DTC P2185: ECT Sensor 2 Circuit High Voltage Honda Insight ZE2 рестайлинг

Testing & Diagnostics 4 illustrations ~567 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 472

Scheme 472: DTC P2185: ECT Sensor 2 Circuit High Voltage

Scheme 473

Scheme 473

Scheme 474

Scheme 474

Scheme 475

Scheme 475
  1. Turn the ignition switch to ON (II).
  2. Check ECT SENSOR 2 in the DATA LIST with the HDS. Is about -40°F(-40°C) or less, or 4.90 V or more indicated? YES -Go to step 3. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at ECT sensor 2 and the PCM.
  3. Turn the ignition switch to LOCK (0).
  4. Disconnect the ECT sensor 2 2P connector.
  5. Connect ECT sensor 2 2P connector terminals No. 1 and No. 2 with a jumper wire.
  6. Turn the ignition switch to ON (II).
  7. Check ECT SENSOR 2 in the DATA LIST with the HDS. Is about -40°F(-40°C) or less, or 4.90 V or more indicated? YES -Go to step 8. NO -Go to step 20 .
  8. Turn the ignition switch to LOCK (0).
  9. Remove the jumper wire.
  10. Turn the ignition switch to ON (II).
  11. Measure the voltage between ECT sensor 2 2P connector terminal No. 2 and body ground. Is there about 5 V? YES -Go to step 12. NO -Go to step 16 .
  12. Turn the ignition switch to LOCK (0).
  13. Jump the SCS line with the HDS.
  14. Disconnect PCM connector A (49P).
  15. Check for continuity between PCM connector terminal A10 and ECT sensor 2 2P connector terminal No. 1. Is there continuity? YES -Go to step 27 . NO -Repair an open in the wire between the PCM (A10) and ECT sensor 2, then go to step 22 .
  16. Turn the ignition switch to LOCK (0).
  17. Jump the SCS line with the HDS.
  18. Disconnect PCM connector A (49P).
  19. Check for continuity between PCM connector terminal A34 and ECT sensor 2 2P connector terminal No. 2. Is there continuity? YES -Go to step 27 . NO -Repair an open in the wire between the PCM (A34) and ECT sensor 2, then go to step 22 .
  20. Turn the ignition switch to LOCK (0).
  21. Replace ECT sensor 2 (see «ECT SENSOR 2 REPLACEMENT»(ref-513153-S19104315722012110700000) ).
  22. Reconnect all connectors.
  23. Turn the ignition switch to ON (II).
  24. Reset the PCM with the HDS.
  25. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-513173-S16164063582012110700000) ).
  26. Check for Pending or Confirmed DTCs with the HDS. Is DTC P2185 indicated? YES -Check for poor connections or loose terminals at ECT sensor 2 and the PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(ref-513153-S06499438282012110700000) .
  27. Reconnect all connectors.
  28. Update the PCM if it does not have the latest software (see «PCM UPDATE»(ref-513153-S08553155092012110700000) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-513169-S18138486322012110700000) ).
  29. Check for Pending or Confirmed DTCs with the HDS. Is DTC P2185 indicated? YES -Check for poor connections or loose terminals at ECT sensor 2 and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-513169-S18138486322012110700000) ), then recheck. If the PCM was substituted, go to step 1 . NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-513153-S08243124262012110700000) ). If any other Pending or Confirmed DTCs are indicated, go to the indicated «DTC'S TROUBLESHOOTING»(ref-513153-S06499438282012110700000) .
