Automatic Transaxle Shift Mechanism: Overview Mazda 3 BL рестайлинг

Identifying Selector Cable, Lever Component And Lock. Scheme 637

Scheme 638

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal. (Scheme 638): Identifying Upper, Shift And Indicator Panels, Selector Lever And Cable With Torque Specifications

Scheme 639

Scheme 640

Scheme 641

1. Remove the shift panel and indicator panel as a single unit. Release the hooks securing the shift panel and console, and then release the hooks securing the shift panel and ashtray panel. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Lift up the shift panel and indicator panel and disconnect the bulb socket from the indicator panel. (Scheme 639): Disconnecting Bulb Socket From Indicator Panel Remove the shift panel and indicator panel from the selector lever as a single unit. (Scheme 640): Identifying Shift Panel And Indicator Panel Of Selector Lever
2. Detach the hooks as shown in the figure and remove the indicator panel from the shift panel. (Scheme 641): Identifying Hooks On Indicator Panel

Scheme 642

Scheme 643

1. Align the locator pin with the hole in the floor as shown in the figure and install the selector lever. (Scheme 642): Identifying Selector Lever, Locator Pins And Holes
2. Tighten the selector lever installation bolts. (Scheme 643): Identifying Selector Lever Installation Bolt Tightening torque 8-10 N.m {82-101 kgf.cm, 71-88 in.lbf}

Scheme 644

Scheme 645

1. Install the selector cable end (selector lever side) as shown in the figure. (Scheme 644): Locating Selector Cable End (Selector Lever Side)
2. Install the cable outer end (selector lever side) to the selector cable bracket as shown in the figure. (Scheme 645): Identifying Cable Outer End (Selector Lever Side)
3. Adjust the selector cable. (See «SELECTOR CABLE ADJUSTMENT»(ref-520491-S17800055662013010300000).)

Scheme 646

Scheme 647

Scheme 648

1. Install the shift panel to the indicator panel. (Scheme 646): Identifying Shift And Indicator Panels
2. Install the shift panel and indicator panel to the selector lever as a single unit. (Scheme 647): Identifying Shift And Indicator Panels On Selector Lever
3. Connect the bulb socket to the indicator panel. (Scheme 648): Connecting Bulb Socket To Indicator Panel
4. Install the shift panel and indicator panel to the console and ashtray panel as a single unit. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000) )

Scheme 649

Scheme 650

Scheme 651

Scheme 652

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
3. Remove the battery component (ex: battery, battery tray and PCM component). (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
4. Remove the air cleaner component. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520380-S16554744642013010300000).) (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520422-S09166380872013010300000).)
5. Remove the aerodynamic under cover NO.2. (See «AERODYNAMIC UNDER COVER NO.2 REMOVAL/INSTALLATION»(ref-520448-S37186396192013010300000).)
6. Remove the tunnel member (rear). (MZR 2.0, MZR 2.5) (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520385-S15369017672013010300000).)
7. Remove the brace bar. (SKYACTIV-G 2.0) (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520426-S34458217012013010300000).)
8. Remove the insulator (front) installation nuts and set the insulator (front) aside. (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520385-S15369017672013010300000).) (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520426-S34458217012013010300000).)
9. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).)
10. Remove the knob. (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-520491-S02257412942013010300000).)
11. Remove the shift panel and indicator panel as a single unit. Release the hooks securing the shift panel and console, and then release the hooks securing the shift panel and ashtray panel. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Lift up the shift panel and indicator panel and disconnect the bulb socket from the indicator panel. (Scheme 649): Disconnecting/Connecting Bulb Socket From/To Indicator Panel Remove the shift panel and indicator panel from the selector lever as a single unit. (Scheme 650): Identifying Shift And Indicator Panels On Selector Lever
12. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).)
13. Disconnect the drain hose connected to A/C unit. (See «A/C UNIT REMOVAL/INSTALLATION»(ref-520443-S01420897172013010300000). (Scheme 651): Identifying A/C Unit And Drain Hose
14. Remove in the order indicated in the table.
15. Install in reverse of removal. FS5A-EL (Scheme 652): Exploded View Of Selector Cable With Torque Specifications

Scheme 653

1. Remove the clip, and then disconnect the selector cable end from the manual shaft lever. (Scheme 653): Identifying Selector Cable End, Manual Shaft Lever And Clip (FS5A-EL And FW6A-EL)

