Removing the torque-converter sealing ring
Installation Location
Scheme 227
Scheme 228
1. Using the bolt adapter from the slide hammer kit 168 , screw countersunk head bolt into sealing ring -direction of arrow- .
| WARNING | Danger of scalding and chemical burns from hot ATF |
> Allow ATF to cool down
> Wear personal protective gear (goggles, gloves)
Scheme 229
2. Screw on slide hammer from slide hammer kit 168 and remove sealing ring.
Installing the torque-converter sealing ring
Installation Location
1. Position new sealing ring on special tool assembly sleeve 3295 .
Scheme 230
2. Drive in sealing ring with special tool assembly sleeve 3295 -arrow- until special tool touches transmission housing. (Scheme 230)
1. Install torque converter. > 325019 Removing and Installing torque converter - "Installing" [9PAAE1 9PAAF1 9PAAJ1 9PAAK1] , > 325019 Removing and Installing torque converter - "Installing" [9PAAD1] .
2. Install transmission. Refer to 37 35 19 Removing and installing transmission - as of MY 2003 (Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) . Refer to 37 35 19 Removing and installing transmission - as of MY 2003 (Cayenne TIP) .
1. Remove Tiptronic gears. Refer to 37 35 19 Removing and installing transmission - as of MY 2003 (Cayenne TIP) .
Installation Location
Scheme 231
| WARNING | Danger of scalding and chemical burns from hot ATF |
> Allow ATF to cool down
> Wear personal protective gear (goggles, gloves)
1. Place oil collection pan under the converter bell housing.
Note. ATF can leak out when removing the torque converter. Place torque converter with transmission side pointing upwards.
2. Remove torque converter from the transmission shaft.
Installation Location
1. Clean any emerging oil off converter bell housing.
Note. Ensure that converter is seated correctly.
2. Push torque converter as far as it will go on to the transmission shaft.
1. Install Tiptronic transmission. Refer to 37 35 19 Removing and installing transmission - as of MY 2003 (Cayenne TIP) .
2. Check and if necessary, top up the ATF. Refer to 37 02 35 Checking and topping up the ATF - as of MY 2003 (Cayenne TIP, Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) .
