Remove
- 1. Disconnect battery negative lead • Release nut
- 2. Remove lower trim panel (1) from instrument panel • Release 10x clip
- 3. Disconnect 6x harness connector (4) from junction block
- 4. Disconnect 3x harness connector (3) from body control module (BCM)
- 5. Release BCM and junction block assembly (5) from vehicle • Remove 2x nut (2)
- 6. Remove BCM and junction block assembly from vehicle • Disconnect 7x harness connector (2) from junction block • Release 3x harness connector (1) from junction block – Release 3x clip
Install
- 7. Locate new BCM and junction block assembly to vehicle • Secure 3x harness connector (1) to junction block – Secure 3x clip • Connect 7x harness connector (2) to junction block
- 8. Secure BCM and junction block assembly (5) to vehicle • Install 2x nut (2)
- 9. Connect 3x harness connector (3) to BCM
- 10. Connect 6x harness connector (4) to junction block
- 11. Install lower trim (1) to instrument panel • Secure 10x clip
- 12. Connect battery negative lead • Secure nut 11 Nm
- 13. Program (BCM) Body Control Module • Connect Tech 2 to diagnostic socket • Select F0: DIAGNOSTICS • Select corresponding vehicle identification • Select F4: Body • Select BCM Body Control Module • Turn "ON" Ignition and press Confirm • Select F0: Diagnostic Trouble Codes • Select F2: Clear DTC Information • Follow menu guide in Tech 2 to end of program
- 14. Turn off Tech 2, then remove from vehicle • Disconnect Tech 2 from diagnostic socket
- 15. Program key transmitter code – see operation “Program Key Transmitter Code”
- 16. Program all volatile memories – see operation “Program Volatile Memories”
