Roof: Overhaul Nissan Pathfinder III рестайлинг

GLASS LID ASSEMBLY

Removal

1. Open sunshade assembly.
2. Ensure glass lid assembly is closed.
3. Remove the screws securing glass lid assembly to the sunroof unit.
4. Remove the glass lid assembly.

Installation

Scheme 110

1. Position glass lid assembly to sunroof unit.
2. Install the glass lid assembly screws. (First tighten left front bolt, then tighten right rear bolt on glass lid assembly to prevent lid from moving while tightening other bolts.)
3. Adjust the sunroof glass. Refer to " «ADJUSTMENT»(ref-519840-S18001038872012122900000) ". CAUTION: After installing the glass lid assembly, be sure to check gap adjustment to ensure there are no malfunctions.

Removal

1. Remove glass lid, refer to «GLASS LID ASSEMBLY»(ref-519840-S24110233702012122900000) in this article
2. Inspect rubber edge of glass lid. NOTE: If rubber edge is deformed or damaged, entire glass lid must be replaced.
3. Remove sunroof lid seal from the rubber edge of glass lid by pulling it outward.

Installation

1. Inspect and clean the ditch groove of the rubber edge for dirt or debris.
2. Stretch sunroof lid seal around glass lid and push the tongue edge into the ditch groove. NOTE: If needed, very light taps with a rubber hammer can be used to press the seal into place.
3. Place glass lid into sunroof assembly and install, refer to «GLASS LID ASSEMBLY»(ref-519840-S24110233702012122900000) in this article.

SUNSHADE ASSEMBLY

Removal

Scheme 111

1. Remove the sunroof unit. Refer to «SUNROOF UNIT»(ref-519840-S03453725792012122900000) in this article.
2. Remove the sunshade assembly stoppers (two points) from the rear end of the sunroof unit.
3. Remove the sunshade assembly from the rear end of the sunroof unit.

Installation

Installation is in the reverse order of removal.

Removal

Scheme 112

1. Position the sunroof assembly in the fully closed position.
2. Remove the front roof console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S39057959832012122900000) ".
3. Disconnect the harness connector from the sunroof motor assembly.
4. Remove the mounting screws and the sunroof motor assembly.

Installation

Scheme 113

1. Move the sunroof motor assembly laterally little by little so that the gear is completely engaged into the wire on the sunroof unit and the mounting surface becomes parallel. Then secure the motor with the screws.
2. Connect the harness connector to the sunroof motor assembly.
3. Install the front roof console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S39057959832012122900000) ".
4. Reset the sunroof motor assembly memory. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-519840-S00417416802012122900000) ".
