Oil Filter Chrysler Crossfire I final

The oil filter is mounted on the upper side of the front of the engine. It uses a replaceable element that can be incinerated.

Scheme 93

Scheme 94

1. Use an oil filter wrench if necessary to remove the oil filter cap (1).
2. Remove oil filter cap with the filter.
3. Remove the oil filter.

Scheme 95

Scheme 96

1. Replace the oil filter cap seal.
2. Install a new filter (1) in the cap.
3. Install the filter and cap (1). Tighten to 25 N.m (18 ft. lbs.).

Scheme 97

Scheme 98

1. Disconnect the negative battery cable.
2. Raise and support the vehicle.
3. Remove the lower splash shield screws (1) and the splash shield (2).
4. Remove the lower oil pan. See «REMOVAL»(ref-306563-S17026739872008121700000) .
5. Remove the front exhaust pipes. Refer to «REMOVAL»(ref-306569-S17295290192008121700000) .
6. Disconnect the oil level/temperature sensor harness connector.
7. Remove the front engine mount bolts (1).
8. Lower the vehicle.
9. Remove the engine cover. See «REMOVAL»(ref-306563-S23334034382008121700000) .
10. Remove the dipstick tube. See «REMOVAL»(ref-306563-S17026739872008121700000) .
11. Install and engine support bracket. NOTE: Be sure not to lift the engine to far. Damage to the coolant hoses, power steering lines, and A/C lines could occur.
12. Raise the engine using the support bracket.
13. Raise the vehicle.
14. Remove the 24 upper oil pan bolts (1).
15. Separate the upper oil pan from the engine block.

Scheme 99

Scheme 100

1. Drain the engine oil. See «STANDARD PROCEDURE»(ref-306563-S17946985482008121700000) .
2. Remove the lower splash shield screws (1) and the splash shield.
3. Remove the transmission oil cooler line retainer bolts (1). Reposition the cooler lines out of the way.
4. Remove the lower oil pan retaining bolts and the lower oil pan (1).

Scheme 101

Note. The components using sealant must be assembled within ten minutes of sealant application.

1. Clean the lower oil pan and the lower portion of the upper oil pan gasket surfaces thoroughly.
2. Apply a 1.5 mm to 2.5 mm bead of Mopar Engine Sealant RTV, 04883971 or equivalent to the lower oil pan sealing surface (1) as shown in the illustration.
3. Install the lower oil pan and oil pan bolts. Tighten the lower oil pan bolts to 14 N.m (10 ft. lbs.).
4. Position and install the transmission cooler lines and retainers (1). Tighten the bolts to 10 N.m (7 ft. lbs.).
5. Install and tighten the oil pan drain plug to 30 N.m (22 ft lbs.).
6. Install the lower splash shield and screws (1). Tighten the screws to 5 N.m (44 in. lbs.).
7. Lower the vehicle.
8. Fill the crankcase to the specified oil level.
9. Start the engine and check for leaks.

Scheme 102

Scheme 103

1. Clean the gasket surfaces thoroughly. NOTE: The components using sealant must be assembled within ten minutes of sealant application.
2. Apply a 1.5 to 2.5 mm. bead of Mopar Engine Sealant RTV, 04883971 or equivalent to the oil pan sealing surface as shown the illustration.
3. Position the upper oil pan on the engine block.
4. Install the oil pan bolts with the proper size and length bolt in the correct bolt hole. (1) M6 X 20 (2) M6 X 40 (3) M6 X 90 (4) M8 X 30
5. Tighten the M6 size bolts to 10 N.m (89 in. lbs). Follow the tightening sequence diagram.
6. Tighten the M8 size bolts to 20 N.m (15 ft. lbs.). Follow the tightening sequence diagram.
7. Install the lower oil pan. See «INSTALLATION»(ref-306563-S27064216822008121700000) .
8. Lower the vehicle.
9. Lower the engine back into position using the support bracket.
10. Remove the engine support bracket.
11. Install the dipstick tube. See «INSTALLATION»(ref-306563-S27064216822008121700000) .
12. Raise the vehicle.
13. Install the front engine mount bolts. Tighten the bolts to 35 N.m (26 ft. lbs.).
14. Connect the oil level/temperature sensor harness connector.
15. Install the front exhaust pipes. Refer to «INSTALLATION»(ref-306569-S16573602502008121700000) .
16. Install the lower splash shield (2) and retaining screws (1). Tighten screws to 5 N.m (44 in. lbs.).
17. Lower the vehicle.
18. Install the engine cover. See «INSTALLATION»(ref-306563-S35429154772008121700000) .
19. Refill engine oil to proper specification.
20. Connect the negative battery cable.

Scheme 104

Scheme 105

1. Remove the lower oil pan. See «REMOVAL»(ref-306563-S17026739872008121700000) .
2. Disconnect the oil level/temperature sensor harness connector (1).
3. Remove the two oil level/temperature sensor screws (1).
4. Remove the two harness retainer screws (2) and the oil level/temperature sensor.
