Disassembling cover for selector lever
Installation Location
Scheme 85
Note. Use a clean and soft working surface to disassemble the cover for the selector lever.
Note. Only press the retaining lugs until the shade loosens from the upper part. Otherwise, the retaining lugs can break.
Scheme 86
1. Release the lugs -arrows- on one side on the underside of the cover for the selector lever. (Scheme 85)
Scheme 87
2. Tip shade up on this side --> Removing the shade and remove. (Scheme 86)
Assembling cover for selector lever
Note. Use a clean and soft working surface to disassemble the cover for the selector lever.
Scheme 88
1. Before assembly, the printed circuit board is to be inserted correctly -arrows-. (Scheme 87)
Scheme 89
2. The shade must be inserted in the correct position, sliding contact -1- on grinding track -2-. (Scheme 88)
Scheme 90
3. Fasten shade on the one side with the retaining lugs -arrows-. (Scheme 89)
Scheme 91
4. Push shade onto the upper part --> Fastening the shade, until it locks with an audible click. (Scheme 90)
