How to Replace the Coolant Temperature Sensor Opel Combo C

Remove

1. 1. Open bonnet
2. 2. Drain coolant • Place collecting basin underneath. • Open drain bolt

3. 3. Remove fuel filter housing (2) • Disconnect 4 lines (1) and (4) – Use KM-796-A • Disconnect 2 wiring harness plugs – Housing cover (3) – Housing bottom (arrow) • Close 4 fuel lines

4. 4. Loosen coolant compensation tank • Unclip coolant compensation tank
5. 5. Remove crash box • Remove nut • Remove nut
6. 6. Detach charge air pipe (1) from intake manifold • Release clamp • Unscrew 4 bolts (arrows)

7. 7. Remove coolant temperature sensor (1) • Lock wiring harness plug (2) • Unscrew coolant temperature sensor

8. 8. Cleaning work

Install

9. 9. Install coolant temperature sensor • Coolant temperature sensor • Lock wiring harness plug
10. 10. Install charge air pipe • Replace seal ring • Tighten 4 bolts • Fasten clamp 3.5 Nm
11. 11. Install crash box • Tighten 2 nuts 25 Nm
12. 12. Install fuel filter • Connect 2 wiring harness plugs • Connect 4 lines
13. 13. Fasten coolant compensation tank • Clip in coolant compensation tank
14. 14. Top up coolant
15. 15. Close bonnet