Scheme 654

Scheme 655

Scheme 656

Scheme 657

Scheme 658

Scheme 659

Scheme 660

Scheme 661

Scheme 662

1. Install the grommet as shown in the figure. (Scheme 654): Identifying Grommet And Mounting Nuts Tightening torque 4.0-9.8 N.m {41-99 kgf.cm, 36-86 in.lbf}
2. Install the selector cable end (selector lever side) as shown in the figure. (Scheme 655): Locating Selector Cable End (Selector Lever Side)
3. Install the cable outer end (selector lever side) to the selector cable bracket as shown in the figure. (Scheme 656): Identifying Cable Outer End (Selector Lever Side)
4. Install the clip as shown in the figure and tighten the nut. (Scheme 657): Locating Position Of Clips And Nut (FS5A-EL) (Scheme 658): Locating Position Of Clips And Nut (FW6A-EL) Tightening torque 19-25 N.m {2.0-2.5 kgf.m, 15-18 ft.lbf}
5. Install the selector cable end (transaxle side) and the cable outer end (transaxle side). CAUTION: When installing selector cable, make sure the boot is not twisted. Bending the selector cable in the manner shown in the figure will damage the cable and it may become loose when shifted. When installing the selector cable, hold it straight. (Scheme 659): Caution - Do Not Bend Selector Cable Install the cable outer end (transaxle side) to the selector cable bracket as shown in the figure. (Scheme 660): Identifying Cable Outer End (Transaxle Side) Install the clip to the selector cable end (transaxle side) as shown in the figure. (Scheme 661): Identifying Clip On Selector Cable End (Transaxle Side) Install the selector cable end (transaxle side) to the manual shaft lever as shown in the figure. (Scheme 662): Identifying Selector Cable End (Transaxle Side), Manual Shaft Lever And Clip (FS5A-EL And FW6A-EL)
6. Verify that the selector cable is securely installed.
7. Adjust the selector cable. (See «SELECTOR CABLE ADJUSTMENT»(ref-520491-S17800055662013010300000).)

Scheme 663

Scheme 664

Scheme 665

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
3. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).)
4. Remove the knob. (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-520491-S02257412942013010300000).)
5. Remove the shift panel and indicator panel as a single unit. Release the hooks securing the shift panel and console, and then release the hooks securing the shift panel and ashtray panel. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000) ) Lift up the shift panel and indicator panel and disconnect the bulb socket from the indicator panel. (Scheme 663): Disconnecting/Connecting Bulb Socket From/To Indicator Panel Remove the shift panel and indicator pane from the selector lever as a single unit. (Scheme 664): Identifying Shift Panel And Indicator Panel Of Selector Lever
6. Remove the bulb from the bulb socket. (Scheme 665): Identifying Bulb And Bulb Socket
7. Install in the reverse order of removal.

Scheme 666

Scheme 667

Scheme 668

Scheme 669

1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).)
3. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-520454-S17814587652013010300000).)
4. Remove the knob. (See «SELECTOR LEVER REMOVAL/INSTALLATION»(ref-520491-S02257412942013010300000).)
5. Remove the shift panel and indicator panel as a single unit. Release the hooks securing the shift panel and console, and then release the hooks securing the shift panel and ashtray panel. (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-520454-S17124509942013010300000).) Lift up the shift panel and indicator panel and disconnect the bulb socket from the indicator panel. (Scheme 666): Disconnecting/Connecting Bulb Socket From/To Indicator Panel Remove the shift panel and indicator panel from the selector lever as a single unit. (Scheme 667): Identifying Shift And Indicator Panels On Selector Lever
6. Shift the selector lever to the P position.
7. Unlock the lock piece of the selector cable end (selector lever side) in the order as shown in the figure. (Scheme 668): Order Of Unlocking Lock Piece Of Selector Cable End (Selector Lever Side)
8. Verify that the manual shaft is in the P position.
9. Lock the lock piece and safety lock of the selector cable end (selector lever side) in the order as shown in the figure. (Scheme 669): Sequence Of Locking Lock Piece And Safety Lock Of Selector Cable End (Selector Lever Side)

Scheme 670

1. Switch the ignition to ON.
2. Perform the following procedures to inspect the selector lever. If there is any malfunction, adjust the selector cable. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).) Verify that the selector lever can be operated as shown in the figure. (Scheme 670): Selector Lever Operation Diagram Verify that the selector lever can be operated smoothly and moderately.

Shift-Lock System Inspection

1. Switch the ignition to ON.
2. Shift the selector lever to the P position.
3. Perform the following procedures to inspect the shift-lock system. If there is any malfunction, inspect the shift-lock solenoid and P position switch. (See «SHIFT-LOCK SOLENOID AND P POSITION SWITCH INSPECTION»(ref-520491-S12422934732013010300000) .) Verify that the selector lever cannot be shifted from P to R position when the brake pedal is released. Verify that the selector lever can be shifted from P to R position when the brake pedal is depressed.

Scheme 671

Scheme 672

1. Perform the following procedures. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).) Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-520427-S28538867222013010300000).) Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-520454-S28438507612013010300000).) Disconnect the selector lever component connector. (Scheme 671): Identifying Selector Lever Component Connector
2. Measure the voltage between the selector lever component terminals. (Scheme 672): Identifying Selector Lever Component Terminals If there is any malfunction, repair or replace the related wiring harness. If there is no malfunction even though the shift-lock system has any malfunction, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).)
