Power Window Control System: Other Nissan Pathfinder III рестайлинг

Windows 13 illustrations ~3514 words

DETAILED FLOW

  1. OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred) as much as possible when the customer brings the vehicle in. GO TO 2
  2. REPRODUCE THE MALFUNCTION INFORMATION Check the malfunction on the vehicle that the customer describes. Inspect the relation of the symptoms and the condition when the symptoms occur. GO TO 3
  3. IDENTIFY THE MALFUNCTIONING SYSTEM WITH "SYMPTOM DIAGNOSIS" Use "Symptom diagnosis" from the symptom inspection result in step 2 and then identify where to start performing the diagnosis based on possible causes and symptoms. GO TO 4
  4. IDENTIFY THE MALFUNCTIONING PARTS WITH "DTC/CIRCUIT DIAGNOSIS" Perform the diagnosis with "DTC/Circuit diagnosis" of the applicable system. GO TO 5
  5. REPAIR OR REPLACE THE MALFUNCTIONING PARTS Repair or replace the specified malfunctioning parts. GO TO 6
  6. FINAL CHECK Check that malfunctions are not reproduced when obtaining the malfunction information from the customer, referring to the symptom inspection result in step 2 . Are the malfunctions corrected? YES: Inspection End. NO: GO TO 3

INITIALIZATION PROCEDURE

After installing each component, perform the following procedure to reset the limit switch.

Scheme 64

Scheme 64: INITIALIZATION PROCEDURE
Scheme 64: INITIALIZATION PROCEDURE
  1. Raise the glass to the top position.
  2. While pressing and holding the reset switch, lower the glass to the bottom position.
  3. Release the reset switch. Verify that the reset switch returns to the original position, if not, pull the switch using suitable tool.
  4. CAUTION: Do not operate the glass automatically to raise the glass to the top position. Raise the glass to the top position.

ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: Special Repair Requirement

Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT " for initialization procedure and check anti-pinch function.

Scheme 65

Scheme 65: FRONT WINDOW ANTI-PINCH SYSTEM
Scheme 65: FRONT WINDOW ANTI-PINCH SYSTEM

INPUT/OUTPUT SIGNAL CHART

ItemInput signal to main power window and door lock/unlock switchMain power window and door lock/unlock switch functionActuator
Key cylinder switchLOCK/UNLOCK signal (more than 1.5 seconds over)Power window controlFront power window motor
EncoderEncoder pulse signal
Main power window and door lock/unlock switchFront power window motor LH UP/DOWN signal
Power window and door lock/unlock switch RHFront power window motor RH UP/DOWN signal
BCMRAP signal
Rear power window switchRear power window motor UP/DOWN signalRear power window motor
ItemInput signal to front power window switchFront power window switch functionActuator
Power window and door lock/unlock switch RHFront power window motor RH UP/DOWN signalPower window controlFront power window motor RH
EncoderEncoder pulse signal
BCMRAP signal

POWER WINDOW LOCK

Ground circuit inside main power window and door lock/unlock switch shuts off when power window lock switch is ON. This inhibits power window switch operation except with the main power window and door lock/unlock switch.

FRONT WINDOW ANTI-PINCH SYSTEM

ComponentFunction
BCMSupplies power supply to power window switch. Controls retained power.
Main power window and door lock/unlock switchDirectly controls all power window motor of all doors. Controls anti-pinch operation of front power window LH.
Power window and door lock/unlock switch RHControls front power window motor RH. Controls anti-pinch operation of front power window RH.
Rear power window switchControls rear power window motors LH and RH.
Front power window motor LHIntegrates the ENCODER POWER and WINDOW MOTOR. Starts operating with signals from main power window and door lock/unlock switch. Transmits power window motor rotation as a pulse signal to main power window and door lock/unlock switch.
Front power window motor RHIntegrates the ENCODER POWER and WINDOW MOTOR. Starts operating with signals from main power window and door lock/unlock switch & power window and door lock/unlock switch RH. Transmits power window motor rotation as a pulse signal to power window and door lock/unlock switch RH.
Rear power window motorStarts operating with signals from main power window and door lock/unlock switch & rear power window switch.
Front door lock assembly LH (key cylinder switch)Transmits operation condition of key cylinder switch to power window main switch.
Front door switch LH or RHDetects door open/close condition and transmits to BCM.

