Power Window Control System: Overview Nissan Pathfinder III рестайлинг

ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: Description

Note. ANTI-PINCH SYSTEM

If any of the following work has been done Initial setting is necessary.

1. Power supply to the power window main switch or power window motor is cut off by the removal of battery terminal or the battery fuse is blown.
2. Disconnection and connection of power window main switch harness connector.
3. Power window motor or regulator is replaced.
4. Removal and installation of glass.
5. Removal and installation of door glass run.
6. Window is partly opened and/or closed many times without being fully closed.

Note. The following specified operations can not be performed under the non-initialized condition.

1. Auto-up operation

Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT ".

ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: Description

Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: DESCRIPTION ".

POWER WINDOW OPERATION

1. Power window system is operable during the retained power operation timer after turning ignition switch ON and OFF.
2. Main power window and door lock/unlock switch can open/close all windows.
3. Power window and door lock unlock switch RH & rear power window switches LH and RH can open/close the corresponding windows.

POWER WINDOW AUTO-OPERATION (FRONT LH & RH)

1. AUTO UP/DOWN operation can be performed when main power window and door lock/unlock switch & power window and door lock/unlock switch RH turns to AUTO.
2. Encoder continues detecting the movement of power window motor and transmits to power window switch as the encoder pulse signal while power window motor is operating.
3. Power window switch reads the changes of encoder signal and stops AUTO operation when door glass is at fully opened/closed position.
4. Power window motor is operable in case encoder is malfunctioning.

RETAINED POWER OPERATION

1. Retained power operation is an additional power supply function that enables power window system to operate during the 45 seconds even when ignition switch is turned OFF

Retained power function cancel conditions

1. Front door CLOSE (door switch OFF)-->OPEN (door switch ON).
2. When ignition switch is ON.
3. When timer time passes. (45 seconds)

ANTI-PINCH OPERATION (FRONT LH & RH)

1. Pinch foreign material in the door glass during AUTO-UP operation, and it is the anti-pinch function that lowers the door glass 150 mm (5.91 in) or 2 seconds when detected.
2. Encoder continues detecting the movement of power window motor and transmits to power window switch as the encoder pulse signal while power window motor is operating.
3. Resistance is applied to the power window motor rotation that changes the frequency of encoder pulse signal if foreign material is trapped in the door glass.
4. Power window switch controls to lower the window glass for 150 mm (5.91 in) or 2 seconds after it detects encoder pulse signal frequency change.

OPERATION CONDITION

1. When all door glass AUTO-UP operation is performed (anti-pinch function does not operate just before the door glass closes and is fully closed)

Note. Depending on environment and driving conditions, if a similar impact or load is applied to the door glass, it may lower. KEY CYLINDER SWITCH OPERATION

Hold the driver's door key cylinder to the LOCK or UNLOCK direction for more than 1 second to OPEN or CLOSE front power windows when ignition switch is OFF. In addition, it stops when key position is moved to NEUTRAL when operating.

OPERATION CONDITION

1. Ignition switch OFF
2. Hold driver's door key cylinder to LOCK position for more than 1 second to perform CLOSE operation of the door glass.
3. Hold driver's door key cylinder to UNLOCK position for more than 1 second to perform OPEN operation of the door glass.

KEYLESS POWER WINDOW DOWN OPERATION (FRONT LH & RH)

Front power windows open when the unlock button on Intelligent Key or keyfob is activated and kept pressed for more than 3 (NOTE) seconds with the ignition switch OFF. The windows keep opening if the unlock button is continuously pressed.

The power window opening stops when the following operations are performed

1. When the unlock button is kept pressed more than 15 seconds.
2. When the ignition switch is turned ON while the power window opening is operated.
3. When the unlock button is released.

While retained power operation is activated, keyless power window down function cannot be operated.

Note. Keyless power window down operation mode can be changed by "P/W DOWN DELAY" mode in "WORK SUPPORT". Refer to " INTELLIGENT KEY: CONSULT FUNCTION (BCM - INTELLIGENT KEY) " with Intelligent Key or " MULTI REMOTE ENT: CONSULT FUNCTION (BCM - MULTI REMOTE ENT) " with remote keyless entry system.

Scheme 1

POWER WINDOW MAIN SWITCH: Description

1. BCM supplies power.
2. It operates each power window motor via corresponding power window switch and makes window move up/down when main power window and door lock/unlock switch is operated.

FRONT POWER WINDOW SWITCH: Description

1. BCM supplies power.
2. Front power window motor RH will be operated if power window and door lock/unlock switch RH is operated.

REAR POWER WINDOW SWITCH: Description

1. BCM supplies power.
2. Rear power window motor will be operated if rear power window switch is operated.

DRIVER SIDE: Description

Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch.

PASSENGER SIDE: Description

Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or power window and door lock/unlock switch RH.

REAR LH: Description

Door glass moves UP/DOWN by receiving the signal from power window main switch or rear power window switch LH.

REAR RH: Description

Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or rear power window switch RH.

Detects condition of the front power window motor LH operation and transmits to main power window and door lock/unlock switch as pulse signal.

Detects condition of the front power window motor RH operation and transmits to power window and door lock/unlock switch RH as pulse signal.

Description

Detects door open/close condition and transmits the signal to BCM.

Main power window and door lock/unlock switch detects condition of the door key cylinder and transmits to BCM as the LOCK or UNLOCK signals.

Main power window and door lock/unlock switch, power window and door lock/unlock switch RH and BCM transmit and receive the signal by power window serial link.

The signal mentioned below is transmitted from BCM to main power window and door lock/unlock switch and power window and door lock/unlock switch RH

1. Keyless power window down signal

The signal mentioned below is transmitted from main power window and door lock/unlock switch to power window and door lock/unlock switch RH

1. Front door window RH operation signal
2. Power window control by key cylinder switch signal
3. Power window lock switch signal
4. Retained power operation signal

Main power window and door lock/unlock switch, power window and door lock/unlock switch RH and BCM transmit and receive the signal by power window serial link.

The signal mentioned below is transmitted from BCM to main power window and door lock/unlock switch and power window and door lock/unlock switch RH

1. Keyless power window down signal

The signal mentioned below is transmitted from main power window and door lock/unlock switch to power window and door lock/unlock switch RH

1. Front door window RH operation signal
2. Power window control by key cylinder switch signal
3. Retained power operation signal
4. Power window lock switch signal

Ground circuit of main power window and door lock/unlock switch shuts off if power window lock switch of main power window and door lock/unlock switch is operated. This inhibits all operation, except for the main switch.

OPERATION PROCEDURE

1. Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the "ACC" position. At this time, the steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the "LOCK" position before connecting the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT.
