Tools
Designation Type Number Explanation slide hammer kit commercially available tool 168 assembly sleeve VW-tool 3295
1. Remove transmission. Refer to 37 35 19 Removing and installing transmission - as of MY 2003 (Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) . Refer to 37 35 19 Removing and installing transmission - as of MY 2003 (Cayenne TIP) .
2. Remove torque converter. > 325019 Removing and Installing torque converter - "Removing" [9PAAE1 9PAAF1 9PAAJ1 9PAAK1] , > 325019 Removing and Installing torque converter - "Removing" [9PAAD1] .
| Designation | Type | Number | Explanation | |
|---|---|---|---|---|
| Dowel pin | Special tool | 95950 |
1. Remove Tiptronic gears. Refer to 37 35 19 Removing and installing transmission - as of MY 2003 (Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) .
Installation Location
| WARNING | Danger of scalding and chemical burns from hot ATF |
> Allow ATF to cool down
> Wear personal protective gear (goggles, gloves)
1. Place oil collection pan under the converter bell housing.
Note. ATF can leak out when removing the torque converter. Place torque converter with transmission side pointing upwards.
2. Remove torque converter from the transmission shaft.
Installation Location
Note. Ensure that converter is seated correctly.
1. Clean any emerging oil off converter bell housing.
2. Push torque converter as far as it will go on to the transmission shaft.
Scheme 232
3. The correct installation position is achieved when the special tool dowel pin 95950 can be inserted through the opening in the converter bell housing in front of the converter -inset-. (Scheme 232)
1. Install Tiptronic transmission. Refer to 37 35 19 Removing and installing transmission - as of MY 2003 (Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) .
2. Check and if necessary, top up the ATF. Refer to 37 02 35 Checking and topping up the ATF - as of MY 2003 (Cayenne TIP, Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) .
