Shift-lock solenoid specification
| Terminals | Connected to | Test condition | Voltage (V) |
|---|
| E-GND | Brake switch | Brake pedal released | Below 1.0 |
| Brake pedal depressed | B+ |
| I-GND | Ignition switch | Switch the ignition to off | Below 1.0 |
| Switch the ignition to ACC or ON | B+ |
| K-GND | GND | Under any condition | Below 1.0 |
Scheme 636
Scheme 636: Emergency Override Button Inspection
- Switch the ignition to off.
- Verify that the selector lever is in the P position.
- Without the brake pedal depressed, verify that the selector lever cannot be shifted from the P position.
- Remove the cover using a tape-wrapped flathead screwdriver. (Scheme 636): Removing Cover Using Tape-Wrapped Flathead Screwdriver
- Insert the flathead screwdriver into the emergency override hole and push it down.
- Verify that the selector lever can be shifted from the P position. If there is any malfunction, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-520491-S31259650412013010300000).)
NOT P position switch specification
| Test condition | Continuity |
|---|
| P position | No continuity |
| Except P position | Continuity |
