DTC P0102 MAF Sensor Circuit Low Voltage Honda Crosstour I

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION (+).

Scheme 328

Scheme 329

Scheme 330

Scheme 331

1. Turn the ignition switch to ON (II), and wait 2 seconds.
2. Check the MAF SENSOR in the DATA LIST with the HAS. Is about 0 GM/s, or 0.1 V or less indicated? YES -Go to next step. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the MAF sensor/IAT sensor and the PCM.
3. Turn the ignition switch to LOCK (0).
4. Disconnect the MAF sensor/IAT sensor up connector.
5. Turn the ignition switch to ON (II).
6. Measure the voltage between MAF sensor/IAT sensor up connector terminal No. 1 and body ground. Is there battery voltage? YES -Go to next step. NO -Repair an open in the wire between PGM-FI main relay 1 and the MAF sensor/IAT sensor, then go to step 19 .
7. Turn the ignition switch to LOCK (0).
8. Measure the resistance between MAF sensor/IAT sensor up connector terminal No. 3 and body ground. Is there 190-210 kohms at room temperature (65-70 °F, 18-21 °C)? YES -Go to step 13 . NO -Go to next step.
9. Jump the SCS line with the HAS.
10. Disconnect PCM connector A (49P).
11. Check for continuity between PCM connector terminal A20 and body ground. Is there continuity? YES -Repair a short in the wire between the PCM (A20) and the MAF sensor/IAT sensor, then go to step 20 . NO -Go to next step.
12. Check for continuity between MAF sensor/IAT sensor up connector terminal No. 3 and PCM connector terminal A20. Is there continuity? YES -Go to step 25 . NO -Repair an open in the wire between the PCM (A20) and the MAF sensor/IAT sensor, then go to step 20 .
13. Substitute a known-good MAF sensor/IAT sensor (see «MAF SENSOR/IAT SENSOR REPLACEMENT»(ref-360080-S20771661482010042600000) (+).
14. Reconnect all connectors.
15. Turn the ignition switch to ON (II).
16. Clear the DTC with the HAS.
17. Start the engine. Hold the engine speed at 2,000 RPM without load (in P or N).
18. Check for Pending or Confirmed DTCs with the HAS. Is DTC P0102 indicated? YES -Reinstall the original MAF sensor/IAT sensor, then go to step 26 . NO -Replace the original MAF sensor/IAT sensor (see «MAF SENSOR/IAT SENSOR REPLACEMENT»(ref-360080-S20771661482010042600000) (+) then go to next step.
19. Turn the ignition switch to LOCK (0).
20. Reconnect all connectors.
21. Turn the ignition switch to ON (II).
22. Reset the PCM with the HAS.
23. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-360079-S22847966492010042600000) (+).
24. Check for Pending or Confirmed DTCs with the HAS. Is DTC P0102 indicated? YES -Check for poor connections or loose terminals at the MAF sensor/IAT sensor and the PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
25. Reconnect all connectors.
26. Update the PCM if it does not have the latest software (see «PCM UPDATE»(ref-360080-S11980508702010042600000) (+) or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-360056-S32194616542010042600000) (+).
27. Check for Pending or Confirmed DTCs with the HAS. Is DTC P0102 indicated? YES -Check for poor connections or loose terminals at the MAF sensor/IAT sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-360056-S32194616542010042600000) (+) then recheck. If the PCM was substituted, go to step 1 . NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-360080-S27881728262010042600000) (+). If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
