Preliminary work for wiring harness
1. Remove ATF filter. Refer to 37 58 19 Removing and installing ATF filter - as of MY 2003 (Cayenne TIP, Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) .
Removing wire harness in transmission
Installation Location
Scheme 190
Scheme 191
Note. The adaptation values of the Tiptronic control unit must be reset using the Porsche System Tester when replacing/renewing the wire harness. Refer to 37 30 19 Removing and installing the Tiptronic control unit - as of MY 2003 (All Models) .
1. Remove fastening screw from both connectors -Arrow-. (Scheme 191)
Scheme 192
2. Pull off connectors -Arrows- on the solenoid valves -8-12-. (Scheme 192), (Scheme 190).
3. Pull off cable plugs -1,5,13-. (Scheme 190)
Scheme 193
4. Remove wire harness for solenoid valves through opening in the housing -Arrow-. (Scheme 193)
Scheme 194
5. Pull off plug -Arrow- for input shaft inductive pickup -6-. (Scheme 194), (Scheme 190).
6. Pull off cable plugs from the oil pressure switches -4,3-. (Scheme 190)
Scheme 195
7. Unscrew fastening screw -Arrow- for ATF temperature sensor -7- and remove sensor. (Scheme 195), (Scheme 190).
Scheme 196
8. Pull off cable plug -2- for output shaft speed inductive pickup -Arrow-. (Scheme 190), (Scheme 196).
9. Remove wire harness for sensors through opening in the housing -Arrow-. see scheme 9
Scheme 197
10. Remove electrohydraulic control unit. To do this, unscrew fastening screws -Arrows- and take out the control unit. (Scheme 197)
Scheme 198
11. Remove output shaft speed inductive pickup. To do this, unscrew fastening screw -Arrow-. (Scheme 198)
Installing wiring harness in transmission
Installation Location
Scheme 199
Note. The adaptation values of the Tiptronic control unit must be reset using the Porsche System Tester when replacing/renewing the wire harness. Refer to 37 30 19 Removing and installing the Tiptronic control unit - as of MY 2003 (All Models) .
1. Install output shaft speed inductive pickup. To do this, screw in fastening screw -arrow-. --> Tightening torque: 7.5 ftlb. see scheme 13
Note. Screws which are tightened with a torque angle must be replaced with new ones.
2. Install electrohydraulic control unit and screw in new fastening screws -arrows-. --> Initial tightening: 6 ftlb. --> Final tightening: 90 Winkel-Grad. see scheme 14
3. Plug in cable plug -2- for output shaft speed inductive pickup. -arrow- (Scheme 199), see scheme 17.
4. Install wire set for sensors through opening in the housing.
5. Insert ATF temperature sensor -7- and screw in fastening screw -arrow-. --> Tightening torque: 7.5 ftlb. (Scheme 199), see scheme 16.
6. Plug in cable plug for oil pressure switch -3,4- and inductive pickup for input shaft -6- -arrow-. (Scheme 199), see scheme 17.
7. Install wire set for solenoid valves through opening in the housing.
8. Push in the cable plug for the solenoid valves -1,5,8-13-. (Scheme 199)
9. Screw in the fastening screw from both plugs -arrow-. --> Tightening torque: 7.5 ftlb. see scheme 18
Reworking wiring harness
1. Install ATF filter. Refer to 37 58 19 Removing and installing ATF filter - as of MY 2003 (Cayenne TIP, Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) .
Scheme 200
2. Unscrew ATF control screw -A- and fill in ATF until a constant discharge is visible at the lifting tube. (Scheme 200)
3. Screw in ATF control screw with a new sealing ring. --> Tightening torque: 52 ftlb.
4. Check and if necessary, top up the ATF. Refer to 37 02 35 Checking and topping up the ATF - as of MY 2003 (Cayenne TIP, Cayenne S TIP, Cayenne Turbo, Cayenne Turbo S, Cayenne S TIO Titan) .
