ADJUSTMENT

Note. Adjustment of valve clearance should be performed while engine is cold.

Scheme 262

Scheme 263

1. Measure all the valve clearances. INSPECTION, Valve Clearance.> NOTE: Record each valve clearance after measurement.
2. Remove the camshaft. REMOVAL, Camshaft.>
3. Remove the valve lifter.
4. Measure the thickness of valve lifter using micrometer.
5. Select a valve lifter of suitable thickness from the following table using the measured valve clearance and valve lifter thickness. VALVE LIFTER THICKNESS SPECIFICATION Unit: (mm) Intake valve: S = (V + T) - 0.20 Exhaust valve: S = (V + T) - 0.35 S: Valve lifter thickness required V: Measured valve clearance T: Valve lifter thickness to be used VALVE LIFTER THICKNESS SPECIFICATION Part No. Thickness mm (in) 13228 AB102 4.68(0.1843) 13228 AB112 4.69(0.1846) 13228 AB122 4.70(0.1850) 13228 AB132 4.71 (0.1854) 13228 AB142 4.72(0.1858) 13228 AB152 4.73(0.1862) 13228 AB162 4.74(0.1866) 13228 AB172 4.75(0.1870) 13228 AB182 4.76(0.1874) 13228 AB192 4.77(0.1878) 13228 AB202 4.78(0.1882) 13228 AB212 4.79(0.1886) 13228 AB222 4.80(0.1890) 13228 AB232 4.81 (0.1894) 13228 AB242 4.82(0.1898) 13228 AB252 4.83(0.1902) 13228 AB262 4.84(0.1906) 13228 AB272 4.85(0.1909) 13228 AB282 4.86(0.1913) 13228 AB292 4.87(0.1917) 13228 AB302 4.88(0.1921) 13228 AB312 4.89(0.1925) 13228 AB322 4.90(0.1929) 13228 AB332 4.91 (0.1933) 13228 AB342 4.92(0.1937) 13228 AB352 4.93(0.1941) 13228 AB362 4.94(0.1945) 13228 AB372 4.95(0.1949) 13228 AB382 4.96(0.1953) 13228 AB392 4.97(0.1957) 13228 AB402 4.98(0.1961) 13228 AB412 4.99(0.1965) 13228 AB422 5.00(0.1969) 13228 AB432 5.01 (0.1972) 13228 AB442 5.02(0.1976) 13228 AB452 5.03(0.1980) 13228 AB462 5.04(0.1984) 13228 AB472 5.05(0.1988) 13228 AB482 5.06(0.1992) 13228 AB492 5.07(0.1996) 13228 AB502 5.08 (0.2000) 13228 AB512 5.09 (0.2004) 13228 AB522 5.10(0.2008) 13228 AB532 5.11 (0.2012) 13228 AB542 5.12 (0.2016) 13228 AB552 5.13 (0.2020) 13228 AB562 5.14(0.2024) 13228 AB572 5.15(0.2028) 13228 AB582 5.16(0.2031) 13228 AB592 5.17 (0.2035) 13228 AB602 5.18 (0.2039) 13228 AB612 5.19 (0.2043) 13228 AB622 5.20 (0.2047) 13228 AB632 5.21 (0.2051) 13228 AB642 5.22 (0.2055) 13228 AB652 5.23 (0.2059) 13228 AB662 5.24 (0.2063) 13228 AB672 5.25 (0.2067) 13228 AB682 5.26(0.2071) 13228 AB692 5.27 (0.2075) 13228 AB702 4.38(0.1724) 13228 AB712 4.40(0.1732) 13228 AB722 4.42(0.1740) 13228 AB732 4.44(0.1748) 13228 AB742 4.46(0.1756) 13228 AB752 4.48(0.1764) 13228 AB762 4.50(0.1771) 13228 AB772 4.52(0.1780) 13228 AB782 4.54(0.1787) 13228 AB792 4.56 (0.1795) 13228 AB802 4.58(0.1803) 13228 AB812 4.60(0.1811) 13228 AB822 4.62(0.1819) 13228 AB832 4.64(0.1827) 13228 AB842 4.66(0.1835) 13228 AB852 5.29 (0.2083) 13228 AB862 5.31 (0.2091) 13228 AB872 5.33 (0.2098) 13228 AB882 5.35(0.2106) 13228 AB892 5.37(0.2114) 13228 AB902 5.39(0.2122) 13228 AB912 5.41 (0.2123) 13228 AB922 5.43(0.2138) 13228 AB932 5.45 (0.2146) 13228 AB942 5.47(0.2154) 13228 AB952 5.49(0.2161) 13228 AB962 5.51 (0.2169) 13228 AB972 5.53 (0.2177) 13228 AB982 5.55(0.2185) 13228 AB992 5.57(0.2193) 13228 AC002 5.59(0.2201) 13228 AC012 5.61 (0.2209) 13228 AC022 5.63 (0.2217) 13228 AC032 5.65 (0.2224)
6. Inspect all valves for valve clearance again at this time. If the valve clearance is not correct, repeat the procedure over again from the first step.
7. After inspection, install the related parts in the reverse order of removal.

