Automatic Transaxle Shift Mechanism: Diagnosis Mazda 3 BL рестайлинг

Automatic Trans 4 illustrations ~294 words

Key Interlock System Inspection

  1. Switch the ignition to ON.
  2. Perform the following procedures to inspect the key interlock system. If there is any malfunction, inspect the key interlock solenoid and NOT P position switch. (See «KEY INTERLOCK SOLENOID INSPECTION»(ref-520491-S41788739742013010300000) .)(See «NOT P POSITION SWITCH INSPECTION»(ref-520491-S38966104182013010300000) .) Verify that the ignition cannot be switched to off when the selector lever is not in the P position. Verify that the ignition can be switched to off when the selector lever is in the P position.

Scheme 673

Scheme 673: Key Interlock Solenoid Inspection

Scheme 674

Scheme 674
  1. Perform the following procedures. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).) Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).) Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-520454-S20642177192013010300000).) Disconnect the key interlock solenoid connector. (Scheme 673): Identifying Key Interlock Solenoid Connector
  2. Measure the resistance between the key interlock solenoid terminals A and B. (Scheme 674): Identifying Key Interlock Solenoid Terminals If there is any malfunction, replace the steering lock. (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-520445-S38694288302013010300000).) Key interlock solenoid specification Approx.36 ohms

Scheme 675

Scheme 675: NOT P Position Switch Inspection

Scheme 676

Scheme 676
  1. Perform the following procedures. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).) Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).) Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).) Disconnect the selector lever component connector. (Scheme 675): Identifying Selector Lever Component Connector
  2. Inspect the continuity between the selector lever component terminals G and K. (Scheme 676): Identifying Selector Lever Component Terminals If there is any malfunction, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).)
