Cylinder Sleeve Installation
Special Tools
EN 45680-850 Cylinder Sleeve Removal and Installation Kit
Cylinder Sleeve Trimming
The EN 45680-861 trim tool assembly (2) from EN 45680-850 contains or requires the following components to complete 86 mm cylinder sleeve trimming:
| • | Debris collector (3) with filter EN 45680-865 from EN 45680-850 |
| • | Drill motor with 1/2 inch chuck, 1 1/8 hp, 7 amps, triple gear reduction, and a 450-600 RPM rotational speed in a clockwise direction |
| • | EN 45680-869 bore cutter bit and screw from EN 45680-850 |
| • | EN 45680-899 Bore trimmer pilot from EN 45680-850 , white in color |
| • | Gage ring assembly EN 45680-862 from EN 45680-850 |
| • | EN 45680-412 Set Gage Ring (2) |
| • | EN 45680-863 metal shavings catch plug (3) from EN 45680-850 |
| • | EN 45680-866 drive adapter (4) from EN 45680-850 |
| • | EN 45680-864 bolts (5) from EN 45680-850 |