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

1. Set the vehicle on a lift.
2. Open the front hood fully and support with the front food stay.
3. Remove the collector cover.
4. Collect the refrigerant from A/C system. REFRIGERANT RECOVERY PROCEDURE . >
5. Release the fuel pressure. RELEASING OF FUEL PRESSURE , PROCEDURE, Fuel.>
6. Disconnect the ground cable from the battery.
7. Open the fuel filler flap lid, and remove the fuel filler cap.
8. Remove the air intake duct and air cleaner case. REMOVAL , Air Intake Duct.> REMOVAL , Air Cleaner Case.>
9. Remove the intercooler. REMOVAL , Intercooler.>
10. Remove the radiator from vehicle. REMOVAL , Radiator.>
11. Remove the coolant filler tank. REMOVAL , Coolant Filler Tank.>
12. Disconnect the A/C pressure hoses from A/C compressor. REMOVAL , Hose and Tube.>
13. Disconnect the following connectors and cables. Engine harness connectors Engine ground terminal Generator connector and terminal A/C compressor connector
14. Disconnect the following hoses. Brake booster vacuum hose Heater inlet and outlet hoses
15. Remove the power steering pump from the bracket. Loosen the lock bolt and slider bolt, and remove the front side belt. FRONT SIDE BELT, REMOVAL, V-belt.> Disconnect the power steering pump switch connector. Remove the power steering pump from the engine. REMOVAL , Oil Pump.> Place the power steering pump on the right side wheel apron.
16. Lift the vehicle.
17. Remove the center exhaust pipe. REMOVAL , Center Exhaust Pipe .>
18. Remove the bolts and nuts which hold the lower side of transmission to the engine.
19. Remove the nuts which install front cushion rubber onto front crossmember.
20. Separate the torque converter clutch from drive plate. (AT model) Lower the vehicle. Remove the service hole plug. Remove the bolts which hold torque converter clutch to drive plate. Remove other bolts while rotating the crankshaft using socket wrench.
21. Remove the pitching stopper.
22. Attach ST to the fuel delivery pipe and push ST in the direction of arrow mark to disconnect the fuel delivery hose. ST 42099AE000 CONNECTOR REMOVER CAUTION: Be careful not to spill fuel. Catch the fuel from hoses using a container or cloth.
23. Disconnect the fuel return hose using the ST. ST 18371AA000 CONNECTOR REMOVER CAUTION: Be careful not to spill fuel. Catch the fuel from hoses using a container or cloth. Attach the ST to the fuel return pipe as shown in the figure. Insert the front side of ST into the quick connector. Insert the back side of ST into the quick connector and push ST in the direction of arrow mark to disconnect the fuel return hose.
24. Remove the clip and disconnect the evaporation hose from the fuel pipe.
25. Support the engine with a lifting device and wire ropes.
26. Support the transmission with a garage jack. CAUTION: Doing this is very important to prevent the transmission from lowering due to its own weight. CAUTION: Before removing the engine away from transmission, check to be sure no work has been overlooked.
27. Separation of engine and transmission. Remove the starter. REMOVAL , Starter.> Set the ST to torque converter clutch case. (AT model) ST 498277200 STOPPER SET Remove the bolts which hold the upper side of the transmission to the engine.
28. Remove the engine from vehicle. Slightly raise the engine. Raise the transmission with garage jack. Move the engine horizontally until main shaft is withdrawn from clutch cover. Slowly move the engine away from engine compartment. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc. 29) Remove the front cushion rubbers.

