Scheme 100
AUTO OPERATION
The sunroof AUTO feature makes it possible to slide open and slide close or tilt up and tilt down the sunroof without holding the sunroof switch in the slide open/tilt down or slide close/tilt up position.
RETAINED POWER OPERATION
Retained power operation is an additional power supply function that enables the sunroof system to operate up to 45 seconds after the ignition switch is turned OFF.
Retained power function cancel conditions
- When a front door is opened (door switch ON)
- When ignition switch is turned ON again.
- When 45 seconds elapse on the timer.
Scheme 101
Component Description
| Component | Function |
|---|---|
| BCM | Supplies power to the sunroof motor assembly. |
| Sunroof switch | Transmits tilt up/down & slide open/close operation signal to sunroof motor assembly. |
| Sunroof motor assembly | The sunroof motor and integrated CPU enables tilt up/down & slide open/close as requested by the sunroof switch. |
| Front door switch | Detects door open/close condition and transmits to BCM. |
| Combination meter | Transmits vehicle speed signal to sunroof motor assembly. |
Description
The BCM supplies power to the integrated CPU of the sunroof motor assembly. The tilt and slide functions of the sunroof motor assembly is controlled by the sunroof switch.
Detects door open/close condition.
OPERATION PROCEDURE
- Connect both battery cables. NOTE: Supply power using jumper cables if battery is discharged.
- Use the Intelligent Key or mechanical key to turn the ignition switch to the? ACC? position. At this time, the steering lock will be released.
- Disconnect both battery cables. The steering lock will remain released and the steering wheel can be rotated.
- Perform the necessary repair operation.
- When the repair work is completed, return the ignition switch to the "LOCK" position before connecting the battery cables. (At this time, the steering lock mechanism will engage.)
- Perform a self-diagnosis check of all control units using CONSULT.