DATA MONITOR

Monitor Item [Unit]Description
IGN ON SW [On/Off]Indicates condition of ignition switch ON position.
DOOR SW-DR [On/Off]Indicates condition of front door switch LH.
DOOR SW-AS [On/Off]Indicates condition of front door switch RH.

WORK SUPPORT

Support ItemSettingDescription
RETAINED PWR SETMODE32 minSets the retained accessory power operating time.
MODE2OFF
MODE1 (1)45 sec
(1) Initial setting
(1)Initial setting

POWER WINDOW MAIN SWITCH: Component Function Check

Main Power Window And Door Lock/Unlock Switch

  1. CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH FUNCTION Check power window motor operation with main power window and door lock/unlock switch. Is the inspection result normal? YES: Main power window and door lock/unlock switch power supply and ground circuit are OK. NO: Refer to " «POWER WINDOW MAIN SWITCH: DIAGNOSIS PROCEDURE»(ref-519836-S06383064362012122900000) ".

FRONT POWER WINDOW SWITCH: Component Function Check

Power Window And Door Lock/Unlock Switch RH

  1. CHECK FRONT POWER WINDOW MOTOR RH FUNCTION Check front power window motor RH operation with power window and door lock/unlock switch RH. Is the inspection result normal? YES: Power window and door lock/unlock switch RH power supply and ground circuit are OK. NO: Refer to " «FRONT POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-519836-S38984176252012122900000) ".

REAR POWER WINDOW SWITCH: Component Function Check

Rear Power Window Switch

  1. CHECK REAR POWER WINDOW MOTOR FUNCTION Check rear power window motor operation with rear power window switch. Is the inspection result normal? YES: Rear power window switch power supply and ground circuit are OK. NO: Refer to " «REAR POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-519836-S13576124532012122900000) ".

DRIVER SIDE: Component Function Check

  1. CHECK POWER WINDOW MOTOR CIRCUIT Check front power window motor LH operation with operating main power window and door lock/unlock switch. Is the inspection result normal? YES: Front power window motor LH is OK. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-519836-S03267205462012122900000) ".

PASSENGER SIDE: Component Function Check

  1. CHECK POWER WINDOW MOTOR CIRCUIT Check power window motor operation with operating main power window and door lock/unlock switch or power window and door lock/unlock switch RH. Is the inspection result normal? YES: Front power window motor RH is OK. NO: Refer to " «PASSENGER SIDE: DIAGNOSIS PROCEDURE»(ref-519836-S22867335072012122900000) ".

REAR LH: Component Function Check

  1. CHECK REAR POWER WINDOW MOTOR LH CIRCUIT Check rear power window motor LH operation with main power window and door lock/unlock switch or rear power window switch LH. Is the inspection result normal? YES: Rear power window motor LH is OK. NO: Refer to " «REAR LH: DIAGNOSIS PROCEDURE»(ref-519836-S41758191632012122900000) "

REAR RH: Component Function Check

  1. CHECK REAR POWER WINDOW MOTOR RH CIRCUIT Check rear power window motor RH operation with operating main power window and door lock/unlock switch or rear power window switch RH. Is the inspection result normal? YES: Rear power window motor RH is OK. NO: Refer to " «REAR RH: DIAGNOSIS PROCEDURE»(ref-519836-S18397298232012122900000) ".
  1. CHECK ENCODER OPERATION Check front door glass LH perform AUTO open/close operation normally when operating main power window and door lock/unlock switch. Is the inspection result normal? YES: Encoder operation is OK. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-519836-S38008919592012122900000) "
  1. CHECK ENCODER OPERATION Check front door glass RH perform AUTO open/close operation normally when operating power window and door lock/unlock switch RH. Is the inspection result normal? YES: Encoder operation is OK. NO: Refer to " «PASSENGER SIDE: DIAGNOSIS PROCEDURE»(ref-519836-S19790164442012122900000) ".

