Thread Repair

General Thread Repair

Special Tools

J 42385-850

The thread repair process involves a solid, thin walled, self-locking, carbon steel, bushing type insert (1). During the bushing installation process, the driver tool expands the bottom external threads of the insert into the base material (2). This action mechanically locks the insert in place. Also, when installed to the proper depth, the flange of the insert will be seated against the counterbore of the repaired hole.

  1. The use of a cutting type fluid GM P/N 1052864 (Canadian P/N 992881), WD 40®, or equivalent, is recommended when performing the drilling, counterboring, and tapping procedures.
  2. Using compressed air, clean out any chips.
  3. Counterbore the hole to the full depth permitted by the tool (1).
  4. Using compressed air, clean out any chips.
  5. Using a tap wrench (2), tap the threads of the drilled hole.
  6. Using compressed air, clean out any chips.
  7. Spray cleaner GM P/N 12346139, GM P/N 12377981 (Canadian P/N 10953463), or equivalent, into the hole.
  8. Using compressed air, clean any cutting oil and chips out of the hole.
  9. Do not allow oil or other foreign material to contact the outside diameter (OD) of the insert.
  10. Install the insert (2) onto the driver tool (1).
  11. Apply threadlock LOCTITE™ 277, J 42385-109 (1), or equivalent, to the insert OD threads (2).
  12. Install the insert (2) into the hole.
  13. Inspect the insert for proper installation into the hole.

Cylinder Head Bolt Hole Thread Repair

  1. The cylinder head bolt hole thread repair kit consists of the following items:
  2. The use of a cutting type fluid GM P/N 1052864 (Canadian P/N 992881), WD 40®, or equivalent, is recommended when performing the drilling and tapping procedures.
  3. Position the alignment pin (1) through the bushing and into the hole.
  4. With the alignment pin in the desired hole, tighten the fixture retaining bolts (2).
  5. Remove the alignment pin from the hole.
  6. Install the sleeve (2) onto the drill (1), if required.
  7. During the reaming process, it is necessary to repeatedly remove the drill and clean the chips from the hole.
  8. Using compressed air, clean out any chips.
  9. Using a tap wrench, tap the threads of the drilled hole.
  10. Using a TAP wrench, tap the threads of the drilled hole.
  11. Remove the fixture plate (1), bushing (2), and bolts.
  12. Using compressed air, clean out any chips.
  13. Spray cleaner GM P/N 12346139 or GM P/N 1237798 (Canadian P/N 10953463), or equivalent, into the hole.
  14. Using compressed air, clean any cutting oil and chips out of the hole.
  15. Do not allow oil or other foreign material to contact the OD of the insert.
  16. Install the insert (2) onto the driver tool (1).
  17. Apply threadlock LOCTITE™ 277, J 42385-109 (1), or equivalent, to the insert OD threads (2).
  18. Install the insert and driver (1) into the hole.

Main Cap Bolt Hole Thread Repair

  1. The main cap bolt hole thread repair kit consists of the following items:
  2. Remove the alignment dowel pins from the holes (1-4), if necessary.
  3. Install the fixture plate, bolt, and bushing, onto the engine block.
  4. Position the alignment pin in the desired hole and tighten the fixture retaining bolts.
  5. Drill out the damaged hole.
  6. Using compressed air, clean out any chips.
  7. Using a tap wrench, tap the threads of the drilled hole.
  8. Using compressed air, clean out any chips.
  9. Spray cleaner GM P/N 12346139 (Canadian P/N 10953463), or equivalent, into the hole.
  10. Using compressed air, clean any cutting oil and chips out of the hole.
  11. Do not allow oil or other foreign material to contact the OD of the insert.
  12. Install the insert (2) onto the driver tool (1).
  13. Apply threadlock LOCTITE™ 277, J 42385-109 (1), or equivalent, to the insert OD threads (2).
  14. The fixture plate and bushing remains installed onto the engine block during the insert installation procedure.
  15. Remove the driver, bushing (2), fixture plate (1), and bolts.
  16. Install the alignment dowel pins in holes (1-4), if necessary.
