Roof: Diagnosis Nissan Pathfinder III рестайлинг

BASIC INSPECTION

1. INSPECTION START Check the service history. Check the following parts. Fuse/circuit breaker blown. Poor connection, open or short circuit of harness connector. Battery voltage. Is the inspection result normal? YES: Inspection End. NO: Repair or replace the malfunctioning parts.

Scheme 104

ACTIVE TEST

Diagnosis Procedure

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

Scheme 105

Scheme 106

1. CHECK SUNROOF SWITCH INPUT SIGNAL Turn ignition switch ON. Check voltage between sunroof switch connector and ground. Connector Terminals Sunroof switch position Voltage (V) (Approx.) (+) (-) R4 1 2 DOWN/OPEN 0V Other than above Battery voltage 3 UP/CLOSE 0V Other than above Battery voltage Are the voltage measurements as specified? YES: Sunroof switch is operating normally. NO: GO TO 2
2. CHECK SUNROOF SWITCH CIRCUITS Turn ignition switch OFF. Disconnect sunroof motor assembly connector B83 and sunroof switch connector R4. Check continuity between sunroof motor assembly connector B83 (A) and sunroof switch connector R4 (B). A B Continuity Connector Terminal Connector Terminal B83 1 R4 3 Yes 5 1 Check continuity between sunroof motor assembly connector B83 (A) and ground. A - Continuity Connector Terminal B83 5 Ground No 1 Are the continuity test results as specified? YES: GO TO 3 NO: Repair harness or connector.
3. CHECK SUNROOF SWITCH GROUND CIRCUIT Connect sunroof motor assembly. Check continuity between sunroof switch connector R4 and ground. Sunroof switch connector Terminal Ground Continuity R4 2 Yes Is the continuity test result as specified? YES: GO to 4 NO: Repair or replace harness.
4. CHECK SUNROOF SWITCH Check continuity between sunroof switch terminals. Terminals Sunroof switch position Continuity 1 2 DOWN/OPEN Yes Other than above No 3 UP/CLOSE Yes Other than above No Are the continuity test results as specified? YES: Sunroof switch is operating normally. NO: Replace sunroof switch (map lamp assembly). Refer to " «REMOVAL AND INSTALLATION»(ref-519831-S23969070712012122900000) ".

Regarding Wiring Diagram information, refer to " WIRING DIAGRAM ".

1. CHECK DOOR SWITCHES INPUT SIGNAL With CONSULT Check door switches ("DOOR SW-DR", "DOOR SW-AS") in DATA MONITOR mode with CONSULT. Refer to " «DOOR LOCK: CONSULT FUNCTION (BCM - DOOR LOCK)»(ref-519820-S39239165002012122900000) ". When any doors are open: DOOR SW-DR: ON DOOR SW-AS: ON When any doors are closed: DOOR SW-DR: OFF DOOR SW-AS: OFF Without CONSULT Check voltage between BCM connector M18 or M19 terminals 12, 47 and ground. Connector Item Terminals Condition Voltage (V) (Approx.) (+) (-) M19 Front door switch LH 47 Ground Open ↓ Closed 0 ↓ Battery voltage M18 Front door switch RH 12 Is the inspection result normal? YES: Door switch circuit is OK. NO: GO TO 2
2. CHECK DOOR SWITCH CIRCUIT Turn ignition switch OFF. Disconnect door switch and BCM. Check continuity between door switch connector B8 (Front LH), B108 (Front RH) terminal 2 and BCM connector M18, M19 terminals 12, 47. 2 - 47: Continuity should exist 2 - 12: Continuity should exist Check continuity between door switch connector B8 (Front LH), B108 (Front RH) terminal 2 and ground. 2 - Ground: Continuity should not exist Is the inspection result normal? YES: GO TO 3 NO: Repair or replace harness.
3. CHECK DOOR SWITCHES Check continuity between door switch terminals. Terminal Condition Continuity Door switch 2 - Ground Open Yes Closed No Is the inspection result normal? YES: Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-519820-S41424990012012122900000) ". NO: Replace door switch.

VALUES ON THE DIAGNOSIS TOOL

Scheme 107

DTC Inspection Priority Chart

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority chart.

DTC Index

Note. Details of time display CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning ignition switch OFF --> ON again. 1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases like 1 --> 2 --> 3...38 --> 39 after returning to the normal condition whenever ignition switch OFF --> ON. The counter remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch OFF --> ON after returning to the normal condition if the malfunction is detected again.

Scheme 108

1. CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to " «DIAGNOSIS PROCEDURE»(ref-519820-S02156635892012122900000) ". GO TO 2
2. CHECK SUNROOF MOTOR ASSEMBLY POWER SUPPLY AND GROUND CIRCUIT Check sunroof motor assembly power supply and ground circuit. Refer to " «SUNROOF MOTOR ASSEMBLY: DIAGNOSIS PROCEDURE»(ref-519840-S37709497512012122900000) ". GO TO 3
3. CHECK SUNROOF SWITCH CIRCUIT Check sunroof switch circuit. Refer to " «DESCRIPTION»(ref-519840-S41140743222012122900000) ". Is the inspection result normal? YES: GO TO 4. NO: Repair or replace malfunctioning parts.
4. CHECK VEHICLE SPEED SIGNAL CIRCUIT Check vehicle speed signal circuit. Refer to " «COMPONENT FUNCTION CHECK»(ref-519840-S21630721352012122900000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «INTERMITTENT INCIDENT»(ref-519769-S29819125922012122900000) ". NO: Repair or replace malfunctioning parts.

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-519840-S00417416802012122900000) ". Is the inspection result normal? YES: Inspection End. NO: Perform basic inspection. Refer to " «WORK FLOW»(ref-519840-S15060053602012122900000) ".

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-519840-S00417416802012122900000) ". Is the inspection result normal? YES: Inspection End. NO: Perform basic inspection. Refer to " «WORK FLOW»(ref-519840-S15060053602012122900000) ".

1. CHECK FRONT DOOR SWITCH Check front door switch. Refer to " «COMPONENT FUNCTION CHECK»(ref-519840-S14759039512012122900000) ". Is the inspection result normal? YES: Check intermittent incident. Refer to " «WORK FLOW»(ref-519840-S15060053602012122900000) ". NO: Repair or replace malfunctioning parts.

1. PERFORM INITIALIZATION PROCEDURE Perform initialization procedure. Refer to " «ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: SPECIAL REPAIR REQUIREMENT»(ref-519840-S00417416802012122900000) ". Is the inspection result normal? YES: Inspection End. NO: Perform basic inspection. Refer to " «WORK FLOW»(ref-519840-S15060053602012122900000) ".

Scheme 109

DUPLICATE THE NOISE AND TEST DRIVE

If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to duplicate the same conditions when you confirm the repair.

If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to duplicate the noise with the vehicle stopped by doing one or all of the following

1. Close a door.
2. Tap or push/pull around the area where the noise appears to be coming from.
3. Rev the engine.
4. Use a floor jack to recreate vehicle "twist".
5. At idle, apply engine load (electrical load, half-clutch on M/T model, drive position on CVT and A/T models).
6. Raise the vehicle on a hoist and hit a tire with a rubber hammer. Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs. If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the vehicle body.

Generic Squeak and Rattle Troubleshooting

Refer to the appropriate service category for specific component removal and installation information.