Component Function Check

  1. CHECK FRONT DOOR SWITCH INPUT SIGNAL Check ("DOOR SW-DR" and "DOOR SW-AS") in "DATA MONITOR" mode with CONSULT. Refer to " «RETAINED PWR: CONSULT FUNCTION (BCM - RETAINED PWR)»(ref-519820-S09479919912012122900000) ". Monitor item Condition DOOR SW-DR OPEN : ON CLOSE : OFF DOOR SW-AS OPEN : ON CLOSE : OFF Is the inspection result normal? YES: Front door switch circuit is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-519836-S17790912962012122900000) ".
  1. CHECK DOOR KEY CYLINDER SWITCH INPUT SIGNAL Check ("KEY CYL LK-SW", "KEY CYL UN-SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT. Refer to " «DOOR LOCK: CONSULT FUNCTION (BCM - DOOR LOCK)»(ref-519820-S39239165002012122900000) ". Monitor item Condition KEY CYL LK-SW Lock : ON Neutral / Unlock : OFF KEY CYL UN-SW Unlock : ON Neutral / Lock : OFF Is the inspection result normal? YES: Key cylinder switch is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-519836-S10225512362012122900000) ".
  1. CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OUTPUT SIGNAL Check ("CDL LOCK SW", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT. Refer to " «COMMON ITEM: CONSULT FUNCTION (BCM - COMMON ITEM)»(ref-519820-S01072333122012122900000) ". Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «POWER WINDOW MAIN SWITCH: DIAGNOSIS PROCEDURE»(ref-519836-S09907064392012122900000) ".
  1. CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH OUTPUT SIGNAL Check ("CDL LOCK SW", "CDL UNLOCK SW") in "DATA MONITOR" mode for "POWER DOOR LOCK SYSTEM" with CONSULT. Refer to " «DOOR LOCK: CONSULT FUNCTION (BCM - DOOR LOCK)»(ref-519820-S39239165002012122900000) ". Monitor item Condition CDL LOCK SW LOCK : ON UNLOCK : OFF CDL UNLOCK SW LOCK : OFF UNLOCK : ON Is the inspection result normal? YES: Power window serial link is OK. NO: Refer to " «FRONT POWER WINDOW SWITCH: DIAGNOSIS PROCEDURE»(ref-519836-S04202677582012122900000) ".
  1. CHECK POWER WINDOW LOCK SIGNAL Exchanges for a normal main power window and door lock/unlock switch, and operation is checked. Does power window lock operate? YES: Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-519836-S14968735482012122900000) ". NO: Check condition of harness and connector.

Scheme 66

Scheme 66: TERMINAL LAYOUT
Scheme 66: TERMINAL LAYOUT

MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH

Terminal No. (Wire color) Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 1 (R) Ground Rear power window motor LH UP signal Output When rear LH switch in power window main switch is operated UP. Battery voltage 2 (BR) Ground Encoder ground - - 0 3 (LG) Ground Rear power window motor LH DOWN signal Output When rear LH switch in power window main switch is operated DOWN. Battery voltage 4 (SB) Ground Door key cylinder switch LH LOCK signal Input Key position (Neutral/Unlocked --> Locked) 5 --> 0 5 (P) Ground Rear power window motor RH DOWN signal Output When rear RH switch in power window main switch is operated DOWN. Battery voltage 6 (R/W) Ground Door key cylinder switch LH UNLOCK signal Input Key position (Neutral/Locked --> Unlocked) 5 --> 0 7 (Y) Ground Rear power window motor RH UP signal Output When rear RH switch in power window main switch is operated UP. Battery voltage 8 (O) 11 Front door power window motor LH UP signal Output When front LH switch in power window main switch is operated UP. Battery voltage 9 (Y) 2 Encoder pulse signal 2 Input When power window motor operates. 10 (W/R) Ground RAP signal Input IGN SW ON Battery voltage Within 45 second after ignition switch is turned to OFF. Battery voltage When front LH or RH door is opened during retained power operation. 0 11 (GR) 8 Front door power window motor LH DOWN signal Output When front LH switch in power window main switch is operated DOWN. Battery voltage 13 (LB) 2 Encoder pulse signal 1 Input When power window motor operates. 14 (V) Ground Power window serial link Input/Output IGN SW ON or power window timer operating. 15 (W/R) Ground Encoder power supply Output When ignition switch ON or power window timer operates. 10 17 (B) Ground Ground - - 0 19 (L) Ground Battery power supply Input - Battery voltage

