Catalytic Converter System: Removal & Installation Honda Insight ZE2 рестайлинг

Warm Up TWC Removal/Installation

Note. If the warm up TWC is damaged internally, inspect the under-floor TWC for debris.

Scheme 692

Scheme 693

1. Raise the vehicle on a lift.
2. Remove the bolts (A, B).
3. Remove the cowl cover and the under-cowl panel (see «COWL COVER REPLACEMENT»(ref-513174-S22314343132012110700000) ).
4. Remove the EGR pipe (see «EGR PIPE REMOVAL AND INSTALLATION»(ref-513186-S33806646082012110700000) ).
5. Remove the A/F sensor (Sensor 1) (see «A/F SENSOR REPLACEMENT»(ref-513153-S42837029252012110700000) ).
6. Remove the cover (A).
7. Remove the bolts (B) and the nuts (C).
8. Remove the WU-TWC (D).
9. Install the parts in the reverse order of removal with new gaskets (E).

Scheme 694

1. Raise the vehicle on a lift.
2. Remove secondary HO2S (Sensor 2) (see «A/F SENSOR REPLACEMENT»(ref-513153-S42837029252012110700000) ).
3. Remove the nuts (A) and the bolts (B).
4. Remove the under-floor TWC (C).
5. Remove the cover (D).
6. Install the parts in the reverse order of removal with new gaskets (E).
