Remove
Remove fastening nuts (1) from alternator cover.
Remove alternator cover (2) from alternator.
Remove attachment screw (6) and fastening nuts (3) from alternator regulator.
Remove alternator regulator (4) from alternator (5).
Caution
Further disassembly and assembly of the alternator is not provided for because of warranty reasons.
Install
Insert alternator regulator into alternator.
Attach alternator regulator to alternator using attachment screw and fastening nuts.
Place alternator cover onto alternator.
Attach alternator cover to alternator using fastening nuts.
