| DESCRIPTION | SPECIFICATION |
|---|---|
| GENERAL SPECIFICATIONS | |
| Engine Type | 90 ° Bank Angle Liquid Cooled with Dual Tuned Intake Manifold and Twin Ignition |
| Displacement | 3.2 L (195.2 cu. in.) |
| Bore | 89.9 mm (3.54 in.) |
| Stroke | 84 mm (3.31 in.) |
| Valve System | SOHC 2 Intake and 1 Exhaust Valve per Cylinder Roller Rocker Arms |
| Compression Ratio | 10.0:1 |
| Brake Horsepower | 215 (160 KW) @ 5700 RPM (67.2 bhp/liter) |
| Torque | 230 lb. ft. (312 N.m) @ 3000 RPM |
| Firing Order | 1-4-3-6-2-5 |
| Lubrication | Pressure Feed - Full Flow Filtration |
| Cooling System | Reverse Flow - Forced Circulation |
| Cylinder Block | Cast Aluminum Alloy with Siltec Bore Liners |
| Crankshaft | Forged Steel |
| Connecting Rods | Forged Steel |
| Pistons | Aluminum Alloy - Flat Topped |
| Compression Pressure | 689 kPa (100 psi) |
| Max. Variation Between Cylinders | 172 kPa (25 psi) |
| CYLINDER BLOCK | |
| Cylinder Bore Diameter | |
| Standard | 89.900 - 89.915 mm (3.539 - 3.540 in.) |
| Repair Max. | 90.150 - 90.165 mm (3.549 - 3.550 in.) |
| Out of Round | 0.014 mm (.0005 in.) |
| Taper | 0.03 mm (.0011 in.) |
| PISTONS | |
| Piston Diameter | 89.87 - 89.90 mm (3.538 -3.539 in.) |
| Piston Ring Groove Depth No. 1 | 3.1 mm (0.122 in.) |
| Piston Ring Groove Depth No. 2 | 3.1 mm (0.122 in.) |
| Piston Ring Groove Depth No. 3 | 3.5 mm (0.137 in.) |
| PISTON RING GAP | |
| Compression Ring No. 1 | 0.20 - 0.35 mm (0.007 - 0.013 in.) |
| Compression Ring No. 2 | 0.20 - 0.40 mm (0.007 - 0.015 in.) |
| PISTON RING WIDTH | |
| Compression Rings | 1.5 mm (0.059 in.) |
| Oil Ring (Steel Rails) | 3.5 mm (0.137 in.) |
| CONNECTING RODS | |
| Bearing Clearance | 0.026 - 0.054 mm (0.001 - 0.002 in.) |
| CRANKSHAFT | |
| Main Bearing Clearance | |
| Radial | 0.030 - 0.052 mm (0.001 - 0.002 in.) |
| Axial | 0.100 - 0.266 mm (0.003 - 0.010 in.) |
| CYLINDER HEAD VALVE SEAT | |
| Valve Seat Width | |
| Intake | 31.000 - 31.016 mm (1.220 - 1.221 in.) |
| Exhaust | 35.000 - 35.016 mm (1.378 - 1.379 in.) |
| VALVES | |
| Face Angle | 45° ± 1.5° |
| Stem Diameter | |
| Intake | 6.975 mm (0.274 in.) |
| Exhaust | 6.974 mm (0.274 in.) |
| Head Diameter | |
| Intake | 36 ± 0.4 mm (1.417 in.) |
| Exhaust | 41 ± 0.1 mm (1.614 in.) |
| Length | |
| Intake | 119.4 ± 0.2 mm (4.700 in.) |
| Exhaust | 122.2 ± 0.2 mm (4.811 in.) |
| Valve Margin | |
| Intake | 1.2 mm (0.047 in.) |
| Exhaust | 1.6 mm (0.062 in.) |
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Note. The engine cover is held in place by four rubber grommets and four spring clips.
- Remove the air inlet tubes (2).
- Grasp both rear corners of the engine cover, and pull up firmly. Lift the engine cover (1) from the rear first, then from the front.
Scheme 24
- Install the engine cover (1). Align the engine cover retaining clips to the rubber mounts, and push down firmly to connect engine cover to rubber mounts. NOTE: To ease the installation of the engine cover, apply a small amount of lubricant to the engine cover rubber mounts.
- Install the air inlet tubes (2).
Scheme 25
Scheme 26
- Remove the engine cover/air cleaner housing. See «REMOVAL»(ref-306563-S23334034382008121700000) .
- Remove the screws (1) and the air cleaner element covers. (1 cover on each side of housing.)
- Remove the air cleaner elements (2) from the air cleaner housing (1).
