Removing and installing cable adjustment
Note. When a new selector support is used, the cable adjustment of the selector cable must be modified.
Scheme 82
1. Remove pins -direction of arrow- and take out cable adjustment. see scheme 47
Scheme 83
2. Insert cable adjustment on the new selector support and install pins -direction of arrow-. (Scheme 82)
Scheme 84
3. When doing so, ensure that the opening for the adjusting screw -arrow- is turned upwards. (Scheme 83)
Note. When a new selector support is used, the cable adjustment of the selector cable must be modified.
1. Remove pins -direction of arrow- and take out cable adjustment. see scheme 105
2. Insert cable adjustment on the new selector support and install pins -direction of arrow-. see scheme 106
3. When doing so, ensure that the opening for the adjusting screw -arrow- is turned upwards. see scheme 107
Note. When a new selector support is used, the cable adjustment of the selector cable must be modified.
1. Remove pins -direction of arrow- and take out cable adjustment. see scheme 115
2. Insert cable adjustment on the new selector support and install pins -direction of arrow-. see scheme 116
3. When doing so, ensure that the opening for the adjusting screw -arrow- is turned upwards. see scheme 117
Note. When a new selector support is used, the cable adjustment of the selector cable must be modified.
1. Remove pins -direction of arrow- and take out cable adjustment. see scheme 123
2. Insert cable adjustment on the new selector support and install pins -direction of arrow-. see scheme 124
3. When doing so, ensure that the opening for the adjusting screw -arrow- is turned upwards. see scheme 125
