K700100 – Automatic Transmission Remove and Install
1. Flex plate
- J335500 – Flex Plate Replacement
2. Flex plate bolt
3. Torque converter
- K701100 – Torque Converter Replacement
1. Harness bracket
2. Transmission rear cover
- K703161 – Transmission Rear Cover Reseal
3. Rear cover plug
4. Rear cover O ring
5. Reverse clutch drum thrust bearing
6. Front sun gear thrust bearing race
7. Front planetary sun gear
8. Planetary gear thrust bearing
9. One way clutch number one assembly
10. Rear planetary sun gear assembly
11. Rear sun gear thrust bearing race
12. Rear sun gear thrust bearing
13. Forward clutch hub
14. Intermediate shaft thrust bearing race
15. Intermediate shaft thrust bearing
16. Second brake piston snap ring
17. Overdrive and second coast brake retaining plate snap ring
18. Overdrive and second coast brake retaining plate
19. Overdrive and second coast brake disc
20. Overdrive and second coast brake separator plate
21. Overdrive and second coast brake rear plate
22. First and reverse brake piston
23. O ring
24. First and reverse brake return spring assembly
25. First and reverse brake disc
26. First and reverse brake separator plate
27. First and reverse brake retaining plate
28. First and reverse brake snap ring
29. Planetary gear assembly
30. Planetary carrier thrust washer
31. One way clutch number two assembly
32. One way clutch outer race retainer
33. Second brake retaining plate
34. Second brake disc
35. Second brake separator plate
36. Second brake return spring assembly
1. Torque converter
- K701100 – Torque Converter Replacement
2. Axle shaft oil seal
- E302110 – Axle Shaft Oil Seal Replacement
3. Torque converter housing
4. Torque converter housing plug
5. Output shaft speed sensor
- K607300 – Output Shaft Speed Sensor Replacement
6. Lubrication left tube
7. Lubrication right tube
8. Lubrication tube clamp
9. Breather union
10. Input shaft speed sensor
- K607310 – Input Shaft Speed Sensor Replacement
11. Breather hose
- K200600
12. Breather hose plug
13. Solenoid harness connector
14. Input shaft front thrust bearing
15. Fluid reservoir plate
16. Input shaft rear thrust bearing
17. Input shaft rear thrust bearing race
18. Direct clutch hub
19. Fluid reservoir left plate
20. Governor gasket number two
21. Automatic transmission case
22. Spring
23. Cooler check valve
24. Reduction drive gear nut
25. Transmission fluid cooler pipe threaded connector
- K603110
26. Reduction drive gear
27. Planetary ring gear assembly
28. Brake drum gasket
29. Second brake gasket
30. Fluid level gauge
31. Transmission fluid cooler pipe – inlet
- K603000 – Transmission Fluid Cooler Pipe Assembly Replacement
32. Transmission fluid cooler pipe – outlet
- K603000 – Transmission Fluid Cooler Pipe Assembly Replacement
33. Transmission fluid filler pipe
- K603110 – Transmission Fluid Filler Pipe Replacement
34. Transmission case plug
35. Accumulator spring
36. Accumulator spring O ring
37. Direct clutch accumulator piston
38. Forward clutch accumulator piston
39. Overdrive and second brake accumulator piston
40. Transmission selector position sensor
- K600700 – Transmission Selector Position Sensor Replacement
41. Lock washer
42. Manual select lever
43. Automatic transmission fluid drain plug
44. Governor gasket number one
45. Valve body cover
- K615200 – Valve Body Cover and/or Gasket Replacement
46. Valve body cover gasket
- K615200 – Valve Body Cover and/or Gasket Replacement
47. Manual shift shaft oil seal
48. Manual shift shaft
49. Manual valve lever
50. Manual valve lever pin
51. Oil strainer assembly
52. Parking lock pawl rod
53. Manual detent spring
54. Parking lock pawl bracket
55. Parking lock pawl
56. Parking lock pawl shaft
57. Parking lock pawl return spring
