IMA Motor Rotor Position Calibration

Do the IMA motor rotor position calibration whenever any of these actions are done

1. The MCM is replaced.
2. The IMA motor rotor position sensor is replaced or removed during service.
3. The IMA motor is replaced.
4. The engine assembly is replaced.
5. The transmission is replaced.

Scheme 2

1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
2. Turn the ignition switch to ON (II).
3. Make sure the HDS communicates with the vehicle and the MCM (IMA system). If it doesn't, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(ref-513150-S05348875882012110700000) ).
4. Select IMA SYSTEM on the HDS.
5. Select the MOTOR ROTOR POSITION CALIBRATION in the ADJUSTMENT MENU of the HDS.
6. Turn the ignition switch to LOCK (0), and disconnect the HDS from the DLC.

Idle Stop Switch Adjustment

Note. When either the brake pedal position switch or the idle stop switch needs adjusting, both switches must be adjusted together to keep their functions synchronized. Always adjust the brake pedal position switch first, then adjust the idle stop switch; never adjust the switches independently. When the brake pedal is released, the idle stop switch is normally closed.

Scheme 3

1. Lightly screw the idle stop switch (A) until it contacts the pad on the brake pedal arm.
2. While pulling the pedal toward you, turn the switch clockwise until its thread end contacts the pedal stop bracket (B).
3. Rotate the switch 1/2 to 3/4 of a turn counterclockwise (clearance is 0.6-0.9 mm (0.02-0.04 in)), then tighten its lock nut (C), and connect its 2P connector.
4. Start the engine, and make sure its stops when you press the brake pedal.
