Identifying Automatic Transaxle Components Location (1 Of 2). Scheme 476
Scheme 476: Identifying Automatic Transaxle Components Location (1 Of 2)
Identifying Automatic Transaxle Components Location (2 Of 2). Scheme 477
Scheme 477: Identifying Automatic Transaxle Components Location (2 Of 2)
Operation Inspection
- Perform the following procedures to inspect the TR switch. If there is any malfunction, adjust the TR switch. (See «TRANSAXLE RANGE (TR) SWITCH ADJUSTMENT [FS5A-EL]»(ref-520434-S37278945852013010300000) .) Engage the parking brake and use wheel chocks at the front and rear of the wheels. Verify that the starter operates only when the ignition is switched to START with the selector lever in the P position or the N position. Verify that the back-up lights illuminate when shifted to the R position with the ignition at ON. Verify that the positions of the selector lever and the selector indicator light are aligned.
Scheme 478
Scheme 478: On-Vehicle Inspection
Scheme 479
- Engage the parking brake and use wheel chocks at the front and rear of the wheels.
- Perform the following procedures. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520388-S24063200782013010300000).) Disconnect the negative battery cable. Remove the air cleaner component. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-520380-S16554744642013010300000).) Disconnect the TR switch connector. (Scheme 478): Identifying TR Switch Connector
- Inspect continuity as indicated in the table. (Scheme 479): TR Switch Connector Terminals Continuity Chart If there is any malfunction, adjust the TR switch. (See «TRANSAXLE RANGE (TR) SWITCH ADJUSTMENT [FS5A-EL]»(ref-520434-S37278945852013010300000).)