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

1. Install the front cushion rubbers to engine. Tightening torque: 35 N.m (3.6 kgf-m, 25.8 ft-lb)
2. Apply a small amount of grease to splines of main shaft. (MT model)
3. Position the engine in engine compartment and align it with transmission. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc.
4. Tighten the bolts which hold upper side of transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
5. Remove the lifting device and wire ropes.
6. Remove the garage jack.
7. Install the pitching stopper. Tightening torque: TV. 50 N.m (5.1 kgf-m, 36.9 ft-lb) T2: 58 N.m (5.9 kgf-m, 43 ft-lb)
8. Remove the ST from the torque converter clutch case. (AT model) NOTE: Be careful not to drop the ST into the torque converter clutch case when removing the ST. ST 498277200 STOPPER SET
9. Install the starter. INSTALLATION , Starter.>
10. Install the torque converter clutch to drive plate. (AT model) Tighten the bolts which hold torque converter clutch to drive plate. Tighten other bolts while rotating the crankshaft using socket wrench. NOTE: Be careful not to drop bolts into the torque converter clutch housing. Tightening torque: 25 N.m (2.5 kgf-m, 18.1 ft-lb)
11. Fit the plug to service hole.
12. Install the power steering pump. Install the power steering pump. Tightening torque: 20.1 N.m (2.05 kgf-m, 14.8 ft-lb) Connect the power steering pump switch connector. Install and adjust the front side belt. FRONT SIDE BELT, INSTALLATION, V-belt.>
13. Lift the vehicle.
14. Tighten the bolts and nuts which hold lower side of the transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb)
15. Tighten the nuts which install the front cushion rubber onto crossmember. Tightening torque: 85 N.m (8.7 kgf-m, 62.7 ft-lb) NOTE: Make sure that the front cushion rubber mounting bolts and locator are securely installed.
16. Install the center exhaust pipe. INSTALLATION , Center Exhaust Pipe .>
17. Lower the vehicle.
18. Connect the following hoses. Fuel delivery hose, return hose and evaporation hose Heater inlet and outlet hoses Brake booster vacuum hose Pressure regulator hose
19. Connect the following connectors and terminals. Engine ground terminal Engine harness connectors Generator connector and terminal A/C compressor connector
20. Install the intercooler. INSTALLATION , Intercooler.>
21. Install the air cleaner case and air intake duct. INSTALLATION , Air Cleaner Case.> INSTALLATION , Air Intake Duct.>
22. Install the A/C pressure hoses. INSTALLATION , Hose and Tube.>
23. Install the radiator. INSTALLATION , Radiator.>
24. Install the coolant filler tank. INSTALLATION , Coolant Filler Tank.>
25. Install the battery to the vehicle, and connect the battery ground terminal.
26. Fill engine coolant. FILLING OF ENGINE COOLANT , REPLACEMENT, Engine Coolant.>
27. Charge the A/C system with refrigerant. PROCEDURE , Refrigerant Charging Procedure.>
28. Check the ATF level and replenish it if necessary. REPLACEMENT , Automatic Transmission Fluid .>
29. Install the collector cover.
30. Remove the front hood stay, and close the front hood.
31. Lower the vehicle from the lift.