Scheme 67

Scheme 67: MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
Scheme 67: MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH

FAIL-SAFE CONTROL

Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.

ErrorError condition
Pulse sensor malfunctionWhen only one side of pulse signal is being detected for more than the specified value.
Both pulse sensors malfunctionWhen both pulse signals have not been detected for more than the specified value during glass open/close operation.
Pulse direction malfunctionWhen the pulse signal that is detected during glass open/close operation detects the opposite condition of power window motor operating direction.
Glass recognition position malfunction 1When it detects the error between glass fully closed position in power window switch memory and actual fully closed position during glass open/close operation is more than the specified value.
Glass recognition position malfunction 2When it detects pulse count more than the value of glass full stroke during glass open/close operation.
Malfunction of not yet updated closed position of glassWhen glass open/close operation is continuously performed without fully closing more than the specified value (approximately 10 strokes).

It changes to condition before initialization and the following functions do not operate when switched to failsafe control.

  1. Auto-up operation
  2. Anti-pinch function
  3. Retained power function

Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window switch or in motor.

Scheme 68

Scheme 68: TERMINAL LAYOUT
Scheme 68: TERMINAL LAYOUT

POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH

Terminal No. (Wire color) Description Condition Voltage [V] (Approx.) + - Signal name Input/Output 3 (BR) Ground Encoder ground - - 0 4 (W/R) Ground Encoder power supply Output When ignition switch ON or power window timer operates 10 8 (L) 9 Power window motor UP signal Output When power window motor is UP at operated. Battery voltage 9 (G) 8 Power window motor DOWN signal Output When power window motor is DOWN at operated. Battery voltage 10 (Y) Ground Battery power supply Input - Battery voltage 11 (B) Ground Ground - - 0 12 (LB) 3 Encoder pulse signal 1 Input When power window motor operates. 15 (Y) 3 Encoder pulse signal 2 Input When power window motor operates. 16 (V) Ground Power window serial link Input/Output IGN SW ON or power window timer operating

Scheme 69

Scheme 69: POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
Scheme 69: POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH

Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.

ErrorError condition
Pulse sensor malfunctionWhen only one side of pulse signal is being detected for more than the specified value.
Both pulse sensors malfunctionWhen both pulse signals have not been detected for more than the specified value during glass open/close operation.
Pulse direction malfunctionWhen the pulse signal that is detected during glass open/close operation detects the opposite condition of power window motor operating direction.
Glass recognition position malfunction 1When it detects the error between glass fully closed position in power window switch memory and actual fully closed position during glass open/close operation is more than the specified value.
Glass recognition position malfunction 2When it detects pulse count more than the value of glass full stroke during glass open/close operation.
Malfunction of not yet updated closed position of glassWhen glass open/close operation is continuously performed without fully closing more than the specified value (approximately 10 strokes).

It changes to condition before initialization and the following functions do not operate when switched to failsafe control.

  1. Auto-up operation
  2. Anti-pinch function
  3. Retained power function

Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window switch or in motor.

Reference Value

Note. The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II User Guide for additional information.

