Evaporative Emissions: Other Jaguar S-type I

Testing & Diagnostics 11 illustrations ~657 words

A1: CHECK FOR CORRECT CONNECTION

Pinpoint Test A

A5 Are all tubes, hoses and components in good condition?

B1: CHECK THE RESISTANCE OF THE EVAP CANISTER PURGE VALVE

Pinpoint Test B

B3 Is the resistance between 30 and 33 Ohms?

B2: CHECK THE EVAP CANISTER PURGE VALVE SUPPLY VOLTAGE

Pinpoint Test B

B1 Is the voltage greater than 10 Volts?

B3: CHECK THE EVAP CANISTER PURGE VALVE SIGNAL CIRCUIT FOR OPEN CIRCUIT

Pinpoint Test B

B2 Is the resistance greater than 10,000 Ohms?

B4: CHECK THE EVAP CANISTER PURGE VALVE SIGNAL CIRCUIT FOR SHORT TO GROUND

Pinpoint Test B

B2 Is the resistance less than 10,000 Ohms?

C1: CHECK THE RESISTANCE OF THE CANISTER CLOSE VALVE

Pinpoint Test C

C5 Is the resistance between 25 and 40 Ohms?

C2: CHECK THE SUPPLY VOLTAGE TO THE CANISTER CLOSE VALVE

Pinpoint Test C

C2 Is the voltage greater than 10 Volts?

C3: CHECK THE CANISTER CLOSE VALVE SIGNAL CIRCUIT FOR OPEN

Pinpoint Test C

C2 Is the resistance greater than 10,000 Ohms?

C4: CHECK THE CANISTER CLOSE VALVE SIGNAL CIRCUIT FOR SHORT TO GROUND

Pinpoint Test C

C2 -> Yes

D1: CHECK THE FUEL TANK PRESSURE SENSOR SUPPLY VOLTAGE

Pinpoint Test D

D5 Is the supply voltage greater than 1 Volts?

D2: CHECK THE FUEL TANK PRESSURE SENSOR GROUND CIRCUIT FOR OPEN

Pinpoint Test D

D2 Is the resistance greater than 10,000 Ohms?

D3: CHECK THE FUEL TANK PRESSURE SENSOR SIGNAL CIRCUIT FOR OPEN

Pinpoint Test D

D1 Is the resistance greater than 10,000 Ohms?

D4: CHECK THE FUEL TANK PRESSURE SENSOR SIGNAL CIRCUIT FOR SHORT TO GROUND

Pinpoint Test D

D2 Is the resistance less than 10,000 Ohms?

D5: CHECK CONTINUITY OF THE FUEL TANK PRESSURE SENSOR SUPPLY CIRCUIT

Pinpoint Test D

D3 Is the resistance greater than 0.5 Ohms?

D6: CHECK CONTINUITY OF THE FUEL TANK PRESSURE SENSOR GROUND CIRCUIT

Pinpoint Test D

D1 Is the resistance greater than 0.5 Ohms?

D7: CHECK CONTINUITY OF THE FUEL TANK PRESSURE SENSOR SIGNAL CIRCUIT

Pinpoint Test D

D1 Is the resistance greater than 0.5 Ohms?

Scheme 45

Scheme 45: Removal
Scheme 45: Removal

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. Remove the crossmember. For additional information, refer to «REAR SUBFRAME»(ref-207828-S36688836752005120100000)
  2. Disconnect the left-hand ABS sensor electrical connector.
  3. Disconnect the right-hand ABS sensor electrical connector.
  4. Disconnect the evaporative emission canister tube.
  5. Disconnect the evaporative emission canister electrical connector.
  6. Remove the evaporative emission canister and carrier.
  7. Disconnect the evaporative emission canister tubes.
  8. Remove the evaporative emission canister. Push the evaporative canister through the access hole.(1) Remove the evaporative emission canister. (2)

Scheme 52

Scheme 52: Installation
Scheme 52: Installation
  1. To install, reverse the Removal procedure.

Scheme 53

Scheme 53: Removal
Scheme 53: Removal

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55
  1. Disconnect the canister purge valve electrical connector and vacuum hose.
  2. Disconnect the canister purge valve vacuum hoses.
  3. Remove the canister purge valve.
