Engine Intake System - Intake (Induction) (H4DOTC): Overhaul Subaru Outback BP рестайлинг

ASSEMBLY

Assemble in the reverse order of disassembly.

Note. Use new O-rings. Be careful not to pinch the O-ring. Tightening torque: 6.5 N.m (0.66 kgf-m, 4.8 ft-lb)

Scheme 470

Scheme 471

Scheme 472

Scheme 473

Scheme 474

1. Set the vehicle on a lift.
2. Remove the collector cover.
3. Disconnect the ground cable from the battery.
4. Remove the intercooler. REMOVAL, Intercooler .>
5. Remove the center exhaust pipe. REMOVAL , Center Exhaust Pipe.>
6. Lower the vehicle.
7. Separate the turbocharger joint pipe from turbocharger.
8. Disconnect the engine coolant hose which is connected to coolant filler tank.
9. Loosen the clamp which secures turbocharger to intake duct.
10. Remove the bolts which secure oil pipe bracket to turbocharger.
11. Remove the oil pipe from the turbocharger.
12. Disconnect the engine coolant hose from the pipe, and remove the turbocharger bracket RH.
13. Disconnect the oil outlet hose from pipe.
14. Take out the turbocharger from engine compartment.