  1. Activate and display TPMS transmitter IDs
  2. Display tire pressure reported by the TPMS transmitter
  3. Read TPMS DTCs
  4. Register TPMS transmitter IDs

Physical Values

Terminal Wire color Signal name Signal input/output Measuring condition Reference value or waveform (Approx.) Ignition switch Operation or condition 1 BR Ignition keyhole illumination Output OFF Door is locked (SW OFF) Battery voltage Door is unlocked (SW ON) 0V 2 P Combination switch input 5 Input ON Lighting, turn, wiper OFF Wiper dial position 4 3 SB Combination switch input 4 Input ON Lighting, turn, wiper OFF Wiper dial position 4 4 V Combination switch input 3 Input ON Lighting, turn, wiper OFF Wiper dial position 4 5 L Combination switch input 2 Input ON Lighting, turn, wiper OFF Wiper dial position 4 6 R Combination switch input 1 9 Y Rear window defogger switch Input ON Rear window defogger switch ON 0V Rear window defogger switch OFF 5V 11 G/B Ignition switch (ACC or ON) Input ACC or ON Ignition switch ACC or ON Battery voltage 12 LG Front door switch RH Input OFF ON (open) 0V OFF (closed) Battery voltage 13 L Rear door switch RH Input OFF ON (open) 0V OFF (closed) Battery voltage 15 W Tire pressure warning check connector Input OFF - 5V 18 BR Remote keyless entry receiver and optical sensor (ground) Output OFF - 0V 19 V Remote keyless entry receiver (power supply) Output OFF Ignition switch OFF 20 G Remote keyless entry receiver (signal) Input OFF Stand-by (keyfob buttons released) When remote keyless entry receiver receives signal from keyfob (keyfob buttons pressed) 21 GR NATS antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move for approx. 1 second, then return to battery voltage. 22 V BUS - - Ignition switch ON or power window timer operates 23 G Security indicator lamp Output OFF Goes OFF --> illuminates (Every 2.4 seconds) Battery voltage --> 0V 25 BR NATS antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move for approx. 1 second, then return to battery voltage. 27 W Compressor ON signal Input ON A/C switch OFF 5V A/C switch ON 0V 28 R Front blower monitor Input ON Front blower motor OFF Battery voltage Front blower motor ON 0V 29 G Hazard switch Input OFF ON 0V OFF 5V 30 (1) G Back door opener switch Input OFF ON (open) 0V OFF (closed) Battery voltage 30 (2) SB Back door opener switch Input OFF ON (open) 0V OFF (closed) Battery voltage 32 O Combination switch output 5 Output ON Lighting, turn, wiper OFF Wiper dial position 4 33 GR Combination switch output 4 Output ON Lighting, turn, wiper OFF Wiper dial position 4 34 G Combination switch output 3 Output ON Lighting, turn, wiper OFF Wiper dial position 4 35 BR Combination switch output 2 Output ON Lighting, turn, wiper OFF Wiper dial position 4 36 LG Combination switch output 1 37 (1) B Key switch and key lock solenoid Input OFF Key inserted Battery voltage Key inserted 0V 37 (2) B Key switch and ignition knob switch Input OFF Intelligent Key inserted Battery voltage Intelligent Key inserted 0V 38 W/R Ignition switch (ON) Input ON - Battery voltage 39 L CAN-H - - - - 40 P CAN-L - - - - 42 LG Glass hatch ajar switch Input ON Glass hatch open 0V Glass hatch closed Battery voltage 43 P Back door latch switch Input OFF ON (open) 0V OFF (closed) Battery voltage 44 O Rear wiper auto stop switch Input ON Rise up position (rear wiper arm on stopper) 0V A Position (full clockwise stop position) Battery voltage Forward sweep (counterclockwise direction) Fluctuating B Position (full counterclockwise stop position) 0V Reverse sweep (clockwise direction) Fluctuating 47 GR Front door switch LH Input OFF ON (open) 0V OFF (closed) Battery voltage 48 P Rear door switch LH Input OFF ON (open) 0V OFF (closed) Battery voltage 49 L Cargo lamp Output OFF Any door open (ON) 0V All doors closed (OFF) Battery voltage 51 O Trailer turn signal (right) Output ON Turn right ON 52 LG Trailer turn signal (left) Output ON Turn left ON 53 L Back door latch actuator Output OFF OFF 0 ON Battery voltage 55 W Rear wiper output circuit 1 Output ON OFF 0 ON Battery voltage 56 R/Y Battery saver output Output OFF 15 minutes after ignition switch is turned OFF 0V ON - Battery voltage 57 R/Y Battery power supply Input OFF - Battery voltage 58 W Optical sensor Input ON When optical sensor is illuminated 3.1V or more When optical sensor is not illuminated 0.6V or less 59 GR Front door lock assembly LH actuator (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 60 LG Turn signal (left) Output ON Turn left ON 61 G Turn signal (right) Output ON Turn right ON 63 BR Interior room/map lamp Output OFF Any door switch ON (open) 0V OFF (closed) Battery voltage 65 V All door lock actuators (lock) Output OFF OFF (neutral) 0V ON (lock) Battery voltage 66 L Front door lock actuator RH, rear door lock actuators LH/RH and glass hatch lock actuator (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 67 B Ground Input ON - 0V 68 W/R Power window power supply (RAP) Output - Ignition switch ON Battery voltage Within 45 seconds after ignition switch OFF Battery voltage More than 45 seconds after ignition switch OFF 0V When front door LH or RH is open or power window timer operates 0V 69 L Power window power supply Output - - Battery voltage 70 W Battery power supply Input OFF - Battery voltage (1) With remote keyless entry system (2) With Intelligent Key system

