cylinder Block" for removal and installation procedures of pistons. REMOVAL, Cylinder Block .> INSTALLATION, Cylinder Block .>
Refer to "Cylinder Block" for removal and installation procedures of connecting rod. REMOVAL, Cylinder Block .> INSTALLATION, Cylinder Block .>
Refer to "Cylinder Block" for removal and installation procedures of the crankshaft. INSTALLATION, Cylinder Block .>