Scheme 70

Scheme 70: Physical Values
Scheme 70: Physical Values

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74

Fail Safe

Fail-safe index

BCM performs fail-safe control when any DTC listed below is detected.

Display contents of CONSULTFail-safeCancellation
U1000: CAN COMM CIRCUITInhibit engine crankingWhen the BCM re-establishes communication with the other modules.

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS articles of this Service Information.

WARNINGTo avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNINGWhen working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery, and wait at least 3 minutes before performing any service.

Precaution Necessary for Steering Wheel Rotation After Battery Disconnect

Note. This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYSTEM). Remove and install all control units after disconnecting both battery cables with the ignition knob in the "LOCK" position. Always use CONSULT to perform self-diagnosis as a part of each function inspection after finishing work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.

For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mechanism is adopted on the key cylinder.

For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and steering wheel rotation will become impossible.

If steering wheel rotation is required when battery power is interrupted, follow the procedure below before starting the repair operation.

Precaution for Work

  1. When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
  2. When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
  3. Protect the removed parts with a shop cloth and prevent them from being dropped.
  4. Replace a deformed or damaged clip.
  5. If a part is specified as a non-reusable part, always replace it with new one.
  6. Be sure to tighten bolts and nuts securely to the specified torque.
  7. After installation is complete, be sure to check that each part works properly.
  8. Follow the steps below to clean components.
  1. Water soluble dirt: Dip a soft cloth into lukewarm water, and wring the water out of the cloth to wipe the dirty area. Then rub with a soft and dry cloth.
  2. Oily dirt: Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%), and wipe the dirty area. Then dip a cloth into fresh water, and wring the water out of the cloth to wipe the detergent off. Then rub with a soft and dry cloth.
  1. Do not use organic solvent such as thinner, benzene, alcohol, or gasoline.
  2. For genuine leather seats, use a genuine leather seat cleaner.

Special Service Tool

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number (Kent-Moore No.) Tool name Description - (J-46534) Trim tool set Removing trim components

Scheme 75

Scheme 75: Special Service Tool
Scheme 75: Special Service Tool

Scheme 76

Scheme 76: REMOVAL
Scheme 76: REMOVAL
  1. Using a suitable tool, release the metal clip and pawls, then lift the main power window and door lock/unlock switch and finisher (2) upward as an assembly. CAUTION: Wrap a cloth around suitable tool to protect components from damage.
  2. Disconnect the harness connectors, then remove the assembly from front door finisher.
  3. Remove the three screws (A) and separate the main power window and door lock/unlock switch (1) from the switch finisher (2).
